FACTORY AUTOMATION
QUICK START GUIDE
OHV2000-F22-B15
Handheld Reader

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OHV2000-F22-B15 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pepperl+Fuchs OHV2000-F22-B15

  • Page 1 FACTORY AUTOMATION QUICK START GUIDE OHV2000-F22-B15 Handheld Reader...
  • Page 2 OHV2000-F22-B15 With regard to the supply of products, the current issue of the following document is applicable: The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation...
  • Page 3: Table Of Contents

    OHV2000-F22-B15 Contents 1 Purpose of this Quick Start Guide ........4 2 Product Description............5 Use and Application ................... 5 Indicators and Operating Elements ............8 Scope of Delivery ..................9 Accessories....................9 Storage and Disposal ................10 3 Installation ...............11 Inserting and Removing the Battery ............11 Mounting the Charger and Charging the Handheld Reader .....
  • Page 4: Purpose Of This Quick Start Guide

    OHV2000-F22-B15 Purpose of this Quick Start Guide Purpose of this Quick Start Guide This quick start guide contains basic instructions for operating the device. However, the manual takes priority over the quick start guide.
  • Page 5: Product Description

    OHV2000-F22-B15 Product Description Product Description Use and Application Caution! Irritation caused by optical radiation The optical unit on the handheld reader is equipped with very bright LEDs that can cause irritation in dark environments. Do not point the handheld reader at people.
  • Page 6 OHV2000-F22-B15 Product Description Using the Vision Configurator software, rule sets can be created for formatting read results without the need for extensive programming work. This facilitates integration into ERP systems. The read data is transferred via the Bluetooth interface or by plugging the handheld reader into the charger. With its robust housing and IP65 protection, the handheld reader is suitable for outdoor use.
  • Page 7 OHV2000-F22-B15 Product Description The device is only approved for appropriate and intended use. Ignoring these instructions will void any warranty and absolve the manufacturer from any liability. Use the device only within the specified ambient and operating conditions.
  • Page 8: Indicators And Operating Elements

    OHV2000-F22-B15 Product Description Protection of the personnel and the plant is not ensured if the device is not used according to its intended use. Indicators and Operating Elements OHV2000-F221 Memory Bluetooth connection Function indicator Trigger buttons...
  • Page 9: Scope Of Delivery

    OHV2000-F22-B15 Product Description Scope of Delivery Check the packaging and contents for damage. Check if you have received every item and if the items received are the ones you ordered. Handheld reader OHV2000-F221-B15 Lithium-ion battery, 1300 mAh OHV-BAT Quick reference guide...
  • Page 10: Storage And Disposal

    OHV2000-F22-B15 Product Description Storage and Disposal Keep the original packaging. Always store and transport the device in the original packaging. Store the device in a clean and dry environment. The permitted ambient conditions must be considered, see datasheet. Disposing of device, packaging, and possibly contained batteries must be in...
  • Page 11: Installation

    OHV2000-F22-B15 Installation Installation Inserting and Removing the Battery Inserting the Battery 1. Insert the battery into the handheld reader. 2. Make sure that the battery audibly snaps into place. Removing the Battery 1. Move the locking device on the bottom of the handheld reader in the direction...
  • Page 12: Mounting The Charger And Charging The Handheld Reader

    OHV2000-F22-B15 Installation 2. Remove the battery. Mounting the Charger and Charging the Handheld Reader Mounting the Charger 1. Insert the USB cable or the plug of the plug-in power supply into the socket provided on the bottom of the charger.
  • Page 13 OHV2000-F22-B15 Installation 2. Place the charger in the position you wish to mount it. 3. Screw the charger into place using the mounting holes provided. Charging the Handheld Reader 1. Ensure that the charger is connected to the USB cable or the plug of the plug-...
  • Page 14 OHV2000-F22-B15 Installation 2. Place the handheld reader in the charger. 3. When the handheld reader's battery is charging, the battery's charge status display flashes. Charge Status Display To check the charge status of the lithium-ion battery, press the button on the back of the battery.
  • Page 15: Operation

    OHV2000-F22-B15 Operation Operation Switching On the Handheld Reader To switch on the handheld reader, hold down any trigger button for approx. two seconds. The function indicator on the handheld reader briefly lights up red then briefly lights up green. An audible signal is emitted and the handheld reader vibrates.
  • Page 16: Bluetooth Mode

    OHV2000-F22-B15 Operation Reading Codes The handheld reader registers itself with other devices as an input device or keyboard. Before you read a code, start or activate the application to which the read result is to be transferred. 1. To read the code, hold the trigger button down.
  • Page 17 OHV2000-F22-B15 Operation CC002942_Reader_step1_2 3. Read the Quick Connect code on the front of the charger or the modem. Bluetooth mode is activated. Read codes are transferred to the charger via Bluetooth immediately after they are read. The charging tray then automatically transfers the codes to the PC.
  • Page 18: Keyboard Layout

    OHV2000-F22-B15 Operation Keyboard Layout You can use the following control codes to modify the keyboard layout for the current operating mode.
  • Page 19 OHV2000-F22-B15 Operation Microsoft Windows English (US) English (US International) English (GB) M10460_02 M10469_01 M10471_01 German (Germany) German (Switzerland) French (France) M10463_02 M10466_02 M10462_02...
  • Page 20 OHV2000-F22-B15 Operation French (Belgium) Spanish (Spain) Spanish (Latin America) M10461_02 M10472_01 M10465_02 Russian Japanese M10418_02 M10464_02...
  • Page 21 OHV2000-F22-B15 Operation Apple OS X and iOS English German (Germany) German (Switzerland) M10419_02 M10421_02 M10422_02 French Spanish Italian M10420_02 M10424_02 M10423_02...
  • Page 22: Activating Suffix

    OHV2000-F22-B15 Operation Activating Suffix To append a suffix to the read result, scan the appropriate code with the handheld. Suffixes Code Description Suffix comma Adds a comma to the end of the read result. M10131_01 Suffix space Adds a space to the end of the read result.
  • Page 23 OHV2000-F22-B15 Operation Code Description Suffix enter Adds an input character to the end of the read result. M10134_01 Suffix tab Adds a tab to the end of the read result. M10133_01 Suffix erase/none Removes all suffixes. M10130_01...
  • Page 24 Twinsburg, Ohio 44087 · USA Tel. +1 330 4253555 E-Mail: sales@us.pepperl-fuchs.com Asia Pacific Headquarters Pepperl+Fuchs Pte Ltd. Company Registration No. 199003130E Singapur 139942 Tel. +65 67799091 E-Mail: sales@sg.pepperl-fuchs.com www.pepperl-fuchs.com 292677 DOCT-5169 Subject to modifications • Copyright Pepperl+Fuchs • Printed in Germany 05/2016...
