THE BRAND YOU CAN TRUST
Before you start:
Check the contents
1. Top pump connector and flow
temperature gauge.
2. Circulating pump and washers.
3. bottom pump connector and return
temperature gauge.
4. ESBE Temperature control valve
There are two versions available:
VTA322 for 2-5 port manifolds up to 60
VTA572 for 6-12 port manifolds up to 70
1
This guide is specific to our ESBE temperature control pump station and should be used in conjunction with the relevant Manifold user guide.
In the unlikely event of any shortage please contact us and a replacement will be despatched immediately. Tel. 0800 083 2677
ESBE Pump Station
✆ 0800 083 2677
Check the pump station contents against the list below.
o
C
o
C
2. Circulating pump and
washers.
4. ESBE temperature control valve.
*Small ESBE valve illustrated.
www.wundatrade.co.uk
1. Top pump connector and flow
temperature gauge.
M11
3. bottom connector with return
temperature gauge.
Revision date: 26-4-2018
Advertisement
Table of Contents
Related Manuals for Wunda ESBE
Summary of Contents for Wunda ESBE
- Page 1 *Small ESBE valve illustrated. This guide is specific to our ESBE temperature control pump station and should be used in conjunction with the relevant Manifold user guide. In the unlikely event of any shortage please contact us and a replacement will be despatched immediately. Tel. 0800 083 2677...
- Page 2 Understanding how the Flow Bar ESBE pump station works Warm water is pumped from the heat source to the pump set and manifold assembly. If the floor heating system requires a top up of heated water, the mixing valve will allow more heated water into the system via the inlet or release cooled water back to the heat source via the outlet.
- Page 3 This stage should be carried out by a suitably qualified professional. The same assembly steps should be followed for both small and large ESBE valves. It’s good practice to use PTFE tape on every connection but beware not to over use. Hemp and Paste on connections is not advised.
- Page 4 Many floor finishes require limiting the floor surface temperature, this is achieved using a thermostat and floor probe. Once required temperature has been achieved – replace the protective cap to the ESBE valve. Flow rates and final manifold commissioning should be set in accordance with the correct manifold user guide.
- Page 5 25mm thick work well with floor heating. All wood flooring alkaline conditions the oxide film dissolves exposing the metal. Some over many years. Wunda Group Plc recommends regular use products must be acclimatised to the heating system and its...
- Page 6 Your Notes: Tech support opening hours are subject to change - please visit our website for the latest information Revision date: 26-4-2018...
