- Page 1 BRAVO 400S LT SERIES COMPUTER MULTI-ROW SPRAYER 4674L15XX 4674L17XX Software rel. 1.0.X INSTALLATION, USE AND MAINTENANCE...
- Page 2 This manual is an integral part of the equipment to which it refers and must accompany the equipment in case of sale or change of ownership. Keep it for any future reference; ARAG reserves the right to modify product specifications and instructions at any moment and without notice.
-
Page 3: Table Of Contents
CONTENTS Risks and protections before assembly .........5 SECTION VALVES ............... 28 • Type ................. 28 Intended use ................5 • Shut-off time ..............28 Precautions ................5 • Switch-on time ..............28 Package content ...............6 11.4.6 Nozzles data ............... 29 • Flowrate ................29 Position on farming machine ..........7 •... - Page 4 CONTENTS 11.7 TRACTOR ADVANCED SETTINGS ......42 15 Job menu .................66 11.7 .1 Camera ................42 15.1 Tank ................66 11.7 .2 Geometry settings 15.2 Prescription map ............68 (SELF-PROPELLED) ............42 15.3 Job data .................68 11.7 .3 Geometry settings 15.4 Camera ................69 (TRACTOR WITH REAR 3-POINT HITCH IMPLEMENT) ..
-
Page 5: Risks And Protections Before Assembly
• RESPONSIBILITY The installer must carry out workmanlike installations and ensure to the end user the perfect operation of the whole system both with ARAG components only and other brands' components. ARAG always recommends using its components to install control systems. -
Page 6: Package Content
INTRODUCTION PACKAGE CONTENT The table below indicates the components that you will find in the Bravo 400S LT computer package: BRAVO 400S LT BRAVO 400S LT WITH HYDRAULIC CONTROLS Fig. 1 Fig. 2 Legend: Legend: 1 Bravo 400S LT 1 Bravo 400S LT 2 Power supply cable 2 Power supply cable 3 Power supply connector... -
Page 7: Position On Farming Machine
INSTALLATION POSITION ON FARMING MACHINE System recommended composition ASSEMBLY DIAGRAM FOR MULTI-ROW SPRAYER WITH DIAPHRAGM PUMP - SYSTEM WITH MAIN VALVE Legend: Monitor Battery GPS receiver Filling pump Oil-hydraulic unit Flowmeter Main valve External main control Pressure sensor Regulating valve Speed sensor Filling flowmeter / Level sensor... -
Page 8: Computer Positioning
INSTALLATION Computer positioning • Bravo 400S LT series computer must be placed in the control cabin of the farming machine. Observe the following precautions: - Do NOT install the computer in areas where it would be subjected to excessive vibrations or shocks, to prevent any damage or accidental use of the control keys;... -
Page 9: Bracket Fixing
WARNING: the Bravo 400S LT computer must be fastened by means of the supplied bracket only, using suitable screws. OTHER FASTENING METHODS ARE NOT ALLOWED. ARAG is not liable for any damage to the equipment, persons or animals caused by failure to observe the above instructions. Control unit position The control unit must be fixed with the special brackets supplied and fitted to the unit, positioning it as shown in the manual provided with the assembly. -
Page 10: Wiring Connections
• Use of unsuitable cables not provided by ARAG automatically voids the warranty. • ARAG is not liable for any damage to the equipment, persons or animals caused by failure to observe the above instructions. General precautions for a correct harness position •... -
Page 11: Control Unit Valve Connection
• Use ARAG valves: use of unsuitable valves not provided by ARAG automatically voids the warranty. ARAG is not liable for damage to the equipment, persons or animals caused by failure to observe the above instructions. • All valve connectors must be provided with seals before being connected (Fig. 10). -
Page 12: Sensor Connection
• level sensor; • filling flowmeter; • RPM sensor. All ARAG sensors use the same type of connector. Connect the sensor connector to the relevant harness; make sure it is correctly fitted and push it until locking it. Fig. 12 Fig. -
Page 13: Power Supply Connection
INSTALLATION Power supply connection The package includes the power connector (component , Fig. 1 / Fig. 2) to be connected to the farming machine battery; Fig. 17 shows the drilling template of the power connector. Connect the power connector to the battery wires using two 6-mm faston connectors, as indicated in Fig. 15 and Fig. 16. Use the cable provided with the package (component , Fig. -
Page 14: Accessories
ACCESSORIES ACCESSORIES SD memory card The SD memory card may be used to exchange data with the Bravo 400S LT computer. Before use, format the SD card in FAT 32 mode; make sure that the card is not protected and can be read by the system (Fig. 19). The system is ONLY compatible with SD or SDHC memory cards with up to 8 Gb memory. -
Page 15: Setup
PROGRAMMING SETUP Setup preparation Before computer setup, check: • that all components are correctly installed (control unit and sensors); • the correct connection to the power source; • the correct connection of components (control unit and sensors). Failure to correctly connect system components or to use specified components might damage the device or its components. Switching on SOFTWARE VERSION TURNING ON... -
Page 16: Switching Off
PROGRAMMING FIRST DEVICE SWITCHING ON Fig. 27 Fig. 28 Fig. 26 Upon first switching on, after system checks, the monitor directly accesses screen "Home" (Fig. 26). Set the monitor language. LANGUAGE SETTING Settings - In the "Home" (Fig. 26) screen press to enter the menu(Fig. -
Page 17: Use Of Keys For Setup
PROGRAMMING Use of keys for setup SELECTION AND ACCESS TO MENU ITEMS 1A Press in succession to move across the menu items (UP / DOWN). The selected item is highlighted with a gray bar (A). 1B Press in succession to move across the available options (RIGHT / LEFT). -
Page 18: Menu Structure
PROGRAMMING MENU STRUCTURE Upon first switching on, enter the device basic settings (chap. 10). Afterwards, it will be possible to select the preset settings by pressing chap. 14 “Home” menu chap. 10 chap. 11 Basic settings Advanced setup Create / Load settings User usrxx ("... -
Page 19: Basic Settings
7 switches • MAIN VALVE Smart-Ag Smart 6 AgStar Atlas Main control valve installed on the control unit: : ARAG receivers code 467016xx. None 2 ways (drain valve) 3 ways (main valve) • FLOWRATE REFERENCE SENSOR Device used to calculate flowrate:... -
Page 20: Advanced Setup
ADVANCED SETUP ADVANCED SETUP ACTIVE SETTINGS Before starting advanced setup, select the type of system configuration: all the modifications to advanced setup will be applied to ACTIVE SETTINGS ( self-propelled machine with carried /towed implement machine 11.1 Configuration management Press in the “Home”... -
Page 21: Device Reduced Configuration
ADVANCED SETUP LOADING A SETUP Instead of saving, you can activate a previously saved setup. Load > Setup 1 Select in Fig. 48) and press 2 From the example in Fig. 49 select the setting type to be loaded and press Follow the steps and select the desired options. -
Page 22: Settings
ADVANCED SETUP 11.3 Settings Settings 1 In the "Home” screen (Fig. 55) press to enter the menu (Fig. 56 / Fig. 57). 2 Perform monitor advanced setup: select the desired menu item (with 3 Press to shift to the selected item setup. Fig. -
Page 23: Implement Settings
ADVANCED SETTINGS "IMPLEMENT" 11.4 IMPLEMENT SETTINGS THE BASIC SETTINGS (CHAP. 10) AFFECT WHICH AND HOW MENU ITEMS ARE DISPLAYED, HENCE WHICH ADVANCED SETTING IT IS POSSIBLE TO CONTROL. A NAVIGATION SUMMARY IS AVAILABLE IN Fig. 56 AND Fig. 57. 11.4.1 Boom settings It allows defining the number of the nozzles used and setting the coverage. - Page 24 ADVANCED SETTINGS "IMPLEMENT" HALF-ROWS COVERAGE DISABLED Example: Section Section valve valve 1 Fig. 58 For every row side figure associate the valve that is going to control it ( Fig. 59 - Section valve 1 sprays on the first row (RIGHT HALF-ROW SIDE).
-
Page 25: Half-Rows Enablement
ADVANCED SETTINGS "IMPLEMENT" • Half-rows enablement Allows enabling / disabling spraying of single half-rows. Spraying of disabled half-rows will be prevented until the new half-row enabling (from this menu). Half-row enabled Half-row disabled 11.4.2 Flowmeter Enter the values for the flowmeter installed on the system. The table below indicates the values that are automatically set when selecting the flowmeter code. -
Page 26: Filling Flowmeter
ADVANCED SETTINGS "IMPLEMENT" 11.4.3 Filling flowmeter This menu is only visible when the filling flowmeter is selected as tank level source (basic settings, chap. 10). The filling flowmeter allows displaying the tank filling data in real time. Enter the values for the filling flowmeter installed on the system: the following table indicates the values which will be set automatically by selecting the corresponding flowmeter code. -
Page 27: Pressure Sensor
- Enter the values for the pressure sensor installed on the system. The table below indicates the values that are automatically set selecting the sensor code. If the installed sensor is not displayed, select Other and enter the relevant values. ARAG PRESSURE SENSOR Maximum pressure Type ARAG 466113.200... -
Page 28: Pressure Regulating Valve
ADVANCED SETTINGS "IMPLEMENT" > > > 11.4.5 Valves PRESSURE REGULATING VALVE • Regulation direction Indicate the type of installed control valve. Available options are: Standard • Reverse • • Type Indicate the type of installed control valve. Available options are: •... -
Page 29: Nozzles Data
ADVANCED SETTINGS "IMPLEMENT" 11.4.6 Nozzles data Allows quick nozzle selection and to set characteristic data among those types of nozzles: 12 types of nozzles ISO, 10 ATR nozzles, 10 HCC nozzles and 6 USR “User” nozzles (A ÷ F). The values for Flowrate Pressure can be modified for “User”... -
Page 30: Rev Counter
ADVANCED SETTINGS "IMPLEMENT" 11.4.8 Rev counter • Status Rev counter enabled / Rev counter disabled). To configure the items on this menu, you must enable the rev counter Enter the values for the rev counter installed on the system. • Constant: Indicate the constant of the installed rev counter. -
Page 31: Alarms
ADVANCED SETTINGS "IMPLEMENT" 11.4.10 Alarms Set monitor job alarms. NOZZLE ALARMS • Nozzle wear check Enable the function to set the nozzle wear limit percentage. Check enabled Check disabled This alarm can be enabled ONLY if the system features both flowmeter and pressure sensor •... -
Page 32: Working Parameters
ADVANCED SETTINGS "IMPLEMENT" 11.4.11 Working parameters Set the farming machine job limits. SPRAYING LIMITS • Spraying speed limit Enable the function to set the spraying speed limit. Limit enabled Limit disabled • Minimum spraying speed Set the minimum spraying speed: The monitor closes the main valve when the tractor speed is lower than the set value. -
Page 33: Automatic Section Control
ADVANCED SETTINGS "IMPLEMENT" > > > 11.4.11 Working parameters AUTOMATIC SECTION CONTROL • Sections overlapping limit Set the acceptable threshold for overlapping of already-sprayed areas. When this value is exceeded, the monitor restores the correct spraying: depending on the section management mode enabled (par. 13.5 Boom section management), the monitor will prompt the operator to close the relevant valves or proceed to the automatic closing of the spraying points. -
Page 34: Spray Closing Delay
ADVANCED SETTINGS "IMPLEMENT" > > > 11.4.11 Working parameters • Spray closing delay Indicate the distance corresponding to the delayed closing of sections during spraying, to ensure correct spraying range. Closing delay: 0.3 m Fig. 67 • Spray opening advance Indicate the distance corresponding to the advanced opening of sections during spraying, to ensure correct spraying range. -
Page 35: Guidance
ADVANCED SETTINGS "IMPLEMENT" > > > 11.4.11 Working parameters GUIDANCE • Steering radius By setting this value, an acoustic alarm will indicate the exact moment when the operator must steer in order to align the machine with the following track, avoiding unsprayed or overlapping areas between the two sprays. The acoustic alarm may be enabled or disabled from the User >... -
Page 36: Device Calibration
ADVANCED SETTINGS "IMPLEMENT" 11.4.12 Device calibration Allows starting calibration for the devices connected to the monitor. THE BASIC SETTINGS (CHAP. 10) AFFECT WHICH AND HOW MENU ITEMS ARE DISPLAYED, HENCE WHICH ADVANCED SETTING IT IS POSSIBLE TO CONTROL. SENSORS • Pressure sensor zero value To access this menu, the pressure sensor must be enabled , par. - Page 37 ADVANCED SETTINGS "IMPLEMENT" > > > 11.4.12 Device calibration • Tank profile calibration The calibration of the tank profile is ONLY possible if a flowmeter is installed on the system (par. 11.4.2). Before starting the procedure carry out the following operations: 1 Make sure the main control is in OFF position (par.
-
Page 38: Implement Geometry (Machine With Towed / Carried Implement)
ADVANCED SETUP "TOWED IMPLEMENT GEOMETRY" 11.5 IMPLEMENT GEOMETRY (MACHINE WITH TOWED / CARRIED IMPLEMENT) The displaying of this menu depends on the selected basic settings (cap. 10). FOR SELF-PROPELLING MACHINE GEOMETRY, REFER TO PAR. 11.7.2. 11.5.1 Geometry settings (TOWED IMPLEMENT) The settings displayed below vary based on the type of system set (cap. -
Page 39: Geometry Settings (Carried Implement)
ADVANCED SETUP "CARRIED IMPLEMENT GEOMETRY" 11.5.2 Geometry settings (CARRIED IMPLEMENT) The settings displayed below vary based on the type of system set (cap. 10). Enter farming machine measures (Fig. 91). - Press arrow keys (UP, DOWN) to move among the value descriptions: the image of the selected value will be displayed. - Confirm by pressing to enter setup. -
Page 40: Gps Receiver Settings
11.6 GPS RECEIVER SETTINGS ARAG SHALL NOT ACCEPT ANY LIABILITY DUE TO ANY FAILURE OR MALFUNCTION CAUSED BY THE CONNECTION OF RECEIVERS NOT SUPPLIED BY ARAG. The items displayed in this menu depend on the basic settings (chap. 10) and on the features of the connected receiver. The... -
Page 41: Hdop Alarm
"GPS RECEIVER" The items displayed in this menu depend on the basic settings (chap. 10) and on the features of the connected receiver. The connection of ARAG receivers, models , entails a guided pairing procedure assigning to the Smart Ag - Ag Star - Smart 6 - Atlas monitor ONLY the suitable setup menus. -
Page 42: Tractor Advanced Settings
ADVANCED SETUP "TRACTOR" 11.7 TRACTOR ADVANCED SETTINGS 11.7.1 Camera It is possible to connect up to 2 cameras to the monitor in order to monitor the working areas that the operator is unable to see (e.g., when driving in reverse). From the menu it is possible to enable/disable each single camera individually or both cameras: None : No camera connected... -
Page 43: Geometry Settings (Tractor With Rear 3-Point Hitch Implement)
ADVANCED SETUP "TRACTOR" 11.7.3 Geometry settings (TRACTOR WITH REAR 3-POINT HITCH IMPLEMENT) The settings displayed below vary based on the type of system set (cap. 10). Enter farming machine measures. - Press arrow keys (UP, DOWN) to move among the value descriptions: the image of the selected value will be displayed. - Confirm by pressing to enter setup. -
Page 44: User
ADVANCED SETUP "USER" 11.8 USER The monitor is provided with an Alarms menu ( accessible from the “Home” menu by pressing ). This page displays all active notifications for the operator. These notifications are rated by importance as Critical alarms, Low priority alarms and Info. From the User menu it is possible to enable / disable acoustic alarms for each notification: •... -
Page 45: Displayed Data Configuration
ADVANCED SETUP "USER" 11.8.6 Displayed data configuration Allows setting the data of the spraying you want to display on the guidance screen (Fig. 107). Two data pages are available on each side, which can be alternated using keys Both pages can be customized: select the position of datum (Page 1 settings or Page 2 settings) menu and program one of the options available in Fig. -
Page 46: Preferences
ADVANCED SETUP "USER"/ “GENERAL OPTIONS” PREFERENCES 11.8.9 Selective job loading It allows enabling/disabling the Loading options screen (Fig. 166) when the operator loads a previously saved job (par. 14.5 F5 Resume job). Screen enabled Screen disabled Loading options: the following data can be individually enabled. •... -
Page 47: Sampling Period
N = parity (None) 1 = stop bit Ask to Arag technical service the availability of the adapting cables for your data recording system. DATA RECORDING FILE When the sampling period has been set, the system generates a “lastjob.txt” file (containing the active job data), and other “jobxx.txt” files, corresponding to the names of the recorded jobs. -
Page 48: Use
12.1 Controls MONITOR BRAVO 400S LT • Controls on the monitor Function keys. Control and display keys Function keys are contextual: the function of each key depends on what appears on the display, therefore the use of these keys will be illustrated during the description of the corresponding procedures. -
Page 49: Guidance Screen
12.4 Guidance screen USING THE KEYS Display zoom adjustment: Displays job information / Alarms ) increases ) decreases Go to “Home” Views automatic function menu menu Confirmation ON / OFF Aborts a function Aborts data change Enables / disables job functions Switch to job display menu... -
Page 50: Spraying A Field
12.5 Spraying a field • Go to the beginning of the field to be sprayed. • Switch the monitor on (par 8.2). After self-diagnosis, the monitor displays screen Let us assume we want to spray a field "Home" (Fig. 113). along parallel lines, but only once the edges of the field have been sprayed. - Page 51 > > > 12.5 Spraying a field • In the job menu, set the tank level with the function Tank (par. 15.1). • Start spraying by acting on the main valve control. • Start moving along the field perimeter. Fig. 124 MARKING POINTS A AND B Mark A ? •...
-
Page 52: Automatic Functions
"AUTOMATIC FUNCTIONS" - STRUCTURE AUTOMATIC FUNCTIONS New job Resume job Continue last job To access automatic functions, start a job ( chap. 14 “Home” menu); Auto in the guidance screen press . When the list is active (Fig. 128), pressing the key at the side will enable the relevant function. -
Page 53: F2 Automatic Adjustment On/Off
“AUTOMATIC FUNCTIONS” 13.1 Automatic adjustment ON/OFF Enables / disables automatic output adjustment (DEFAULT: ON). In the guidance screen, press Auto Press to enable or disable automatic adjustment. Regulation Regulation adjustment ON adjustment OFF 13.2 Output adjustment The monitor can control chemicals output with an automatic adjustment function (par. 13.1, DEFAULT: ON). AUTOMATIC ADJUSTMENT ON AUTOMATIC ADJUSTMENT OFF (MANUAL) The monitor keeps the set spray rate constant regardless of the changes in speed... -
Page 54: Boom Section Management
“AUTOMATIC FUNCTIONS” 13.5 Boom section management AUTOMATIC MANAGEMENT ON AUTOMATIC MANAGEMENT OFF (MANUAL) The section valves are closed or opened automatically. Section valves must be opened or closed manually. To change section valve management mode, use function Automatic section management ON/OFF (par. 13.4). SPRAYING AND BOOM SECTION STATUS Main control OFF Main control OFF... -
Page 55: 14 "Home" Menu
"HOME" MENU - STRUCTURE "HOME" MENU Fig. 134 Home To enter the menu press the key: once inside the menu, pressing each key will enable the corresponding function. The table below sums up all menu items and corresponding keys: Par. Par. -
Page 56: F1 Continue Last Job
"HOME" MENU - F1 CONTINUE LAST JOB - F2 SAVE JOB 14.1 Continues last job. Continue last job 1 Press to continue the last job, from the point where it has been interrupted. Spraying settings 2 Check the in Fig. 136; modify them if necessary. 3 Select and press to switch to guidance mode. -
Page 57: F3 New Job
"HOME" MENU - F3 NEW JOB 14.3 Starts a new spraying New job 1 Press to start a new job. If the current job has not been saved yet, the monitor will prompt the user to save it (Fig. 141). Press to continue without saving (2A) or to interrupt the procedure and save (2B). -
Page 58: F4 Memories Management
ONLY the SD card reader is an exception. The following paragraphs refer to an example with a pendrive: the procedure is the same with a SD card. ARAG monitors can use different external memories: Bravo 400S LT: Pendrive + SD card The items displayed in this menu depend on the type of external memory used. -
Page 59: Jobs Export
"HOME" MENU - F4 MEMORIES MANAGEMENT 14.4.1 Jobs export Allows exporting the saved data to an external memory device (Pendrive / SD card). When both memories are available, use the pendrives for the exchange of the job data and of the system update data. The monitor featuring ONLY the SD card reader is an exception. -
Page 60: Backup
"HOME" MENU - F4 MEMORIES MANAGEMENT 14.4.2 Backup Manages the system setting exchange between the monitor and an external memory device. When both memories are available, use the pendrives for the exchange of the job data and of the system update data. The monitor featuring ONLY the SD card reader is an exception. -
Page 61: Load Backup File From Usb / Sd Card
"HOME" MENU - F4 MEMORIES MANAGEMENT • Load backup file from USB / SD card Allows loading on the device a copy (backup) of system settings, thus ENABLING THEM. Before carrying out this operation, it is recommended to create a backup of the existing settings. -
Page 62: Internal Memory Deletions
"HOME" MENU - F4 MEMORIES MANAGEMENT 14.4.3 Internal memory deletions Allows deleting data from the monitor internal memory. THE CURRENTLY USED FILES MUST NOT BE DELETED. Implements Tractors, Users, The following paragraphs will use as an example: the same procedure will be valid for all other cases ( etc.). -
Page 63: Remote Devices Upgrade
"HOME" MENU - F4 MEMORIES MANAGEMENT 14.4.5 Remote devices upgrade When both memories are available, use the pendrives for the exchange of the job data and of the system update data. The monitor featuring ONLY the SD card reader is an exception. The following paragraphs refer to an example with a pendrive: the procedure is the same with a SD card. - Page 64 "HOME" MENU - F4 MEMORIES MANAGEMENT > > > • Upgrade monitor firmware - Insert the pendrive in its slot on the monitor. STARTING THE UPDATE: Select Upgrade monitor firmware (Fig. 163) and press . The message in Fig. 164 is displayed once loading is completed. Remove the pendrive and restart the monitor.
-
Page 65: F5 Resume Job
"HOME" MENU - F5 RESUME JOB - F6 INFO / ALARMS 14.5 Enables procedure for resuming a previously saved spraying. Resume job 1 Press to resume a previous job, from the list of saved jobs. New job As for the function (par. -
Page 66: Job Menu
"JOB MENU" - STRUCTURE JOB MENU To access the job menu, press Menu . Pressing the key at the side will enable the relevant function. WARNING: function position is variable, hence also that of the corresponding key. The table below sums up all menu items. If several pages are present, press Menu in sequence to scroll them. - Page 67 "JOB MENU" - TANK • TANK LEVEL SOURCE: MANUAL / FILLING FLOWMETER The computer calculates the quantity of fluid inside the tank (by processing the job data), and allows to enable several manual procedures: - Complete filling, according to the tank capacity (Fig. 170) - Level reset (Fig.
-
Page 68: Prescription Map
"JOB MENU" - PRESCRIPTION MAP 15.2 Overview of the prescription map in use Prescription map Press Menu Press the key at the side of menu Prescription map. From this screen it is possible to view data of the prescription map during spraying and to check the position of the machine on the map. Machine position Spray rate values legend: The highlighted box displays the spray rate referred to... -
Page 69: Camera
"JOB MENU" - CAMERA 15.4 Displays images from connected cameras Camera Press Menu Press the key at the side of menu Camera. By connecting one or more cameras, it is possible to monitor working areas and at the same time view spraying data. Enable camera view during advanced setup (par. -
Page 70: Zoom All
"JOB MENU" - ZOOM ALL 15.6 Overview of the field during spraying Zoom all Press Menu Press the key at the side of menu Zoom all. INDICATORS AND POINTS OF INTEREST ON THE FIELD Job breaking point, enabled with the "PAUSE" function (par. 16.3.1) In this screen it is NOT possible to mark or modify this point. -
Page 71: Menu
"JOB MENU" - MENU 15.7 Job settings menu Menu Press Menu Press the key at the side of menu Menu. In this screen it is possible to access several different menus, which can be useful during spraying: Valves • (par. 11.4.5). Alarms •... -
Page 72: Device Status
"JOB MENU" - DEVICE STATUS Allows checking the correct operation of the monitor: the description of the selected item will appear on the display. 15.8 The items displayed in this menu are READ-ONLY; they depend on the basic settings (chap. 10). Device status Press Menu... -
Page 73: Job Functions
"JOB FUNCTIONS" - STRUCTURE JOB FUNCTIONS New job Resume job Continue last job To access job functions start a job ( Func chap. 14 “Home” menu); in the guidance screen press When the list is active (Fig. 195), pressing the key at the side will enable the relevant function. -
Page 74: F1 Target Rate
"JOB FUNCTIONS" - F1 TARGET RATE 16.1 Target rate Change spray rate 1 In the guidance screen, press Func. 2 Press to enable the function. 3 Change the spray rate value for the spraying (Fig. 197). 4 Confirm the value. Fig. -
Page 75: F3 Point Marking
"JOB FUNCTIONS" - F3 PAUSE 16.3 Groups the available options for marking points of interest. Point marking 1 In the guidance screen, press Func. 2 Press . A list with options for marking the points will appear (Fig. 202). Pressing each key will enable the corresponding function. Fig. -
Page 76: F4 Surface
"JOB FUNCTIONS" - F4 SURFACE 16.4 Surface Enables the procedure to calculate field surface by driving along its perimeter. 1 In the guidance screen, press Func. 2 Press to start the surface calculation procedure (function list disappears). Field edge side selection The following message will appear: prompting the operator to select which side of the machine to use as a reference to define the field perimeter. -
Page 77: F5 Resume From Pause
"JOB FUNCTIONS" - F5 RESUME FROM PAUSE Guidance indications to return to job breaking point 16.5 Resume from pause previously saved with function “F1 Pause” (par. 16.3.1). 1 In the guidance screen, press Func. 2 Press to obtain guidance information and enable the return to job breaking point procedure. -
Page 78: F7 New Ab
"JOB FUNCTIONS" - F7 NEW AB Saves two points A and B on the field, which the monitor uses to draw a line that will act as a 16.7 New AB reference track ( , Fig. 221) for the current spraying. 1 In the guidance screen, press Func. -
Page 79: F8 Display
"JOB FUNCTIONS" - F8 DISPLAY Allows to select different display modes. Includes several options. 16.8 Display 1 In the guidance screen, press Func. 2 Press . A list of options concerning display modes will appear (Fig. 222). Pressing each key will enable the corresponding function: changes tractor themes (par. -
Page 80: F4 Spraying Themes
"JOB FUNCTIONS" - F8 DISPLAY 16.8.2 Spraying themes 1 In the guidance screen, press Func. 2 Press to view the available options. 3 Press in succession to scroll spraying color combinations. SPRAYING THEME 1 (DEFAULT) THEME 2 THEME 3 THEME 4 THEME 5 Fig. -
Page 81: Maintenance / Diagnostics / Repairs
MAINTENANCE / DIAGNOSTICS / REPAIRS MAINTENANCE / DIAGNOSTICS / REPAIRS 17.1 Cleaning rules - Clean only with a soft wet cloth. - DO NOT use aggressive detergents or products. - DO NOT use direct jets of water. 17.2 Troubleshooting FAULT CAUSE REMEDY No power supply... -
Page 82: Error Messages
17.3 Error messages MESSAGE ON DISPLAY CAUSE REMEDY • Start the machine. Move forward! The machine is stopped Main control ON with machine stopped • Disable main control (OFF) Enable pump! No flowrate. Main control ON but flowrate at zero •... -
Page 83: Technical Data
GUARANTEE TERMS 1. ARAG s.r.l. guarantees this apparatus for a period of 360 days (1 year) from the date of sale to the client user (date of the goods delivery note). The components of the apparatus, that in the unappealable opinion of ARAG are faulty due to an original defect in the material or produc- tion process, will be repaired or replaced free of charge at the nearest Assistance Center operating at the moment the request for interven- tion is made. - Page 84 Only use genuine ARAG accessories or spare parts to make sure manufacturer guaranteed safety conditions are maintained in time. Always refer to ARAG spare parts catalog. 42048 RUBIERA (Reggio Emilia) - ITALY Via Palladio, 5/A Tel. +39 0522 622011 Fax +39 0522 628944 http://www.aragnet.com...
