Service Manual
Refrigerator
MODEL : FN15AW
FN15GB
FN-15A3RNWU
Caution :
In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS Corp.
http : //svc.dwe.co.kr
S/M No. : FN15000010
SEP. 2010
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo FN15GB
Summary of Contents for Daewoo FN15GB
- Page 1 In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS Corp. http : //svc.dwe.co.kr SEP. 2010...
-
Page 2: Table Of Contents
CONTENTS 1. SPECIFICATION .......................2 2. EXTERNAL VIEW .....................3 3. WIRE DIAGRAM .......................4 4. NAME OF PARTS......................5 5. REFRIGERANT CYCLE DIAGRAM ................6 6. MACHINE ROOM VIEW AND PARTS LIST..............7 7. MAIN COMPONENTS ....................8 8. DOOR COLOR SPECIFICATION ................10 9. EXPLODED VIEW AND PARTSLIST ...............11... -
Page 3: Specification
SPECIFICATION **** Refrigerant i l o embossed Plat ì Roll Bondî type g i r i t a l a r - d l r i a i t n r f e l a r o r f i t a r a t &... -
Page 4: External View
EXTERNAL VIEW... -
Page 5: Wire Diagram
WIRE DIAGRAM FN15GB FN-15A3RNWU FN15AW... -
Page 6: Name Of Parts
NAME OF PARTS FN-15A3RNWU r cover e l t i r c f l e d i l r cover e l t i r c f l e d i l... -
Page 7: Refrigerant Cycle Diagram
REFRIGERANT CYCLE DIAGRAM EVAPORATOR DRYER COMPRESSOR... -
Page 8: Machine Room View And Parts List
MACHINE ROOM VIEW AND PART LIST BASE CABINET POWER BOX BRACKET EARTH... -
Page 9: Main Components
MAIN COMPONENTS 1.COMPRESSOR i r f 600a Voltage 220V/50Hz 220V/50Hz 220V/50Hz D40CY D43CY Comp model DU40CY 3953140720 Part Code 3953140760 3953140710 Start type RSIR RSIR RSCR 2. RELAY ASSEMBLY i r f R600a 220V/50Hz 220V/50Hz 220V/50Hz Voltage QP2-15C,B28-120 Spec QP2-15,B28-120 QP2-15,B35-120 450V/2uF Part Code... - Page 10 MAIN COMPONENTS POWER CORD SPECIFICATION SHAPE OF POWER CODE PART CODE DESCRIPTION REMARK 3011300321 CP-2PIN 4017J17101 CP-2PIN 4006D17101 KP-30 3011304520 DKP-301U 401PD17101 KP-211 3011316201 BP-3PIN 3011300971 FOR SWISS #267 3011303020 FOR OTHER CONURTY 3011316101 FOR ISRAEL 3011303901 FOR EUROPEAN&SAUDI 3011303921 FOR SINGAPORE BS-1363A 3011303040...
-
Page 11: Door Color Specification
DOOR COLOR SPECIFICATION 1. ASSEMBLY URETHAN DOOR R600a Refrigerant BLACK WHITE Material Normal PCM GLASS GLASS PFTT00D275 PFTT00D270 PFTT00D260 Part Code... -
Page 12: Exploded View And Partslist
EXPLODED VIEW AND PARTS LIST 1. FN15GB FN-15A3RNWU... - Page 13 EXPLODED VIEW AND PARTS LIST CAUTION : In this Service Manual, some parts can be changed for improving their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List)in Service information Center(http://svc.dwe.co.kr)
- Page 14 EXPLODED VIEW AND PARTS LIST 2. FN15AW...
- Page 15 EXPLODED VIEW AND PARTS LIST CAUTION : In this Service Manual, some parts can be changed for improving their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Part s Price List)in Service information Center(http://svc.dwe.co.kr)
- Page 16 DAEWOO ELECTRONICS Corp. 1-2.JEO-DONG L-GA,JOONG-GN SEOUL, KOREA...
