Important: Read these instructions fully before installation.
1. Installation of the appliance and accessories MUST be carried
out by a qualified and suitable competent person.
2. All wiring must conform to current I.E.E. Wiring Regulations
and all applicable national standards and Building Regula-
tions.
3. Installation must be inspected and tested by a suitably quali-
fied person after completion.
4. Installation of the appliance must be carried out in clean, dry
conditions where dust and humidity are at minimal levels.
5. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
6. Children should be supervised to ensure that they do not
play with the appliance.
EN
auralite
TP518
LED Status Indicator
ventilation systems
®

Advertisement

loading

Summary of Contents for Titon auralite TP518

  • Page 1 Important: Read these instructions fully before installation. 1. Installation of the appliance and accessories MUST be carried out by a qualified and suitable competent person. 2. All wiring must conform to current I.E.E. Wiring Regulations and all applicable national standards and Building Regula- tions.
  • Page 2 LED ventilation system status indicator, designed to fit a standard UK patress or recessed backbox. The indicator is for use with specific Titon HRV units. The indicator has six LEDs which display:- Normal Solid light - Unit is running at Continuous Speed.
  • Page 3 Wiring Diagrams White Yellow or Green Black auralite® connection at Indicator White Yellow or Green Black typical plug connection to HRV Wire connection to HRV...
  • Page 4 All lights will momentarily be illuminated indicating a successful reset. MARKETING DIVISION 894 The Crescent Colchester Business Park COLCHESTER Essex CO4 9YQ Tel: +44 (0) 1206 713800 Fax: +44 (0) 1206 543126 Email: ventsales@titon.co.uk Web: www.titon.com DO 5179 Issue 03...
