Communications Specialties' Fiberlink® Card Cage
Fiberlink®
5018A
Universal Data Transceiver
for the Fiberlink® 6000A Card Cage
User's Manual
The Fiberlink® 5018A Universal
Data Transceiver digitally
transmits RS-232/422/485
data over multimode or single
mode fiber at 850 or 1310 nm. It
transmits and receives all standard
data-related signals in accordance
with EIA specifications. The
5018A is suitable for simplex,
full duplex and drop-and-repeat
operation, making it ideal for
Data Acquisition, Intelligent
Transportation, Industrial and
Manufacturing applications.
World Headquarters
55 Cabot Court
Hauppauge, New York 11788 USA
Tel:
(631) 273-0404
Fax: (631) 273-1638
info@commspecial.com
Asia
Communications Specialties Pte Ltd
100 Beach Road
#22-09 Shaw Tower
Singapore 189702
Tel:
+65 6391 8790
Fax: +65 6396 0138
csiasia@commspecial.com
commspecial.com
Advertisement
Table of Contents
Related Manuals for CSI Fiberlink 5018A
Summary of Contents for CSI Fiberlink 5018A
- Page 1 User’s Manual Communications Specialties’ Fiberlink® Card Cage The Fiberlink® 5018A Universal Data Transceiver digitally transmits RS-232/422/485 data over multimode or single mode fiber at 850 or 1310 nm. It transmits and receives all standard data-related signals in accordance with EIA specifications. The 5018A is suitable for simplex, full duplex and drop-and-repeat operation, making it ideal for...
-
Page 2: Table Of Contents
Contents Fiberlink® 5018A Contents Welcome ............... . 3 Features. -
Page 3: Welcome
Welcome | Features | Package Contents Fiberlink® 5018A Welcome Thank you for purchasing Communications Specialties, Inc. ’ s Fiberlink® 5018A. The 5018A transmits and receives all standard data-related signals in accordance with EIA specifications. The 5018A is suitable for simplex, full duplex and drop-and-repeat operation, making it ideal for Data Acquisition, Intelligent Transportation, Industrial and Manufacturing applications. -
Page 4: Quick Installation
Quick Installation Fiberlink® 5018A Quick Installation Guide The following is a quick installation guide for the 5018A model. It is intended for users familiar with the installation of fiber optic transmission systems to get “up and running” in minimal time. Since these units are capable of being configured for operation in many different modes, we strongly suggested that you consult the appropriate sections of this manual. -
Page 5: Technical Specifications
Technical Specifications Fiberlink® 5018A General Information The Universal Data Transceiver is fully compatible with EIA standards for RS-232, RS-422 and RS-485 at data rates from 0 (DC) to 2.1 mbps (200 kbps for RS-232) in the low speed mode or from 10 kbps to 10 mbps in the high speed mode. It may be used for simplex or full duplex asynchronous transmissions in both point-to-point systems and drop-and-repeat data networks. -
Page 6: Operation Theory
Operation Theory Fiberlink® 5018A Theory of Operation The transmitting section of the universal data transceiver converts an incoming RS-232, RS-422 or RS-485 signals into pulses of light at the transmitting LED located in the “Transmit (or Tx)” optical connector on the unit. These pulses of light equate to ON for a positive input level and OFF for a negative or zero input level. -
Page 7: Installation Instructions
Installation Fiberlink® 5018A Installation instructions There are no operating controls on the universal data transceiver. Simply set the mode of operation with the internal DIP switches and then connect the signal, power supply and fiber optic cables between the two units. Connect the data processing equipment to be used to the 6 position terminal block on the 5018A . -
Page 8: Signal And Power Connections
Signal and Power Connections Fiberlink® 5018A Signal and Power Connections The 5018A is designed to operate in any available position in a model 6000A cardcage. When installed, all operating power is provided by the card-cage. The 5018A is ESD protected to + 10 kV on all inputs and outputs. Data Connector Pin Out: Pin 6 Pin 5... -
Page 9: Chassis Ground
Signal and Power Connections Fiberlink® 5018A RS-485 2-Wire Signal Connections: Chassis Ground Transmit/Receive Data (+) (input/output) Transmit/Receive Data (-) (input/output) RTS Enable (when used) (input) All other terminal block positions should not be connected for this format. RS-485 4-Wire Signal Connections: Chassis Ground Transmit Data (+) (input) -
Page 10: Dip Switch Settings
DIP Switch Settings Fiberlink® 5018A Modes of Operation: On the 5018A card-cage model, there are three DIP switch banks located on the printed circuit card. Switch Bank S1 sets the Mode of Operation, Switch Bank S2 sets the Baud Rate (RS-485 Data Format) and Switch Bank S3 sets the Alarm. Setting the MODE DIP switch Switch setting example Switch ON (CLOSED) - Page 11 DIP Switch Settings Fiberlink® 5018A Use the following protocol-specific settings to finish configuring the MODE DIP switch on your universal data transceiver. RS-232 Point-to-Point (Factory-Default Setting) 1 through 6 Off See Page 10 Not Applicable O P E N O P E N Mode RS-232 Drop-and-Repeat See Page 10...
- Page 12 DIP Switch Settings Fiberlink® 5018A RS-422 Drop-and-Repeat Switch 6 ON See Page 10 120 Ohm Termination Switch 7 ON: data input Switch 8 ON: data output O P E N O P E N Mode When using this mode, any RS-422 driver not transmitting data must be in the “low” state (terminal block position 2, negative with respect to position 3).
- Page 13 DIP Switch Settings Fiberlink® 5018A RS-485 2-Wire Point-to-Point Data Derived T/R See Baud Rate See Page 10 settings on page 15 120 Ohm Termination Switch 7 ON: data line O P E N O P E N Mode RS-485 2-Wire Drop-and-Repeat Data Derived T/R See Baud Rate settings on page 15 See Page 10...
- Page 14 DIP Switch Settings Fiberlink® 5018A RS-485 4-Wire Drop-and-Repeat RTS Enable All Off See Page 10 120 Ohm Termination Switch 7 ON: data input Switch 8 ON: data output O P E N O P E N Mode In this mode, the input to terminal 6 must be “high” for the unit to transmit data and “low” to receive data. RS-485 4-Wire Point-to-Point Data-Derived T/R See Baud Rate See Page 10...
-
Page 15: T/R Time Settings (Baud Rate)
DIP Switch Settings Fiberlink® 5018A T/R Time (Baud Rate Settings) - Switch Bank S2 Baud Rate T/R Time 2400 4.73 ms 4800 2.20 ms 9600 1.10 ms 19.2K 620 us 38.4K 300 us 57.6K 180 us 76.8K 150 us 115.2K 110 us 2400 4800... -
Page 16: Alarm Switch Settings
Alarm Switch Settings | Optical Fiber | Indicator LEDs Fiberlink® 5018A Setting the ALARM DIP (Switch Bank S3) The third switch bank is used to set the user-configurable alarm feature that indicates the loss of a data signal. When enabled, the continuous loss of data for more than 1 second will be sensed and trigger this alarm. -
Page 17: Configuring A Ring Or Loop Data Bus
Configuring a Ring or Loop Data Bus Fiberlink® 5018A Configuring a Ring or Loop-Type Data Bus In addition to point-to-point transmissions, the universal data transceiver can be used to implement a ring or loop-type data bus. This is accomplished by setting the internal DIP switches as shown in the following diagram. - Page 18 Considerations Fiberlink® 5018A Operating Considerations forFiber Optic Cable The universal data transceiver may be supplied with ST or FCPC type optical connectors and will operate with most common fiber optic cables. However, it is important to use the correct type of fiber optic cable as required by your particular transceiver model. Some models (ending in -1 and -3) are designed for use at 850 nm, while others (ending in -7) function at 1300 nm.
-
Page 19: Operating Pointers
Operating Pointers | Troubleshooting Fiberlink® 5018A Operating Pointers Remember to check attenuation of the fiber optic cable. The system will only operate properly if these specifications fall within the range of the system’s loss budget. Troubleshooting Multimode fiber optic cable contains an optical fiber with a light carrying “core” that is only .0025 inches (62.5 microns) in diameter. -
Page 20: Maintenance And Repairs
Maintenance and Repairs | Certifications Fiberlink® 5018A Maintenance and Repairs The Fiberlink® 5018A Series has been manufactured using the latest semiconductor devices and techniques that electronic technology has to offer. They have been designed for long, reliable and trouble-free service and are not normally field repairable. Should difficulty be encountered, Communications Specialties maintains a complete service facility to render accurate, timely and reliable service of all products. -
Page 21: Warranty
CSI at the expense and risk of the Buyer. CSI’s obligation under this warranty will be limited, at its option, to either the repair or replacement of defective units, including free materials and labor. In no event shall CSI be responsible for any incidental or consequential damages or loss of profits or goodwill. -
Page 22: Accessories And Related Products
Accessories and Related Products Fiberlink® 5018A Fiberlink® 6610 Visible Light Source The Fiberlink® Visible Light Source provides a visible 650 nm laser output that can be used for identifying fiber breaks and individual fibers within fiber bundles, allowing for convenient, on-site testing of fiber networks during construction and maintenance procedures. - Page 23 Notes Fiberlink® 5018A Fiberlink® 5018A User’s Manual Page 23...
- Page 24 ©2010 Communications Specialties, Inc. All Rights Reserved. Fiberlink and the starburst logo are registered trademarks of Communications Specialties, Inc. CSI and the triangle designs are trademarks of Communications Specialties, Inc. P/N: 121459 Rev. F If y ©2005 Spectra Vision Productions, Inc.
