- Page 1 Manual Control Unit GFC 32 1400004_EN/05.2017...
-
Page 2: Table Of Contents
ATTENTION: Before use, read the instructions thoroughly to acquire sufficient knowledge of the product. For your convenience, keep this sheet as a quick reference. Subject to change without notice. Note: The GFC 32 unit is to be installed by trained personnel only! SIMATEK A/S www.simatek.com Doc. -
Page 3: Main Features
GFC 32 1. Main features The Simatek GFC 32 has been designed to guarantee the control of diaphragm valves mounted on pulse jet dust collector filters containing filter bags or cartridges. The main features of the Simatek GFC 32 are: Manual selection of Pulse and Pause time. -
Page 4: Installation Guidelines
• A disconnecting switch has to be installed on the power line before the control unit. • Do not attempt to repair the control unit – contact Simatek! • • All wiring has to be carried out by a qualified electrician to prevent any risk of fire and electrical shocks. -
Page 5: Preliminary Checks
4. Preliminary checks Check that the Simatek GFC 32 does not have power (switch on/off [1] on 0 and terminals [4] disconnected). Check that the supply voltage indicated on the yellow label [22] as “IN”, corresponds to the available power supply (Voltage end Frequency). -
Page 6: Settings
6.1 Voltage selection CHECK: That the Simatek GFC 32 does not have power (switch on/off [1] on 0 and terminals [4] disconnected). That the supply voltage indicated on the yellow label [22] as “IN” corresponds to the available supply voltage (Voltage and frequency). - Page 7 Switch on/off [1] on 1. LED WD [18] and LED Remote [16] are on. On the display [7] appears, for a few seconds, the Simatek GFC 32 identification code. Once the code disappears, the display will show the letter E (run) and the number of the valve which is going to be activated.
-
Page 8: Remote Control
Shut down cleaning starts as soon as the Fan is switched off, contact on terminals Fan [36] and Common is closed, and LED Shut down [33] flashes. NOTE: Should you have selected 0 at step 4 of paragraph 6.2, Simatek GFC 32 will stop working as soon as the ⋅... -
Page 9: Short Circuit Alarm Of The Outputs
Short circuit alarm of the outputs The short circuit alarm is automatically activated by the Simatek GFC 32 (LED Alarm [17] is on) in order to signal failure of the solenoid/s. The Simatek GFC 32 will not activate the outputs in alarm, and will therefore exclude the faulty valves from the cleaning cycle. -
Page 10: Troubleshooting
Short circuit on one or more outputs. See paragraph 10. IMPORTANT NOTE: Should the Simatek GFC 32 unit be powered with 24 V DC, make sure inlet supply voltage is not lower than 24 V, and that voltage is proportioned to connected loads. Fuse table... -
Page 11: Factory Settings/Program Menu
Any equipment for removal of the separated dust should run during shut down cleaning. Simatek recommends 2-3 cycles, as the current cycle is regarded as the first shut down cycle. Therefore the first cycle will not necessarily be a full cycle. -
Page 12: Legend
Control Unit GFC 32 Legend On/off switch Push in valves terminals Valve earthing Power supply terminals Jumper for inlet supply voltage selection Jumper for voltage selection to valves [6A] Jumper for voltage selection to valves Display Jumper for frequency selection to valves... -
Page 13: Simatek Gfc 32:20: General Assembly
Control Unit GFC 32 Simatek GFC 32:20: General assembly SIMATEK A/S www.simatek.com Doc. No.: 1400004_DK Hotline: +45 4046 7525 Rev.: - aftersales@simatek.dk Date: 05.2017... -
Page 14: Electric Diagram For Simatek Gfc 32: 20 Valves
Control Unit GFC 32 Electric diagram for Simatek GFC 32: 20 valves SIMATEK A/S www.simatek.com Doc. No.: 1400004_EN Hotline: +45 4046 7525 Rev.: - aftersales@simatek.dk Date: 05.2017... -
Page 15: Declaration Of Conformity
Control Unit GFC 32 Declaration of Conformity SIMATEK A/S www.simatek.com Doc. No.: 1400004_DK Hotline: +45 4046 7525 Rev.: - aftersales@simatek.dk Date: 05.2017...
