Summary of Contents for Rioned AquaJet

  • Page 1 AquaJet user manual...
  • Page 2 Rioned. Rioned reserves the right to make changes to parts at any time, without providing prior or direct notification to the buyer. The content of this user manual may also be changed without prior...
  • Page 3 Troubleshooting tips to help you correct minor malfunctions yourself are also provided. Finally, at the end of this user manual you will find an index to help you quickly find information and a number of annexes containing, among other things, Rioned's contact details.

  • Page 5: Table Of Contents

    Table of contents Introduction ........9 7.3.11 Starting Honda GX690 with the 5-channel cable reel ............... 40 Description and principle of Unblocking a sewer..........41 7.4.1 Spray nozzle warning..........41 operation..........11 7.4.2 Preparations for spraying ........41 Introduction............11 7.4.3 Starting spraying ............ 41 Machine ..............
  • Page 6 8.7.4 Hose guide ............84 Maintenance before the work......105 8.7.5 Reeling high pressure hose in/out with the 9.5.1 Check oil levels............. 105 eControl+..............85 9.5.2 Clean water filter ..........105 8.7.6 Manually reeling out high pressure hose 9.5.3 Check high pressure hose and other hoses..106 controlled by eControl+ ........87 9.5.4 Maintenance of remote control......106 8.7.7 Reeling in/out with the Riomote control....

  • Page 9: Introduction

    INTRODUCTION Introduction Congratulations on the purchase of the AquaJet! The AquaJet is intended for unblocking sewers and cleaning walls, terraces and floors. With correct use, this machine will serve you well for years to come. Read this user manual carefully before putting the machine in service, and always use the machine in accordance with the instructions.
  • Page 10 INTRODUCTION...

  • Page 11: Description And Principle Of Operation

    DESCRIPTION AND PRINCIPLE OF OPERATION Description and principle of operation Introduction In this chapter we first briefly describe the operation, the main components and the symbols used for the machine and the accompanying accessories. You will then find a description of the machine's control units in chapter ‘Control’, sections ‘eControl+’, ‘Riomote control’, ‘Control box’...
  • Page 12 DESCRIPTION AND PRINCIPLE OF OPERATION AquaJet 21047002001 AquaJet 21047002001...
  • Page 13 DESCRIPTION AND PRINCIPLE OF OPERATION AquaJet 21047002001 AquaJet 21047002001...
  • Page 14 DESCRIPTION AND PRINCIPLE OF OPERATION AquaJet 21047002001 AquaJet 21047005001...
  • Page 15 DESCRIPTION AND PRINCIPLE OF OPERATION AquaJet 21047506000 AquaJet 21047506000...
  • Page 16 DESCRIPTION AND PRINCIPLE OF OPERATION AquaJet 21047506000...
  • Page 17 DESCRIPTION AND PRINCIPLE OF OPERATION The following is a brief explanation of parts from the illustrations above that are not discussed further in the manual. Securing end of filling hose (3) The end of the filling hose is attached to this connection. Drip tray (4) The drip tray is designed to collect any water that drips off the hoses.
  • Page 18 DESCRIPTION AND PRINCIPLE OF OPERATION Supply valve, water filter (11) This valve is normally open. It is only closed when cleaning the water filter and servicing the high pressure pump. Reel latch (14) This latch prevents the reel from turning. It is operated by twisting the wings. Supply valve, filling reel (17) Open this valve when the water tanks are filled through the filling hose.

  • Page 19: Symbols On Pressure Gauge, Pressure Regulator And Valve Controls

    DESCRIPTION AND PRINCIPLE OF OPERATION 5.2.2 Symbols on pressure gauge, pressure regulator and valve controls Pressure gauge (7) Maximum allowable pressure Operating range Danger zone The maximum operating pressure is indicated on a sticker near the pressure gauge. Reduce the operating pressure with the handwheel of the pressure regulator until the indicator of the pressure gauge is halfway between 0 and the maximum operating pressure.
  • Page 20 DESCRIPTION AND PRINCIPLE OF OPERATION 3. Two open-end spanners for tightening and loosening the spray gun. Open-end spanners 4. This user manual 5. Engine documentation 6. One suction hose with strainer. 7. Attachment: high pressure pump 8. Attachment: exploded view drawings and diagrams.

  • Page 21: Safety

    SAFETY Safety Introduction This user manual contains very important safety instructions. In this chapter we provide general instructions. ALWAYS follow these instructions for use and maintenance. In other chapters we provide specific safety instructions for each action or situation. ALWAYS follow these instructions too.

  • Page 22: Use Only By Authorized Personnel

    > substances subject to special rules Do NOT use the machine in an explosive environment. Rioned ONLY guarantees the safety when working with the machine if the machine is used as described in this user manual. NEVER exceed the following limit values (EN IEC 60204-1): >...

  • Page 23: Spraying

    SAFETY Spraying ALWAYS follow the instructions below when spraying: > NEVER point the jet at people or animals. > If skin penetration occurs, consult a DOCTOR immediately. > NEVER spray on live parts, such as electrical equipment. > NEVER spray the machine itself. >...

  • Page 24: Personal Protective Equipment

    SAFETY 6.15 Personal protective equipment ALWAYS use the following personal protective equipment when working with the machine: > hearing protection > safety glasses or face shield > waterproof work gloves > waterproof workwear > helmet > spray boots with steel toes 6.16 Water discharge Ensure that the water is drained off properly.

  • Page 25: Safety Sticker

    SAFETY 6.18 Safety sticker The safety sticker is located on the back of the vehicle. The symbols used have the following meaning: 1. Hearing, head and eye protection must be worn 2. Safety shoes with extra protection required 3. Reading the manual is mandatory 4.
  • Page 26 SAFETY...

  • Page 27: Operation: Standard Functions

    OPERATION: STANDARD FUNCTIONS Operation: standard functions Introduction In this chapter we first describe the checks you must carry out before departure and the preparations required at the workplace. Then the different ways to start the engine are explained. Next the work will be discussed: unblocking a sewer, properly handling the high pressure hose and cleaning a wall, terrace or floor.

  • Page 28: Preparations At The Workplace

    OPERATION: STANDARD FUNCTIONS Preparations at the workplace 7.3.1 Preparing the vehicle 1. Park the vehicle at the desired location and engage the parking brake. 2. When used on a slope, block the wheels of your vehicle with wheel chocks. 3. Mark the work area in accordance with local regulations. 7.3.2 Before starting >...
  • Page 29 OPERATION: STANDARD FUNCTIONS NOTE It may be that fuel from the vehicle is used. You may use it up before you realize it, in which case the work must stop. Then it is also no longer possible to drive the vehicle. Make sure you have a jerrycan with fuel. The water tank can be filled in several ways: Via the filling hose Connect the filling hose to a tap, open the filling valve and open the water...

  • Page 30: Workstations

    OPERATION: STANDARD FUNCTIONS For cleaning façades, terraces and floors: the spray gun. 7.3.3 Workstations The machine has different workstations. These workstations are: Behind the machine at the control box The following operation is possible here: > operation with control box >...
  • Page 31 OPERATION: STANDARD FUNCTIONS Behind the machine at the eControl+ The following operation is possible here: > operation with eControl+ > emergency stop with eControl+ At the manhole or sewer pipe The following operation is possible here: > operation with control box at a distance of less than one metre >...

  • Page 32: Starting The Engine

    OPERATION: STANDARD FUNCTIONS Remotely with 5-channel wired remote control Here you carry out work closer to the blockage. The maximum distance to the machine is 50 m. Risk at this workstation: no supervision of the machine during one-man operation. 7.3.4 Starting the engine ALWAYS wear personal protective equipment! See section ‘Personal protective equipment’...
  • Page 33 OPERATION: STANDARD FUNCTIONS 3. Move the throttle away from the MIN position to approx. 1/3 of the distance to the MAX position. 4. Set the engine switch to the ON position. 5. Operate the starter. > Turn the engine switch to the START position and hold it in this position until the engine starts.

  • Page 34: Starting Engine Type Honda Gx690 With The Control Box

    OPERATION: STANDARD FUNCTIONS 6. Let the engine warm up. After 3 minutes of warming up, the machine is ready for use. 7. If you pulled the choke knob to the CLOSED position to start the engine, gradually push it to the OPEN position as the engine warms 8.

  • Page 35: Starting The Engine With The Econtrol

    OPERATION: STANDARD FUNCTIONS 5. Check whether charge current indicator lamp is lit. > If not: Go to the ‘Malfunctions’ chapter. 6. Start the engine by turning the key further clockwise. 7. Release the key as soon as the engine starts. 8.

  • Page 36: Starting The Engine With The Econtrol

    OPERATION: STANDARD FUNCTIONS 7.3.8 Starting the engine with the eControl+ First read chapter ‘Operation of additional functions’ section ‘eControl+’. Start the vehicle engine with the eControl+ as follows: 1. Insert the key into the key switch. 2. Turn the key a quarter turn clockwise to position 1. The text ‘Work Safe’...
  • Page 37 OPERATION: STANDARD FUNCTIONS 4. Press and hold the Engine on/off button. The engine is now started. When the engine is running, the engine LED is blue: The text ‘Engine ON’ is displayed for two seconds: 5. Let the engine warm up. After three minutes of warming up, the machine is ready for use.

  • Page 38: Starting The Engine With The Riomote Control (Econtrol)

    OPERATION: STANDARD FUNCTIONS 7.3.9 Starting the engine with the Riomote control (eControl) First read chapter ‘Operation of additional functions’ section ‘Riomote control’. Start the vehicle engine with the Riomote control in the following way: 1. Insert the key into the key switch: 2.
  • Page 39 OPERATION: STANDARD FUNCTIONS 2. Turn the key half a turn clockwise to position 2. The text ‘Work Safe’ will now appear for two seconds: The text ‘Riomote Control ON’ is displayed continuously: The Lightbar flashes blue: 3. Now switch on the Riomote control. The Lightbar stops flashing and stays blue when the Riomote control is connected to the receiver.

  • Page 40: Starting Honda Gx690 With The 5-Channel Cable Reel

    OPERATION: STANDARD FUNCTIONS 6. Increase the speed by pressing button 2 ‘Increase speed’ (7- and 9-channel) or button 6 ‘Throttle up’ (11-channel). 7. Let the engine warm up. After three minutes of warming up, the machine is ready for use. 7.3.11 Starting Honda GX690 with the 5-channel cable reel First read chapter ‘Operation of additional functions’...

  • Page 41: Unblocking A Sewer

    OPERATION: STANDARD FUNCTIONS 6. Check whether charge current indicator lamp is lit. > If not: Go to chapter ‘Malfunctions’. 7. Start the engine by turning the key further clockwise. 8. Release the key as soon as the engine starts. 9. Let the engine warm up. After three minutes of warming up, the machine is ready for use.
  • Page 42 OPERATION: STANDARD FUNCTIONS Starting spraying with the high-pressure valve 1. Set the lever of the high pressure valve to the open position. 2. Increase the engine speed with the throttle lever. The high pressure hose will now unwind and at the same time work its way into the blocked sewer: Starting spraying with the control box: 1.
  • Page 43 OPERATION: STANDARD FUNCTIONS 3. With the RPM buttons you can now do the following: • Press button ‘+’ to increase the speed. • Press button ‘-’ to decrease the speed. Starting spraying with the eControl+ 1. Check that the high pressure valve is open. 2.
  • Page 44 OPERATION: STANDARD FUNCTIONS Starting spraying with the Riomote control 1. Check that the high pressure valve is open. 2. Press button 4 ‘Start spraying’ (7- and 9-channel) or button 4 ‘HP on’ (11-channel). 3. Press button 2 ‘Increase speed’ (7- and 9-channel) or button 6 ‘Throttle up’...

  • Page 45: Stopping Spraying

    OPERATION: STANDARD FUNCTIONS 5. Check whether the water is drained off. 6. Continue flushing for a while after the blockage is removed. 7. Reel the hose in slowly at the same time. 8. Stop spraying. 7.4.4 Stopping spraying After unblocking, it is important to flush as follows: replace the ‘Open nozzle’ with the ‘Blind nozzle’.

  • Page 46: Handling The High Pressure Hose

    Handling the high pressure hose carefully: > Make sure there are no sharp objects near the hose. > Make sure no vehicles drive over the hose. > Clean the hose after each use. > Contact Rioned if the hose requires repair.

  • Page 47: Cleaning A Wall, Terrace Or Floor

    OPERATION: STANDARD FUNCTIONS Cleaning a wall, terrace or floor 7.6.1 Warnings for spray gun WARNING! ALWAYS observe the following warnings when working with the spray gun: Before use: • Set the pressure regulator to half of the maximum operating pressure (see section ‘Symbols on pressure gauge, pressure regulator and valve controls’).
  • Page 48 OPERATION: STANDARD FUNCTIONS Pressurizing with the high pressure valve (throttle lever op machine) 1. Set the lever of the high pressure valve to the open position. 2. Move the throttle lever to increase or decrease the speed. Pressurizing with the control box: 1.

  • Page 49: Starting Spraying

    OPERATION: STANDARD FUNCTIONS 2. Press the High pressure on/off button. 3. Turn the navigation knob to increase (clockwise) or decrease (anticlockwise) the speed: Pressurizing with the Riomote control 1. Press button 4 ‘Start spraying’ (7- and 9-channel) or button 4 ‘HP on’ (11-channel) to start spraying.
  • Page 50 OPERATION: STANDARD FUNCTIONS The system can be depressurized in several ways: with the high pressure valve, with the control box, with the eControl, with the eControl+, with the Riomote control and with the 5-channel wired remote control. Depressurizing the system with the high pressure valve and Honda GX630 4.

  • Page 51: Stopping The Engine

    OPERATION: STANDARD FUNCTIONS Depressurizing the system with the eControl+ 8. Press the High pressure on/off button. > The LED for high pressure goes out: > Pressure drops off. > The text ‘High Pressure OFF’ is displayed for two seconds: > The engine speed decreases. Depressurizing the system with the Riomote control 1.
  • Page 52 OPERATION: STANDARD FUNCTIONS 1. Move the throttle to the MIN position. Some engine versions have a remotely mounted throttle rather than an engine-mounted throttle as shown here. Throttle lever 2. Set the engine switch to the OFF position. Engine switch 3.

  • Page 53: Ending The Work

    OPERATION: STANDARD FUNCTIONS Ending the work 7.7.1 Cleaning up, securing and draining At the end of the work, complete the following steps: > Is the high pressure hose completely rolled up? > Is the high pressure reel secured? > Is the high pressure hose secured in the hose holder with the safety clip? >...
  • Page 54 OPERATION: STANDARD FUNCTIONS With the high pressure valve 1. Open the drain valve for the water filter and water filter supply valve. This will drain the water tank. 2. When no more water comes out of the valve, Then close the drain valve and water filter supply valve.
  • Page 55 OPERATION: STANDARD FUNCTIONS With the control box 1. Open the drain valve for the water filter and water filter supply valve. This will drain the water tank. 2. When no more water comes out of the valve, Then close the drain valve and water filter supply valve.
  • Page 56 OPERATION: STANDARD FUNCTIONS With the eControl 1. Open the drain valve for the water filter and water filter supply valve. This will drain the water tank. 2. When no more water comes out of the valve, Then close the drain valve and water filter supply valve.
  • Page 57 OPERATION: STANDARD FUNCTIONS NOTE When pumping out the water, there is no need to place a spray nozzle or spray gun on the high pressure hose. The machine is now ready for departure. Removing antifreeze Complete the following procedure to remove the antifreeze from the lines: Method 1: 1.
  • Page 58 OPERATION: STANDARD FUNCTIONS...

  • Page 59: Operation: Extra Functions

    Hose holder on hose guide arm Transmitter Connection, strainer hose, suction 12. Electric water level control venturi 13. 2nd HP reel Oil tank, hydraulic system 14. Non-return valve in supply line Hose guide 15. Antifreeze tank AquaJet 21047002001 AquaJet 21047005001...
  • Page 60 OPERATION: EXTRA FUNCTIONS...

  • Page 61: Econtrol

    OPERATION: EXTRA FUNCTIONS eControl 8.2.1 Design and principle of operation With the eControl you can operate the machine via the buttons. You cannot operate any options with the eControl. You will need the eControl+ option for that. 8.2.2 eControl 16. Battery voltage symbol 23.

  • Page 62: Econtrol

    OPERATION: EXTRA FUNCTIONS eControl+ 8.3.1 Design and principle of operation With the eControl+ you can operate the machine via the navigation knob. You can also use the eControl+ to control a number of options. The status is always shown on the display of the eControl+.

  • Page 63: Econtrol

    OPERATION: EXTRA FUNCTIONS 8.3.2 eControl+ 28. Lightbar 38. High pressure LED 29. Navigation bullets 39. High pressure on/off button 30. Function icons 40. Not applicable 31. Tachometer 41. Not applicable 32. Tachometer pointer 42. Navigation knob 33. Icon eco mode 43.

  • Page 64: Lightbar

    OPERATION: EXTRA FUNCTIONS The following illustrations and text provide a more detailed description of the various parts of the eControl+. 8.3.3 Lightbar The lightbar around the display is switched off (always grey) by default: In the following cases it changes to one of these four colours: BLUE ORANGE GREEN...
  • Page 65 OPERATION: EXTRA FUNCTIONS Inactive (grey): Active (blue): Depending on where you are in the menu, one navigation bullet is visible or – in a pop-up – all navigation bullets disappear. The navigation bullets represent the following, from left to right: Fault Home Pulsator...
  • Page 66 OPERATION: EXTRA FUNCTIONS Fault The first navigation bullet (Fault ) is only visible when a fault message is suppressed, for example ‘too little water in the water tank (run dry)’. Only then can you navigate to this bullet. In other cases, the bullet is hidden. Fault (inactive, grey): Fault (active, blue):...
  • Page 67 OPERATION: EXTRA FUNCTIONS Home The second navigation bullet (Home ) is always visible. You can always navigate to it. Pulsator, electric reel operation and hose counter The following three navigation bullets represent: > the pulsator > the reel > the hose counter These bullets are only visible when the relevant function is available on the machine.

  • Page 68: Functions And Symbols

    OPERATION: EXTRA FUNCTIONS 8.3.5 Functions and symbols A function (pulsator, electric reel operation or hose counter) may be shown in either of two ways: inactive and active. The pulsator is shown below, as an example: Inactive (grey): Active (blue): Depending on where you are in the menu, one function is visible or – in a pop-up –...

  • Page 69: Tachometer

    OPERATION: EXTRA FUNCTIONS Hose counter switched on 8.3.6 Tachometer Just like on a car, the tachometer shows the engine speed, in revolutions per minute. The speed can be increased or decreased with the navigation button. The tachometer can be displayed in the following four ways: Inactive (standard) Inactive (eco mode) Active (standard)

  • Page 70: Riomote Control (Option)

    OPERATION: EXTRA FUNCTIONS Riomote control (option) 8.4.1 Introduction The Riomote control can be purchased as an option for a machine with an eControl or eControl+. With the Riomote control you can control the machine remotely. There are two different Riomote controls available: 1.
  • Page 71 If everything is working properly, the engine will now be shut off. WARNING! If the engine does NOT shut off when the emergency stop button is pressed, the machine may NOT be operated with the Riomote control. In that case, contact Rioned. eControl+ Do this as follows:...
  • Page 72 OPERATION: EXTRA FUNCTIONS 1. Insert the key into the key switch: 2. Turn the key half a turn clockwise to position 2. The text ‘Work Safe’ will now appear for two seconds: The text ‘Riomote Control ON’ is displayed continuously: The lightbar flashes blue: 3.

  • Page 73: Replacing The Battery

    If the engine does NOT shut off when the emergency stop button is pressed, the machine may NOT be operated with the Riomote control. In that case, contact Rioned. 8.4.3 Replacing the battery If the indicator light on the Riomote control lights up, the battery should...

  • Page 74: 5-Channel Riomote Control (Econtrol)

    OPERATION: EXTRA FUNCTIONS 8.4.4 5-channel Riomote control (eControl) The 5-channel Riomote control has the following buttons: 1. Decrease speed 2. Increase speed 3. Stop spraying 4. Start spraying 5. Emergency stop START Button at bottom right: Switch Riomote control on/off After pressing the corresponding button, the following is displayed on the eControl: 7.

  • Page 75: 5-Channel Riomote Control (Econtrol+)

    OPERATION: EXTRA FUNCTIONS 8.4.5 5-channel Riomote control (eControl+) The 5-channel Riomote control has the following buttons: 1. Decrease speed 2. Increase speed 3. Stop spraying 4. Start spraying 5. Emergency stop START Button at bottom right: Switch Riomote control on/off After pressing the corresponding button, the following is displayed on the eControl screen: 1.

  • Page 76: 7-Channel Riomote Control

    OPERATION: EXTRA FUNCTIONS 8.4.6 7-channel Riomote control The 7-channel Riomote control has the following buttons: 1. Decrease speed 2. Increase speed 3. Stop spraying 4. Start spraying 5. Stop engine 6. Start engine 7. Emergency stop START Button at bottom right: Switch Riomote control on/off After pressing the corresponding button, the following is displayed on the eControl screen: 1.

  • Page 77: Functions 5-Channel Wired Remote Control

    OPERATION: EXTRA FUNCTIONS 5. Stop engine: 6. Start engine: Functions 5-channel wired remote control Purpose: Remotely operate the high-pressure machine. Principle of operation: The buttons on the wired remote control are connected to the machine. With these buttons you can control the spraying and activate the emergency stop. Starting suction: 1.

  • Page 78: Pulsator

    OPERATION: EXTRA FUNCTIONS Stop spraying: RPM+ Emergency stop Pulsator 8.6.1 Introduction The purpose of the pulsator is to reach the blockage in the sewer pipe faster with less water consumption. Use the pulsator to get to the blockage more quickly or in case of stubborn blockages.

  • Page 79: Manual Operation Pulsator

    OPERATION: EXTRA FUNCTIONS 8.6.2 Manual operation pulsator Without front panel: > Open the three-way ball valve to start the pulsator. > Close the three-way ball valve to stop the pulsator. OPEN With front panel: > Open the three-way ball valve to start the pulsator. >...

  • Page 80: Stopping The Pulsator With The Econtrol

    OPERATION: EXTRA FUNCTIONS > Turn the navigation knob clockwise: The text ‘ON’ is now shown below Pulsator. > Press the navigation knob to activate the pulsator: icon will now light up. > Press the High pressure on/off button: See section ‘Starting spraying’. 8.6.4 Stopping the pulsator with the eControl+ Perform the following operations: 1.

  • Page 81: Setting The Speed With The Econtrol+ When The Pulsator Is Switched On

    OPERATION: EXTRA FUNCTIONS The navigation bullet now goes out and the pulsator icon lights up blue. 4. Turn the navigation knob anticlockwise: The text ‘OFF’ is now shown below Pulsator. 5. Press the navigation knob to deactivate the pulsator: The pulsator icon now goes out.

  • Page 82: Starting The Pulsator With The Riomote Control

    OPERATION: EXTRA FUNCTIONS The pulsator icon now goes out en the navigation bullet lights up blue: 2. Go to the Home screen: • press the engine symbol: The tachometer will now light up: 3. Turn the navigation knob to increase (clockwise) or decrease (anticlockwise) the speed: 8.6.6 Starting the pulsator with the Riomote control Perform the following operations:...

  • Page 83: Reel

    OPERATION: EXTRA FUNCTIONS Reel 8.7.1 Safety WARNING! There is a danger of pinching/crushing during reel operation! You may only operate the reels if there are no other people in the work area. This is YOUR responsibility. 8.7.2 Hydraulically reeling high pressure hose in/out NOTE Water can still come out of the high pressure hose while reeling it in! The control lever has four positions:...

  • Page 84: Manually Reeling High Pressure Hose Out

    OPERATION: EXTRA FUNCTIONS Push the control lever downwards to reel out the high pressure hose: The control lever also allows you to control the speed of reeling in/out. 8.7.3 Manually reeling high pressure hose out To switch off the hydraulic drive, move the control lever to the position.

  • Page 85: Reeling High Pressure Hose In/Out With The Econtrol

    OPERATION: EXTRA FUNCTIONS After use 1. Swing back the hose guide. 2. Secure the hose guide. Advantages Use of the hose guide provides the following advantages: > improved work safety > more freedom of movement > no dirty hands > the high pressure hose lasts longer >...
  • Page 86 OPERATION: EXTRA FUNCTIONS The navigation bullet will now go out. The high pressure reel icon now lights up blue: 4. Turn the navigation knob anticlockwise to reel in the high pressure hose: 5. Turn the navigation knob clockwise to reel out the high pressure hose: 6.

  • Page 87: Manually Reeling Out High Pressure Hose Controlled By Econtrol

    OPERATION: EXTRA FUNCTIONS Switching off reeling in/out with the eControl+ 1. Turn the navigation knob to the centre (neutral) position: 2. Press the navigation knob to deactivate the high pressure reel: The high pressure reel icon now goes out. The navigation bullet turns blue: 8.7.6 Manually reeling out high pressure hose controlled by eControl+ Your machine may be equipped with a mechanical freewheel locking option.
  • Page 88 OPERATION: EXTRA FUNCTIONS Freewheel To manually reel out the high pressure hose, move the lever to the position shown below: The locking pin is now released and the high pressure reel can rotate freely, without resistance. Locked To reel the high pressure hose in/out with the eControl+, move the lever to the position shown below: The pin locks and you can reel with the eControl+ again.

  • Page 89: Reeling In/Out With The Riomote Control

    OPERATION: EXTRA FUNCTIONS 8.7.7 Reeling in/out with the Riomote control Reel in 1. Check that the engine is running. 2. If not, start the engine with the Riomote control (see section ‘Starting the engine with the Riomote control’). 3. Set the rocker switch to the ‘Reel in high pressure hose’ position (rocker switch up). Reel out 1.

  • Page 90: Hose Meter Counter Econtrol

    OPERATION: EXTRA FUNCTIONS 8.7.8 Hose meter counter eControl+ Introduction The hose counter indicates how many metres of high pressure hose is in the sewer. Things to keep in mind during use Keep the following in mind when using the hose counter: The hose counter only measures when the ignition is turned on and the emergency stop is off.

  • Page 91: Switching Between 'Metres' And 'Feet

    OPERATION: EXTRA FUNCTIONS Make sure the hose is completely rolled up. Press the navigation knob. Select Reset and press the navigation knob. The hose counter now shows 0. Select Back and press the navigation knob. You are now back on the home screen. 8.7.12 Switching between ‘metres’...

  • Page 92: Dry Running Protection

    OPERATION: EXTRA FUNCTIONS Filling the water tank 1. Connect a filling hose to the coupling of the filling line on the machine. 2. Turn on the mains water supply tap. 3. Turn on the switch for the water level control. The water tank is now filled with water.

  • Page 93: Suction Venturi

    OPERATION: EXTRA FUNCTIONS Use this function for: > Suction venturi. The water is used to create a vacuum in the venturi, to suck up surface water. > Freezing protection. The last remaining water is pumped out of the water tank. Bypassing the dry-running protection on the eControl is described in chapter ‘Malfunctions’, section ‘Water level too low’.

  • Page 94: Second Hp Reel Instead Of Supply Reel

    OPERATION: EXTRA FUNCTIONS Stopping suction: > Set the lever of the high pressure valve to the other position. > Stop the machine. > Disconnect the suction hose and put it away. 8.11 Second HP reel instead of supply reel The operation of a second high pressure reel is identical to that of just a single high pressure reel.

  • Page 95: Hour Counter

    OPERATION: EXTRA FUNCTIONS 8.13 Hour counter The usage of the machine is indicated by means of an hour counter. This indicates the number of operating hours that the key switch has been in the ‘on’ position, not the number of hours the engine has been run! 8.14 Work light The switch is used to switch the work light on and off.
  • Page 96 OPERATION: EXTRA FUNCTIONS With option control box: > Press button on control box. With option eControl/eControl+: > Press the High pressure on/off button on the eControl/eControl+. With option Riomote control: Press button 4 ‘Start spraying’. 13. All the water is now pumped out of the high pressure hose. 14.

  • Page 97: Removing Antifreeze

    OPERATION: EXTRA FUNCTIONS With option eControl/eControl+: > Press the High pressure on/off button on the eControl/eControl+. With option Riomote control: Press button 3 ‘Stop spraying’. 22. Stop the engine. 8.16.1 Removing antifreeze Complete the following procedure to remove the antifreeze from the lines: 1.
  • Page 98 OPERATION: EXTRA FUNCTIONS 2. Press the navigation knob to activate the eco mode: The navigation bullet now goes out and the eco mode icon lights up green: 3. Turn the navigation knob anticlockwise to switch off eco mode: 4. Press the navigation knob to deactivate eco mode:...

  • Page 99: Eco Start/Stop

    OPERATION: EXTRA FUNCTIONS The eco mode icon now goes out and the navigation bullet lights up blue: After two seconds the text ‘Hours Total’ is displayed: 8.17.3 ECO Start/Stop This variant of the eco mode allows the engine to be stopped when spraying is stopped and automatically restarted when spraying is restarted.

  • Page 100: Eco Stop

    OPERATION: EXTRA FUNCTIONS 1. Press the Engine on/off button: 2. Press the High pressure on/off button: Now water comes out of the high pressure hose. 3. Increase the speed for higher pressure and more water: turn the navigation knob clockwise: 8.17.4 ECO Stop This variant of the eco mode allows the engine to be stopped when spraying is stopped but NOT automatically restarted when spraying is restarted.
  • Page 101 OPERATION: EXTRA FUNCTIONS Activate the management function as follows: 1. Turn the navigation knob clockwise and move the navigation bullet to the ‘Management’ position: 2. Press the navigation knob to activate the management function: Now the navigation bullet will go out and the line under ‘Management’...
  • Page 102 OPERATION: EXTRA FUNCTIONS The machine displays the following message after starting if periodic maintenance is required: Press the navigation knob to clear the message: You can now continue working with the machine. The next time the machine is started, the message will be displayed again.

  • Page 103: Maintenance

    Rioned. The use of original replacement parts and Rioned-approved accessories is important for safety. If you use other parts, Rioned is NOT liable for any consequential damage. Maintenance schedule The next scheduled maintenance is set to 360 days or 250 hours of operation on the eControl+.
  • Page 104 MAINTENANCE Maintain the various parts of the machine according to the following schedule: Check oil levels Before the work Clean water filter Before the work and when very dirty Check high pressure hose and other hoses Before the work Clean bodywork Weekly or when very dirty Poke the nozzle holes clean Every 50 hours of operation...

  • Page 105: Removal/Installation Of Protective Covers

    MAINTENANCE NOTE The maintenance of the engine is beyond the scope of this user manual. That information can be found in the documentation you received with the machine. Removal/installation of protective covers Removal: 1. Insert the key into the lock. 2.

  • Page 106: Check High Pressure Hose And Other Hoses

    MAINTENANCE 2. Unscrew the filter cap from the filter body. 3. Clean the filter screen and other contaminated parts of the filter. 4. Screw the filter cap back onto the filter body. 5. Open the supply valve in the suction hose. 6.

  • Page 107: Maintenance Every 250 Hours Of Operation Or At Least Once Every Six Months

    9.9.1 Change hydraulic oil Change the oil in the hydraulic system every 1000 hours of operation (or at least once a year). Use oil from Rioned. P/N 71-003-000-046. 9.9.2 Clean suction valves of high pressure pump Clean the suction valves of the high pressure pump once a year.

  • Page 108: Clean Pressure Valves Of High Pressure Pump

    Clean the pressure valves of the high pressure pump once a year. See accompanying annex for more information. 9.9.4 Major scheduled maintenance Have Rioned technical service inspect and maintain the machine once a year. This will ensure the continued good performance and long service life of the machine.

  • Page 109: Malfunctions

    MALFUNCTIONS 10 Malfunctions 10.1 Fault messages eControl+ The eControl+ can display various fault messages. They are also listed in the section about the management function (see section ‘Management function eControl+’). Each of these fault messages, and what you should do if they appear, is explained hereafter. 10.1.1 Emergency stop If the emergency stop is pressed, the following message appears: Consequences for systems:...

  • Page 110: Heat Exchanger Temperature Too High

    MALFUNCTIONS 10.1.3 Heat exchanger temperature too high If the temperature of the heat exchanger becomes too high, the following message appears: Consequences for systems: 1. The engine, high pressure pump, vacuum system, pulsator, reel and/ or hose counter are switched off. 2.

  • Page 111: Coolant Level Too Low

    MALFUNCTIONS Solution: 1. Press the navigation knob to clear the message: 2. Top up hydraulic oil (P/N 71003500046). Work can continue after sufficient oil has been added. This can be measured via the dipstick or seen on the sight glass, depending on which version is mounted.

  • Page 112: Water Level Too Low

    MALFUNCTIONS 10.1.8 Water level too low If the machine is in danger of running dry, the following message appears: Consequences for systems: 1. If the engine is running, it will go to idle. 2. The high pressure pump, vacuum system, pulsator, reel and/or hose counter are switched off.

  • Page 113: Troubleshooting

    Refill the fuel tank. suddenly. Main or accessory fuse blown. Replace defective fuse. Restart engine. If the fuse blows again, contact Rioned. Battery voltage too low. Charge the battery or replace the battery Air in fuel line. Bleed air at engine.
  • Page 114 Air in high pressure pump. Let the machine run several minutes with the high pressure valve open. If the fault is not cleared, contact Rioned. Suction valves of high pressure Carefully free the valves. pump seized. Remove any lime scale build- Suction valves of high pressure Contact Rioned.
  • Page 115 Check condition of pressure valves. Descale pressure valves or Replace pressure valves. High pressure pump sealing ring Stop machine. worn. Replace sealing ring. Ceramic pistons in high pressure Contact Rioned. pump damaged. Pressure regulator internally Contact Rioned. restricted or damaged.
  • Page 116 Drive chain not sufficiently Tighten chain. tensioned. Set operating pressure is too low. Set higher operating pressure, if possible. Hydraulic system damaged. Contact Rioned. Problem Cause Solution No response to switched on No power. Charge battery of RioMote control. Riomote control.
  • Page 117 No connection to receiver. Check all indicator lights for all functions. Command via Riomote control not Open in electrical circuit. Check all plug connections. performed. Push plugs in or Connect detached plugs. Check all indicator lights for all functions. Receiver defective. Contact Rioned.
  • Page 118 MALFUNCTIONS...

  • Page 119: Index

    INDEX Index antifreeze eco mode filling reel freeze-protection ........96 ECO Start/Stop ............99 filling water tank with ........54 Eco Stop ..............100 option antifreeze tank ..........95 standard setting ............97 removing ...............57 switching off ..............97 eControl+ colour lightbar .............64 emergency stop ............109 battery voltage too low ............111 fault messages ............109 navigation bullets ............64...
  • Page 120 INDEX high pressure reel open-end spanners ............20 freewheel lock ..............88 operation standard functions .........27 freewheel release ............88 handle ................17 high pressure valve ............ 17 parts UrbanCombi ............11 hose counter personnel activating eControl+ ........... 90 operation by authorized personnel ......22 function ...............
  • Page 121 INDEX starting engine running dry ............... 112 Honda GX630 ............. 32 bypassing control box ..........92 Honda GX690 with control box ...34 bypassing eControl ............ 112 with cable reel ............40 principle of operation ..........92 with eControl ............... 35 resetting ..............
  • Page 122 INDEX...

  • Page 123: Attachments

    ATTACHMENTS 12 Attachments Rior, Industrie- en handelsonderneming B.V. declares that: Brand: Rioned Type AquaJet Machine number: see p. 2 of this manual > is in conformity with the Machinery Directive (2006/42/EC); > complies with the provisions of the following other EC Directives: 2014/30/EC >...
  • Page 124 ATTACHMENTS Annex 2 Type plate The type plate is located at the left on the back side (relative to the driving direction) and shows the following information: CE Marking Manufacturer of the machine European approval number (not yet available) Chassis number of the vehicle Identification of the machine Manufacturer's address details Year of manufacture of the machine...
  • Page 125 ATTACHMENTS Annex 3 Dimensions...
  • Page 126 ATTACHMENTS Annex 4 Technical specifications General Capacity, water tank: 400 litres (expandable) Length, high pressure hose: 60 m standard (extendable up to 100 m) Diameter, high pressure hose: 1/2" (NW13) standard, 3/4" (NW19) or 5/8" (NW16) Length, filling hose: 35 m Diameter, filling hose: 3/4"...
  • Page 127 ATTACHMENTS High pressure pump Type: Speck P30 Number of cylinders: Number of valves: Maximum capacity: See type plate Mass: 14.2 kg Maximum water temperature: 60 °C Oil type: GX 80W90 (P/N 71002000090) Volume: 0.7 l Type: Speck P41 Number of cylinders: Number of valves: Maximum capacity: see type plate...
  • Page 128 ATTACHMENTS Annex 5 Contact details Rioned Customer Service Centaurusweg 45 5015 TC Tilburg P.O. Box 5070 NL-5004 EB Tilburg Tel. no.: +31 13-5479100 Email: info@rioned.com Internet: www.rioned.com AGENTS South Netherlands Clément Thobie Mobile +31 6-46062830 West Netherlands Ronald Groenewege Mobile +31 6-51145821...

Table of Contents
