Die Gewährleistung entspricht der gesetzlichen Regelung. Eine Rücksendung kann nur nach vorheriger
Absprache und in der Originalverpackung erfolgen. Bitte unbedingt einen maschinell erstellten
Kaufbeleg und eine Fehlerbeschreibung beilegen. Von der Gewährleistung ausgeschlossen sind Defekte,
die durch Überlastung, unsachgemäße Behandlung oder bei Teilnahme an Wettbewerben entstanden
sind. Wir behalten uns das Recht vor, zukünftig nötige Änderungen oder Verbesserungen an dem
Produkt vorzunehmen ohne den Kunden darüber zu informieren.
Limited warranty - defective products must be returned in original packaging - please add a copy of the
original purchasing invoice showing the purchasing date and a detailed description of the failure. Failure
caused by overload, misuse or by using the product for competition purpose are not covered by the
warranty. We reserve the right to make needed change or improvement to the product without informing
customer about this in advance.
De Garantie bepalingen van alle door ground zero geleverde producten is volgens wettelijke
bepalingen geregeld, Een retourzending kan alleen na duidelijke afspraak en in de originele
verpakking plaatsvinden.SVP een aankoopbon en een duidelijke storingsomschrijving bijvoegen.Van
garantie uitgesloten zijn defecten door overbelasting, onkundig gebruik, of door deelname aan
wedstrijden (SPL) ontstaan zijn. Wij behouden ons het recht om de nodige veranderingen of
verbeteringen aan het product door te voeren zonder de klant hierover te informeren.
La garantie est conforme aux droits légaux. Un retour du produit défectueux doit être dans son
emballage d'origine sur présentation du reçu ou de la facture indiquant la description du defaut.La
présente Garantie n'est pas applicable lorsque le produit a été endommagé en raison: Mauvaise
alimentation, Trop de puissance (HP,Subwoofer) Accident, Installation ou Utilisation non conforme aux
normes Technique (Concours SPL etc). Nous nous réservons le droit d'entreprendre à l'avenir
nécessairement des modifications ou des
améliorations au produit sans informer le client.
Ground Zero GmbH
Erlenweg 25, 85658 Egmating, Germany
Tel. +49 (0)8095/873 830
Fax -8310
www.ground-zero-audio.com

Advertisement

Table of Contents
loading

Summary of Contents for Ground Zero RADIOACTIVE Series

  • Page 1 We reserve the right to make needed change or improvement to the product without informing customer about this in advance. De Garantie bepalingen van alle door ground zero geleverde producten is volgens wettelijke bepalingen geregeld, Een retourzending kan alleen na duidelijke afspraak en in de originele verpakking plaatsvinden.SVP een aankoopbon en een duidelijke storingsomschrijving bijvoegen.Van...
  • Page 2: Radioactive-Series Amplifier

    RADIOACTIVE-SERIES AMPLIFIER OWNER’S MANUAL GZRA MICRO ONE Features • High efficient compact amplifier • 1 Channel class D • 2 Ohm stable • Variable 12dB Bass boost (45Hz) • Variable Phase shift 0 - 180° • Variable Subsonic 15 - 25 Hz •...
  • Page 3: Planning Your System

    Tools and materials you need • Screwdriver • Electric drill, 3 mm / 0.12” carbide drill bit • Mounting screws • Soldering gun • Power wire min. 8 mm² / 8AWG • Ground wire min. 8 mm² / 8AWG • Speaker wire min.
  • Page 4: Controls And Functions

    Controls and functions Input level controller With this controller you can adjust the input sensitivity. This controller allows you to filter low frequencies in a range between Subsonic controller 15 and 25 Hz. This function reduces the mechanical Xmax and raises the capacity of the connected subwoofer.
  • Page 5: Amplifier Connection

    Make sure input connectors are making good contact with input jacks of the amplifier to avoid shortage or interruption • Never use any other connector instead of the original Ground Zero connector. In case of a defective connector cable, please contact the Ground Zero service. Turning on the amplifier The amplifier automatically turns on a few seconds after you turn on your radio.
  • Page 6 RCA (low level) wiring...
  • Page 7 High level wiring...
  • Page 8: Specifications

    Specifications Model GZRA MICRO ONE Type 1 Channel Class D RMS Power @ 4 Ω 1 x 220 W (1% THD+N) CEA Standard CEA-2006-A 1 x 270 W (10% THD+N) RMS Power @ 2 Ω 1 x 350 W (1% THD+N) CEA Standard CEA-2006-A 1 x 400 W (10% THD+N) Damping factor...
