Summary of Contents for SEW-Eurodrive DOP11B
- Page 1 Drive Technology \ Drive Automation \ System Integration \ Services DOP11B Operator Terminals Safety Notes and Edition 11/2008 Short Summary 16642813 / EN...
- Page 2 SEW-EURODRIVE – Driving the world...
-
Page 3: Table Of Contents
5 Operation and Service ..................22 Operating display at unit start ..............22 Error messages..................23 SEW Electronics Service ................ 25 6 Technical Data ....................26 Pin assignment ..................26 Cables ..................... 28 Safety Notes and Short Summary – DOP11B Operator Terminal... -
Page 4: General Information
• Please note that this documentation does not replace the detailed system manual. • You must read the detailed system manual before working with DOP11B operator terminals. • Note and follow the information, instructions and notes in the detailed system manual. -
Page 5: Safety Notes
The controller must react appropriately to communication errors between it and the DOP11B. Appropriate measures (e.g. limit switch, position monitoring) should be taken to ensure that an error in communication to the DOP11B cannot cause any kind of damage. Do not start up the unit (take it into operation in the designated fashion) until you have... -
Page 6: Installation And Startup
Required protection devices: Overcurrent protective devices Safety functions WARNING! The operator terminals of the DOP11B series may not execute any safety functions without higher-level safety systems. Severe or fatal injuries. • Use higher-level safety systems to ensure protection of equipment and personnel. -
Page 7: Transportation/Storage
Service and maintenance • The agreed limited warranty applies. • Clean the display and face of the terminal with a soft cloth and mild detergent. • Repairs must be performed by qualified personnel. Safety Notes and Short Summary – DOP11B Operator Terminals... -
Page 8: Installation
Shielding can also be achieved by laying the cables in grounded sheet metal ducts or metal pipes. In this case, the power cables and control cables should be routed separately. • The unit is grounded via the connector for 24 V voltage supply. Safety Notes and Short Summary – DOP11B Operator Terminals... -
Page 9: Ul-Compliant Installation
(I ≤ 8 A) as an external DC 24 V voltage source. UL certification does not apply to operation in voltage supply systems with a non- earthed star point (IT systems). Safety Notes and Short Summary – DOP11B Operator Terminals... -
Page 10: Space Required For Installation
• Space required for installing the operator terminal: 100 mm 50 mm 50 mm 63788AXX The openings in the housing are used for convection cooling. These opening must not be sealed. Safety Notes and Short Summary – DOP11B Operator Terminals... -
Page 11: Installation Process
63789AXX 3. Use all the retaining bores and the brackets and screws supplied to fix the operator terminal in place: 0.5 - 1.0 Nm 63827AXX 63825AXX Safety Notes and Short Summary – DOP11B Operator Terminals... - Page 12 Ensure that the voltage and polarity of the power source are correct. Control cabinet 5. Take care when removing the laminated foil from the operator terminal’s display to avoid any damage resulting from static electricity. Safety Notes and Short Summary – DOP11B Operator Terminals...
-
Page 13: Connecting Basic Units Dop11B-10 To Dop11B-60
Make sure that the operator terminal and the controller system have the same electrical grounding (reference voltage value). Otherwise, there could be communication errors. 60059AXX Figure 2: Voltage supply for DOP11B-10 to DOP11B-60 [1] Ground [2] 0 V [3] +24 V Safety Notes and Short Summary – DOP11B Operator Terminals... -
Page 14: Startup
Switch on the PC. If the HMI-Builder project planning software is not already installed on the PC, install it now and then start the software. DOP11B PCS11B RS-232 RS-232 60060AXX Figure 4: Connection between PC and operator terminal Safety Notes and Short Summary – DOP11B Operator Terminals... -
Page 15: Initial Operation
Activate the supply (24 V) for the operator terminal and connected frequency inverters. NOTE Alternatively, the DOP11B can also be programmed via ETHERNET and via USB. Initial operation Units are delivered without a loaded project. After initial power on, the units will report the following information:... -
Page 16: Terminal Functions
This chapter describes the different modes in the operator terminal, the keyboard and the information page in the terminal. 4.3.1 Terminal keypad 60097AXX [1] Integrated function keys [2] Arrow keys [3] Alphanumeric keys Safety Notes and Short Summary – DOP11B Operator Terminals... - Page 17 Use this key to delete characters to the left of the cursor. NOTE If the main block (block number 0) has been displayed, the <PREV> key will not work, since the block history is deleted when the main block is shown. Safety Notes and Short Summary – DOP11B Operator Terminals...
- Page 18 DIP switch assignment is as follows: 1 = ON, 0 = OFF Interrupt the power supply to the terminal to call up individual modes for DOP11B. Then turn the DIP switch on the side or back of the terminal to the position shown in the following table.
- Page 19 Service menu The service menu is called up by setting the mode switch on the operator terminal to "1000". For details on mode switches, refer to the section "Switches on DOP11B terminals" on page 18. The service menu includes the following options: Network settings Select this option to call up the network menu.
- Page 20 The functional principle of individual objects and functions in operating mode will be explained in connection with the description of the respective objects and functions. Safety Notes and Short Summary – DOP11B Operator Terminals...
- Page 21 1 = RS-422 port, 2 = RS-232 port and 3 = RS-485 port. FRAME The number of frame errors in each port OVERRUN The number of overrun errors in each port PARITY The number of parity errors in each port Safety Notes and Short Summary – DOP11B Operator Terminals...
-
Page 22: Operation And Service
Communication driver loaded in controller 2 e.g.: SEW_MOVILINK_(serial) SEW_SMLP_(TCP/IP) DEMO Communication status of controller 1 e.g.: NO CONNECTION MOVI-PLC MOVITRAC B MOVIDRIVE B Communication status of controller 2 e.g.: NO CONNECTION MOVI-PLC MOVITRAC B MOVIDRIVE B Safety Notes and Short Summary – DOP11B Operator Terminals... -
Page 23: Error Messages
1: Comm Error 254 53590AXX Controller where the communication error occurs e.g. 1 or 2 Error type e.g. operation error - Comm error With address: e.g. 01 - 99 254 (= point to point!) Safety Notes and Short Summary – DOP11B Operator Terminals... - Page 24 Parameter cannot be changed with enabled output stage • The addressed parameter can only be altered with inhibited inverter. Activate the controller inhibit status by removing terminal X13.0 or via fieldbus (control word 1/2 basic block = 01hex). Safety Notes and Short Summary – DOP11B Operator Terminals...
-
Page 25: Sew Electronics Service
• Brief description of the application • Nature of the error • Accompanying circumstances • Your own presumptions as to what has happened • Any unusual events preceding the problem, etc. Safety Notes and Short Summary – DOP11B Operator Terminals... -
Page 26: Technical Data
2) Connected directly to pin 2 internally (Tx / Rx+) 3) Note: Only the first and last bus stations should have a bus terminator. 4) Connected internally to pin 15 (Tx / Rx-) via 120 Ohm 1/4 resistor. Safety Notes and Short Summary – DOP11B Operator Terminals... - Page 27 ↔ – USB-B VBUS – ↔ ↔ – 6.1.5 PCS21A RJ10 Termi- Name Signal direction operator terminal ↔ XXX 4-pin connector nal no. Do not assign Reserved ↔ Tx/Rx+ ↔ Tx/Rx- Safety Notes and Short Summary – DOP11B Operator Terminals...
-
Page 28: Cables
63833AXX 6.2.2 PCS21A MC07 TX/RX+ TX/RX+ TX/RX- TX/RX- TX/RX-/1200 TX/RX+ 5 m + 50 mm 100 ± 10 RJ10 Label Etherline Y Flex 2 x 2 x AWG22/7 UNC 4-40 63840AXX Safety Notes and Short Summary – DOP11B Operator Terminals... - Page 29 RS-232 communication cables (sub-D 9-pole prefabricated cables) RS-232 RS-232 9-pin D-Sub Female 9-pin D-Sub Male max 15 3 m + 50 mm UNC 4-40 UNC 4-40 Non-UL 28 AWG 9C Label 64007AXX Safety Notes and Short Summary – DOP11B Operator Terminals...
- Page 31 SEW-EURODRIVE – Driving the world...
- Page 32 Drive Technology \ Drive Automation \ System Integration \ Services How we’re driving the world With people who With comprehensive With uncompromising think fast and With a worldwide With drives and controls knowledge in virtually quality that reduces the develop the service network that is that automatically every branch of...
