Velocity
®
Workstation
Assembly Guide
Tools Required:
7/16 inch wrench
2010 © Vehicle Service Group

Advertisement

loading
Need help?

Need help?

Do you have a question about the Velocity and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CHIEF Velocity

  • Page 1 Velocity ® Workstation Assembly Guide Tools Required: 7/16 inch wrench 2010 © Vehicle Service Group...
  • Page 2 Velocity Workstation — ® Assembly Instructions This manual contains basic guidelines for the initial assembly of the Velocity Workstation. Refer to it often ® to be certain that all components are installed correctly and all wiring is accurate. IMPORTANT: Before starting the assembly process, remove keys (and cable harness) from top of work- station and remove all components from the drawers and compartments.
  • Page 3 4. Position keyboard on mounting platform and route cord through hole at rear of workstation. (Figure 4.) 5. Align monitor base with holes in bottom of monitor and snap the components together. (Figure 5.) 6. Position monitor on mounting platform and slide monitor base as far forward as possible.
  • Page 4 8. Connect power cable to rear of monitor (Figure 8) and route monitor signal cable through hole at rear of workstation (Figure 9). 9. Position mouse on pad (Figure 10) and route USB cable through hole at rear of workstation (Figure 11).
  • Page 5 12. Place computer in workstation being careful to lift it over bracket at bottom of compart- ment. (Figure 17.) Adjust position of bracket as needed to accomodate length of comput- er. (Figure 18.) 13. Open workstation’s rear panel and secure monitor signal cable.
  • Page 6 16. Attach opposite end of computer power cord to electrical powerstrip on rear panel. (Figure 25.) 17. Place printer on slide out tray (Figure 26) and install the printer cartridges. Follow instruc- tions provided with the printer and the car- tridges.
  • Page 7 21. Secure all loose cables in workstation with a plastic tie. (Figure 31.) Also, re-insert cable harness in hole on top of workstation. (See inset.) Wire Support 22. Close rear panel and attach Velocity power cable. (Figure 32.) Engage its wire support to prevent accidental removal.
  • Page 8 23. Insert receptacle tester into electrical outlet where Velocity system will be used. (Figure 33.) Follow instructions packaged with tester to ensure a proper ground. 24. If the electrical test was satisfactory, plug the Velocity system into the wall outlet. (Figure 34.)
  • Page 9 27. Push printer’s “on” button. (Figure 37.) 28. Push monitor’s “on” button. (Figure 38.) 29. Attach body scanner cable to end of scanner (Figure 39) and to back panel of workstation. (Figure 40.) Cable end with cylindrical RFI suppressor must be attached to the scanner. NOTE: Figure 40 inset shows cable attach- ment to 'loop back' test port for diagnostic purposes.
  • Page 10 (Figure 44.) 33. Insert magnetic bolt attachments in the remaining holes making sure their numbers match the numerical references in the tray. (Figure 45.) 34. Place Velocity owners / parts manual binder at rear of drawer. (Figure 46.)
  • Page 11 Upper Right Hand Drawer 35. Install hole attachments as shown. (Figure 47.) Snap In Attachments 36. Install snap-in attachments, magnetic hole attachments and bottom hole clips as shown. (Figure 48.) Magnetic Hole Bottom Hole Attachment Clips 37. Install magnetic attachments in tray at rear of drawer.
  • Page 12 Hole Caps Nut/Stud Caps Side Hole Clips Middle Right Hand Drawer Magnetic Hole 38. Install hole caps, nut/stud caps, and Attachments side hole clips in rows at rear of drawer. Also install magnetic hole attachments in numerical holes and install the verti- cal surface attachments identified by the following letters.
  • Page 13 (Figure 54.) NOTE: In order to fit in the tray, Targets 41 and 42 must be positioned as shown in the inset. 43. Attach Velocity quick guide to workstation han- dle using the metal ring provided. (Figure 55.)
  • Page 14 996 Industrial Drive Madison, IN 47250 Customer Support Phone: 800-445-9262 Option 2 Fax: 866-275-0173 Email: salesOrders@chiefautomotive.com Tech Support Phone: 800-445-9262 Option 1 Email: techsupport@chiefautomotive.com CO7692 Rev. A...
