OPERATING INSTRUCTIONS
Revision: 1.2
®
::
VUCAM
XO
www.vizaar.com
DXX-80-000162
BA01-018_1-2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VUCAM XO and is the answer not in the manual?

Questions and answers

Related Manuals for viZaar VUCAM XO

Summary of Contents for viZaar VUCAM XO

  • Page 1 ® OPERATING INSTRUCTIONS Revision: 1.2 ® VUCAM www.vizaar.com DXX-80-000162 BA01-018_1-2...
  • Page 2 Kindly contact us even if you have suggestions for the improvement of this manual or the product. For contact details please consult the following page. Thank you for choosing a viZaar ® product for your inspection service.
  • Page 3 Hechinger Straße 152 72461 Albstadt / Germany Fon: +49 7432 98375-0 Fax: +49 7432 98375-50 www.vizaar.de info@vizaar.com viZaar Industrial Imaging - North America 4533 Gibsonia Road PA 15044 Gibsonia / USA Fon: +1 (724) 449-3270 Fax: +1 (724) 449-3273 www.vizaar-na.com info@vizaar-na.com...
  • Page 4 ® viZaar is not liable under any circumstances for Warning against life- the consequences of misinterpretation or faulty threatening...
  • Page 5 WARNING The device must never be opened by the user at any place. Life-threatening electric currents are used or generated in the device; in particular, the device must never be used with the housing open. The device must never be used when there are audibly loose parts inside the device.
  • Page 6 WARNING The device must be checked annually by the manufacturer or an authorized third party for compliance with the electrical safety instructions obligatory at the usage site and conformance with the as-delivered condition of the device. The device must not be connected to the electric supply mains or otherwise operated after the ascertainment of a defect or any deviation from the as-delivered condition.
  • Page 7 Avoid direct exposure to sunlight for long periods of time. ® Exclusively the viZaar accessory articles or spare parts described in this instructions manual may be used in connection with the device. Always consult and follow the national and international operations and safety regulations, Norms or regulatory authority’s...
  • Page 8 WARNING The device can be connected to the public electric supply mains through a ‘IEC-plug lead’ included in the delivery or a ‘IEC-plug lead’ which complies with the local socket standards. The system accepts faultlessly all power supplies known worldwide with alternate currents of 96 VAC to 246 VAC at 46 to 60 Hz.
  • Page 9 WARNING Never connect a triploar plug to a bipolar socket! Avoid any contact between the device (and all working equipment) and components carrying electrical charges. The video probe of the device must never be used in or in the vicinity of apparatus or equipment, which are partly or fully energized by electric current of any type (e.g.
  • Page 10 WARNING Never bring the probe in contact with corrosive substances of any kind (acid or alkali). Risk of damage and injury while manipulating the probe. Never bring the probe in contact with solvent containing liquids! Risk of damage! Never insert the probe in plant parts the contents of which are unknown! Never insert the probe in plant parts, if weld or cutting work is being undertaken simulta-...
  • Page 11 WARNING Do not use the probe for transporting the system! This can damage your probe! To transport the system use the handle on the control unit. Do not insert the insert tube into any flammable gas or liquid (such as a fuel tank) to avoid dangers.

  • Page 12: Table Of Contents

    CONTENT STRUCTURE AND START-UP Scope of delivery Removal from the transport case Specifications Initial operation Mounting the protection ring Flashback recording Changing the tip adapter Changing the batteries OPERATION - USER INTERFACE - DOCUMENTATION Introduction Setup Operation menu Text generator menu File manager OPTIONAL ACCESSORY EQUIPMENT Optional tip adapters...

  • Page 13: Structure And Start-Up

    STRUCTURE AND START-UP Scopy of delivery Removal from the transport case Specifications Initial operation Mounting the protection ring Flashback recording Changing the tip adapter Changing the batteries...

  • Page 14: Scope Of Delivery

    1 STRUCTURE AND START-UP 1.1 Scope of delivery Scope of delivery: ® VUCAM with standard straight view 45° Protection ring Two field replacable batteries Power supply ® Power supply to VUCAM adapter SD card 8 GB (FAT32 formated) ® Hard copy VUCAM XO manual Transport &...
  • Page 15 1 STRUCTURE AND START-UP Optional accessory For further information on optional accessory please refer to chapter “3 Optional accessory“: Tip adapter straight view: DOV 0°, FOV 100° 10 Tip adapter side view (close focus): DOV 90°, FOV 100° 11 Tip adapter side view (far focus): DOV 90°, FOV 45°...

  • Page 16: Removal From The Transport Case

    1 STRUCTURE AND START-UP 1.2 Removal from the transport case Before opening the transport case, check the container for possible transport damages. Dimensions: (H) 515 x (W) 395 x (D) 190 mm; PE; Weight empty: 3,3 kg. 1 Carry handle 2 Pull here to open the transport case NOTE! Open the transport case in the correct position! Opening the transport case in...
  • Page 17 1 STRUCTURE AND START-UP VUCAM ® Optional tip adapters Two field replacable batteries Optional battery charger Power supply SD card 8 GB (FAT32 formated) ® Hard copy VUCAM XO manual NOTE! Store the video probe correctly! Do not store the the probe with sharp bends! Possible damage to the probe and the probe head! NOTE! Please check the correct position of the probe before closing the transport case.
  • Page 18 1 STRUCTURE AND START-UP Memorize the location of each part during removal to proceed later in reverse sequence when storing the system again. 1 LCD touch screen 2 White balance 3 Digital image capture 4 Digital video capture 5 File management / last captured file 6 Setup 7 Illumination - 8 Illumination +...
  • Page 19 1 STRUCTURE AND START-UP Possible ways to use the system Neck strap For the mounting of the optional shoulder strap refer to picture 1.1d. Connect the third shoulder strap connection to the Connect the neck strap here wrist loop. 1.1d Horizontal position The special construction of the VUCAM ®...
  • Page 20 1 STRUCTURE AND START-UP Mounted to tripod Use the “ tripod connection for operation with a standard tripod. Mounted to a magic arm ® Use the “ mounting to operate the VUCAM XO system mounted to a magic arm.

  • Page 21: Specifications

    1 STRUCTURE AND START-UP 1.3 Specifications Probe Working length 2.2 m / 7.2 ft. 3.3 m / 10.8 ft. 6.6 m / 21.6 ft. Diameter 6.0 mm / 0.23“ 6.0 mm / 0.23“ 6.0 mm / 0.23“ Articulation 130° 120° 100°...
  • Page 22 1 STRUCTURE AND START-UP Functions Text is displayed and captured outside of the inspection image, thus not covering any application detail. Text annotation Text is captured with image and video recording, printer friendly text formats available. Touch screen menu, handpiece controls, multiple language options, real time image brightness, Menu contrast, saturisation, color control;...

  • Page 23: Initial Operation

    1 STRUCTURE AND START-UP Confirm the white balance. The white balance 1.4 Initial operation symbol flashes while performing. Before starting the system, choose operation with batteries or power supply. For operation with power supply, connect the power supply to the connection cable.

  • Page 24: Mounting The Protection Ring

    1 STRUCTURE AND START-UP To return to the operation menu and continue ATTENTION! Never use the probe without the your inspection, press protection ring! Operation without the protection ring may damage the probe! To mount the protection ring to the probe head (double thread protection), follow further instructions: NOTE! Do not store the device in low temperature environment! If stored in...

  • Page 25: Flashback Recording

    1 STRUCTURE AND START-UP ATTENTION! Due to small dimensions, the 1.6 Flashback recording threads of the probe and the protection ring / tip adapters are very delicate. To prevent Many areas of interest are passed by while inspec- any damage, pay attention to dirt in the threads! ting.
  • Page 26 1 STRUCTURE AND START-UP 2. Turn the mounting support gently until you hit 5. Make sure the pins of the battery mounting fit ® the stopper. the insertion of the VUCAM XO system. 3. Now, push the mounting support on its sides and make a full turn.

  • Page 27: Operation - User Interface - Documentation

    OPERATION - USER INTERFACE - DOCUMENTATION Introduction Setup 2.2.1 File manager 2.2.2 Video in 2.2.3 Date & time configuration 2.2.4 Device 2.2.5 GUI configuration 2.2.6 Release SD card Operation menu 2.3.1 Flashback Buffer Recording 2.3.2 Buttons Text generator menu 2.4.1 Buttons File manager...

  • Page 28: File Manager

    2 OPERATION - USER INTERFACE - DOCUMENTATION 2.1 Introduction 2.2.1 File manager Take a moment to prepare and get the most out of your system. Before using the device you should configure it to your individual demand. Choose your language, set the date and time, and configure the view settings.

  • Page 29: Date & Time Configuration

    2 OPERATION - USER INTERFACE - DOCUMENTATION 2.2.3 Date & time configuration 2.2.4 Device This chapter contains the configuration of date & Enter the menu for following settings: time. Set year, month, day, hour, minute & second. A) Set time, date and time/date format A) Format SD card B) System status Browse through the settings with...

  • Page 30: Gui Configuration

    2 OPERATION - USER INTERFACE - DOCUMENTATION System status Reset to default settings Check the status of your software version, your sd Set all your individual settings back to default settings. card capacity or your battery status. Return without resetting or reset to defautl set- tings and turn off the system.

  • Page 31: Release Sd Card

    2 OPERATION - USER INTERFACE - DOCUMENTATION 2.2.6 Release SD card Use this menu to correctly release the SD card. NOTE! Always release the SD card performing the „Release card“ menu! Releasing the SD card without performing via specific menu might damage the SD card and/or the data! To release the SD card, confirm with To return without releasing the SD card, press...

  • Page 32: Operation Menu

    2 OPERATION - USER INTERFACE - DOCUMENTATION 2.3 Operation menu When turning on the device, your system will start with the operation menu. 1 White balance 2 Digital image capture 3 Digital video capture 4 File management / last captured file 5 Setup 6 Illumination - 7 Illumination +...

  • Page 33: Buttons

    2 OPERATION - USER INTERFACE - DOCUMENTATION 2.3.2 Buttons Press White Balance to adjust the inspection White balance image before recording. Press Image Recording to freeze the image. Image recording Press again to record an image. Press Video Recording to start recording a digital video.
  • Page 34 2 OPERATION - USER INTERFACE - DOCUMENTATION On: Press button for min. 2 seconds. On / Off Off: Press button for min. 2 seconds. Eliminate revisits with Flashback Buffer Recording. Many areas of interest are passed Flashback by while inspecting. By the time deficiency is recording realized, revisits are needed for analysis and documentation.

  • Page 35: Text Generator Menu

    2 OPERATION - USER INTERFACE - DOCUMENTATION 2.4 Text generator menu You can add text information to your inspection results. To enter the text generation menu, press the text area (10). 1 Shift 2 Space 3 ALT 4 Delete previous character 5 Confirm 6 Up 7 Down...

  • Page 36: Buttons

    2 OPERATION - USER INTERFACE - DOCUMENTATION 2.4.1 Buttons Press Shift to enter the layer with capital Shift letters Press ALT to enter the layer with special characters. Delete previous Press Delete Previous Character to delete character the last character typed on the keyboard. Confirm your text or text change with Confirm Confirm and enter the operation menu.

  • Page 37: File Manager

    2 OPERATION - USER INTERFACE - DOCUMENTATION 2.5 File manager Enter the File Manager to get an overview of all captured files (images and videos). Press to select the file. Then press to open the file. If you want to delete an inspec- tion file, press To exit the File Manager press By choosing a image / video, the File Manager...

  • Page 38: Optional Accessory Equipment

    OPTIONAL ACCESSORY EQUIPMENT Optional side tip adapter Optional car charger Optional battery pack Optional neck strap...

  • Page 39: Optional Car Charger

    3 OPTIONAL ACCESSORY EQUIPMENT ATTENTION! The change of the tip adapters 3.1 Optional side tip adapter must be performed by briefed personnel only! To change the tip adapter remove the protection ATTENTION! Do not use force to screw the tip ring from the probe head.

  • Page 40: Optional Neck Strap

    3 OPTIONAL ACCESSORY EQUIPMENT 2. Take note that the charging option is on „LiFePo“. Li-FeP NOTE! Charging the batteries with other options than “Li-FeP“ can damage the batteries! NOTE! Remove the batteries before longer breaks or longer storage. Never store the system with fully discharged batteries! NOTE! IATA classification of the batteries: UN 3481 Lithium ion batteries packed with...

  • Page 41: Maintenance, Care & Repair

    MAINTENANCE, CARE & REPAIR Maintenance by the manufacturer Cleaning of the system Transport Customer service...

  • Page 42: Maintenance By The Manufacturer

    :: Safety check according to accident protection regulations and VDE. :: Concluding report. viZaar industrial imaging AG VT repair service Use holidays or the standstill time between your Hechinger Straße 152 inspections and send in the system for check ups...

  • Page 43: Warranty, Technical Data & Confirmity

    WARRANTY, TECHNICAL DATA & CONFIRMITY Warranty 5.1.1 Exluded from the warranty regulation 5.1.2 Special fabrications are subject to a special warranty agreement General device specifications 5.2.1 Device dimensions 5.2.2 Operating conditions 5.2.3 General system data 5.2.4 Camera / camera head Disposal of the device after end of life-expectancy Confirmation of CE confirmity...

  • Page 44: Warranty

    5 WARRANTY, TECHNICAL DATA & CONFIRMITY 5.1 Warranty 5.1.1 Excluded from the warranty regulation ® viZaar warranties, that all video endoscope system :: Wear and tear parts like, steering components are free of faults to the specifications cables, braid work, cable pulls and light fibres.

  • Page 45: Disposal Of The Device After End Of Life-Expectancy

    ® All the devices of viZaar described in this instructions ® manual shall be taken back for disposal by viZaar without any time-limit and free of cost if desired by the legitimate possessor. viZaar ® shall not pay for the costs of delivery.
  • Page 46 AFFIX...
  • Page 47 QUALITY STANDARDS Quality is the focus o our activities! To provide you with the most innovative and reliable products and services in constant high quality we work on continues improvements in all aspects of our business. This is an ongoing process involving all staff and processes guided and certified by experts.
