- Page 1 Technical Installation Guide...
- Page 2 • Drill • Phillips screwdriver • Slotted screwdriver • Measuring tape • Pipe cutter • Adapters and additional pipe (as necessary) • All items from the Syclone Amalgam Separator box Before installation, ensure that the vacuum is turned off .
- Page 3 Find an appropriate location for the Syclone™ Amalgam Separator • Generally installed close to the vacuum pump • The Syclone Amalgam Separator outlet should be at least 4-6 inches higher than the vacuum inlet...
- Page 4 Secure the mounting bracket • • • Check for studs and mark one of the Check for studs and mark one of the Attach the top corner of the mounting top corners top corners bracket • • Use level to confi rm alignment If a stud is not available, wall anchors, •...
- Page 5 Attach the top chamber • • Choose either left- or right-facing installation based on layout Use a Phillips-head screwdriver to tighten the screws and • washers provided for the bottom prongs of the top chamber Seat the prongs of the top chamber into the corresponding until snug slots on the mounting bracket •...
- Page 6 • • Use one of the two couplings provided along with adapters and The outlet from the operatories should be installed to the top inlet of the Syclone™ Amalgam Separator additional pipe as necessary • Measure the piping and cut...
- Page 7 • Be sure to tighten all connections to prevent leaking NOTE: Depending on the confi guration of the pipes, you may need to get PVC adaptors to connect the plumbing to the system (not provided with Syclone™ Amalgam Separator)
- Page 8 The unit is now ready for use Additional information: Crosstex.com/Syclone All product names are trademarks of Crosstex International Inc., a Cantel Medical Company, its affi liates or related companies, unless otherwise noted. Patent pending. © 2018 Crosstex International, Inc. 1018 DLIT00488-Rev B...
