IMPORTANT: RECEIVING INSTRUCTIONS: Visually inspect all components for shipping damage. If any shipping
damage is found, notify carrier at once. Shipping damage is NOT covered by warranty. The carrier is responsible for
all repair or replacement costs resulting from damage in shipment.
IMPORTANT USER SAFETY AND PROTECTION: In setting up systems to fit your operations, care must be taken to
select the proper components and design to insure appropriate integration with your operations and existing
equipment and that all safety measures have been taken to avoid the risk of personal injury and property damage
from your application or system.
GB ELECTRICAL, INC. CANNOT BE HELD RESPONSIBLE FOR DAMAGE OR INJURY CAUSED BY UNSAFE
USE, MAINTENANCE OR APPLICATION OF ITS PRODUCTS. Please contact GB's technical service department
for assistance if you are in doubt as to the proper safety precautions essential to designing and setting up your
particular application.
Preliminary Procedure:
Read all instructions carefully and completely before
attempting to mount a hydraulic bender on this table
and/or operate this table.
Hydraulic Bender Operation:
Read all Eegor™ hydraulic bender instructions
before attempting to assemble or operate your
hydraulic bender.
Use Standard Precautions with Hydraulic
Hoses and Couplings:
Avoid developing
sharp bends in, or
pinching, hoses.
Always provide
sufficient
clearances for
hoses and
couplings to avoid
rubbing or contact
with sharp edges.
Falling objects:
Before rotating
table top, always
remove any loose
objects from the
table or bender.
Check for proper
assembly of table,
bender and conduit
to avoid possible
injury due to falling
objects.
Instruction
Sheet
Clearances:
Before tilting table top,
always check for and
provide sufficient
clearances for table,
bender, and conduit.
Hydraulic Jack
Handle:
When you are not operating
hydraulic jack, place handle
in storage clips provided.
Keep Clear of
Possible Pinch
Points:
Motion between table
components could severely
pinch or cut any objects
wedged between.
BE400 Eegor™
Bending Table
