SE 07-Track Tracer SE 08-Roman Chair & Hyperextension SE 09-Double Airwalker SE 10-Airwalker System SE 11-One Arm Rotation SAYSU GmbH Outdoor Fitness Equipment Weitzesweg 16 A 61118 Bad Vilbel/ Germany Tel.: 0049 (0) 6101 802 707 - 0 Fax: 0049 (0) 6101 802 707 - 30 E-Mail: info@saysu.de...
Page 2
Installation Instructions Installation Instructions SE Installation Instructions Installation Instructions SE- - - - Serie Serie Serie Series s s s Underground Before the installation you have to decide on which underground the equipment will be installed. Possible undergrounds are (more precisely defined in DIN 1176-1.2008; table F.1): Concrete/stone •...
Page 3
Installation Instructions Installation Instructions SE Installation Instructions Installation Instructions SE- - - - Serie Serie Serie Series s s s Under-ground installation with loose material If you use loose material like sand, gravel, mulch or wood chips, then you have to built the foundation 200mm below ground level and bevel the foundation around the mounting plate (see page 4).
Page 4
Installation Instructions Installation Instructions SE Installation Instructions Installation Instructions SE- - - - Serie Serie Serie Series s s s Beveling of the foundation with loose filling material To avoid edges of the foundation looking out of the covering, it is required to bevel the foundation along the mounting plate on all sides as shown in figure (a) (see DIN EN 1176-1).
Page 5
Installation Instructions Installation Instructions SE Installation Instructions Installation Instructions SE- - - - Serie Serie Serie Series s s s Foundation system 1 SE 01-Twister SE 02-Twister & Stepper SE 03-Bike & Trapezius SE 05-Arm Rotation SE 06-Balance Seat SE 08-Roman Chair & Hyperextension SE 09-Double Airwalker SE 11-One Arm Rotation 1.
Page 6
Installation Instructions Installation Instructions SE Installation Instructions Installation Instructions SE- - - - Serie Serie Serie Series s s s Foundation system 2 SE 04-Jump Tower 1. Dig a hole for the foundation as shown in figure (c), with the minimum dimensions of (l) 800mm, (w) 800mm, (h) 1000mm.
Page 7
Installation Instructions Installation Instructions SE Installation Instructions Installation Instructions SE- - - - Serie Serie Serie Series s s s Positioning the foundation anchor The foundation anchor included in the delivery should be positioned in the concrete as shown in figure (d). The equipment fixing bolts have to be above the concrete.
Page 8
Installation Instructions Installation Instructions Installation Instructions Installation Instructions SE Installation Instructions Installation Instructions Installation Instructions Installation Instructions SE- - - - Serie Serie Serie Series s s s SE 07-Track Tracer SE 10-Airwalker For these units, a twin anchoring system is used. 1.
Page 9
Installation Instructions Installation Instructions SE Installation Instructions Installation Instructions SE- - - - Serie Serie Serie Series s s s Positioning of the foundation anchor The foundation anchor and distance piece included in the delivery should be positioned in the concrete as shown in figure (f).
Installation Instructions Installation Instructions SE Installation Instructions Installation Instructions SE- - - - Serie Serie Serie Series s s s Mounting of equipment Before mounting the totally assembled delivered equipment to the foundation, it has to be assured the concrete has dried completely. The drying time is changing depending on the weather conditions. The drying time of concrete at normal weather conditions is approximately 15 days.
