Tomahawk 4.2-SBG
Barbecue Grill
2 5 31 - 18
10033512

Advertisement

Table of Contents
loading

Related Manuals for Klarstein Tomahawk 4.2-SBG

Summary of Contents for Klarstein Tomahawk 4.2-SBG

  • Page 1 Tomahawk 4.2-SBG Barbecue Grill 2 5 31 - 18 10033512...

  • Page 3: Table Of Contents

    Dear Customer, Congratulations on purchasing this equipment. Please read this manual carefully and take care of the following hints on installation and use to avoid technical damages. Any failure caused by ignoring the items and cautions mentioned in the operation and installation instructions is not covered by our warranty or any liability.

  • Page 4: Technical Data

    TECHNICAL DATA Item number 10033512 Total heat input 20.7 kW (1507 g/h) Gas category I3B/P (30) I3B/P (50) I3 + (28-30/37) Types of gas Butane (G30) Propane (G31) Butane, propane or their mixtures Gas pressure 28-30 mbar 37 mbar 28-30 mbar 50 mbar Grill burner 0.9 mm...

  • Page 6: Overview

    OVERVIEW Warming plate (1 pc) 12 Rollers (2 pcs) Cooking grill (2 pcs) 13 Wheels with brakes (2 pcs) Flame tamer (3 pcs) 14 Right trolley panel (1 pc) Body (1 pc) 15 Right door (1 pc) Left side table (1 pc) 16 Trolley back panel (1 pc) Left trolley panel (1 pc) 17 Right side table (1 pc)

  • Page 15: Connection To Appliance

    CONNECTION TO APPLIANCE • This appliance is only suitable for use with low-pressure butane or propane gas or LPG mixtures, fitted with the appropriate low-pressure regulator via a flexible hose. • The hose should be secured to the regulator and the appliance with hose clips. Make sure the flexible hose cannot come in contact with hot surfaces and avoid twisting.

  • Page 16: Checking For Leaks

    distance of 1 m from the side or rear of the appliance. It is important that the ventilation openings of the appliance are not obstructed. The barbecue must be used on a level, stable surface. The appliance should be protected from direct draughts and shall be positioned or protected against direct penetration by any trickling water (e.g.

  • Page 17: Lighting Instructions For Barbecue

    LIGHTING INSTRUCTIONS FOR BARBECUE 1. Open the hood of the barbecue before attempting to light the burners. 2. Turn all the control knobs clockwise to 'OFF' position. 3. Connect the regulator to the gas bottle. Turn the gas supply “ON” at the regulator. Check with the use of soapy water for any gas leakage between the bottle and the regulator.
  • Page 18 How to use the electric igniter 1. Unscrew the igniter button cap(A),install a “AAA” battery (B). 2. Control knob must be in the 'OFF' position. 3. Connect propane cylinder (see manual). 4. Push and turn control knob counter-clockwise to 'MAX'. 5.

  • Page 20: Troubleshooting

    TROUBLESHOOTING Problem Possible Cause Solution LP gas cylinder is empty. Replace with full cylinder. Have regulator Faulty regulator checked or replace. Obstructions in burner. Clean burner. Obstructions in gas Clean jets and gas hose. Burners will not light using jets or gas hose. the ignition system.
