Designed for care
5970S2-EL
ELECTRICAL CISTERN W. HEIGHT-ADJUSTMENT
5970-MA
MANUAL CISTERN W. HEIGHT-ADJUSTMENT
INSTALLATION INSTRUCTIONS
BANO
SISTERNE/ CISTERN
Bano AS
Utstillingsplassen 3,
6823 Sandane
Bano's products meet the provisions in the
EU safety requirements laid down in the
Medical Devices Directive 93/42/EEC, class 1.
NRF 6035974
NRF 6035975
Bano provides a 3-year warraty against
manufacturing defects: i.e.if such defects
appear within 3 years of installation,
customers can replace the defective
item with a corresponding properties.
Phone: +47 57 86 98 00
www.bano.no
E-mail: post@bano.no
NO
ENG
SE
DK
NL
FI
Advertisement
Table of Contents
Related Manuals for Bano 5970S2-EL
Summary of Contents for Bano 5970S2-EL
- Page 1 INSTALLATION INSTRUCTIONS BANO SISTERNE/ CISTERN Bano provides a 3-year warraty against Bano’s products meet the provisions in the manufacturing defects: i.e.if such defects EU safety requirements laid down in the appear within 3 years of installation, Medical Devices Directive 93/42/EEC, class 1.
-
Page 2: Table Of Contents
Designed for care TABLE OF CONTENTS Page 3 Introduction Page 3 Compliance with the EU directive Page 3 Accessories Page 4 Technical data Page 5 Interface Page 6 Contents, loose parts Page 7 Preparation before assembling/Installing flexible WC-pipe Page 8-10 Fixing to wall Page 8 Adjustment in case of uneven floor Page 10... -
Page 3: Compliance With The Eu Directive
EN 14055: 2011: WC and urinal flushing cisterns EN 997: 2013: Sanatary appliances, washbasins Accessories Installed with a Bano WC 530 or a Bano WC 700 (5965/5975), and grab bars for WC/cistern (5603/5604). With external pipes, please use an extension (5970-22/5970-23), either 50 mm or 100 mm. -
Page 4: Technical Data
Static load, grab bars: 250 kg Maximum dynamic load, height-adjustment: 200 kg BANO AS Producer Email: post@bano.no Phone: +47 57 86 98 00 Web site: www.bano.no CISTERN WITH ELECTRICAL HEIGHT-ADJUSTMENT Product name 5970S2-EL Product number Height-adjustment : 200 cm (from 410 mm to 610 mm) -
Page 5: Interface
NOTE! ELECTRICAL: This ONLY applies to 5970-EL with electrical height-adjustment. Ferdig gulv NOTE! CONSTRUCTION: Loadtested untill 500 kg. Min.: 48x198 board Nailingstrips must be placed flush against wall material. Nailing strips are indicated with shaded area. For more information: www.bano.no 5/19... -
Page 6: Contents, Loose Parts
Designed for care Contents, loose parts 9750 White caps for 9751 Nut (2 for EL, 1 for MA) ISO 7380 M4x12 mounting WC-bowl 9716 Installation bolts WC- 9794 Flexible drainage pipe 9787 Flexible drainage pipe for wall bowl for floor 9700 Flush button, cistern 9753 Double jetcoupling 9710-01 Clamp (when the... - Page 7 Designed for care Preparation before assembling Drain in the floor, reinforcements, Drainage in the wall, hidden pipes reinforcements, hidden pipes NB! Flush the pipes for 30 seconds before you install the cistern. Installing flexible WC-pipe 7/19...
-
Page 8: Fixing To Wall
Designed for care Fixing to wall The cistern be adjusted up or down with the crank (MA) or by connecting it to the power grid (EL) in order to get to the mounting holes while installing. Follow the instructions for fixing to wall on page 9. Adjustment in case of uneven floor If uneven floors (eg. - Page 9 M6 in combination with a nylon plug. Step 2: Raise the cistern to the top position and secure to the wall with appropriate screws for the wall. Bano recom- mends M8 A4 DIN571 Hex head wood screws.. For concrete Bano recommends French wood screws M6 in combination with a nylon plug.
-
Page 10: Silicone
Designed for care Silicone Step 3: NB! Apply silicone before installing the cover and bowl. 10/19... - Page 11 Designed for care Hooking up reinforced hose NB! Make sure the valves are open. Adjusting threaded rods for toilet fixing NB! On the MA-model you have to make sure the shaft stays clear of the nuts and threaded rods. 11/19...
-
Page 12: Installing Wc Pipe, Flush Pipe And Cover
Designed for care Installing WC pipe, flush pipe and cover 12/19... -
Page 13: Installing Crank And Nut
Designed for care Installing crank and nut NB! The EL-model does not have a crank, but it has two nuts for each side of the cistern. 13/19... -
Page 14: Installing Flush Button
Designed for care Installing flush button: Break the green and white adjust- ment pin by the 95mm mark (B) Cut the left pin in the middle 14/19... - Page 15 Designed for care Installing WC-bowl It is recomended to have the cistern in its highest possition when mounting the WC-bowl Installing the grab bars Put them in their sockets and attach them with the child proof cranks (push and twist to tighten) 15/19...
- Page 16 This crank can be mounted on both sides of the cistern. The crank must be pushed in before it can be used and is therefor safe to use with demetia patients.The crank can easily be removed and replaced with a nut. (Contact Bano for more information) 16/19...
-
Page 17: Installing Roller Blind
Designed for care Installing roller blind 17/19... -
Page 18: Spare Parts Cistern
Spare cistern Designed for care Controll Box Cistern Sanicontroll 6l start/stop + dual - flush ech (from 01-2010) Type A31. 9735 9743-01 9734 9701-01 9743 9732 9742-01 9742 9726-04 Inlet valve 9726-04 Flexible hose for inlet valve 9713-02 Shut of valve support 1/2” 9733-01 9713-02 Flushing valve, complete 9741 Basket holder for flushing valve... -
Page 19: Electric Parts
Electric parts Designed for care Controll unit Coupling box Actuator 19/19...
