phaiser CORE BHS-950 User Manual

Hide thumbs Also See for CORE BHS-950:
Table of Contents

Advertisement

Quick Links

Download this manual
CORE
BHS-950

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CORE BHS-950 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for phaiser CORE BHS-950

Summary of Contents for phaiser CORE BHS-950

  • Page 1 CORE BHS-950...
  • Page 2 BHS-950 features Nanocoating- Technology that safeguards against Sweat and Moisture. So if you haven’t registered your free lifetime sweatproof warranty, please do so here: phaiser.com/extra. Electronic user guide can be found at: phaiser.com/manuals. Enjoy the headset! We hope it’ll help you #LiveLoud!
  • Page 3 THANKS FOR PURCHASING PHAISER PRODUCTS! We’re so happy to have you on board, we’d like to invite you to Join The Phaiser VIP Club! Become a member of an exclusive club for new and existing customers with access to amazing benefits such...

  • Page 4: Product Features

    PRODUCT FEATURES 1. Lightweight behind-the-neck design for best stability while working out. 2. Premium Speakers with strong Bass and HD Stereo Music. 3. Extra long Playback and Standby time. 4. The easily operable buttons offer functions for answering phone calls and controlling audio playback.

  • Page 5: First Steps

    FIRST STEPS To ensure best battery performance, it is recommended to charge the head- set fully before first use. Please open the charging port cover with your fingernail and connect the USB charging cable. CHARGING THE HEADSET Just plug in the micro USB charging cable.
  • Page 6 INSTALLING THE COMPLY™ PREMIUM EARPHONE TIPS 1. Remove the silico ne tip from the ear- phone. 2. Clean the earphone nozzle of any deb- ris with a dry cloth. 3. Insert the earphone sound port nozzle into the tip‘s core at an angle.
  • Page 7 INSERTING THE COMPLY™ PREMIUM EARPHONE TIP 1. Squeeze down the foam tip and roll the tip into a thin, round cylinder. 2. Pull back and up on ear to open the canal. Gently insert the entire tip into the ear. 3.
  • Page 8 Note regarding the functions descri- bed in this manual: Not all phones or other connected Bluetooth devices support every function. For further information, please refer to your de- vice’s user manual. PAIRING Before using the headset for the first time, you must pair it with another Bluetooth-enabled device (for exam- ple a phone).
  • Page 9 list and pair it. 3. Once the headset is successfully connected to your phone, you will hear the audio message “Connected”. ADDITIONAL PAIRING NOTES 1. If asked for the Pass/PIN code, please enter “0000”. Newer phones don‘t require this. 2. The headset will automatically turn off if not paired within 5 minutes.
  • Page 10 2. Search the Bluetooth menu of your device for “BHS-950” and complete above regular pairing steps until successfully connected. 3. To delete all pairings from the head- set, press and hold Plus, Minus and Call buttons for 10 seconds until you hear the low tone confirmation.
  • Page 11 Bluetooth menu). This device will be the secondary device. 2. Pair the headset with the primary device according to the instructions under “manual pairing” (press and hold call and play for 3 seconds). This device will be the primary device where all functions for the multifunction button work by de fault.

  • Page 12: Auto Reconnect

    use Multipoint functions again. AUTO RECONNECT 1. If you turn the headset off, it will be disconnected from your phone. It will automatically attempt to recon- nect once turned back on and in range. 2. A secondary device may need to be reconnected through the Bluetooth- menu by selecting “BHS-950”.
  • Page 13 last connected device. 3. While you are in multi connection mode, a device which goes out of range, will lose connection. The headset will keep trying to connect to the lost device for 5 minutes. 4. In case you intentionally switched off the Bluetooth function on a single connected device and hear the “Disconnected”...
  • Page 14 Call Button 2 Play Button 3 Incresase Volume Button 4 Decrease Volume Button 5 PreviousTrack / Rewind Button 6 Next Track / Fast Forward Button 7 Power Switch 8 Microphone 9 Indicator LED 10 USB Charging Port...

  • Page 15: Resetting The Headset

    ON / OFF-FUNCTION Slide the Power Switch to ON position to turn the headset On. You will hear the audio message “Power On”. You will see the indicator LED turn Blue for a short time, then turn o if automati- cally reconnected to your phone or stay Blue while in pairing mode.

  • Page 16: Answering Calls

    Call buttons for about 10s until you hear a low beep tone. ANSWERING CALLS As soon as you have an incoming phone call, the headset will notify you by ringtone and read the phone number of the caller to you. To answer, briefly push the call button or answer the call on your phone.

  • Page 17: Last Number Redial

    LAST NUMBER REDIAL To redial the last number you called, triple click the call button and the phone will start dialling. VOLUME CONTROL By pressing “+” (plus button) you can increase the volume and by pressing “-” (minus button) you can decrease it.

  • Page 18: Next / Previous Track

    VOICE ASSISTANT AND VOICE DIALING Double press the middle control but- ton to activate your phone’s Voice As- sistant function such as Siri or Google Now. It‘s necessary that your phone supports this feature and that it‘s turned on. Please refer to your phones user manual for further information.

  • Page 19: Fast Forward/Rewind

    between tracks by double pressing the “+” (upper button) for Next Track or “-” (lower button) for Previous Track. FAST FORWARD / REWIND During media playback you can fast forward by pressing and holding the “+” (upper button). When you arrive at your desired position, release the button and normal playback will resume.
  • Page 20 change the equalizer setting. There are 3 equalizer settings available: “Normal” (default), “Bass” and “Tre- ble”. Try them out to find the most suitable one for your preferred music style. BATTERY STATUS NOTIFICATION Every time you turn the headset on, you will hear the battery status notification.
  • Page 21 before automatic shutdown. On iOS and some Android devices, you will be able to see the battery level of the headset in the upper right corner near the Bluetooth-symbol. MICROPHONE MUTE AND UNMUTE While on a call, press and hold the “-” button for 2 seconds, until you hear the notification tone, to mute the microphone.

  • Page 22: Using The Charging Case

    USING THE CHARGING CASE The headphones can also be charged using the (optionally) included head- phones charger. To do so, connect the headphones to the charger using the included USB cable and press the big silver button on the charger to turn it on.
  • Page 23 TROUBLESHOOTING THE HEADSET Issue: Headset does not work Solution: Please make sure the head- set is turned on and charged. Issue: Phone disconnects with headset Solution: Make sure the phone supports the Bluetooth Hands-Free Profile and is in range. Issue: Headset does not work properly with the phone Solution: Pair phone and headset again, make sure headset is in range...

  • Page 24: Avoiding Problems

    AVOIDING PROBLEMS - Please turn the headset off before putting it into your bag or pocket to avoid accidental calls. - Do not clean the headset with solvents or abrasives. - Do not expose the headset to extre- me temperature (not outside 14°F/- 10°C to 140°F/60°C).

  • Page 25: Additional Information

    To safeguard against potential pro- blems, make sure you’ve registered your 2-year manufacturer and lifetime sweatproof warranties at phaiser.com/ extra. ADDITIONAL INFORMATION Radio Frequency Exposure This headset is a radio transmitter and receiver. It communicates with Blue- tooth equipped devices by receiving...
  • Page 26 Potentially Explosive Atmosphere If you enter a potentially explosive atmosphere, please make sure you turn off your headset. Such areas are rare and in most cases, but not always, clearly marked. It is unlikely but pos- sible that your device could generate a spark and cause an explosion or fire resulting in serious injury or death.
  • Page 27 that you protect your hearing. It is better to use the headset only for a limited time at high volume. It is not suggested to turn up the volume in noisy surroundings to block out the noise. In case you cannot hear people talking to you anymore, please turn down the volume.
  • Page 28 CAUTION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interfe- rence in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accor-...
  • Page 29 - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. - Consult the dealer or an experien ced radio/TV technician for help.
  • Page 30 RF EXPOSURE The equipment complies with FCC ra- diation exposure limits set forth for an uncontrolled environment. This device should be installed and operated with minimum distance 0mm between the radiator & your body.
  • Page 31 Before you go… Love Free Stuff? Become a Phaiser VIP to get exclusive benefits such as: - 10% Off Your Next Order - Free Replacement Eartips - Early Access To New Products - Free Monthly Giveaways - 24 Month Manufacturer’s Warranty - Lifetime Sweatproof Warranty It’s fast.
  • Page 32 BHS-950 Customer Service support@phaiser.com FCC ID: 2AGY3BHS950 © 2018 Phaiser Phaiser LLC, 909 Silber RD APT 59, Houston, TX 77024-3636, United States © 2018 Liquipel Liquipel is a registered trademark of Liquipel IP LLC © 2018 Hearing Components Comply is a registered trademark of Hearing Components Made in China www.phaiser.com...
