R
IS 9100
—
Mounting and Commissioning instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IS 9100 and is the answer not in the manual?

Questions and answers

Related Manuals for Iseo IS 9100

Summary of Contents for Iseo IS 9100

  • Page 1 IS 9100 — Mounting and Commissioning instructions...

  • Page 2: Table Of Contents

    10. Diagnosis/Troubleshooting .....................29 11. Error messages ........................31 12. Product operating description ....................33 13. Maintenance and care ......................34 14. Maintenance by ISEO ......................34 15. Troubleshooting ........................35 16. Disassembly, recycling and disposal..................35 EC Declaration of conformity ....................35 18. EC Declaration of incorporation ....................35 1.

  • Page 3: Safety

    Follow all of the enclosed instructions to guarantee your Safety glass must be used for glass door leaves. safety. If installing the IS 9100 on a metallic door leaf, ground Incorrect installation may result in serious injuries. the door leaf properly.

  • Page 4: Product Description

    3.2.1 Operating modes 23 Nm/5 lbf unless the hold-open system has been The IS 9100 can be operated in 2 modes: as a door closer activated or the power failed. or an automatic swing door drive. In the door closer mode...
  • Page 5 IS 9100 — 3.2.4 Wind load control The IS 9100 is especially suited for external doors that are < 3s Quit exposed to changing wind loads or internal doors separating > 3s Reset > 3s rooms in which pressure differences might occur. In...
  • Page 6 The Upgrade Card allows you to extend the functional range electrical door opener (E-opener), motor locks, multi-point of the automatic swing door drive unit is 9100. During locking device with response contact, holding magnets. the installation of the Upgrade Card, information between...
  • Page 7 IS 9100 — 3.7 Technical data Outputs Connecting terminals max. 1.5 mm Application conditions Potential-free status contact Door closed Ambient temperature - 15 – + 50 °C Door open Only for dry rooms Relative air humidity max. 93 % Error...

  • Page 8: Preparing For Installation

    IS 9100 — 4. Preparing for installation Depending on the installation situation, select the corresponding drilling pattern on pages 9-12. Assembly on the hinge side pull version with slide channel pages 9 and 10 Assembly on the opposite hinge side push version with slide...
  • Page 9 IS 9100 — Assembly on the hinge side pull version with slide channel and 12.5 mm lever pin 10 0 12 0 12 0 1 20 Ø 6.6 12,5 mm lever pin 45 1 15 5 Upper edge door Rooms for cable feed...
  • Page 10 IS 9100 — Assembly on the hinge side pull version with slide channel and 25 mm lever pin 15 0 10 6 12 0 Ø 6.6 25 mm lever pin 15 5 Upper edge door Space for cable feed Door with rabbet Upper edge door Lintel depth maximum ±...
  • Page 11 IS 9100 — Assembly on the opposite hinge side push version with slide channel and 12.5 mm lever pin Ø 6.6 Lower edge frame Space for cable feed Lower edge frame The maximum opening width is 95° The axis adaptor is turned 45°.
  • Page 12 IS 9100 — Assembly on the opposite hinge side push version with standard arm 12 0 Ø 6.6 Lower edge frame Rooms for cable feed Lower edge frame 0 mm – 225 mm Axis extension Standard (9 mm) 19 mm...

  • Page 13: Installing The Drive Unit

    IS 9100 — 5. Installing the drive unit Required tools 2.5 mm 5 mm 13 mm Secure the workspace against trespassing. Dropped 6 mm parts or tools may result in injuries. The described procedure is only an example. A different procedure might be preferable due to structural or local conditions, available tools or other circumstances.
  • Page 14 IS 9100 — 5.3 Mounting the mounting plate Fasten the mounting plate with 12 screws into the prepared holes. For the fastening, use dowels and screws that match the background. Use 3mm allen hey to drive the supplied holding pin into the lower one of the 2 holes.
  • Page 15 IS 9100 — 5.5 Driving the axis extension into the lever Drive the axis extension into the lever. Mounting position on the hinge side in case of an installation with slide channel and on the opposite hinge side in case of a normal arm assembly.
  • Page 16 IS 9100 — 5.6 Mounting the lever of slide channel set.-pull version Screw disk using a high tightening torque (35 Nm) to the drive shaft. Use only the supplied self-locking screw. If this screw is loosened during repair or maintenance work, it needs to be replaced with a new self-locking screw.
  • Page 17 IS 9100 — 5.8 Mounting the normal arm assembly Screw the tensioning screw (A) with 2 screws into the prepared holes. Screw the lever (B) using a high tightening torque (35 Nm) to the drive shaft. Use only the supplied self-locking screw. If this screw is loosened during repair or maintenance work, it needs to be replaced with a new self-locking screw.
  • Page 18 IS 9100 — 5.10 Adjusting the spring force The spring is not tensioned when delivered. A primary tension of at least 10 rotations is required for the operation. The adjustment will be tested during the teach-in run. The teach-in run will be aborted if the spring force is too low. A new teach-in run must be carried out if the spring has been readjusted.
  • Page 19 IS 9100 — 5.14 Installing the 2-panel door For more information on installation, referto mounting instruction of extra cover for double door. 5.15 Installing the casing Push the cover onto the drive unit and press until it clicks into place.

  • Page 20: Connecting The Accessories

    IS 9100 — 6. Connecting the accessories Connect the connecting cables to the connector and insert the connector into the connection board. • Maximum 1.5 A total load on the terminals 1, 1G and 3. • Cable length maximum 30 m for J-Y(ST)Y 0.8 mm 6.1 Terminal assignment...

  • Page 21: Commissioning

    The device identification will “run“ through In case the spring force is too low, the display will the display. IS 9100 and the firmware version show the small spinning “o“ and “F“. (indicated by XX XX). A small, spinning “o“ and “P“ indicate that a...

  • Page 22: Installing Upgrade Cards

    IS 9100 — 8. Installing Upgrade Cards 8.1 Requirements: The following is also to be considered during the installation: • The drive unit is completely installed. • If the container module is removed, the previously • The teach-in run has been successfully completed.

  • Page 23: Parameterization/Service

    IS 9100 — 9. Parameterization/Service < 3s Quit After a completed teach-in run, the drive unit can be operated with the basic parameters. > 3s Reset > 3s The system also offers the option to adapt the moving parameters to the actual conditions and to activate the enhanced functions.
  • Page 24 IS 9100 — Parameter/display Value range Unit Explanation Factory setting = Bold Wall suppression BS 60 – 99 Degrees Once the set angle has been reached, the input signal of the safety sensor hinge side will be ignored. The wall suppression is required if the door opens against an obstacle.
  • Page 25 IS 9100 — Parameter/display Value range Unit Explanation Factory setting = Bold Static force in the 2 – 15 10 N The forces acting on the closing edge can be changed using opening direction this parameter. The permissibility of the setting is checked...
  • Page 26 IS 9100 — Parameter/display Value range Unit Explanation Factory setting = Bold Day activation 0 – 1 The door will always be locked when it reaches the CLOSED position. In the automatic operating mode, the door will not be locked when the CLOSED position is reached.
  • Page 27 IS 9100 — Parameter/display Value range Unit Explanation Factory setting = Bold Door closer/ 0 – 1 The automatic mode should be used if the door is preferably opened automatic mode automatically and if motion sensors are used. In case of blockages during the closing, the drive will automatically reverse.
  • Page 28 IS 9100 — Parameter/display Value range Unit Explanation Factory setting = Bold Configuration of the 0 – 1 Not applicable interface COM1 Not applicable (upright connector) Opening dampening 5 – 40 10° In this case, enter the angle after which the door is braked when opened when manually opened.

  • Page 29: Diagnosis/Troubleshooting

    IS 9100 — 10. Diagnosis/Troubleshooting ISEO drive units meet a high safety standard and comply Information "In" with all technical regulations and requirements. Internal as Information is provided for the easy servicing of the drive well as external safety circuits managed by the drive unit will unit and points to both faulty states and operating states be periodically monitored.
  • Page 30 IS 9100 — Error Possible cause Remedy During the installation: The connector of the braking circuit is The connector must be positioned correctly depending in the incorrect position. on the arms assembly used. It is difficult to manually open the door and the See page 17 point 5.9.

  • Page 31: Error Messages

    IS 9100 — 11. Error messages Display Display Meaning/cause Troubleshooting In 01 none Blockage The door movement should be tested in a deenergized state The door is blocked due to an obstacle and and a possibly existing stiffness must be eliminated. The...
  • Page 32 IS 9100 — Display Display Meaning/cause Troubleshooting E 02 Locking error In this case, you have to assume a defect on the locking flashing The drive unit tries to open or close a locking device or an error in the wiring. The locking feedback device with a feedback contact or a DCW contact must be tested and replaced, if necessary.

  • Page 33: Product Operating Description

    Power switch Internal program switch 12.5 Low/Full Energy mode Drive IS 9100 can be operated in the low and full energy mode. Low energy mode The low speed of the door avoids most of the risk posed by automatic movements.

  • Page 34: Maintenance And Care

    (AUTOMATIC). However, in case of a fire, trained by ISEO. The door system is then to be inspected and the door must close in order to prevent smoke and fire from maintained, if necessary, at least once a year by a specialist.

  • Page 35: Troubleshooting

    This is indicated by a red LED on the program switch. that the standards and/or technical specifications referred to in the following have been applied. The display flashes or lights permanently and indicates an error that need to be eliminated by the ISEO Service. 2006/95/EC Low Voltage Directive Directive:...
  • Page 36 "II". EXIT ONLY (only for 1-panel systems) The front switch is set to "I", the rear switch is set to "I". ISEO Serrature s.p.a. Via San Girolamo 13 25055 Pisogne (BS) Italy Tel. : +39 0364 8821 Fax : +39 0364 882263 iseo@iseo.eu...
