Controller Settings - Vasindux Pro 3.0 User Manual

Setup and Use of the
Vasindux Home
• Connect the Vasindux Pro 3.0 mat (or
accessory device) to the "Out1" or "Out2"
port on the Controller. Only one device can
be connected at a time. The controller will
automatically detect the port and operate off
of the port that was connected first.
• Plug the AC adapter into your electrical outlet.
• Connect the AC adapter to the Controller
using input connection "PS 12V". Be sure to
use the AC adapter provided with your unit.
• Plug a set of headphones into the audio jack
to listen to relaxing music during your session.
See the instructions for adjusting volume
below.

Controller Settings

You can access the settings menu from the home
screen showing If, Ch, Br by pressing and holding
the left and right arrows for 5 seconds.
Use the navigation (right arrow, left arrow)
buttons to select the settings you want to change:
"Language", "Date", "Time", "Sound", "Volume",
"Contrast", "Device Data".
Pressing the "OK" button will enter the sub menu
of the selected option, where you can use the
navigation keys to select from the available
options. Then press the "OK" button to confirm
the selection. You can exit the settings menu by
briefly pressing the ON / OFF button.
Note: "Sound" is referring to the Beep Signal. "Volume" is referring to
the sound level emitted by the headset.
P A G E 6 | Copyright © 2019 PEMF Supply LLC
To turn on the device, press the "Power" button (1). When the device has powered
on, the logo will appear on the display. During this time, calibration is checked and
completed. If the applicator is not plugged in or is poorly connected, the device warns
the user with 3 shorts beeps. The unit will then turn off. If everything is fine during the
calibration check, the main screen will be displayed. To turn off the device, Press and
hold "Power" (1) for 4 seconds. If the device is inactive for at 5 minutes, it will
automatically power off.
4
1. Power
2. Preset Functions
Turning the Device
On and Off
2 1
3
3. OK
4. Navigation Buttons
P A G E 7
