- Page 1 USE AND MAINTENANCE MANUAL Water-oil series M Brazed plates Heat exchanger M 18 – 25 – 55...
-
Page 2: Table Of Contents
Water-oil series M USE AND MAINTENANCE Heat exchanger MANUAL Brazed plates INDEX INTRODUCTION ..................3 WARNINGS .................... 3 ASSEMBLY AND INSTALLATION ............4 TECHNICAL SPECIFICATIONS OF USE ..........6 PERIODIC MAINTENANCE ..............7 TAMPERING ..................8 STORAGE ....................8 DISPOSAL ..................... 8... -
Page 3: Introduction
Water-oil series M USE AND MAINTENANCE Heat exchanger MANUAL Brazed plates INTRODUCTION This manual should be considered an integral part of the heat exchanger and should be kept with it. Keep this manual intact and available for the whole product life. Carefully read the manual before installation of the heat exchanger. -
Page 4: Assembly And Installation
Water-oil series M USE AND MAINTENANCE Heat exchanger MANUAL Brazed plates Do not touch the heat exchanger while it is running. During operation, some external surfaces may be hot. Do not remove the nameplate of the heat exchanger. It reports the product specifications and contractual references that allow the traceability of the same. - Page 5 Water-oil series M USE AND MAINTENANCE Heat exchanger MANUAL Brazed plates outlet oil rates are variable. In this way, it is possible to obtain a better thermal performance. In the hydraulic systems it is possible the occurrence of pressure peaks (fluid hammers) that could approach or exceed the maximum allowable pressure of the exchanger.
-
Page 6: Technical Specifications Of Use
Water-oil series M USE AND MAINTENANCE Heat exchanger MANUAL Brazed plates TECHNICAL SPECIFICATIONS OF USE 225°C • Hot fluid inlet max. temperature: -160°C • Cold fluid inlet min. temperature: Mineral oil Synthetic oil • Operating fluids: Emulsified water Water- Ethylene glycol 30 bar •... -
Page 7: Periodic Maintenance
Perform this cleaning at regular intervals. During this operation, Costante Sesino S.p.A. recommend to comply with the anti-pollution standards and to use the appropriate services for the collection of waste oil. -
Page 8: Tampering
1 mm do not cause any malfunction. TAMPERING Any operation aimed to modify the heat exchanger, executed without prior authorization from the Constante Sesino S.p.A. will automatically result in the decline of the warranty provisions. STORAGE The heat exchanger has to be stored in a moisture free environment (<60%) and at a...
