Installation Instructions – Evolve Cabinets
Follow these installation instructions for Evolve upper, base, tall, and scope cabinets with AireCore or
wood composite construction.
Tools needed:
•
Flat head screwdriver
•
Level
Preparing for cabinet installation
Step 1
•
Identify the location and placement of your cabinets and clean floor
and surrounding area.
Step 2
•
If infill panels are needed, attach infill panel directly to the inside
of the cabinet with wood screws before installing cabinets.
S t o r a g e s o l u t i o n s f o r h e a l t h c a r e
Advertisement
Related Manuals for Solaire Medical Inner Space Evolve
Summary of Contents for Solaire Medical Inner Space Evolve
- Page 1 Installation Instructions – Evolve Cabinets Follow these installation instructions for Evolve upper, base, tall, and scope cabinets with AireCore or wood composite construction. Tools needed: • Flat head screwdriver • Level Preparing for cabinet installation Step 1 • Identify the location and placement of your cabinets and clean floor and surrounding area.
- Page 2 Installation Instructions – Evolve Cabinets Installing a single base, tall, or scope cabinet NOTE: USE APPROPRIATE FASTENERS FOR WALL TYPE STUD Step 1 SUGGESTED • Position base against the wall. Access leveling feet inside of base, SUGGESTED MOUNTING MOUNTING LOCATION and, with a flat head screw driver, adjust the four leveling feet until LOCATION the cabinet is level.
- Page 3 Installation Instructions – Evolve Cabinets Installing multiple base, tall, and scope cabinets NOTE: USE APPROPRIATE FASTENERS FOR WALL TYPE STUD Step 1 SUGGESTED • Attach the run of bases together using wood screws, making sure SUGGESTED MOUNTING MOUNTING LOCATION the bases are flush front to back and top to bottom. Position the LOCATION run of bases against the wall.
- Page 4 12" Installation Instructions – Evolve Cabinets (16") DEPENDENT ON VARIES STUD SPACING Installing upper wall cabinets NOTE: USE APPROPRIATE STUD FASTENERS FOR WALL TYPE Step 1 SUGGESTED SUGGESTED MOUNTING MOUNTING LOCATION LOCATION • Determine location of upper cabinet or cabinet run. Using a level, "...
- Page 5 Installation Instructions – Evolve Cabinets Attaching slope tops to Evolve cabinets For cabinets with roll-top doors Step 1 • Align the clips on the top of the cabinet and the bottom of the slope top. Place the slope top on the cabinet. Make sure all 4 clips are engaged.
- Page 6 Grand Rapids, Michigan 49501 888-435-2256 phone 616-743-5944 fax solairemedical.com Roam Rover Tempo Evolve Evolve Supply Carts Workstations Procedure Carts Cabinets Casework © 2018 Solaire Medical, Grand Rapids, MI 49501 ® InnerSpace is a registered trademarks of Solaire Medical, Grand Rapids, MI 49501 75K0918...
