Summary of Contents for CHIEF KWT-110
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S All in One Work Station Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description KWT-110...
-
Page 2: Installation Instructions
Do not use this product outdoors. no responsibility for accuracy, completeness or sufficiency of the information contained in this document. --SAVE THESE INSTRUCTIONS-- Chief® and Centris® are registered trademarks of Milestone AV Technologies. All rights reserved. IMPORTANT WARNINGS AND CAUTIONS! -
Page 3: Vertical Installation
Installation Instructions KWT-110 DIMENSIONS VERTICAL INSTALLATION CPU WALL MOUNT CABLE MAX WEIGHT: 40LBS. MANAGEMENT CHANNELS .60 DEPTH FROM WALL TO ACCESSORY MONITOR MOUNT MOUNTING SURFACE MAX WEIGHT: 25LBS. 9.47 6.91 10.00 KEYBOARD TRAY 16.00 MAX WEIGHT: 10LBS. 4.50 HORIZONTAL INSTALLATION .25 TYP. - Page 4 KWT-110 Installation Instructions DIMENSIONS PIVOT 180 2.36 RETRACTED 19.45 LIFT ARM 13.25" VERTICAL RANGE [254] 1.63 10.0 VESA STANDARD 75mm 100mm 6.50 1.30 10.57 5.63 5.67 2.40...
- Page 5 Installation Instructions KWT-110 DIMENSIONS COMPONENT MOUNTING BRACKET OPTIONS "X" DRYWALL MINIMUM DISTANCE BETWEEN COMPONENT MOUNTING BRACKETS IN HORIZONTAL CONFIGURATION INSTALLATION AVAILABLE OPTIONS ADJUSTMENT STEEL STUD 8" 23" WOOD STUD BRACKET [0 - 191] 0" - 8.50" WIDTH OF CPU RANGE...
- Page 6 KWT-110 Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 7: Tools Required For Installation
Installation Instructions KWT-110 TOOLS REQUIRED FOR INSTALLATION 7/64" 3/32" (included) 17/64" 7/16" 1/8" (included) 1/2" 3/16" (included) 5/32" (included) PARTS A (1) [Wall track accessory] B (1) [Centris display mount] C (1) [Keyboard tray mount] D (1) [CPU mount] F (1) -
Page 8: Cpu Installation
KWT-110 Installation Instructions ASSEMBLY AND INSTALLATION - CPU Loosen adjustment knob at the back of the mounting unit and adjust height of mount to a height greater than the MOUNT height of the CPU to be installed. Loosen strap at the front of the mount if necessary. - Page 9 Installation Instructions KWT-110 Use adjustment knobs to compress mount around CPU until CPU is tightly secured within mount (D). (See Figure 5) (R) x 2 mounting bracket Figure 5 Figure 6 Tighten front strap to desired tension. Install two #12 x 2 1/2" round Phillips wood screws (R) through bracket and drywall into wood stud.
- Page 10 KWT-110 Installation Instructions Site Requirements for Using Steel Studs WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! The figure below identifies the minimum requirements for installation of display mounts onto a steel stud structure. If the structure or its components do not meet these requirements contact the mount manufacturer for specific instructions before attempting installation.
- Page 11 Installation Instructions KWT-110 Wall Mounting Using Steel Studs or Drywall After determining the site meets the installation requirements: Steel Stud Drywall Identify desired mounting location on wall. Using a stud finder or similar method locate stud. Align mounting holes in mount with stud making sure Plastic Cap mounting holes are centered on stud.
- Page 12 KWT-110 Installation Instructions Steel Stud Drywall (X) x 2 Latch closed Figure 14 WALL TRACK INSTALLATION Mounting Bracket Determine mounting location on wall. Anchor Metal Channel Determine whether wall track accessory will be mounted (SIDE VIEW) horizontally or vertically. Figure 12...
- Page 13 Installation Instructions KWT-110 Drill three 7/64" holes. (See Figure 15) Drill six 1/2" holes at locations marked in Step 1. (See Figure 18) Install three #12 x 2 1/2" round pan wood screws (R) through small center bracket holes and into drilled holes.
- Page 14 KWT-110 Installation Instructions Horizontal Installation using Wood Studs NOTE: Wall track accessory may be mounted horizontally to two studs that are 16", 20" or 24" apart. Drywall Use a stud finder or similar method to determine location of studs. Plastic Cap Draw a vertical line down the center of the studs to be used.
- Page 15 Installation Instructions KWT-110 Vertical Installation using Steel Studs Slide plastic cap on anchor (K) towards wall until flange of cap is flush with wall. (See Figure 26) After determining the site meets the installation requirements (see Site Requirements for Using Steel Studs section): Steel Stud Identify desired mounting location on wall.
- Page 16 KWT-110 Installation Instructions WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! Overtightening of mounting hardware can damage the steel studs. DO NOT overtighten mounting hardware! Steel Stud Drywall (X) x 3 Figure 29 Hold metal channel on anchor (K) flat alongside plastic straps and slide channel through hole.
- Page 17 Installation Instructions KWT-110 10. Repeat steps 6 through 9 for each mounting hole. Steel Stud Steel Stud Drywall Drywall Plastic Cap (D) x 4 or 6 Plastic Straps Anchor Metal Channel SIDE VIEW Anchor Metal Channel SIDE VIEW Figure 32 Figure 33 11.
- Page 18 KWT-110 Installation Instructions (J) x 2 (N) x 2 (V) x 2 Figure 35 Reinstall side cover to wall track accessory after locking plate brackets have been inserted. (See Figure 35) Use 1/8" hex key (BB) to install #10 button head cap screws (V) through #10 washers (N) and wall plate (H) into center holes of locking plate brackets (J).
- Page 19 Installation Instructions KWT-110 Use 5/32" hex driver (AA) to tighten set screw in bottom of Mount Installation on Vertical Bracket wall mount. (See Figure 37) NOTE: Ensure set screw engages on back side of wall plate to WARNING: properly secure wall mount.
- Page 20 KWT-110 Installation Instructions Swing keyboard tray mount (C) down flush against wall. (See Figure 38) 10. Use 5/32" hex driver (AA) to tighten set screw in bottom of wall mount. (See Figure 37) NOTE: Ensure set screw engages on back side of wall plate to properly secure wall mount.
- Page 21 Installation Instructions KWT-110 Mouse Holder Installation Remove adhesive backing from mouse holder (G). Place mouse holder (G) on wall at desired location. (See Figure 42) Cable Management Bracket (in open position) Cable Path (typical) Figure 44 Close cable management bracket by sliding it back towards the centerline of the arm.
- Page 22 KWT-110 Installation Instructions cable management flap Height adjustment screw Height adjustable cable path (typical) Figure 48 Figure 46 Adjust tray tension using a 7/16" wrench and a 5/32" (AA) KEYBOARD TRAY ADJUSTMENTS hex key. (See Figure 49) Swing Arm Pivot/Swing Adjustment...
- Page 23 Installation Instructions KWT-110 Flush Mount Display Place the four selected spacers over each of the mount holes on the back of the display. Pick up and orient the mount (B) so that the mounting holes in the Centris bracket are aligned with the holes in the...
- Page 24 KWT-110 Installation Instructions CAUTION: Ensure that adequate cable slack exists for movement of keyboard and mouse, and that cables will not be pinched when bracket is closed. cable management flap Carefully insert cables into bracket. (See Figure 53) cable path...
- Page 25 Installation Instructions KWT-110 Adjustment Screw Figure 57 Centris Head If previously attached, disconnect cables from display, then remove display. Using Phillips screwdriver, slightly loosen or tighten the adjustment screw as necessary. (See Figure 58) Adjustment Screw Phillips Screwdriver Figure 58...
- Page 26 KWT-110 Installation Instructions...
- Page 27 Installation Instructions KWT-110...
- Page 28 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
