Page 1
Important: Read these instructions fully before installation. 1. Installation of the appliance and accessories MUST be carried out by a qualified and suitable competent person. 2. All wiring must conform to current I.E.E. Wiring Regulations and all applicable national standards and Building Regula- tions.
Page 2
LED ventilation system status indicator, designed to fit a standard UK patress or recessed backbox. The indicator is for use with specific Titon HRV units. The indicator has six LEDs which display:- Normal Solid light - Unit is running at Continuous Speed.
Page 3
Wiring Diagrams auralite® connection at Indicator auralite® connection at HRV Unit...
Page 4
All lights will momentarily be illuminated indicating a successful reset. MARKETING DIVISION 894 The Crescent Colchester Business Park COLCHESTER Essex CO4 9YQ Tel: +44 (0) 1206 713800 Fax: +44 (0) 1206 543126 Email: ventsales@titon.co.uk Web: www.titon.com DO 5539 Issue 01...
