- Page 1 V.8.00 MORPHEUS SURgical cHaiR Installation, use and maintenance manual CODE DE1000X...
-
Page 2: Table Of Contents
CONTENTS SECTION PAGE 1- SYMBOLS 1.1- WARNING LABELS 2- GENERAL WARNINGS 2.1 - GENERAL INSPECTION 2.2 - IN-TRANSIT DAMAGES FOR DELIVERIES IN ITALY 2.3 - IN-TRANSIT DAMAGES FOR DELIVERIES OUTSIDE ITALY 2.4 - TRANSPORT AND STORAGE CONDITIONS 3- SAFETY RULES FOR INSTALLATION 3.1 - WORK ENVIRONMENT 3.2 - MAXIMUM LOADS 4- SAFETY PROVISIONS... - Page 3 SECTION PAGE 7.11 - INFUSION STAND 7.12 - BASE WITh FEET 7.13 - BASE WITh WhEELS 7.14 - UNINTERRUPTIBLE POWR SOURCE 8 - CLEANING AND STERILISING 9 - MAINTENANCE 10- TROUBLEShOOTING 10.1- FIRMWARE 11- RELATED ITEMS 12- DISPOSAL 13- WARRANTY 14.1- DECLARATION OF CONFORMITY 15- CERTIFICATE OF WARRANTY 16- ELECTRICAL TEST...
-
Page 4: 1- Symbols
1- SYMBOLS MANUFACTURER SYMBOL. This symbol is placed on the product next to the name and address of the manufacturer. SERIAL NUMBER SYMBOL. This symbol is placed on the product next to the serial number of the device. CE MARKING. This symbol indicates that the product has a CE marking in conformity with the provisions of Directive CEE 93/42 and subsequent amendments (Class I Devices). -
Page 5: Warning Labels
• All the materials contained in this manual are the property of Tecnomed Italia and/ or of the companies represented by it. The images are not binding and are given for explanatory purposes only. -
Page 6: General Inspection
6. Do not return the product to Tecnomed Italy srl before receiving an answer and an authorisation to do so. 7. Send the signed delivery note to Tecnomed Italia srl. 8. Leave the product and the packaging as they are. -
Page 7: In-Transit Damages For Deliveries Outside Italy
2.3 - IN-TRANSIT DAMAGES FOR DELIVERIES OUTSIDE ITALY ATTENTION! Tecnomed Italy srl shall not be liable for damages occurred during transit. Check the goods as soon as you receive them! If the package presents clear signs of damage upon delivery, proceed as follows: 1. -
Page 8: 3- Safety Rules For Installation
DANGER! It is strictly forbidden to make changes to the device. Tecnomed Italia s.r.l. assumes NO responsibility for personal injury and/or direct or indirect property damage resulting from non-compliance with this requirement. -
Page 9: Work Environment
ATTENTION! In order to ensure the functionality and safety of the product and to avoid any wear-related damages, the product requires routine and extraordinary maintenance interventions (specified in this manual) that must be carried out at specified intervals by your Tecnomed Italia s.r.l. dealer. For more information, see the paragraph “Maintenance” on page 37. -
Page 10: 4- Safety Provisions
ATTENTION! Do not expose the device to direct sunlight or to sources of UV light. ATTENTION! Disconnect the pneumatic, hydraulic and electrical power supply at the end of the day (if present). Tecnomed Italia s.r.l. shall not cover damages caused by failure to comply with the indications above. -
Page 11: Safety Requirements
DANGER! The patient’s arms and the feet should rest on the padding of the surgical chair. DANGER! It is strictly forbidden to make changes to the device. Tecnomed Italia s.r.l. assumes NO responsibility for personal injury and/or direct or indirect property damage resulting from non-compliance with this requirement. -
Page 12: 5- Product Description
5.2 - STANDARDS/CERTIFICATIONS Medical device The MORPHEUS surgical chair is fitted with CE marking. The Morpheus device is classified as class IIa medical device based on rule 1 of annex IX of Directive 93/42/CEE. Protection class: Class I (EN 60601-1) -
Page 13: Technical Specifications
On the side of the power button 250V on control unit The scope of supply includes two spare fuses. Packaging dimensions: • PARCEL 1 TECNOMED ITALIA- Box with cart Dimensions 1200 x 800 x 1300 mm (width x depth x height). Weight 180 kg (approx). -
Page 14: Dimensions
5.3.1 - DIMENSIONS... -
Page 15: Identification Plates
5.4 - IDENTIFICATION PLATES Data on the plate • Name of the manufacturer. • Name of the device. • Product code. • Serial number. • Power. • Voltage. • Weight. Guide to reading the serial number 1308001 Year of manufacture Progressive number Week of production... -
Page 16: Product Profile
5.5 - PRODUCT PROFILE A. Thigh rests. K. Joystick 2. B. Blood sampling armrest. L. Support feet or wheels for surgical chair movement. C. Infusion stand. M. Stability knob (only for the optional D. headrest. version with wheels). E. headrest adjustment knob. N. -
Page 17: Configuration
5.6 - CONFIGURATION Morpheus Code Code Item Description DE1000X 4 motors, trendelenburg functions, manual movements Functions DE1000X. 10 Additional position reset memory 2 joysticks for surgical chair movement Joystick (4 motors) Console hand controller with 10 functions Standard padding Padding... -
Page 18: 6- Installation
DANGER! To avoid the risk of electric shock, this device must be connected to an earthed electrical system. DANGER! Tecnomed Italia s.r.l. declines any liability, expressed or implied, and cannot be held liable for personal injury and/or direct or indirect property damage deriving from... - Page 19 Positioning examples for standard configuration...
-
Page 21: Assembly Setup, Full Configuration At The Centre Of The Room
6.1.2 - ASSEMBLY SETUP, FULL CONFIGURATION AT THE CENTRE OF THE ROOM For technical data, see p. 13 Surface connection Legend 1. Power supply line 220 VAC 3x1.5 mm 2. Suction system enabling signal 2x1 mm 3. Media/communication VGA-USB-ethernet 4. Water connection, 3/8” female. 5. - Page 22 Full configuration setup at the centre of the practice * The control unit in the figure belongs to Maycart and Aspirol units. Positioning examples for full configuration at the centre of the room...
-
Page 23: Installation
6.2- INSTALLATION ATTENTION! For wood and concrete floors you need to use special fasteners. These are not included in the scope of supply. The technician is responsible for the correct fixing of the equipment using appropriate fasteners. ATTENTION! Minimum floor sealing 300Kg/m2. - Page 26 *For the electrical cabling see the following: - page 18 for the fitting of standard configuration - page 22 for the fitting of full configuration at the centre of the room...
-
Page 27: 7- Instructions For Use
“Cleaning and sterilising”, on page 46. DANGER! The maximum total load on the Morpheus should not exceed 200 kg. The product may be equipped with additional components, which are described in this manual. -
Page 28: Standard Hand Controller
7.1 - STANDARD HAND CONTROLLER A. Chair on/off light indicator. B. Backrest up. C. Backrest down. D. Leg rest up. E. Leg rest down. F. Quick sitting position (manual). G. Quick lying position (manual). h. Chair up. Chair down. J. Trendelenburg 30°. K. -
Page 29: Chair Movement Control With Joystick
7.2 - CHAIR MOVEMENT CONTROL WITH JOYSTICK Right joystick A. Push the joystick up to raise the seat. A. Push the joystick down to lower the seat. C. Move the joystick to the right to raise the backrest. D. Move the joystick to the left to lower the backrest. Left joystick A. -
Page 30: Seat Rotation
7.3 - SEAT ROTATION Seat rotation facilitates patient sitting positioning. Use the knob placed on the base of the chair to en- able chair rotation. 1. Turn the knob “U” counterclockwise to unlock the chair rotation mechanism. 2. Rotate the chair manually to help the patient sit on/get up off the chair. -
Page 31: Leg Rest
7.6 - LEG REST The length of the leg rest can be adjusted by about 10 1. Turn the knob “P” counterclockwise to unlock the mechanism. 2. Adjust the leg rest to the desired length. 3. Turn the knob “R” clockwise to lock the mecha- nism. -
Page 32: Blood Sampling Armrests
The guides allow proper positioning of the optional accessories, giving you the possibility to slide them to the right or to the left. 1. Rotate the lever “S” counterclockwise to unlock the mechanism. 2. Adjust the position of the optional accessory. 3. -
Page 33: Thigh Rests
The band that comes with the armrest blocks the arm of the patient during the blood sampling or any operation. 7.10 - THIGH RESTS CAUTION! The maximum allowed load on the thigh rests is 30 Kg. Do not exceed this value To adjust the height of the thigh rests, proceed as follows. -
Page 34: Infusion Stand
7.11 - INFUSION STAND The infusion stand can be installed on the left or on the right guide rail, based on your needs. ATTENTION! The maximum allowed load on the infusion stand is 8 Kg. Do not exceed this value To adjust the height of the infusion stand, proceed as follows. -
Page 35: Uninterruptible Powr Source
Besides the wheel brake, the chair also comes with a stability device. To stabilise the chair, turn the knob clockwise until you feel some resistance. Per bloccare il movimento della poltrona spostare con un piede la leva delle ruote verso il basso (STOP). -
Page 36: Cleaning And Sterilising
8 - CLEANING AND STERILISING DANGER! Cut off the power supply to the equipment before carrying out any main- tenance operation, by pressing the green ON/OFF light button placed on the base of the surgical chair. ATTENTION! General information (in accordance with Standard DIN EN ISO 17664) The product and all the instruments must be cleaned and disinfected before use. -
Page 37: Maintenance
2 years, to identify any electrical faults (such as damaged cable insulations). These checks are to be carried out by an authorised Tecnomed Italia s.r.l. technician. ATTENTION! The staff of the practice is responsible for making sure that the product is serviced in due time. -
Page 38: 10- Troubleshooting
2- The power swith is damaged. one supplied (REF.1). not turn on. 3- 3.15A phase fuse blown. 3- Contact an authorised Tecnomed Italia technician. 1- Turn the device off and on again. The controller 1- Button stuck. 2- Press all the keys on the... -
Page 39: Firmware
10.1- FIRMWARE 10.1.1 How to switch the chair on PRESS ThE ON/OFF SWITCh ON ThE ChAIR ThE 24 V TRANSFORMER IS ThE GREEN POWER INDICATOR LIGhTS POWERED ON CONTROL CARD IS POWERED ON... - Page 40 10.1.2 How to move the seat down PUSh ThE ChAIR’S JOYSTICK PRESS ThE ChAIR DOWN BUTTON DOWN RELEASE ThE BUTTON OR JOYSTICK TO hALT ChAIR hOLD ThE BUTTON OR JOYSTICK DESCENT IMMEDIATELY TO MOVE ThE ChAIR INTO ITS FULLY DOWN POSITION...
- Page 41 10.1.3 How to move the seat up PUSh ThE ChAIR’S JOYSTICK UP PRESS ThE ChAIR UP BUTTON RELEASE ThE BUTTON OR JOYSTICK TO hALT ChAIR ASCENT hOLD ThE BUTTON OR JOYSTICK IMMEDIATELY TO MOVE ThE ChAIR INTO ITS FULLY UP POSITION.
- Page 42 10.1.4 How to move the backrest down PRESS ThE BACKREST DOWN PUSh ThE ChAIR’S JOYSTICK TO BUTTON ThE LEFT RELEASE ThE BUTTON OR JOYSTICK TO hALT BACKREST hOLD ThE BUTTON OR JOYSTICK DESCENT IMMEDIATELY TO MOVE ThE BACKREST INTO ITS FULLY DOWN POSITION.
-
Page 43: 11- Related Items
11- RELATED ITEMS To find all items related to this product, visit: www.dentalastec.it 12- DISPOSAL This equipment complies with the European Directive 2002/96/CE on waste electrical and electronic equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences to the environment and human health, which could otherwise arise from improper handling of the product at the end of its service life. -
Page 44: 13- Warranty
Disconnect the pneumatic, hydraulic and electrical power supply at the end of the day (if present). Tecnomed Italia srl shall not cover damages caused by failure to comply with the indications above. Not covered by warranty: •... -
Page 45: Declaration Of Conformity
DECLARATION OF CONFORMITY EC DECLARATION OF CONFORMITY 93/42 CEE MODEL: MORPHEUS SURGICAL CHAIR Tecnomed Italy S.r.l. declares, under its sole responsibility, that the Class I medical device described below Model: MORPhEUS Code: ____________________ Progressive number: __________________ to which this statement refers:... -
Page 46: 15- Certificate Of Warranty
Timbro del rivenditore-Dealer’s stamp Cachet d’achat-Sello del revendedor Data d’acquisto-Purchase date Date d’achat-Fecha de compra Tecnomed Italia s.r.l. Via Salvador Allende n.2, 61040 Castelvecchio di Monte Porzio (PU) Italy Phone +39 0721 95 51 25 Fax +39 0721 95 52 29 - www.dentalastec.it... -
Page 47: 16- Electrical Test
16- ELECTRICAL TEST Electrical safety test of earth (ground) and electrical insulation... - Page 48 Tecnomed Italia s.r.l. Via Salvador Allende n.2, 61040 Castelvecchio di Monte Porzio (PU) Italy Phone +39 0721 95 51 25 Fax +39 0721 95 52 29 - www.dentalastec.it...
