- Page 1 USE AND MAINTENANCE MANUAL Air-oil series AP EMX Heat exchanger AC fan motor – ATEX 300 EMX – 300/2 EMX – 430 EMX – 430/2 EMX – 494 EMX – 580 EMX – 680 EMX – 730 EMX – 830 EMX – 2/680 EMX – 2/730 EMX – 2/830 EMX – 3/830 EMX...
-
Page 2: Table Of Contents
Air-oil series AP EMX USE AND MAINTENANCE Heat exchanger MANUAL AC fan motor - ATEX INDEX INTRODUCTION..................3 WARNINGS .................... 4 ASSEMBLY AND INSTALLATION ............5 AIR-OIL HEAT EXCHANGER SCHEME ..........6 TECHNICAL SPECIFICATION OF USE ..........7 CHECK AFTER INSTALLATION ............. 8 PERIODIC MAINTENANCE .............. -
Page 3: Introduction
AC fan motor - ATEX INTRODUCTION The air-oil heat exchangers AP EMX series are designed and constructed for the oil cooling (or other fluid, compatible with used materials, see paragraph 5), obtained by conveying air via fan through a radiator. -
Page 4: Warnings
Air-oil series AP EMX USE AND MAINTENANCE Heat exchanger MANUAL AC fan motor - ATEX laws, rules and regulations in force in the country where the equipment is commissioned. The information required for proper use of the heat exchangers described in this manual, are completed by the information in the user manual and maintenance of the fan. -
Page 5: Assembly And Installation
Air-oil series AP EMX USE AND MAINTENANCE Heat exchanger MANUAL AC fan motor - ATEX After having installed the exchanger please run a trial in order to test the proper installation and functioning. In case of negative results disconnect the heat exchanger from the current and contact the present writer for the appropriate assistance operations. -
Page 6: Air-Oil Heat Exchanger Scheme
Air-oil series AP EMX USE AND MAINTENANCE Heat exchanger MANUAL AC fan motor - ATEX AIR-OIL HEAT EXCHANGER SCHEME ELECTRIC MOTOR IMPELLER RADIATOR CORE FRAME... -
Page 7: Technical Specification Of Use
Warning: These pulsations move inside the oil at the sound velocity, therefore they cannot be gauged with standard manometers, but only with a proper electronic instrumentation. The maximum static pressure allowed by Sesino heat exchangers is 20 bar and the test pressure is 35 bar. -
Page 8: Check After Installation
Before connecting the exchanger to the circuit, make sure that all the dirt and detergent leftovers had been removed. While carrying this process Costante Sesino S.p.A urges you to respect the anti-pollution regulation and to use the proper services for the exhaust oils disposal. -
Page 9: Tampering
TAMPERING Any operation aimed to modify the heat exchanger, executed without prior authorization from the Costante Sesino S.p.A. will automatically result in the decline of the warranty provisions. STORAGE The heat exchanger has to be stored in a moisture free environment (<60%) and at a temperature (from 5°C to 30°C) such as to prevent condensation and oxidation to its... -
Page 10: Additional Warnings
The additional instructions, which are given below, derive from residual risks of the risk analysis carried out by Costante Sesino S.p.A. and from warnings of the use and maintenance manual of the fan that have not been resolved and managed because the installer and/or end user are responsible for their resolution. - Page 11 (the temperature of which is certainly below 135°C as labelled T4), therefore avoiding the explosive atmosphere ignition. COSTANTE SESINO SPA Heat exchangers www.sesino.com Via Monza 150A/B, 20060 Gessate – Milano (Italy) Tel.
