- Page 1 INSTALLATION GUIDE LED Bay Light with Emergency LED Driver Delta T LLC dba Big Ass Fans...
- Page 2 READ AND SAVE THESE INSTRUCTIONS CAUTION: Risk of electric shock. Disconnect power before servicing. Driver has more than one power source. Disconnect both sources by turning off the AC branch circuit and disconnecting the unit driver connector. CAUTION: Install luminaire suspension cables correctly. Cables must be taut and secure. WARNING: This luminiare and emergency LED driver have not been evaluated to NFPA 101 (Life Safety Code) or ISO 30061:2007 (Emergency Lighting).
- Page 3 CABLE MOUNT A1. Attach the grippers to the tops of the V-hooks. A2. Insert the V-hooks into the holes on top of the fixture. A3. Secure the cables to the mounting structure and insert the ends into the grippers. Tighten the allen set screws on the bottoms of the grippers. Figure A Figure A1 Figure A2...
-
Page 4: Pendant Mount
PENDANT MOUNT B1. Run the facility power wiring through customer-supplied 3/4 NPT conduit. Connect the wiring to the wires coming out of the conduit hub on top of the fixture, and then connect the conduit to the conduit hub. B2. Secure the other end of the conduit to the outlet box and connect the wiring. When finished, complete all Cable Mount steps as shown in Figure A. -
Page 5: Power Wiring
POWER WIRING Fixtures with an emergency LED driver require an unswitched AC power source of 120–277 VAC, 50/60 Hz. Refer to the input voltage rating marked on the fixture, and then wire according to the diagram and table below. Note: The dimming cable is optional. - Page 6 LIGHT MODULE ROTATION (OPTIONAL) 90° or 180° Rotation (Figure C) C1. While supporting the light module, use a 9/64 in. allen wrench to turn the screws on both ends of the fixture counterclockwise until they completely back out of the yellow end caps of the light module. C2.
- Page 7 Figure C Figure C1 Figure C3 Figure C2 Figure D Figure D1 Figure D2 Figure D3 © 2019 DELTA T LLC ALL RIGHTS RESERVED.
- Page 8 CONNECTING THE LED DRIVER CAUTION: To prevent electrical shock, do not mate the unit connector until installation is complete and AC power is applied to the unit. E1. After installation is complete, turn on AC power, and then join the driver unit connector on top of the fixture.
-
Page 9: Maintenance
If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by Big Ass Fans or a Big Ass Fans service agent or a similar qualified person in order to avoid a hazard. For assistance, please contact Customer Service. - Page 10 Removing and replacing the lenses The lenses are designed to be removable for cleaning or replacement. Handle lenses with care. OCCUPANCY SENSOR DEFAULT SETTINGS High Mode......10 V Setpoint ......Disabled Low Mode ......Off Ramp Up ......Disabled Time Delay ......10 min Ramp Down ......
- Page 11 CONTACT US United States Canada 2348 Innovation Drive 2180 Winston Park Drive Lexington, KY 40511 Oakville, Ontario L6H 5W1 Canada 877-244-3267 1 844-924-4277 Outside the U.S. (+1 859-233-1271) bigassfans.com bigassfans.com Singapore Australia 18 Tampines Industrial Crescent #06-07 35 French Street Singapore 528 605 Eagle Farm, Brisbane +65 6709 8500...
- Page 12 LTG-INST-264-MUL-01 REV B 07/26/2019 2251 Innovation Drive, Lexington, KY 40511 1 (877) BIG-FANS | WWW.BIGASSFANS.COM...
