- Page 1 INTELLIGENT LAMP TABLE Clean only with a non abrasive cloth or glass cleaner.
-
Page 2: Structure Diagram
Structure Diagram Hardware List A(8PCS) B(8PCS) C(16PCS) D(8PCS) E(1PC) F(8PCS) Ø20mm M8X30mm Ø6X32mm M8X30mm Ø1 5 mm H(2PCS) J(2PCS) K(4PCS) G(10PCS) I(5PCS) L(4PCS) M3.5X16mm M4X40mm O(1PC) M(1PCS) N(4PCS) P(1PC) R(1PC) - Page 3 Note: Turn the end of barrel for extra adjustment if needed to work the 'push open' mechanism.
- Page 5 Adjustable height feet are optional to use. Recommended if floor is uneven.
- Page 6 Connect cable micro port to the charging unit. Connect the cable USB port to a power source or plug. Place the charger in the cut out of the panel and feed cable along the channel. Note: Charger position has the coil to the top.
- Page 7 (10)
- Page 8 (11) A.Lateral Adjustment B.Verticl adjustment C.Front-to-Back by screw adjusting via slot in the mounting plate by the slackening the hinge-arm mounting screw For help visit www.frankolsenfurniture.co.uk...
