Summary of Contents for Grand Design Solitude 2017

Page 3 RV lifestyle as a family friendly form of leisure, recreation and fun. It is the intent of the Grand Design RV Team and our Dealer Partners to do our absolute best to assure that you enjoy a positive ownership experience and capitalize on all the exciting opportunities this “Grand”...
Page 4 This page is intentionally blank.
Page 5: Table Of Contents
......Service & Warranty ..Grand Design RV One Year Limited Base Warranty . . . Grand Design RV Three Year Limited Structural Warranty .
Page 6 This page is intentionally blank.
Page 7: Introduction
If you have any questions, concerns, or require assistance regarding any aspect of your RV, please contact your dealer or Grand Design RV. Contact Information: www.granddesignrv.com Website customerservice@granddesignrv.com...
Page 8 RV. Manufacturing Certification Grand Design RV recreation vehicles are constructed to the thorough safety and construction standards established by the Recreational Vehicle Industry Association (RVIA). Frequent and random audits are conducted by RVIA and Transport Canada to confirm compliance to U.S.
Page 9 RV's box. It is also listed on the Federal Certification Label. A serial number. breakdown of a typical Grand Design RV VIN is shown in the For the example shown, the example below: serial number is J1100001.
Page 10 Introduction Safety Precautions Nothing is more important than the personal safety of you, your Various safety family and others. Safety encompasses several areas relat- and information labels are attached ed to the RV experience. This includes driving/towing safety, to surfaces both occupant safety, operational safety, environmental safety, and inside and outside your RV.
Page 11 Additional Terminology Used [Customer Supplied] This denotes aftermarket items not installed or included by Grand Design RV. Items noted as “customer supplied” are not covered by the Limited Base and Structural Warranties. The inclusion of items noted as “cus- tomer supplied”...
Page 12: Reporting Safety Defects
If they determine that a safety defect exists in other vehicles, a recall and remedy campaign may be ordered. The NHTSA does not become involved in individual cases between you, your dealer, or Grand Design RV. To contact the NHTSA, www.safercar.gov...
Page 13: Service & Warranty
3. Review with you, and explain the provisions of the Limited Base Warranty and Limited Structural Warranty. 4. Send your completed Warranty Registration and New Vehicle PDI Check List to Grand Design RV. This form is required within 30 days of your delivery date to activate your warranty coverage.
Page 14 Therefore, we recommend warranty and maintenance or not returning requested services be performed by your Grand Design RV dealer. original parts may result in loss of reimbursement and/ or loss of warranty. As with your other personal belongings, it is important to protect yourself and others with insurance coverage.
Page 15 • If a problem re-occurs after leaving the dealership, within a specified time limit. contact the dealer’s service manager and Grand Design Please familiarize yourself RV Customer Support, to quickly resolve the issue. with the RV dealer or repair...
Page 16 Call the RV repair facility to discuss your situation and make an appointment. Ask how their billing will be handled. They may choose to bill Grand Design RV directly; otherwise, you are expected to pay them. b. Have the RV repair facility inspect your RV. Either they...
Page 17 Grand Design RV dealers or service centers. Grand Design RV does not sell parts retail direct or to non-authorized deal- ers. If an original part is no longer available, Grand Design RV or your dealer will try to provide an appropriate substitute.
Page 18 Service & Warranty Updating Your Contact Information Federal law requires that we keep a record of Grand Design RV owners. Please help us keep your contact information up to date, so that we can promptly contact you in the event of a recall or customer notification letter.
Page 19: Grand Design Rv One Year Limited Base Warranty
SUMMARY What does this Warranty cover? Grand Design RV, LLC (“Warrantor”) provides this One (1) Year (“Warranty Period”) Limited Base Warranty [which begins to run from the earlier of (i) the date of purchase by the original retail consumer purchaser or (ii) when the recreational vehicle is put into service] against certain defects in materials...
Page 20 Service & Warranty 3. The defective material or workmanship for which the warranty work and/or part is sought must be to the RECREATIONAL VEHICLE itself only. 4. The other terms and conditions of this Limited Warranty must be satisfied. What types of things are excluded from the Warranty? This Warranty does not cover: a.
Page 21 Service & Warranty r. Damage caused by unregulated water pressure, tank over-fill or plumbing system modifications resulting in flooding of the vehicle; s. Damage caused by unprotected electrical hook-ups (home or campground), power surges, lightning, circuit overload or electrical system modifications; t.
Page 22 Service & Warranty What are purchaser’s obligations? The purchaser shall give notice to the Warrantor’s agent or dealer within Twenty (20) days after it is or should have been discovered, and any action to enforce it shall be commenced not more than three (3) months thereafter;...
Page 23 Service & Warranty What do I do to activate warranties of other manufacturers of component parts and goods? COMPONENT WARRANTIES As stated above, some components, accessories or equipment are not covered by this Base Limited War- ranty. Examples include tires, batteries, optional generators, and some appliance & electronic entertain- ment equipment.
Page 24 Service & Warranty DISCLAIMER OF EXPRESSED AND IMPLIED WARRANTIES THE WARRANTOR EXPRESSLY DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABI- LITY AND FITNESS FOR A PARTICULAR PURPOSE AND ANY OTHER IMPLIED WARRANTIES. THERE IS NO EXPRESS OR IMPLIED WARRANTY MADE BY WARRANTOR BEYOND THAT CONTAINED IN THE LIMITED WARRANTY ABOVE.
Page 25: Grand Design Rv Three Year Limited Structural Warranty
SUMMARY What does this Warranty cover? Grand Design RV, LLC (“Warrantor”) provides this Three (3) Year (“Warranty Period”) Limited Struc- tural Warranty [which begins to run from the earlier of (i) the date of purchase by the original retail consumer purchaser or (ii) when the recreational vehicle is put into service] against certain defects...
Page 26 Service & Warranty 2. The person seeking the replacement of the defective part or labor must be the original retail con- sumer purchaser. An assignment of the recreational vehicle to another person voids this Limited Warranty. 3. The defective material or workmanship for which the warranty work and/or part is sought must be to the STRUCTURAL COMPONENTS only.
Page 27 Service & Warranty t. Consequential/incidental expenses (damages) such as service calls, transportation, lodging, food, fuel, etc. NOTE: Some states do not allow the exclusion of incidental or consequential damages, so this exclusion may not apply to you; u. Fading, yellowing or aging of exterior materials due to UV or sunlight or weather exposure; v.
Page 28 Service & Warranty Warrantor will remedy defects in materials and workmanship covered under this Limited Warranty under normal use and service caused by Warrantor in the STRUCTURAL COMPONENTS ONLY of the recre- ational vehicle. Warranty performance can only be obtained at Warrantor’s authorized dealers and service representatives.
Page 29 Service & Warranty DISCLAIMER OF CONSEQUENTIAL, PUNITIVE AND INCIDENTAL DAMAGES What other conditions or limitations apply to this Warranty? The original retail purchaser of the recreational vehicle and any person to whom the recreational vehicle is transferred or given or conveyed, and any person who is an intended or unintended user or beneficiary of this Limited Warranty, shall not be entitled to recover from Warrantor any consequential, punitive or incidental damages resulting from any defect in the recreational vehicle, or loss of use, time or reve- nues.
Page 30 Service & Warranty DESIGN CHANGES Warrantor reserves the right to change the design of its STRUCTURAL COMPONENTS from time to time without notice and without obligation to make corresponding changes in its products previously manufactured. ATTORNEYS FEES Any warranty claim asserted or brought in violation of this Limited Warranty, or any claim brought against WARRANTOR, directly or indirectly, under which the Purchaser or any other person or entity seeks to broaden the terms of the Limited Warranty or under which the Purchaser or any other person fails to successfully prevail on any issue or matter of any type or nature, shall entitle Warrantor to recover its...
Page 31: Component Supplier Contact Information
Service & Warranty Component Supplier Contact Information All components listed are correct at the time of printing. Grand Design RV may change com- ponents at their discretion. Please contact GDRV Customer Support with any questions. Phone Component Brand Supplier Website...
Page 32: Component Manufacturer Warranty Information
Service & Warranty Component Manufacturer Warranty Information Each manufacturer provides their own warranty for the components on your Solitude FW. This warranty information is current at the time printing, but is subject to change at any time per the manufacturer. Details can be found on the company websites listed or by contacting them directly.
Page 33 Service & Warranty Component Manufacturer Warranty Information Continued Component Brand Manufacturer Warranty Microwave High Pointe Limited one year warranty. Microwave Furrion One year limited warranty. American Technology Monitor Panel Limited one year warranty from date of purchase. Components, Inc. Refrigerator Norcold One year limited warranty.
Page 34 This page is intentionally blank.
Page 35: Occupant Safety
Occupant Safety Occupant Safety Your Solitude Fifth Wheel is designed with comfort and safety WARNING as a priority. This RV meets or exceeds the safety standards and applicable codes in effect at the time it is built. All required safety items are carefully installed to protect you and the During severe weather conditions, move indoors occupants of your RV.
Page 36 Occupant Safety Pet Safety Emergency shelters could refuse to admit pets due to health or space reasons. Prepare an emergency plan for pets that includes (at least) a 3-day supply of dry food and fresh water. The survival of a beloved pet often depends on the careful plans their owner has made in advance.
Page 37 • In a fire emergency, execute your Family Safety Plan. repair your RV. Failure to notify Grand Design RV may • Make sure everyone knows to Stop, Drop & Roll result in loss of coverage.
Page 38 Occupant Safety Fire Extinguisher Safe escape is the most important part of a fire response plan. Fire can spread very fast. Your number one priority MUST be to get all occupants out safely. A dry chemical, Class B /Class C type fire extinguisher is located near the entry door of your RV.
Page 39 Occupant Safety Disposal Please check the local laws BEFORE disposing of your used (non-refillable) dry chemical fire extinguisher. Contact your local fire, sanitation or environmental protection department for rules on disposal. Emergency Egress Window The Emergency Egress Window (or exit window) is your An emergency secondary exit, if the RV's entrance door becomes blocked egress window...
Page 40 Occupant Safety Smoke Alarm The smoke alarm is located on the ceiling in the main living area of your RV. It is intended to help reduce injury or loss of life in a fire. Proper use can give you time to escape, but they are not foolproof.
Page 41 Occupant Safety Battery The smoke alarm will not function if the battery is missing, disconnected, dead, the wrong type of battery is used or the battery is installed incorrectly. When the 9-volt battery becomes weak, the smoke alarm will “chirp” (the low bat- tery warning).
Page 42 Occupant Safety Combination Carbon Monoxide / Propane Alarm The combination alarm contains two independent, self-cleaning WARNING electronic sensors designed to sense the presence of carbon monoxide (CO) and propane gas. When the LED on the front This combination alarm glows green, the alarm is active. will not work without power;...
Page 43 Occupant Safety • The Propane Gas sensor has an approximately one (1) minute warm-up period. After 1 minute the alarm can detect explosive gas. During the warm-up period the unit cannot go into a propane gas alarm. • Do not attempt to fix the combination alarm yourself.
Page 44 Occupant Safety Combination Carbon Monoxide / Propane Alarm, Continued Operation Audible Signal Visual Signal Normal None Steady Green 4 "Beeps", CO Alarm Steady Red 5 Seconds Off Propane Alarm Constant Flashing Red Alarm "Beep" Every Alternating Red/Green Malfunction 30 Seconds "Beep"...
Page 45 Occupant Safety How to take care of your alarm The combination CO/propane gas alarm is designed to be This label is found as maintenance free as possible. To keep your alarm in good loose in your working order: Owner Information Package.
Page 46 Occupant Safety Combination Carbon Monoxide / Propane Alarm, Continued Procedures to take during a CO alarm (USA) If signal sounds (4 beeps and flashing or solid red light): 1. Press the Test/Mute button. 2. Immediately move to fresh air either outdoors or by an open door or window.
Page 47 Occupant Safety Carbon Monoxide Alarm Your Solitude Fifth Wheel is also equipped with an individual carbon monoxide alarm. The CO alarm will sound if Carbon Monoxide (CO) in the air reaches dangerous levels. If you hear this alarm, evacuate the RV immediately and stay outside in fresh air until the CO alarm ceases.
Page 48 Occupant Safety Indoor Air Quality To maintain indoor air quality: • Allow your RV proper ventilation. • Keep the interior clean. • Avoid harmful air pollutants. Common air pollution sources include molds, pollen, pet dander, cigarette smoke, household cleaners and carbon monoxide from burning propane, charcoal or other fuels.
Page 49 Occupant Safety EPA Recommendations The Environmental Protection Agency (EPA) recommends three basic strategies to improve indoor air quality: 1. Remove sources. The most effective ways to improve indoor air quality are to eliminate sources of pollution or reduce their emissions. This strategy can have an impact on the following pollutants: ◦...
Page 50 (MDF), and plywood which are commonly used throughout the Recreational Vehicle Industry. As mandated by the RV Industry, Grand Design RV recreation vehicles contain composite wood products (hardwood plywood, particle board, and MDF) that comply with the California Air Re- source Board (CARB) formaldehyde emission standards under California Code of Regulations §...
Page 51 Occupant Safety Effects of Prolonged Occupancy Your RV is designed primarily for recreational and extended Your RV is not stay use. Be prepared to deal with condensation and the humid designed, nor conditions that may be encountered, if you plan to occupy your intended, for use as permanent RV for an extended period.
Page 52 • To avoid damage to parts, CHECK the outside of the RV for ice BEFORE operating the: slide outs, compartment doors, locks, windows, vents etc. If you have further questions, please contact your dealer or Grand Design RV Customer Service.
Page 53 Occupant Safety Where There Is Moisture, There May Be Mold Molds are microscopic organisms that can live in virtually any indoor or outdoor environment. Mold growth requires a source of moisture (ie., high humidity, wet/damp materials, standing water) and a temperature between 40° and 100° Fahrenheit.
Page 54 Grand Design RV has no control and for which Grand Design RV assumes no respon- sibility. Grand Design RV shall have no liability for any loss or injury caused, in whole or in part, by its actions, omissions or negligence, or for any contingencies beyond its control in pro- curing, compiling or delivering any information.
Page 55 External or third party links may be provided for the convenience of the users of that website. Grand Design RV is not responsible for the availability or content of these external or third party sites...
Page 56 Occupant Safety Additional Safety Precautions, Continued Passenger safety • While your RV is in motion, DO NOT allow anyone to ride inside as a passenger. • In several states, this practice is against the law. Loading & Weight Distribution • Distribute cargo weight evenly throughout your vehicle. •...
Page 57: Pre-Travel Information
RV with one that you already own. Discuss the owner of a Grand Design RV recreational vehicle as a GVWR, size and type of RV that you will be towing. If you plan...
Page 58 • Ratings are maximum limits, NEVER to be exceeded. a warranty, may complicate These limits are established by Grand Design RV and our an insurance claim, and in component manufacturers in the design of the vehicle.
Page 59 Vehicle weight labels are affixed to your RV to help you make an informed decision before your purchase. Do not remove these labels. If the labels are missing, contact your dealer or Grand Design RV Customer Service for replacements. Federal Certification Label This label specifies maximum capacities for GVWR, GAWR and tires.
Page 60 This flexibility allows you to make choices that fit your travel and camping needs. If you have further questions, please contact your dealer or Grand Design RV Customer Service.
Page 61 Pre-Travel Information Loading Your RV WARNING For traveling safety, distribute cargo side-to-side so the Only store items in the weight on each tire does not exceed one-half of the GAWR areas designated for for either axle. storage. Do not store anything in the areas reserved for the furnace, It is important to secure the tie down straps (if so equipped)
Page 62 Pre-Travel Information Weighing Your Tow Vehicle & RV, Continued 2. Hitch the RV to your tow vehicle. Weigh the RV and the tow vehicle to determine the Gross Combined Weight (GCW). Make sure that this rating is less than or equal to the GCWR as specified by the manufacturer of your tow vehicle.
Page 63 Pre-Travel Information Tire Safety Information This portion of the Owner’s Manual contains tire safety information as required by 49 CFR 575.6(4) and is based in part on the National Highway Traffic Safety Administration’s (NHTSA) brochure titled Tire Safety, Everything Rides On It. It can be obtained from NHTSA as a free download at http://www.nhtsa.gov/cars/rules/TireSafety/ridesonit/ tires_index.html.
Page 64 Pre-Travel Information Recommended Tire Pressure & Load Limits The major causes of tire failure are under-inflated tires and overloaded vehicles. Tire information placards and vehicle certification labels give important information on tires and load limits, including: • Recommended Tire Size •...
Page 65 Pre-Travel Information Checking Tire Pressure It is important to check your vehicle’s tire pressure at least WARNING once a month for the following reasons: Always check tire pressure • Most tires may naturally lose air over time. when tires are cold. Cold tire inflation pressure is •...
Page 66 Pre-Travel Information How Overloading Affects Your RV and Tires The results of overloading can have serious consequences DANGER for passenger safety. Too much weight on your vehicle’s sus- pension system can cause spring, shock absorber, or brake If the total weight of the failure, handling or steering problems, irregular tire wear, tire RV exceeds the GVWR, failure or other damage.
Page 67 Pre-Travel Information Tire Safety Tips Preventing tire damage • DO NOT run over curbs or foreign objects in the roadway or when parking. • Slow way down if you can not avoid a pothole or other object in the road. Tire safety checklist 1.
Page 68 Tires are warranted by the tire manufacturer, not by Grand Design RV. If you need tire warranty assistance, please contact your dealer or refer to the tire warranty pamphlets provided with your RV.
Page 69 Pre-Travel Information Tire Tread The tire tread provides the gripping action and traction that prevent your vehicle from slipping or sliding, especially when the road is wet or icy. In general, tires are not safe and should be replaced when the tread is worn down to 1/16 of an inch. Tread wear bars are the raised sections built into the bottom of a tire's tread grooves that show how much tread is remain- ing.
Page 70 Pre-Travel Information Tire Ply Composition & Materials A tire is built from multiple layers of rubber-coated fabric. Each layer is called a ply. In general, the higher the number of plies in a tire, the more weight it can support. Tire manufacturers must report all materials used in the composition of the tire, ie., steel, nylon, polyester, etc.
Page 71 Pre-Travel Information Wheel Nut Torque Torque is the amount of rotating force applied to a fastener, WARNING such as a lug nut. The axle and wheel assemblies of your RV are designed differently than those on your car. The Always torque the wheel overall weight, size and center of gravity of the RV subject the nuts to the specifications wheels to extreme pressures.
Page 72 Pre-Travel Information Roadside Emergency A roadside emergency can happen at any time. ALWAYS carry an emergency kit with three red warning signs (or indicators) to display if necessary. If you must make an emergency roadside stop: • Pull off the road as far as possible. •...
Page 73: Towing & Leveling
Towing & Leveling Towing & Leveling To improve safe driving and help protect against injury, WARNING please follow these recommendations: Do not leave children or • Keep the RV and tow vehicle tires properly inflated, and pets unsupervised in or Replace the tires BEFORE they are excessively worn.
Page 74 Towing & Leveling RV Driving Schools & Seminars If you have any concerns about driving while towing a RV, consult an expert for specific RV driver education. There are private RV schools and some RV owner's organizations that offer driving seminars. The schedules and locations of the various RV driver education seminars and schools can be researched through RV-related publications and websites.
Page 75 Towing & Leveling Battery Isolator (Customer Supplied) You may want to install a battery isolator on your tow vehicle. A battery isolator is a device that: • Receives current from the tow vehicle alternator to independently charge both the RV auxiliary battery and the tow vehicle battery.
Page 76 Towing & Leveling Breakaway Switch The breakaway switch is located by the FW pin box. It is a crucial WARNING part of the RV braking system. If the RV becomes detached from the tow vehicle, the lanyard pulls the pin from the breakaway Be certain there is enough switch, which automatically activates the RV brakes..
Page 77 Towing & Leveling Fifth Wheel Hitching Procedure The FW hitching procedure (below) becomes easier with WARNING practice. To safely hook up your FW to your tow vehicle, use the following steps: NEVER allow anyone to go under the RV while it is 1.
Page 78 Towing & Leveling Towing the RV You will find that your RV will travel safely and comfortably at WARNING most posted trailer highway speed limits. However, it will take longer than a passenger automobile to reach that speed. Keep Towing items behind RV this in mind when overtaking and passing another vehicle.
Page 79 Towing & Leveling Passenger safety • While your RV is in motion, DO NOT allow anyone to ride inside as a passenger. • In several states, this practice is against the law. Weight and Clearance Limits In order to obey all posted weight and clearance limits, you MUST always know the weight and height of your RV/tow vehicle combination.
Page 80 Towing & Leveling Towing the RV, Continued Parking After the RV is in the desired location, set the tow vehicle parking If the parking spot brake and place the transmission in park. Turn OFF the ignition is on asphalt on a switch.
Page 81 This page is intentionally blank.
Page 82 Towing & Leveling Leveling the RV With the unit parked, the next step is to level your RV. A small WARNING level should be used in the refrigerator, and on the counter top or floor to confirm the RV is level. DO NOT USE THE Leveling your RV is important FW LANDING LEGS...
Page 83 Towing & Leveling Instruction Labels To operate the hydraulic leveling system, read and follow NOTICE the instructions printed on the component manufacturer’s instruction labels below. For optimum performance, the Level-Up hydraulic Do not remove these labels from the inside of the system requires a fully forward, off-door side (ODS) compartment door: charged RV auxiliary...
Page 84 Towing & Leveling Overriding the Hydraulic Landing Legs / Leveling Legs / Slides There are two options when overriding the hydraulic leveling legs. The instructions for both options reference the override valves labeled in the sidebar photos. • Rotating a hydraulic system override valve clockwise will open it.
Page 85 Towing & Leveling 5. When the leveling legs are in the desired position, close valves B and C by inserting a 5/32” Allen wrench into the manual override and rotating it 1.5 to 2 turns counter-clockwise until snug. DO NOT over-tighten. 6.
Page 86 Towing & Leveling Lippert Ground Control 3.0 System (Equipped on the S-Class) Prior to operation 1. The trailer is parked on a reasonably level surface. 2. Be sure all persons, pets, and property are clear of the trailer while the leveling system is in operation. 3.
Page 87 Towing & Leveling Basic jack operation Landing gear (or front jacks) can be operated any time the system is ON. By pushing the FRONT button (Fig. 1G),both front jacks can be extended. By pushing either the FRONT and LEFT (Fig. 1H) or FRONT and RIGHT (Fig.1I) buttons, the individual front jacks can be extended.
Page 88 Towing & Leveling Lippert Ground Control 3.0 System, Continued (Equipped on the S-Class) Unhitching from a Tow Vehicle NOTE: Prior to unhitching from the tow vehicle, ensure the trailer is parked on a level surface and be sure to chock the tires of the trailer.
Page 89 Towing & Leveling Auto Level 1. After unhitching from tow vehicle and parking the vehicle at a safe distance away from the trailer, press the “ON/ OFF” button and then press “AUTO LEVEL” (Fig. 1F). NOTE: Once the automatic leveling cycle has been started, it is important that there is no movement in the trailer until the trailer has completed the leveling process.
Page 90 Towing & Leveling Lippert Ground Control 3.0 System, Continued (Equipped on the S-Class) Note: If the AUTO LEVEL sequence does not perform as de- scribed, place the system in manual mode and test that the jacks operate correctly by pushing their coordinating buttons on the touch pad;...
Page 91: Electrical Systems
Electrical Systems Electrical Systems The electrical system on your Solitude FW. is comprised of two independent electrical systems. One system is 12-volt DC power, and the other is 120-volt 60hz AC power. All installations meet or exceed industry standards applicable on the date of manufacture.
Page 92 Electrical Systems 50-Amp Power Cord, Continued Connecting the power cord WARNING 1. Turn OFF the load center main 120-volt circuit breaker. • Do not hook up the power 2. Carefully extend the entire length of the power cord from cord to any receptacle until the electric cable hatch to the external power source.
Page 93 Electrical Systems Power to your 50 amp, 120-volt 60hz AC electrical system can WARNING be supplied by the 120-volt 60hz utilities found at RV camp- grounds or by a generator. A campground's electrical service For 50 amp systems only: may occasionally experience high or low voltage. Make certain the external power source you connect •...
Page 94 Electrical Systems Converter The Power Converter changes 120-volt AC power to usable 12-volt DC power when the shore power cord is connected to an external power source. A thermal breaker is built-in to the converter to protect it from overheating. Overheating is usually caused by the converter operating above its maximum power output for an extended time period, or too little air flow.
Page 95 Electrical Systems Test all GFCI receptacles monthly • Push in the TEST button. This should pop out the RESET button, indicating the GFCI receptacle has been tripped. This will interrupt 120-volt power. • Push in the RESET button. This should restore 120-volt power.
Page 96 Electrical Systems 12-Volt Fuse Panel The label inside the 12-volt fuse panel indicates the fuse sizes, positions and components powered. Annually, at the beginning of the camping season, inspect each 12-volt fuse and replace as needed. Replacing a fuse Before replacing a fuse, always turn off the electrical WARNING component(s) protected by it.
Page 97 Electrical Systems For accuracy, test the auxiliary battery voltage using a volt- ohm meter. A fully charged auxiliary battery will read 12.7 volts DC and 1.265 specific gravity at 80°F (32°C). The auxiliary battery is considered discharged at 11.8 volts, and dead at 11.65 volts.
Page 98 Electrical Systems Battery Disconnect Switch The Battery Disconnect Switch (see photo) is located in the large, front pass-thru compartment. When the RV is in storage or auxiliary power will not be needed: • Shut OFF the Battery Disconnect Switch, and •...
Page 99 Electrical Systems Approximate Electrical Load Ratings Use the actual amperage of the appliance when possible. (Watts ÷ 120) 120 Volt System Air Conditioner 18 amps Coffee Maker 6-12 amps Converter (Each) 8 amps Curling Iron or Hair Dryer 10-14 amps Blu-Ray/DVD System 3 amps Microwave...
Page 100 Electrical Systems Generator Prep (If So Equipped) Generator prep means that your RV includes the basic wiring needed to install an aftermarket generator (customer supplied). RV generators are built in compliance with specific codes and standards. Your RV is designed to ONLY use generators built specifically for RVs.
Page 101: Plumbing Systems
Plumbing Systems Plumbing Systems There are two separate water systems in your RV, the Fresh Water System and the Waste Water System. • The Fresh Water System consists of the fresh water holding tank, fresh water connections, water pump, water heater, faucets, shower or tub, water purification system (if so equipped) and outside shower assembly (if so equipped).
Page 102 Plumbing Systems Monitor Panel The monitor panel is found on the interior, wall-mounted Command Center. It displays the fill levels of your fresh water, grey water, and black water holding tanks. It also shows the voltage of your auxiliary battery. To make a selection, press and hold one of the labeled buttons on the monitor panel faceplate.
Page 103 Plumbing Systems 12-Volt Water Pump Once activated, the water pump (or on-demand pump) will NOTICE self-prime, and provide water. The water pump continues to run until approximately 45 lbs. of pressure is achieved Be careful not to overfill and shut off. The water pump will automatically restart when the fresh water holding pressure drops.
Page 104 Plumbing Systems Water Heater The water heater is designed to heat water quickly and efficiently. WARNING The water heater manufacturer has preset the sensing limit to maintain the water temperature when the water heater is acti- If you smell propane gas vated.
Page 105 Plumbing Systems Anode Rod Protection WARNING The tank of your water heater is protected by a magnesium or aluminum anode rod. The rod absorbs the corrosive action of Water temperatures over hot water to prolong the tank's life. Through normal use, the 125°F (49°C) can cause anode rod will deteriorate.
Page 106 Plumbing Systems Bathroom Shower Unlike your home, the RV does not contain a water pressure balance valve. When the shower is in use, DO NOT run any other water until shower is finished. Air may need to be bled out of the plumbing lines before a steady stream of water flows.
Page 107 Plumbing Systems Outside Shower A handheld shower assembly with both hot and cold water is available for washing or rinsing outside the RV at the utility center. 1. Be sure the water heater is turned ON and has sufficient time to heat the water. 2.
Page 108 Plumbing Systems Water Control System Your Solitude Fifth Wheel is equipped with a Nautilus P1 Water Control System. To understand the operation of your water control system, please refer to the user instructions included in this manual. See Page 115, Nautilus P1 Manual. Draining and winterizing If the RV is to be stored over the winter months, the water heater must be drained to prevent damage from freezing.
Page 109 Plumbing Systems Sanitizing the Fresh Water System Use the following procedures to sanitize your Fresh Water System (or Potable Water System) when it is new, becomes contaminated, or has not been used for a period of time. • Prepare a chlorine solution using one (1) gallon of water and one-quarter (1/4) cup of household bleach (5% sodium hypochlorite solution).
Page 110 Plumbing Systems Winterizing the Plumbing System Preparing your RV for colder weather or storage is very im- WARNING portant for most states and Canada. Failure to prepare your RV may cause water supply lines and the water heater to freeze. Both automotive antifreeze No commodity or product should be added to the fresh water (ethylene glycol) and...
Page 111 Plumbing Systems Black/Grey Water System The sinks and shower drain into the grey water (waste water) WARNING holding tank. The toilet drains into the black water (sewage) holding tank. Never travel with full black or grey water holding tanks. • ALWAYS empty the grey and black water holding tanks This not only wastes your before traveling to avoid carrying unnecessary weight.
Page 112 Plumbing Systems Toilet Your RV toilet is both efficient and easy to operate. • BEFORE use: FLUSH the toilet several times, releasing enough water to cover the bottom of the holding tank. • ALWAYS maintain four to six inches (10-15 cm) of water in the toilet for better sanitation system performance.
Page 113 Plumbing Systems Drain Pipes With Dry Sealing Valve Your RV may be equipped with a dry sealing valve that pre- NOTICE vents the escape of odors from your waste system and eliminates the need for P-traps. Should the RV drain piping Remove the waterless trap system become clogged and a mechanical cleanout tool is before using mechanical...
Page 114 Plumbing Systems Black/Grey Water Holding Tanks When connected to the sewer drain line at a campground, WARNING keep the black tank drain valve closed until the holding tank is at least ¾ full. This should provide sufficient water to assist Do not add automotive in complete draining of the black water holding tank.
Page 115 Plumbing Systems Black Tank Flusher NOTICE The black tank flusher is designed to rinse the interior of the black (waste) tank. A separate water hookup is located in the When flushing the black docking station. Also See page 128, Nautilus P1 Manual tank, the gate valve must be open or damage may To flush the tank after dumping:...
Page 116 This page is intentionally blank.
Page 117: Nautilus P1 Manual
Nautilus P1 Manual Nautilus P1 Manual...
Page 118 Nautilus P1 Manual           ...
Page 119 Nautilus P1 Manual               ...
Page 120 Nautilus P1 Manual         ...
Page 121 Nautilus P1 Manual                         ...
Page 122 Nautilus P1 Manual                 ...
Page 123 Nautilus P1 Manual                 ...
Page 124 Nautilus P1 Manual                     ...
Page 125 Nautilus P1 Manual               ...
Page 126 Nautilus P1 Manual                          ...
Page 127 Nautilus P1 Manual                   ...
Page 128 Nautilus P1 Manual                               ...
Page 129 Nautilus P1 Manual             ...
Page 130 Nautilus P1 Manual               ...
Page 131 Nautilus P1 Manual                ...
Page 132 This page is intentionally blank.
Page 133: Propane System
Maintenance Although both Grand Design RV and your selling dealer carefully test the propane system for leaks, travel vibrations can loosen fittings. Have the RV's propane system checked at all connections soon after your purchase. System should also be checked when the propane tanks are filled for the first time, and again after 5,000 miles of travel.
Page 134 Propane System Propane Gas Cylinders Propane gas, while under pressure in the cylinder, is compressed WARNING into it's liquid form. As the fuel is released from the cylinder, it changes from liquid to gas, and is used to operate the applianc- Propane cylinders should es.
Page 135 Propane System Max output is 200,000 BTU/hr. It is used to connect propane WARNING cylinders to regulators, hoses and other fittings. It is not for use on gas grills and other low pressure devices. Before entering a propane or fuel service station Servicing or filling make sure all pilot lights are extinguished.
Page 136 Propane System Carbon Monoxide (CO)/Propane Alarm Your RV is equipped with a combination carbon monoxide WARNING (CO)/propane alarm. Please read and follow the component manufacturer instructions supplied in your Owner Information Package. Test Propane Gas Alarm operation after the RV has For detailed information on this alarm, See Pages 40-44, been in storage, before each trip and at least once...
Page 137 Propane System • If you do experience a propane freeze up, close the WARNING main valve and wait at least fifteen (15) minutes before trying again. For more information, refer to the regulator All propane connections manufacturer’s operator manual. should be checked periodically as vibrations •...
Page 138 Propane System Propane System Hoses, Tubes, Pipes & Fittings The hoses, pipes, tubes and fittings used in your propane system When there are are designed to withstand pressures exceeding those of the pro- double cylinders pane system. However, because environment and time can both on your RV, use only one at a time.
Page 139 Propane System Using the Propane System After the RV is completely set up and you are prepared for WARNING camping enjoyment, use the following steps for propane operation: Gas appliances must never be operated while RV is in 1. Close ALL burner valves, controls and pilot light valves. motion.
Page 140 Propane System Calculating Propane Use Your Solitude FW's furnace, refrigerator, water heater and range (if applicable) all may use propane to operate. Use the BTU rating of each appliance to determine how long your pro- pane supply will last. Propane consumption depends on their individual use and the length of time operated.
Page 141: Appliances
Appliances Appliances The following is a brief overview of the factory-installed, RV DANGER appliances and equipment. For detailed operating instructions for each specific component, please refer to the manufactur- IF YOU SMELL er’s owner manuals (found in your Owner Information Pack- PROPANE GAS age) or visit that manufacturer’s website.
Page 142 Appliances Range Hood The range hood has a both a light and fan control switch on the WARNING front panel. The 8” x 8” aluminum mesh grease filter (located on the underside range hood) can be gently hand-washed us- ing mild soap and water. Do not turn the gas range burner controls ON and allow propane gas to...
Page 143 Appliances Cooking with Propane For additional safety instructions, See Pages 131 - 138, WARNING Propane System. If using glass, ceramic, earthenware or other In Case Of A Grease Fire glazed utensils (or cookware) verify that it Grease is flammable. Never allow grease to collect is safe for use on the top burners.
Page 144: Electronics
Electronics Electronics Audio/Visual System Guide The following is a basic overview of the audio/visual (A/V) electronics operation. The information in this section is writ- ten for original factory-installed equipment usage. If there have been modifications or replacements made to your elec- tronics system then these instructions may not apply (please contact the service center or technician who performed the modifications or substitutions if assistance is required).
Page 145 Electronics TV Reception Basics TV broadcasting is a point-to-point communication. Any Many television obstructions between the transmitter and the antenna will stations have changed from VHF degrade the signal, affecting picture quality. to UHF channels. UHF channels operate at • Television stations transmit their broadcast signal higher frequencies;...
Page 146 Electronics TV Roof Antenna To watch local TV stations, turn ON power to both the TV and the TV Roof Antenna. For the best TV reception, your antenna must point toward the nearest signal transmitter. You can find the exact locations of transmitting towers at www.fcc.gov. To Aim the Antenna 1.
Page 147 Heating & Cooling Heating & Cooling This section contains an overview of the RV heating and cool- ing components. It applies only to the original factory-installed equipment. For more information on each specific component, please refer to the manufacturer’s operating instructions, or visit that manufacturer’s website.
Page 148: Heating & Cooling
OEM factory least once a year (more often depending on furnace use). authorized parts are to be used on your furnace. If you have any questions, Contact your dealer or Grand Design Customer Service.
Page 149 Heating & Cooling Fireplace Refer to the OEM manual for operation, service and mainte- nance information. If you have further questions, please contact your dealer. NOTICE Roof Vent The roof vents allow fresh air to circulate through your RV. Do not leave a roof vent open when the RV is stored They may be electric (12-volt DC) and/or manual.
Page 150 Heating & Cooling Patio Awning Keep your awning in good condition to prevent costly repairs. It is very important to keep the awning clean. If weather con- ditions are windy or stormy, close the awning into the travel mode position. Shut the awning in the travel position if you will be away from the RV for an extended period of time.
Page 151 Heating & Cooling...
Page 152: Slideout Systems
Slideout Systems Slideout Systems Slideout rooms are designed to provide you additional living WARNING space during stationary camping. The slideout room and mechanism are a potential BEFORE operating your slideout system: crush hazard. Disconnect the auxiliary battery to ◦ Check that you have sufficient power available. disable power to the ◦...
Page 153 If your slideout system: • Stalls out before reaching end of stroke, or • Does NOT close and seal tightly. Contact your dealer or Grand Design RV Customer Service for trouble shooting and/or repair.
Page 154 Slideout Systems Hydraulic Through Frame Slideout System Both your living area and kitchen slide rooms are powered by NOTICE the hydraulic slide out system. Although the system is designed to be almost maintenance free, actuate the slideouts and jacks For optimum performance, once or twice a month to keep the seals and internal moving the hydraulic slideout parts lubricated.
Page 155 Slideout Systems Check that the breather cap is free of contamination before removing, replacing or installing. In colder temperatures (less that 10°F), the cylinders and jacks may extend and retract slowly due to the fluid’s molecular nature. For cold weather operation, fluid specially formatted for low temperatures may be desirable.
Page 156 Slideout Systems Lippert Electric Slideout System (Equipped on the S-Class) Extending and retracting the slideout room is powered by NOTICE the Lippert Through Frame Electric Slideout System. It is a rack and pinion guide system with a motor driven ball screw Use EXTREME CAUTION if actuator.
Page 157 Slideout Systems Maintenance Although the system is designed to be almost maintenance NOTICE free, actuate the room once or twice a month to keep the seals and internal moving parts lubricated. Check for any For long-term storage, it visible signs or external damage before and after movement is recommended that the of the RV.
Page 158 Slideout Systems Schwintek In-Wall Slideout System If the bedroom Schwintek In-Wall slideout does not extend CAUTION or retract, follow these steps to override the system (it will be easier if you have one or more persons to assist you). During this override procedure, the Schwintek slide room motors are not synchronized.
Page 159 Slideout Systems Manually push the slide room in override 1. Locate the circuit board. 2. Unplug both motors from circuit board. (this releases the motor brake) 3. Push or pull slide room in as desired; ◦ Larger rooms may require several people to push. ◦...
Page 160 Slideout Systems Troubleshooting the Schwintek Slideout System Error codes During operation, when an error occurs the board will use the LED’s to indicate where the problem exists. • For motor specific faults, the GREEN LED will blink once for motor 1, and blink twice for motor 2. •...
Page 161 Slideout Systems Low Voltage The Schwintek slide controller is capable of operating the NOTICE bedroom slide room with as little as 8-volts. But at these low- er voltages the amperage requirement is greater. Check the Never ‘jump’ or charge the voltage at the controller;...
Page 162: Hide-A-Bed Sofa
Hide-A-Bed Sofa Hide-A-Bed Sofa 1. Remove the seat back cushions. 2. Lift up and out on the front edge of the sofa, uncovering the legs. 3. Fully extend the legs on both sides. Lift Front of Sofa Extend Both Legs...
Page 163 Hide-A-Bed Sofa 4. Pull the sofa forward and place the legs flat on the floor. 5. Pull the sofa back forward, and lay flat. Pull & Lay Flat (5.) Pull Forward (4.) Converted Hide-A-Bed Sofa. Sofa Back Folded Down...
Page 164: Interior Care
Interior Care Interior Care To keep the value of your RV, perform regular maintenance using the proper materials and procedures. • Check the component manufacturer’s information for the recommended cleaning agent. Using the wrong cleaner may result in damage to the surfaces in your RV.
Page 165 Interior Care Paneling • To clean, use a mild solution of soap and lukewarm water with a soft sponge or cloth. • Do not use abrasive cleaners as they could cause the vinyl to scratch and turn dull. • Grease spots and stubborn dirt can be cleaned off with an all-purpose spray Countertops To prevent permanent damage:...
Page 166 Interior Care Flooring Always test cleaning agents for colorfastness in a hidden or inconspicuous area. Carpet Clean carpet regularly using a vacuum cleaner with a revolving brush or beater bar. Be sure the vacuum does not have teeth, combs or rough edges as they may damage the carpet. It is important to remove loose soil and debris while it is on the sur- face.
Page 167 Interior Care Furniture Upholstery To retain the value of your RV, maintain the furniture uphol- stery carefully and keep the interior clean. Vacuum the fur- niture regularly using a soft brush attachment to remove any loose dirt or debris. Fabric Fabric should be professionally cleaned if it becomes stained or soiled.
Page 168 Interior Care Recliner Sofa or Loveseat Like a residential recliner, the recliner sofa or loveseat sections Some, but not all, have controls allowing you to recline the individual sections. To recliner loveseats revert each recliner section back to the upright position, gently have storage in the middle armrest.
Page 169 Interior Care ABS Plastic ABS plastic components will retain their original beauty with reasonable care. Dust and wipe clean with soft, damp cloth or chamois, wiping gently. Do not use gritty or abrasive parti- cle soaps or scouring compound to clean ABS plastic. AVOID using Citrus or biodegradable cleaners containing D-Limonene;...
Page 170: Exterior Care
Exterior Care Exterior Care The RV exterior is comprised of many different materials includ- ing; fiberglass gel-coat, automotive grade paint finishes, plas- tics, glass, sealant, and aluminum. There is an increased chance of damage to the exterior finish, the longer a foreign substance remains on the surface. Fre- quent washing and waxing is the best way to protect your RV from this damage.
Page 171 Exterior Care • Rinse thoroughly and wipe dry with a chamois or soft cloth. • Carefully clean the joints and flanges of the slideout, doors, etc. where dirt is likely to remain. Some types of hot water washing equipment apply high pres- sure and heat to the RV.
Page 172 Exterior Care Waxing your RV Wax your RV once or twice a year, or when painted surfaces do not shed water well. Use a soft cloth to apply a small amount of wax to the painted surfaces. After the wax has dried, polish the RV with a dry, soft cloth.
Page 173 Exterior Care Exterior Roof 3-4 times per year, clean the Superflex roof and inspect all WARNING roof sealant. While you are cleaning, also clean and inspect the roof vents (including the sealant) for cracks. As with the surface of any roof, a rubber roof can be •...
Page 174 Exterior Care Windows Any ventilating window may permit water inside, especially during heavy rainstorms. Condensation will also cause water to accumulate on windows and in the tracks. The window glass can cleaned normally with a sponge and water. Use glass cleaner to remove wax, oil, grease, dead insects, etc.
Page 175 Exterior Care The sealants may become damaged due to exposure to the elements, freezing temperatures, ultraviolet light, and air pollution. If deteriorated, repair immediately to prevent damage. A quick walk around the RV before leaving may help prevent potential problems during trips and vacations. Your dealer service or parts manager can help you obtain the correct sealant(s).
Page 176 Exterior Care Winterizing The Exterior • BEFORE storing for the winter, be sure your RV is properly Winterized. 1. Check your roof and other surfaces for any damage or potential leaks that could go unnoticed until it is too late. 2.
Page 177: Maintenance
Suggested Maintenance Maintenance Suggested Maintenance Checklist This list is a quick reference sheet for suggested areas of regular maintenance. Review all manufacturer’s operators manuals supplied with your RV to perform these listed main- tenance items. Prior to first trip • Inspect and reseal as needed. •...
Page 178: Required Maintenance Schedule
Required Maintenance Required Maintenance Schedule Procedure to be Performed: Maintenance schedules are minimum Maintenance requirements. Extended use, extreme Item temperatures, high humidity or other extreme conditions will require more frequent maintenance. • • Check settings & adjustments per manufacturers guide. •...
Page 179 Required Maintenance Required Maintenance Schedule Procedure to be Performed: Maintenance schedules are minimum Maintenance requirements. Extended use, extreme Item temperatures, high humidity or other extreme conditions will require more frequent maintenance. • • Check for damage, loose wires and debris. Clean as necessary.
Page 180: Basic Troubleshooting
Basic Troubleshooting Basic Troubleshooting Air Conditioner (Roof) WARNING Will not operate WORKING WITH • Make sure unit is turned on. ELECTRICAL APPLIANCES CAN BE EXTREMELY • Check circuit breakers in coach. DANGEROUS. • Have your dealer check to see if there is proper Always have your dealer or a certified professional voltage from shoreline or generator.
Page 181 Basic Troubleshooting Furnace Furnace does not ignite and/or cycles frequently WARNING • Check that propane tank is full. DO NOT attempt • Remove any obstruction over furnace exhaust. to repair or adjust • Inspect exhaust tube for any obstructions. the furnace. Turn off the thermostat and •...
Page 182 Basic Troubleshooting Monitor Panel No lights on panel when switch is pressed • Check battery voltage and condition. • Check fuse at the battery; if fuse is good have a dealer or qualified RV technician check the condition of panel. Holding tank lights deliver false readings (i.e.
Page 183 Basic Troubleshooting Top burner or oven burner won’t light or won’t stay lit • Check position of top burners and flash tubing. • Clean clogged burner ports with a toothpick. • See Oven Owner’s Manual for proper care and maintenance. Gas smell •...
Page 184 Basic Troubleshooting Propane Gas DANGER Smell gas in or around unit IF YOU SMELL • Propane tanks may be overfilled. PROPANE GAS STOP! Quickly and carefully IF YOU SMELL PROPANE perform the 6-step procedure in the red box. 1. Extinguish any open flames, pilot lights and all smoking materials.
Page 185 Basic Troubleshooting Heavy frost build up on the evaporator fins • Defrost the freezer and refrigerator. • Have the refrigerator checked by your dealer or a qualified RV technician. Running Lights Running lights not working • Blown fuse. Replace fuse with one of the same ampere rating.
Page 186 Basic Troubleshooting Termination Valve Termination valve leaks • Debris keeps valve from seating. Clear debris from and around valve O-ring set. • Bad gasket. Have your dealer or qualified RV technician replace gasket with new. TV Antenna Poor TV reception •...
Page 187 Basic Troubleshooting Water Heater Temperature-pressure relief valve weeping • Weeping or dripping at the relief valve, while water heater is running, does NOT mean it is faulty. There is an odor that smells like rotten eggs • If your fresh water source has a rotten egg odor, you will need to find another source of fresh water before flush- ing or refilling the entire RV water storage system.
Page 188 Basic Troubleshooting Water Heater, Continued 5. If you decide to use air pressure (55 PSI max.), it may be applied either through the inlet or outlet on the rear of the tank. It may also be applied through the relief valve port. ◦...
Page 189 Basic Troubleshooting Water Pump Pump will not start • Check that house battery disconnect switch is on. • Check pump switch at monitor panel. • Check fuse in power center. • Check to see if water is frozen. Pump will not prime, sputters (no discharge, but the motor runs) •...
Page 190: Glossary
Glossary Glossary AC ELECTRICITY—Alternating current also known as shoreline power. For purposes of this manual, it refers to 120-volt AC (abbreviated 120 VAC). AMP—Short for ampere, the electric current unit of measure. RV sites with electric hookup will specify the maximum amps supported, which generally come in units of 20, 30, or 50 amps. The RV power connector must match the various plugs of the site amp rating.
Page 191 12-volt DC (abbreviated 12 VDC). DEALER—For purposes of this manual, this refers to the independent dealer authorized to sell and/or service your camper by Grand Design RV. This term will be used in this context unless specified otherwise.
Page 192 Glossary DRAIN TRAP—This is the curve that is in all drains. Water is trapped in the curve and creates a barrier so tank odors cannot escape through the drain. DRY CAMPING—Camping when there is no city water hookup or shore power (i.e., using only the water and power available in the camper and not from any other source).
Page 193 Glossary FULL TIMERS OR FULL TIMING—The term used for people who live in their RV full time, or at least the vast majority of their time. GALLEY—The kitchen in an RV. GENERATOR—An engine powered device fueled by gasoline or diesel fuel, and some- times propane, for generating 120-volt AC power.
Page 194 Glossary HEAT STRIP—A heat strip is an electric heating element located in the air conditioning system with the warm air distributed by the air conditioner fan and ducting system. They are typically 1500 watt elements (about the same wattage as an electric hair dryer) and have limited func- tion.
Page 195 Glossary JACKKNIFE—90% angle obtained from turning/backing fifth wheel or travel trailer with tow vehicle. Jackknifing a short bed truck towing a fifth wheel without the use of a slider hitch or extended fifth wheel pin box can result in damage to the truck cab or breaking out the back window of the truck cab from the truck and fifth wheel "colliding".
Page 196 Glossary PART TIMERS—The term used for people who use their RV more than usual (more than just a few weekend trips a year), but who still use it less than full time. PATIO MAT—Carpet or woven mat for use on ground outside of RV. Used whether or not a concrete patio pad is available where camping.
Page 197 Glossary SELF CONTAINED—RV which needs no external electrical, drain or water hookup. Thus, it can park overnight anywhere. Of course, self-contained units can also hook up to facilities when at campgrounds. SANITIZATION—Refers to the camper’s fresh water system that has been sanitized with chlorine bleach before use or after storage.
Page 198 Glossary TRAILER BRAKES—Brakes that are built into the trailer axle systems and are activated ei- ther by electric impulse or by a surge mechanism. The overwhelming majority of RVs utilize electric trailer brakes that are actuated when the tow vehicle's brakes are operated, or when a brake controller is manually activated.
Page 199 Glossary WEIGHT & LOAD—These terms are generally used interchangeably. For the purposes of understanding RV applications: Vehicles have WEIGHT, which impart LOADS to tires, axles and hitches. Scale measurements taken when weighing, are LOADS carried by the tires. The measured "loads" are used to calculate Gross Vehicle Weight (GVW), Gross Axle Weight (GAW), Gross Combination Weight (GCW), and hitch loads.
Page 200: Index
Index Index ....... 7-Way Wire Harness ....... 12-Volt DC System .
Page 201 Index ....... Heating & Cooling ....... . Hide-A-Bed Sofa .
Page 202 Customer Notes...
Page 204 11333 County Road 2 Middlebury, IN 46540 (574) 825-8000 www.granddesignrv.com Part # 960188 Rev. 01/2018...

This manual is also suitable for:

Solitude 2018 Solitude 2019 Solitude 2020

Grand Design Solitude 2017 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Grand Design Solitude 2017

Summary of Contents for Grand Design Solitude 2017

This manual is also suitable for:

Table of Contents
