HNI Panel System Installation Instructions Manual

Hide thumbs

Advertisement

Quick Links

Panel System
Installation Instructions
Allsteel Inc.
Muscatine, Iowa 52761-0071
www.allsteeloffice.com
PAPE-E
Index
System Guidelines. . . . . . . . . . . . . . . . . . . . . 2
Panel Connections . . . . . . . . . . . . . . . . . . . . 3
Trim Installation . . . . . . . . . . . . . . . . . . . . . . . 5
Frameless Glass Installation . . . . . . . . . . . . . 7
Stacking Panel Installation . . . . . . . . . . . . . . 9
Power Pole Installation . . . . . . . . . . . . . . . . 10
8-Wire Electrical Installation . . . . . . . . . . . . 11
Countertop Installation. . . . . . . . . . . . . . . . . 18
Overhead Storage Installation . . . . . . . . . . . 19
Sliding Door Installation . . . . . . . . . . . . . . . . 21
Panel Door Installation . . . . . . . . . . . . . . . . 27
KA98000022
45162 25194
6
Pour des instructions en francias, appelar le 800-822-7653
Para instrucciones en enspanol, llame al 800-822-7653
TKAPE-E
Optimize
Contents
System Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 1
Panel Connections and Trim Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pages 2-4
Stacking Panel Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5
Panel Wall Connector Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 6
8 Wire Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pages 7-10
Power Pole Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 11
Worksurface Supports Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pages 12-16
Countertops Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 17
Overhead Storage Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pages 18-21
Sliding Door Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 22-27
Pour des instructions en Français, appeler le 800-822-7653
Para instrucciones en Español, llame al 800-822-7653
K01X014138
7
Power Pole and Trim Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pages 47 thru 48
Countertops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pages 49 thru 52
Permanent Wall Hanger Installation . . . . . . . . . . . . . . . . . . . . . . . . . . Pages 53 thru 54
Stiffener Bracket Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 55
Glass Tile Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pages 56 thru 58
Off Modularity Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pages 59 thru 62
Installation Packet
PREFIX
INSTALLATION
INSTRUCTIONS
M-PFXINST
PX06000569
8
8 1 7 2 8 0 4 9 6 6
Installation Packet
9
343-2270D
(05/13)
343-3890A
