- Page 1 Mobi-Roll’N Stow™ User Manual # 220 740 Usine du Bourisson - 16400 La Couronne - France Tél. : +33 (0) 545 677 030 Fax : +33 (0) 545 678 160 deschamps@deschamps.fr www.mobi-mat.com...
-
Page 2: Table Of Contents
Summary Safety precautions page 1. Instructions for use page a. Preliminary information page b. Recovery of a Mobi-Mat pathway with the Mobi-Roll’N Stow™ page ® c. Deployment of the Mobi-Mat pathway page 10 ® 2. Maintenance and cleaning page 12 3. - Page 3 Technical data Net weight without Mobi-Mat pathway: 44.1 lbs / 20 Kg ® Dimensions: • Overall length: : 87.80’’ / 2230 mm • Overall width: 64.18’’ / 1630 mm • Overall height: 30.71’’ / 780 mm Maximum capacity : 164’ / 50 m of Mobi-Mat width 5’ / 1.53 m. Deployment or recovery : approx.
-
Page 4: Instructions For Use
Kit description # 220 464 (after) N° kit N° pdt N° article Repère Désignation Qté 216832 Mat accessories 168314 X-connector 222736 Fastening strap 222737 Mini I-connector 216833 Tools 222738 5mm Allen key 222739 Mouting instructions 222740 Instructions for use 216834 Spares 222741 Binding screw... -
Page 5: Safety Precautions
Safety precautions Always observe the safety precautions listed in this notice Always make sure that nobody stands within the area during deployment/recovery process Never use the Mobi-Roll’N Stow™ to transport other materiel than Mobi-Mat ® Never use Mobi-Roll’N Stow™ to transport persons After a long sun exposure, metallic parts might cause burns in case of skin contact Never roll more than 164’... -
Page 6: Preliminary Information
1. Instructions for use of Mobi-Roll’N Stow a.Preliminary information a-1.Moving the Mobi-Roll’N Stow™ to the deployment area Reminder: Mobi-roll’N Stow™ does not comply with road regulation. It is not to be used on public roads. Moving the empty Mobi-Roll’N Stow™ Move the Mobi-Roll’N Stow™... -
Page 7: Recovery Of A Mobi-Mat
b. Recovery of a Mobi-Mat pathway with ® the Mobi-Roll’N Stow™ Place the Mobi-Roll’N Stow™ on the mat about 3.3’ / 1m from the loose end. ~.3.3’ / 1 m Fold the mat towards the inner wheels of the Mobi- Roll’N Stow™... - Page 8 Proceed in the same way on the other side. Position the X-connector, connected to the connec- tor, on the inner winding wheels. Start the winding of the mat by pulling it. It is better to raise the Mobi-Roll’N Stow™ in raising the outer rolling wheels slightly.
- Page 9 Make sure to stay in the axis by backing up with the help of the central band of the mat. Once the mat is rolled up, move back so that the end of the mat is on top. Position the straps on the floor and bring over the Mobi-Roll’N Stow™...
-
Page 10: Deployment Of The Mobi-Mat
c. Deployment of the Mobi-Mat pathway ® Deployment in pull mode: Position the mat in the direction of deployment. Remove the carrying straps that hold the mat. Anchor the mat in the ground. Deploy the mat by pulling the Mobi-Roll’N Stow™ in trolley mode Stop when the connecting bar is at the top of the inner wheels. - Page 11 Deployment in push mode: Position the mat in the direction of deployment. Remove the carrying straps that hold the mat. Anchor the mat in the ground. Push the Mobi-Roll’N Stow™ to unroll the mat. Stop when the connecting bar is at the top of the inner wheels.
-
Page 12: Maintenance And Cleaning
2. Maintenance and cleaning After use, we advise to clean the Mobi-Roll’N Stow™ with fresh water. Regular cleaning will enable the stainless steel to keep its initial appearance. Check all tightening screws after10 uses. 3. Transport Mobi-Roll’N Stow™ does not comply with road regulation. It is not designed to be used on public roads. It must be transported in an appropriate vehicle or trailer over public roads. - Page 13 5. Maintenance Replacement of wheel cords Insert the cord into one of the holes Make a knot. Pull the cord to press the knot of the hub. against the hub. Pass the cord in the opposite direc- Check the cord does not block the Pass the cord through the wheel tion through the other hole of the hub axis.
-
Page 14: Possible Problems Encountered
Insert the hub into the wheel axis by Check the hub is properly inserted Insert the cord into the hole of the pulling the cord. to the stop and the cord does not connection part. block the axis. Make a knot. Pull the cord until the knot fits into Check the equipped wheel is cor- the housing of the connection part. -
Page 15: X-Connector
At use Possible problem Possible cause Solution The roll belts are still fastened Remove the roll belts Lift the Mobi-roll ‘N Stow and place it about 6.5’ / 2m backwards on the mat. The mat does not While one operator maintains the deploy The mats is blocked (Mobi-Roll’N deployed mat, the other operator... - Page 16 DiStriBUtor www.mobi-mat.com DESCHAMPS mobimat.access Usine de Bourisson MobiMatUS 16400 La Couronne - France recpath Mobi-Mat + 33 (0) 545 677 030 company/deschamps info@mobi-mat.com : Subject to technical alterations. DESCHAMPS_Mobi-mat_P&R_2019_UK_Manuel Mobi Roll V2 - Non-contractual pictures - © DESCHAMPS...
