INSTALLATION INSTRUCTIONS
5970S2-EL Bano height adjustable toilet/cistern, electrical
5970-MA Bano height adjustable toilet /cistern, manual
BANO HEIGHT ADJUSTABLE TOILET/CISTERN
BANO AS
Utstillingsplassen 3
6823 Sandane-Norge
Phone: +47 57 86 98 00
post@bano.no
www.bano.no
Bano provides a 3-year warraty against
manufacturing defects: i.e.if such defects
appear within 3 years of installation,
customers can replace the defective item
with a corresponding properties.
BANO AB
Hammarby Allé 91
120 63 Stockholm - Sverige
Phone:+46 (0) 8 30 11 10
post@bano.se
www.bano.se
Rev: 06.april.2017
Accepted
mounting instructions
2016:1
BANO A/S
Møllehaven 8
4040 Jyllinge - Danmark
Phone: +4526 24 55 14
post@bano.dk
www.bano.dk
EN
Award for design excellence
Norwegian Design Council
Advertisement
Related Manuals for Bano 5970S2-EL
Summary of Contents for Bano 5970S2-EL
- Page 1 INSTALLATION INSTRUCTIONS 5970S2-EL Bano height adjustable toilet/cistern, electrical 5970-MA Bano height adjustable toilet /cistern, manual Rev: 06.april.2017 BANO HEIGHT ADJUSTABLE TOILET/CISTERN Accepted Bano provides a 3-year warraty against mounting instructions manufacturing defects: i.e.if such defects appear within 3 years of installation,...
-
Page 2: Table Of Contents
TABLE OF CONTENTS: Page 3 Introduction Page 3 Compliance with EU directive Page 3 Accessories Page 4 Technical data Page 5 Interface Page 6 Contents, loose parts Page 7-15 Installation Page 16 Wiring diagram (ONLY 5970S2-EL) Page 17 Operating the height adjustment... -
Page 3: Introduction
EN 997: 2013: Sanatary appliances, washbasins Accessories: Installed with a Bano toilet bowl 530 or Bano toilet bowl 700 mm (5965/5975), and toilet grab bars (5603/5604). With external pipes, please use an extension (5970-22/5970-23), either 50 mm or 100 mm. -
Page 4: Technical Data
Phone: +47 57 86 98 00 Web site: www.bano.co.uk Product name : Cistern with electrical height-adjustment Product number : 5970S2-EL Height-adjustment : 200 mm (from 410 mm to 610 mm) Materials : Main frame: Corrosion treated steel, El galvanized Cover: ABS/ PMMA plastic, colour code RAL 9016. -
Page 5: Interface
Electritian connects IP44-box aftrer the cistern is installed. (IP44-box not included). NOTE! ELECTRICAL: Finished floor This ONLY applies to 5970S2-EL with electrical height-adjustment. NOTE! CONSTRUCTION: Loadtested untill 500 kg. Min.: 48x198 board Nailingstrips must be placed flush against wall material. -
Page 6: Contents, Loose Parts
Contents (loose parts): 9750 White caps for installing, toilet 9700 Flush button, cistern 9716 Installation bolts, toilet 9712 9712 Water pipe, cisterne ISO 7380 M4x12 Control for height adjustment (ONLY for 5970S2-EL) 9755 Krank (ONLY for 5970-MA) 9751 Nut (ONLY for 5970-MA) - Page 7 (7/17) Installing the cistern: Install the drain pipe in the floor drain by using the provided double jetcoupling. Check that the holder 9749 is mounted on the flexible drain pipe before proceeding. Place cistern frame against the wall and ensure that it is level. Mark all the screw holes. (8 pieces). The cistern must be raised up or down using the crank to get to the fixing holes during installation.
- Page 8 (8/17) Adjustment in case of uneven floor: If uneven floors (eg. slope towards the drain) cistern can be adjusted using the adjustment screws found on the bottom of each side. Adjust from above with hex key, M5.
- Page 9 Please note that the product guarantee only applies when the wall and screws are dimensioned according to «Byggebransjens Våtromsnorm» and Bano interface for products mounted in Norway. For products mounted in other countries, please note that the product guarantee only applies when wall and screws are dimensioned according to national guidelines/regulations and Bano interface.
- Page 10 Fixing to wall: Step 1: Lower the cistern to the bottom position and secure to the wall with appropriate screws for the wall. Bano recommends M8 French wood stainless steel screws. For concrete Bano recommends French wood screws DIN571 in combination with a nylon plug.
- Page 11 (11/12) Adjusting installation bolts: Adjust the length of the installation bolt. Each bolt is screwed into the frame and secured with a M12 nut in the back. Make sure the shaft runs freely without coming into contact with nut or threaded rod.
- Page 12 (13/17) Installing flush pipe and drain pipe: Adjust the length of the flushpipe according to the type of toilet. Install drain pipe and holder before installing the toilet. We reccomend raising the cistern to the highest position when installing the toilet. Please check that the water supply pipe is installed, and the valve open, before mounting the cover.
- Page 13 (14/17) Cover and cranck: Mount the main cover and remove the protection film from all plastic parts. Mount the crank on one side, and the nut on the other.
- Page 14 (15/17) Installing the flush button: Break the green and white adjustment pin by 95 mm box (B) The left stick is cut on half length.
- Page 15 (16/17) Installing the grab bar: Toilet grab bar (5603/5604) on each side of the cistern.
-
Page 16: Wiring Diagram (Only 5970S2-El)
(17/17) Wiring diagram (ONLY 5970S2-EL): Parts List PART NUMBER DESCRIPTION PLUS / Lok. MINUS / Lo CB8001T60-0010 Kontrolboks, CB8T M281015-00 Motor for LA28, IP66 0015751-A Håndbetjeningskabel DKJC Suface character: Date 11-09-2013 cons: Confdential: Property of LINAK DK A/S. Silkeborg. Geometrical tolerance: Not to be handed over to, copied or used by third party. -
Page 17: Operating The Height Adjustment
This crank can be mounted on both sides of the cistern. The crank must be pushed in before it can be used and is therefor safe to use with demetia patients.The crank can easily be removed and replaced with a nut. (Contact Bano for more information)
