Summary of Contents for ADB Safegate RELIANCE Navigator
- Page 1 ADB SAFEGATE RELIANCE Navigator Installation and Operation ™ Manual Airport Lighting Control System User Manual 96A0363, Rev. i, 2019/10/31...
- Page 3 Where applicable, per FAA EB67 (applicable edition), ADB SAFEGATE L858(L) Airfield Guidance Signs are warranted against electrical defects in design or manufacture of the LED or LED specific circuitry for a period of 4 years. ADB SAFEGATE LED light fixtures (with the exception of obstruction lighting) are warranted against mechanical and physical defects in design or manufacture for a period of 12 months from date of installation;...
- Page 4 This manual could contain technical inaccuracies or typographical errors. ADB SAFEGATE BVBA reserves the right to revise this manual from time to time in the contents thereof without obligation of ADB SAFEGATE BVBA to notify any person of such revision or change. Details and values given in this manual are average values and have been compiled with care. They are not binding, however, and ADB SAFEGATE BVBA disclaims any liability for damages or detriments suffered as a result of reliance on the information given herein or the use of products, processes or equipment to which this manual refers.
-
Page 5: Table Of Contents
2.0 ADB Safegate Navigator................................. 5 2.1 About this manual........................................5 2.1.1 How to work with the manual................................... 5 2.2 ADB Safegate RELIANCE Navigator Airport Lighting Control System....................5 2.2.1 Airport Lighting Control System................................5 2.2.2 Terms and Abbreviation....................................8 2.2.3 Associated Drawings and Documents..............................8 2.2.4 Components........................................ - Page 6 ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ TABLE OF CONTENTS Copyright ADB Safegate, All Rights Reserved ©...
-
Page 7: Safety
1.0 Safety Introduction to Safety This section contains general safety instructions for installing and using ADB SAFEGATE equipment. Some safety instructions may not apply to the equipment in this manual. Task- and equipment-specific warnings are included in other sections of this manual where appropriate. -
Page 8: Introduction To Safety
ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ Safety 1.1.1 Introduction to Safety CAUTION Unsafe Equipment Use This equipment may contain electrostatic devices, hazardous voltages and sharp edges on components • Read installation instructions in their entirety before starting installation. -
Page 9: Material Handling Precautions: Storage
Allow only qualified personnel to make repairs. Repair or replace the malfunctioning component according to instructions provided in its manual. Failure to follow these instructions can result in death or equipment damage 96A0363, Rev. i, 2019/10/31 Copyright ADB Safegate, All Rights Reserved ©... -
Page 10: Material Handling Precautions, Esd
ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ Safety 1.1.6 Material Handling Precautions, ESD CAUTION Electrostatic Sensitive Devices This equipment may contain electrostatic devices • Protect from electrostatic discharge. • Electronic modules and components should be touched only when this is unavoidable e.g. soldering, replacement. -
Page 11: Adb Safegate Navigator
The standard ADB SAFEGATE Navigator system consists of one Touchscreen/ Panel PC and one PLC cabinet. It controls up to 18 airfield devices, such as CCRs, beacons, REILs, PAPIs, and floodlights. In addition, the Navigator has dedicated contact points to monitor if utility and/or generator is available or on-line. - Page 12 Intuitive user interface provides buttons that lead air traffic controllers through lighting control tasks • The ADB SAFEGATE Navigator can be remotely controlled using an L-854 Radio Control, photocell or phone dial-in device • A static airfield touchscreen graphic (.png file) can be added •...
- Page 13 Stainless Steel Enclosure (H × W × D) 41.75 × 35.75 × 10.75 – in (106.0 × 90.8 × 27.3 – cm) Figure 1: Typical Preset Lighting Page (Shown with optional static graphic) 96A0363, Rev. i, 2019/10/31 Copyright ADB Safegate, All Rights Reserved ©...
-
Page 14: Terms And Abbreviation
ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ ADB Safegate Navigator Figure 2: Typical Runway Lighting Page (Shown with “pop up” button configuration option) 2.2.2 Terms and Abbreviation Term / Abbreviation Description ALCS Airfield Lighting Control System ALCMS Airfield Lighting Control and Monitoring System... -
Page 15: Components
Serial cable, 9 feet (3 m) Other optional components may also be delivered with the system. These components may include: • ALL-in-One Touchscreen Computer with RELIANCE NAVIGATOR software for a remote location • Current sensing devices 96A0363, Rev. i, 2019/10/31... -
Page 16: Inspect Delivered Items
ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ ADB Safegate Navigator • Communication extension equipment • UPS (Uninterruptible Power Supply) Figure 3: Main components 2.2.5 Inspect Delivered Items Inspect the carton and contents for any signs of damage. Notify ADB if any parts are missing or damaged. -
Page 17: Installation
Provide adequate clearance around the cabinet for connecting control and power cables. Enough clearance must be left in front of the cabinet to open the door safely for service. See Drawing 44A7675-01 for dimensions, mounting details, and suggested mounting height. 96A0363, Rev. i, 2019/10/31 Copyright ADB Safegate, All Rights Reserved ©... -
Page 18: Wiring Considerations
Figure • Connect the other end to the network cable in the RELIANCE NAVIGATOR cabinet, as shown in Figure • For connection using communication extension equipment, please refer to the print package for connection details. -
Page 19: Wiring From Ccrs
If a relay is used, the coil of the relay is wired to the controllable element to provide a contact closure of the source voltage back to the PLC. CCR Current sensing/monitoring relay kits can be separately ordered from ADB Airfield Solutions. 96A0363, Rev. i, 2019/10/31 Copyright ADB Safegate, All Rights Reserved ©... -
Page 20: Wiring For Controllable Element Points
TB3 (labeled Remote Control IO) holds the connections for an L-854 Pilot Control Radio (PRC) and photocell, if used. Depending on the type of radio or photocell that is being connected to the RELIANCE NAVIGATOR, an array of contact closure relays will need to be added for the system to read these inputs correctly. If the PCR or photocell is a contact closure, the relay can be sourced (24V DC) from the power block to the right of the remote control inputs. -
Page 21: Wiring Notes For Separate B1/B10 Control
The PLC cabinet requires 120V or 230V AC input power. Power wiring is connected to TB1 as shown in Drawing 43A4582-13. Use only 14 AWG NEC approved 600-volt wire. 96A0363, Rev. i, 2019/10/31 Copyright ADB Safegate, All Rights Reserved ©... - Page 22 ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ Installation Copyright ADB Safegate, All Rights Reserved ©...
-
Page 23: Operation
System ™ This section describes how to start and use the Touchscreen application to control the RELIANCE NAVIGATOR . The Touchscreen program should be running whenever operators need to control the configured CCRs, beacon and other items. The program may be stopped for computer maintenance or airport closure. -
Page 24: Overview Of The Touchscreen
ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ Operation 4.2 Overview of the Touchscreen The layout of buttons and the general screen appearance vary according to the options selected during the Primary Configuration process. The example below in Touchscreen Overview shows the main parts of the screen; the exact location and appearance of some buttons may differ for your configuration. -
Page 25: Choosing A Page To View
The Control buttons allow you to turn any controllable item on or off (CCR, Beacon, Generator, etc). The primary Control button displays the item name and its current status. The display differs according to the button style selected during Primary Configuration: Popup or Push Button. 96A0363, Rev. i, 2019/10/31 Copyright ADB Safegate, All Rights Reserved ©... -
Page 26: Popup Style
ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ Operation 4.4.1 Popup Style Figure 10: CCR Control Page The Popup style layout, shown in Figure 10, displays the Control buttons for all items in the bottom left corner of the screen, with a single button for each configured item. -
Page 27: Push Button Style
4.5 Using the Preset Buttons If presets were configured the navigation buttons will include a PRESET PAGE button to display the configured presets in the lower portion of the window. 96A0363, Rev. i, 2019/10/31 Copyright ADB Safegate, All Rights Reserved ©... - Page 28 ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ Operation To use the preset buttons: • Touch the Preset page navigation button at the top of the window to display the configured preset buttons in the lower portion of the window, as shown below in...
-
Page 29: Using The Alarm Ack Button
The touchscreen displays an alarm when the feedback to the General Fault NAVIGATOR represents any type of overall fault in the item. Note If the ALARM ACK button is grey, the system is normal with no current alarms. 96A0363, Rev. i, 2019/10/31 Copyright ADB Safegate, All Rights Reserved ©... -
Page 30: Alarm Annunciation And Logging
ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ Operation 4.6.1 Alarm Annunciation and Logging When the NAVIGATOR detects an alarm condition: • The ALARM ACK button blinks red and the audible alarm sounds (or the external speakers, if provided) until the current alarm is acknowledged. - Page 31 When you are ready, touch the CLEAN SCREEN button at the top of the window, typically on the PRESET PAGE, if used. Figure 15: Clean Screen Button After the Clean Screen button is touched, the screen display changes to the following: 96A0363, Rev. i, 2019/10/31 Copyright ADB Safegate, All Rights Reserved ©...
-
Page 32: System Passwords
ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ Operation Figure 16: Clean Screen View • Notice the “Time remaining” bar at the bottom of the page. Once the bar fills, the display automatically returns to the last page viewed with all buttons reactivated. - Page 33 The Touchscreen application closes and the display returns to the Windows desktop. • Lights will go to a hardware failsafe, unless the PLC panel switch is set to bypass failsafe. 96A0363, Rev. i, 2019/10/31 Copyright ADB Safegate, All Rights Reserved ©...
- Page 34 ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ Operation Copyright ADB Safegate, All Rights Reserved ©...
-
Page 35: Parts
1 = Internal mounting of second PC Notes • All fiber optic cables should be terminated with ST style connectors. Fiber optic cable and connectors not pro vided by ADB SAFEGATE . PLC cabinet must be within 9 of Touchscreen/PC. - Page 36 ADB SAFEGATE RELIANCE Navigator Installation and Operation Manual ™ Parts Copyright ADB Safegate, All Rights Reserved ©...
-
Page 37: Support
Table 5: ADB SAFEGATE Support Live Technical Support - Americas If at any time you have a question or concern about your product, just contact ADB SAFEGATE’s technical service department. Trained in all areas of system issues, troubleshooting, quality control and technical assistance, our highly experienced Technical support specialists are available 24 hours a day, seven days a week to provide assistance over the phone. -
Page 38: Recycling
A.2.1 Local authority recycling The disposal of ADB SAFEGATE products is to be made at an applicable collection point for the recycling of electrical and electronic equipment. The correct disposal of equipment prevents any potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling. - Page 39 Tel.: +46 (0)40 699 17 00, Internet: www.adbsafegate.com Fax: +46 (0)40 699 17 30 ADB SAFEGATE Airfield Technologies Ltd. China ADB SAFEGATE, China: Unit 603, D Block, CAMIC International Convention Center, No 3, Hua Jia Di East road, ChaoYang district, Beijing 100102 P.R.
