  • Page 1 Tobii Dynavox I-Series User’s Manual I–13 I–16...
  • Page 2 +46 8 663 69 90 +1-800-344-1778 The following products are protected by U.S. Patents 7,572,008, 6,659,611, 8,185,845 and 9,996,159: ● I–13 ● I–16 You can locate the Type of Tobii Dynavox I-Series device on the label on the back side.

  • Page 3: Table Of Contents

    Intended User Profile....................8 1.3.2 Portable Use ......................9 1.3.3 Mounted Use ......................9 Package Contents.........................9 1.4.1 Tobii Dynavox I-Series with Snap Core First / Communicator 5 ........9 Safety............................11 Avoiding Hearing Damage ....................11 Temperature ........................12 Power Supply and Batteries ....................12 Mounting ..........................13 Emergency .........................13 Infrared ..........................13...
  • Page 4 Temperature & Humidity ......................43 6.1.1 General Use - Operating Temperature ..............43 6.1.2 Transportation and Storage ..................43 Cleaning of the Tobii Dynavox I-Series Device...............43 Placement ..........................43 Transporting the Tobii Dynavox I-Series Device ..............43 Disposing of the Tobii Dynavox I-Series Device ..............44...
  • Page 5 Support, Warranty, Training Resources and Trouble-shooting ........45 A4.1 If the Tobii Dynavox I-Series does not Power up .............45 A4.2 How do I carry out a Power Reset on the Tobii Dynavox I-Series?......45 Appendix B Compliance Information ....................47 B1.1 For P15B Equipment ....................47...

  • Page 6: Introduction

    The Tobii Dynavox I-Series device is available in two different sizes: the Tobii Dynavox I–13 with a 13.3" screen and the To- bii Dynavox I–16 with a 15.6" screen. The Tobii Dynavox I-Series is a Eye Gaze device but can be ordered without the Eye Gaze function.
  • Page 7 Conforms to relevant Australian EMC requirements Manufacturer Reference number Serial Number Safety Class II equipment (reinforced insulation) This mark shows the pin out polarity on the AC/DC Power Adapter 1 Introduction #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 8: Intended Use

    The Tobii Dynavox I-Series is a device with an optional Tobii Eye Tracker and a capacitive touch screen for touch access. The device is intended to be used on a mounting arm, or standing upright on an appropriate surface. In addition to eye gaze and touch, the device can be operated through switch scanning, mouse, keyboard, or a combination thereof.

  • Page 9: Portable Use

    It is recommended to keep the original packaging materials for the Tobii Dynavox I-Series. If device needs to be returned to Tobii Dynavox for Warranty related issues or repair, it is beneficial that the origi- nal packaging or equivalent is used for shipping. Most shipping carriers require at least 2 inches of packing mate- rial around the device.
  • Page 10 1 Snap Core First Training Cards ● 1 Communicator 5 Training Cards ● 1 Safety and Compliance documents (printed) ● 1 Software license documents (printed) ● 1 Warranty Document (printed) 1 Introduction #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 11: Safety

    In case of failure of the Tobii Dynavox I-Series device, the user cannot communicate using it. The Tobii Dynavox I-Series is not to be used as a life supporting device, and it shall not be relied on in case of loss of function due to power loss or other causes.

  • Page 12: Temperature

    Windows Shut Down or Hibernate (depending on Windows Power Button configuration) to prevent risk of harm to the user. It may take a while before the Tobii Dynavox I-Series device can be restarted, as the unit may need time to cool down.

  • Page 13: Mounting

    The Tobii Dynavox I-Series should be mounted according to MANUFACTURER instructions of approved mounts. Tobii Dynavox or its agents are not liable for damage or injuries to a person or its property due to a Tobii Dynavox I-Series falling from a mounted configuration. The mounting of a Tobii Dynavox I-Series is done entirely at the user’s own risk.

  • Page 14: 2.10 Child Safety

    Tobii Dynavox assumes no responsibility for any consequence resulting from use of the Tobii Dynavox I-Series in a manner inconsistent with its intended use, including any use of the Tobii Dynavox I-Series with third-party soft- ware and/or hardware that changes the intended use.

  • Page 15: Overview Of The Tobii Dynavox I-13 And I-16

    A Tobii Dynavox I-Series device has a color capacitive touch, LED Backlight screen. The Tobii Dynavox I–13 has a 13.3″ screen with a 1920 × 1080 pixel resolution. The Tobii Dynavox I–16 has a 15.6″ screen with a 1920 × 1080 pixel resolution.

  • Page 16: Ports, Sensors And Device Buttons

    Adaptive Button 2 — Square (Configurable) Calibrate Eye Tracker (Default for touch) Microphone Volume Down Camera 2 MP Fixed Focus(FF) Volume Up Eye Tracker 3 Overview of the Tobii Dynavox I–13 and I–16 #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...
  • Page 17 Position Description Camera 8 MP Auto Focus (AF) Mounting Plate Power Button Speakers Partner Window Programmable IR Remote/ ECU (transmitter and receiver) 3 Overview of the Tobii Dynavox I–13 and I–16 #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 18: Preinstalled Software

    Be extra careful with the USB connectors. Preinstalled Software The Tobii Dynavox I-Series device is delivered with all pre-ordered and required software installed and ready to use. Should a reinstallation become necessary at any stage, perform a Factory Recovery. For more information, see 5.11 Reset the Tobii Dynavox I-Series, page 40.

  • Page 19: Batteries In The Tobii Dynavox I-Series

    The Tobii Dynavox I-Series device has one built-in battery and a battery indicator. The battery indicator will send out a warning of Low battery when the battery drops below 10% of its capacity. If the Tobii Dynavox I-Series device is not pow- ered up by the power supply for charging, the Tobii Dynavox I-Series device will shut down automatically.
  • Page 20 Align the two battery icons, one is located on the battery and one on the device, for the battery to be in the correct position. Place the battery cover back in place. Tighten the five (5) screws with a Phillips screwdriver. 4 Batteries in the Tobii Dynavox I-Series #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 21: Using The Tobii Dynavox I-Series

    First Start Up When you start your Tobii Dynavox I-Series for the first time, you are required to go through a couple steps to set your I- Series up with the correct software and language installation. The whole process usually takes between 10-15 minutes.

  • Page 22: Creating A User Account

    Tobii Dynavox Configuration Once completing the above steps, a Tobii Dynavox setup guide will launch. The setup guide will ask you for a QR-code that defines what Tobii Dynavox software is to be installed. The QR-code is supplied on paper with your device, and the setup guide will let you use the built-in rear camera to scan it.

  • Page 23: Password Information

    If you decide to use a password for your user account on your Tobii Dynavox I-Series device, be sure to write it down in a safe place for later use. Without the operating system’s access password, Tobii Dynavox Support may be unable to assist you until you have recovered it through Microsoft.

  • Page 24: Track Box

    At 70 cm (27.5 in) the Tobii Dynavox I-Series allows for lateral Freedom of Head Movement in an area of about 50 × 36 cm (20 × 14 in) or 35 × 30 cm (13,8 × 11,8 in) depending on which Eye tracker the Tobii Dynavox I-Series is equipped with. For more information, see Appendix D Technical Specifications, page 52.

  • Page 25: Track Status

    Select one of the following ways to access the Track Status: ● Select the Track Status Button, pos x in Fig y, on the device ● Open Track Status from within your Tobii Dynavox Snap Core First ® / Communicator 5 Position the user.

  • Page 26: Eye Tracking Settings

    Select Yes to delete the selected profile or No to cancel. Select Close to leave the page. 5.3.4.1.2 Create New Profile Select the Calibration type to use. 5 Using the Tobii Dynavox I-Series #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 27: Calibration Results

    Toggle the Select points using gaze On/Off check box to On to gaze enable the calibration points in order to select them with gaze. (Optional) 5 Using the Tobii Dynavox I-Series #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 28: Test Calibration

    Look at each dot in each circle on the screen to see how accurate the eye tracking is in that area. Select Close when finished. 5 Using the Tobii Dynavox I-Series #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 29: Calibration

    Stimulus Size: Select the size of the stimulus when the stimulus is displayed on the screen: ● Small ● Medium ● Large Close: Select the Close button to leave the page. 5 Using the Tobii Dynavox I-Series #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 30: Wake-On-Gaze

    5.3.4.1.6 Wake-on-Gaze ® The Tobii Dynavox I-Series device can be set to wake automatically from Sleep mode when your eyes are registered as looking at the display. 5 Using the Tobii Dynavox I-Series #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 31: The Activation Tab

    Off - Choose Off to deactivate Make pause button available when looking outside screen. When Off, the pause button for pausing the eye tracking will not be available when the user looks outside of the screen (Default). 5 Using the Tobii Dynavox I-Series #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 32: Gaze & Switch Settings

    Pausing the eye tracking – Select the Pause button to pause the eye tracking. – Select the Play button to active the eye tracking, 5 Using the Tobii Dynavox I-Series #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 33: The Feedback Tab

    Large Using the Stand Adjustable Base The Tobii Dynavox I-Series comes with a Stand Adjustable Base as an accessory, which allows the user to place the Tobii Dynavox I-Series device in more positions for the best possible Eye Gaze. To use the Stand Adjustable base follow these instructions: Place the Stand Adjustable Base on a flat surface and place the Tobii Dynavox I-Series device on to the Stand Ad- justable base.

  • Page 34: Using The Partner Window

    Tobii Dynavox Snap Core First ® / Communicator 5. Using the Cameras The two built-in cameras allows you to take snapshots of items in front of the Tobii Dynavox I-Series device and also from the display side. Use Tobii Dynavox Snap Core First ®...

  • Page 35: Using The Programmable Ir Remote Control

    Core First User’s Manual or the Communicator User’s Guide. If the device you are trying to control is not responding, try tilting the Tobii Dynavox I-Series device up or down slightly to change the angle at which the IR signal is being sent.

  • Page 36: Adaptive Buttons

    The touch behavior of the of the Adaptive buttons can be set and changed here. The Eye Gaze behaviors for the adaptive buttons are set in your Tobii Dynavox communications software. See the User’s Manual for SNAP + Core First in the sec- tion named “Page Set Settings - Adaptive Buttons”...

  • Page 37: Eye Tracker

    To change the Eye Tracker Settings, select the Open button and you will be taken to the Eye Tracking Settings application. For more information, see 5.3.4 Eye Tracking Settings. 5.10.3 Switches 5 Using the Tobii Dynavox I-Series #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 38: Enabling A Connected Switch

    Snap, and will not allow the user to access other programs on the device. For more information on Ki- osk Mode, see https://docs.microsoft.com/en-us/windows/configuration/set-up-a-kiosk-for-windows-10-for-desktop-edi- tions#set-up-assigned-access-in-pc-settings 5 Using the Tobii Dynavox I-Series #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 39: Enabling Lock Screen

    I-Series Product Key(s) on the device are not valid for that feature. Some Tobii Dynavox software products may not appear in this list. To view the license status of a product, launch the software and look in the Settings>About section.

  • Page 40: System & Diagnostics

    You can attach the file containing the System & Diagnostics information to an e-mail. 5.11 Reset the Tobii Dynavox I-Series If you have made a lot of different changes to the Tobii Dynavox I-Series and would like to start over, perform a Recovery from within Windows.
  • Page 41 Remove everything – Reinstalls Windows 10 and removes all your personal files. – Removes apps and drivers you installed. – Removes changes you made to settings. 5 Using the Tobii Dynavox I-Series #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...
  • Page 42 Select Next to continue or Cancel to abort. Select Reset to continue or Cancel to abort. This will take several minutes. When finished, the Tobii Dynavox I-Series will reboot and you will be presented with the Manual key entry menu.

  • Page 43: Product Care

    The cleaning should be done using a wipe style product only. Wipe only outer surfaces of the Tobii Dynavox I-Series device and allow the product to dry natu- rally or follow the wipe instructions.

  • Page 44: Disposing Of The Tobii Dynavox I-Series Device

    Disposing of the Tobii Dynavox I-Series Device Do not dispose of the Tobii Dynavox I-Series Device in general household or office waste. Follow your local regulations for the disposal of electrical and electronic equipment. 6 Product Care #12007957 Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 45: Appendix A Support, Warranty, Training Resources And Trouble-Shooting

    It is recommended to keep the original packaging materials for the Tobii Dynavox I-Series. If device needs to be returned to Tobii Dynavox for Warranty related issues or repair, it is beneficial that the origi- nal packaging or equivalent is used for shipping. Most shipping carriers require at least 2 inches of packing mate- rial around the device.
  • Page 46 Connect the power supply and wait a couple of minutes to allow charging before trying to power up the device again. If the device does not start up correctly, please contact Customer Support. See A1 Customer Support for contact information. Appendix A Support, Warranty, Training Resources and Trou- Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US ble-shooting...

  • Page 47: Appendix B Compliance Information

    Radio Wave Exposure and Specific Absorption Rate (SAR) Information The Tobii Dynavox I-Series device has been tested as a Class 1 Medical Device. Medical electrical equipment such as this requires special caution regarding Electro-magnetic Compatibility (EMC) and thus needs to be installed and placed into service according to the information provided in this manual.
  • Page 48 Electromagnetic Compatibility (EMC) Directive 2014/30/EU on the approximation of the laws of the Member States relating to electromagnetic compatibility and Radio Equipment Directive (RED) 2014/53/EU to meet the regulation of the radio equipment and telecommunications terminal equipment. Appendix B Compliance Information Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...
  • Page 49 Directives and Standards The Tobii Dynavox I-Series complies with the following directives: ● Medical Device Directive 93/42/EEC ● Low voltage Directive 2014/35/EU ● Electromagnetic Compatibility (EMC) Directive 2014/30/EU ● Radio Equipment Directive (RED) 2014/53/EU ● RoHS2 Directive 2011/65/EU ● WEEE Directive 2012/19/EU ●...

  • Page 50: Appendix C Computer Device States Of Operation And Led Status

    The device is powered off and Windows is not running. The Power Button will start up the device and the device will go into Normal operating state with Windows session running. Appendix C Computer Device States of Operation and LED Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US Status...
  • Page 51 Comment Color Status White Off / Low / High The four (4) touch panel button LED The status is set by API Appendix C Computer Device States of Operation and LED Status Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 52: Appendix D Technical Specifications

    Web Camera (front) 2 MP FF (Fixed Focus) Eye Tracker Tobii IS5 Module Expected Service Life 5 years Battery Run Time ~9 h ~8 h Battery Charge Time Maximum 5.4 h (0-100%) Appendix D Technical Specifications Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...
  • Page 53 Type/Model I–13 I–16 Deskstand Integrated Mounting Systems Supported Tobii Dynavox QR adapter plate for Daessy and REHAdapt Power Supply 65 W AC adapter IP class IP54 Pass for device only, with I/O covers in place. Adaptor mode is excluded. IP22 In adapter mode.
  • Page 54 Freedom of head movement describes the volume in front of the tracker in which the user must have at least one of the eyes. The numbers are specified parallell/orthogonal to screen surface, assuming eye tracker is at 20 degree angle to screen. Appendix D Technical Specifications Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...
  • Page 55 Though “ideal” numbers are useful to get a general feel about comparative quality and performance, they are not appli- cable to real world usage in the same way as quantitative degree-of-accuracy and precision over percentage-of-population numbers based on extensive testing across representatives of the whole population. Appendix D Technical Specifications Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...

  • Page 56: Appendix E Maximum Allowed Temperature

    Figure E.1 Temperature Threshold Area Do not touch the area specified in Figure E.1 Temperature Threshold Area, page 56 when the Tobii Dynavox I- Series device is running. The specified area can reach temperatures which may cause permanent bodily harm in the event of prolonged direct skin contact.

  • Page 57: Appendix F Approved Accessories

    TDG G1 12006939 Stand Adjustable Base I-13/I-16 12006959 For information about the latest approved Tobii Dynavox Accessories, please visit the www.tobiidynavox.com website or contact your local Tobii Dynavox reseller. Appendix F Approved Accessories Tobii Dynavox I-Series User’s manual v.1.0.1 - en-US...
