M&G Duravent Duratech Canada HT Installation And Operation Instruction Manual

Factory-built chimney 5, 6, 7, 8, 10 dia.
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
D
T
URA
OUR PRODUCTS LIVE UP TO OUR NAME, WARNING. . . . . . . . . . . . . . . 2
KEEP YOUR CHIMNEY CLEAN, SIZING CHART . . . . . . . . . . . . . . . . . . . 3
GENERAL INSTALLATION NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
INTERIOR INSTALLATION WITH CATHEDRAL CEILING . . . . . . . . . . . . . . 7
OFFSET INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
EXTERIOR INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
SPECIALIZED COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Read these instructions and keep them for future reference
Listed:
CAN/ULC-S629 (6'',7'',8'' only)
CAN /ULC-S604
UL-103HT
C
ECH
ANADA (DTC)
SUMMARY
PIDURATECH REV. 2 07/2013
Factory-built CHIMNEY
5", 6", 7", 8" & 10" dia.
INSTALLATION
OPERATION
INSTRUCTIONS
Duravent
www.duravent.com
TYPE HT
AND

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Duravent Duratech Canada HT and is the answer not in the manual?

Questions and answers

Related Manuals for M&G Duravent Duratech Canada HT

Summary of Contents for M&G Duravent Duratech Canada HT

  • Page 1: Table Of Contents

    ANADA (DTC) Factory-built CHIMNEY 5”, 6”, 7”, 8” & 10” dia. TYPE HT SUMMARY INSTALLATION OUR PRODUCTS LIVE UP TO OUR NAME, WARNING....2 KEEP YOUR CHIMNEY CLEAN, SIZING CHART ....3 GENERAL INSTALLATION NOTES .

  • Page 2: Our Products Live Up To Our Name, Warning

    BURNING SMART OUR PRODUCTS LIVE UP TO OUR NAME How you burn wood in your stove or fireplace directly affects the forma- tion of creosote. Smaller, hotter fires are better than large, smouldering ones. Fast, effective start ups are important, as is the moisture content CONGRATULATIONS! of the wood.

  • Page 3: Keep Your Chimney Clean, Sizing Chart

    KEEP YOUR CHIMNEY CLEAN SIZING CHART CHIMNEY-SIZE 5” 6” 7” 8” 10” CHIMNEY OPERATION AND MAINTENANCE OUTSIDE-DIAMETER 7” 8” 9” 10” 12” HOLE-DIMENSION-REQUIRED Wood stoves can quickly create large deposits of creosote in the chimney. Base-support (DTC-BS) 12-1/8” 12-1/8” 14-3/8” 14-3/8” Some wood stoves can create enough creosote in two weeks to cause a chimney fire.

  • Page 4: General Installation Notes

    GENERAL INSTALLATION NOTES INSTALLATION NOTES 1. The chimney is intended for use with solid (6’’,7’’,8’’ dia. only) or liquid and gaseous fuel burning appliances.(all diameters) 2 ft MIN. Allowable flue gas temperature: Maximum continuous 540°C (1000°F) 3 ft Brief forced firing 760°C (1400°F) 10 ft MIN.

  • Page 5: Interior Straight Installation With Multiple Floors

    INTERIOR STRAIGHT INSTALLATION WITH MULTIPLE FLOOR Locate the chimney in a convenient place as near as possible to the ROOF FLASHING INSTALLATION appliance outlet. Put the roof flashing in place. Seal the joint between the roof and the Cut and frame the holes in the floor, ceiling and roof where the chimney flashing with roofing pitch.
  • Page 6 INSULATION PAD SCREWS SILICONE CAULKING RADIATION SHIELD CONNECTOR (DTC-RSCI) RADIATION SHIELD CONNECTOR FIRESTOP Figure 5 Figure 6 (DTC-FRSC) NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

  • Page 7: Interior Installation With Cathedral Ceiling

    INTERIOR INSTALLATION WITH CATHEDRAL CEILING A - CATHEDRAL SUPPORT (DTC-RCSC) HOLE SIZE DOWN 12 IN ROOF SLOPE This support is designed to be used in rooms INCHES with cathedral ceilings (no attic space between SIDES OF HOLE MUST the ceiling and the roof). If the support is used as ACROSS BE VERTICAL a regular floor support, follow the instructions for...

  • Page 8: Offset Installation

    OFFSET DEVIATION Stack the next chimney length on the first length. Be sure that the male OFFSET CHIMNEY and female threads are not in line when putting the lengths together. Turn the chimney clockwise to lock it in place. You may add a 1/2in stainless steel self tapping screw to prevent accidental unlocking.
  • Page 9 OFFSET DEVIATION (CONT’D) ROOF SUPPORT (DTC-RS) WARNING A support must always be installed right above each offset (two elbows) to support the chimney above the offset. Figure 14 The roof support has three possible uses: RISE It may be used to support a chimney from the roof. It adjusts to any roof pitch.

  • Page 10: Exterior Installation

    EXTERIOR INSTALLATION INSTALLATION INSTRUCTIONS STEPS TEE & WALL SUPPORT WALL FRAMED OPENING WALL STUDS ADJUSTABLE FRAME OPENING WITH LUMBER ADJUSTABLE DTC-TS DTC-TSAC DTC-TSA THE SAME DIMENSION AS WALL FRAMING Figure 16 Figure 17 Determine where the chimney will pass through the wall. Three supports are available, an adjustable with collar (DTC-TSA), an •...
  • Page 11 EXTERIOR INSTALLATION (CONT’D) Attach the flue extension to the horizontal chimney length using the three metal screws provided. Stack a chimney length on top of the tee. Turn it clockwise to lock it in place. FOR UNENCLOSED INSTALLATION OR VENTING OF OIL OR GAS APPLIANCES: Continue until the required chimney height is reached.

  • Page 12: Interior Installation On A Furnace & Water Heater

    INTERIOR INSTALLATION ON A FURNACE AND WATER HEATER Step 1. Locate the chimney in a convenient place as near as possible to FINISH SUPPORT the appliance outlet. Cut and frame the holes in the floor, ceiling (DTC-FSC) or (DTC-BS) NAILS and roof where the chimney will pass.

  • Page 13: Specialized Components

     SPECIALIZED COMPONENTS ANCHOR PLATE (DTC-AP) This support is used on a masonry fireplace or on top of a furnace to provide a positive connection to the chimney. It is not to be used in contact with any combustible mate- rial, such as on a wood floor.
  • Page 14 1. INSULATED ELBOW 2. INSULATED WALL RADIATION SHIELD 3. INSULATED LENGTH 4. OFFSEST SUPPORT 5. FIRESTOP 6. ATTIC RADIATION SHIELD 7. ADJUSTABLE ROOF SUPPORT 8. RAIN CAP Figure 27 NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

  • Page 15: Warranty

    M&G DuraVent Limited Lifetime Warranty M&G DuraVent, Inc. (“DuraVent”) provides this limited M&G DuraVent’s relining products including DuraLiner®, lifetime warranty for all of its products with the exception DuraFlex® (SW, Pro, 316, 304), and Ventinox®. For purposes of Ventinox® (lifetime), and PolyPro® (ten years). Subject of this warranty, a trained professional installer is defined as to the limitations set forth below, DuraVent warrants one of the following: licensed contractors with prior chimney...
  • Page 16 WARRANTY When ordering repair parts, always give the following information: 1. The model number of the vent system. This product has a limited lifetime warranty. Please read the warranty to 2. The part number. be familiar with its coverage. 3. The description of the part. 4.
