Technical
Description
APCIe-7300, APCIe-7420, APCIe-7500 and APCIe-7800
1-port, 2-port, 4-port and 8-port serial interface
Edition: 02.06-09/2019
DIN EN ISO 9001:2015 certified

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APCIe-7300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Addi-Data APCIe-7300

  • Page 1 Technical Description APCIe-7300, APCIe-7420, APCIe-7500 and APCIe-7800 1-port, 2-port, 4-port and 8-port serial interface Edition: 02.06-09/2019 DIN EN ISO 9001:2015 certified...
  • Page 2 The content of this manual and the technical product data may be changed without prior notice. ADDI-DATA GmbH reserves the right to make changes to the technical data and the materials included herein.
  • Page 3: Warning

    If the instructions are ignored, the board, the PC and/or peripherals may be destroyed. WARNING! Designates a possibly dangerous situation. If the instructions are ignored, the board, the PC and/or peripherals may be destroyed and persons may be endangered. www.addi-data.com...
  • Page 4: Table Of Contents

    Block diagrams ..........................32     Return or disposal......................35     Return .............................35     Disposal of ADDI-DATA waste equipment...................36     Technical data and limit values ..................37     Electromagnetic compatibility (EMC) ...................37     Mechanical structure ........................37  ...
  • Page 5 Table 2-2: Plug-in modules and their transmission standards..............10   Table 3-1: APCIe-7500: Pin assignment ....................15   Table 3-2: APCIe-7300, APCIe-7420, APCIe-7500/4C and breakout cables: Pin assignment ....16   Table 3-3: APCIe-7800: Pin assignment ....................17   Table 3-4: APCIe-7500, APCIe-7800 and breakout cables: Pin assignment..........20  ...
  • Page 6: Chapter Overview

    Tip: Print out this chapter to have help at hand for inserting and installing the board. Block diagrams of the boards Procedure for returning (repairing, etc.) or disposing of the board List of technical data and limit values of the board Appendix with glossary and index Contact and support address www.addi-data.com...
  • Page 7: Definition Of Application, User, Handling

    Please do not delete the identification numbers of the board or the warranty claim will be invalid. 1.2 User 1.2.1 Qualification Only persons trained in electronics are entitled to perform the following works: • Installation • Commissioning • • Maintenance. 1 APCIe-7xx0 = APCIe-7300, APCIe-7420, APCIe-7500 and APCIe-7800 www.addi-data.com...
  • Page 8: Country-Specific Regulations

    Manual and software download from the Internet The latest versions of the technical manual and the standard software for the APCIe-7xx0 board can be downloaded for free at: www.addi-data.com. NOTICE! Before using the board and in case of malfunction during operation, check if there is an update (manual, driver) available.
  • Page 9: Brief Description

    APCIe-7xx0 2 Brief description The boards APCIe-7300, APCIe-7420, APCIe-7500 and APCIe-7800 provide industrial PCs with one, two, four or eight asynchronous serial interfaces for the communication with external devices. The configuration of these communication boards is determined by SI modules, which are automatically detected by the boards.
  • Page 10: Table 2-2: Plug-In Modules And Their Transmission Standards

    1 Plug-in module SIxxx-G: The -G suffix stands for optical isolation. The SITTY module is always optically isolated. 2 The indicated maximum lengths apply to normal interface cables (shielded control lead, 0.14 mm²). The length is also limited by the number of users, line capacity, impedance and transfer rate. www.addi-data.com...
  • Page 11: Insertion And Installation Of The Board

    Unscrew the back cover from the selected slot. For this, follow the operating instructions provided by the PC manufacturer! Keep the back cover in a safe place. You will need it if you remove the board. Provide for potential equalisation. Take the board out of its protective packaging. www.addi-data.com...
  • Page 12: Replacing The Si Modules

    - Respect the combination options according to the intended use! - Follow the safety precautions! - Remove/fit the SI module carefully according to the following figures! Fig. 3-2: Removing an SI module Fig. 3-3: Fitting an SI module Wrong mounting protection www.addi-data.com...
  • Page 13: Inserting The Board

    Fasten the board to the rear of the PC housing using the screw which held the back cover in place. Fig. 3-5: PC housing: Fasten the board Tighten all loose screws. 3.1.5 Closing the PC Close the PC as described in the manual of the PC manufacturer. www.addi-data.com...
  • Page 14: Connecting The Accessories

    When installing the connection cable, ensure that it is placed a sufficient distance away from sensitive analog signals and that the distance from potential sources of interference such as frequency inverters, mains supplies, etc. is as large as possible. 3.2.1 Pin assignment 1) APCIe-7500 Fig. 3-6: APCIe-7500: 37-pin D-Sub male connector www.addi-data.com...
  • Page 15: Table 3-1: Apcie-7500: Pin Assignment

    (Rx+) (Rx+) Tx/Rx+ (Rx+) Anode (CTS-) Termination Termination UART 2 100 Ω 120 Ω (CTS+) (RTS-) Source (RTS+) Source (Rx-) (Rx-) Tx/Rx- (Rx-) Cathode (Tx+) (Tx+) (Tx+) Collector UART 3 (Tx-) (Tx-) (Tx-) Emitter (Rx+) (Rx+) Tx/Rx+ (Rx+) Anode www.addi-data.com...
  • Page 16: Fig. 3-7: Apcie-7300, Apcie-7420, Apcie-7500/4C And Breakout Cables: 9-Pin D-Sub Connector

    A cable connection between the resistor (RS422/RS485) and R activates the termination resistor. Termination 2) APCIe-7300, APCIe-7420, APCIe-7500/4C and breakout cables Fig. 3-7: APCIe-7300, APCIe-7420, APCIe-7500/4C and breakout cables: 9-pin D-Sub connector Table 3-2: APCIe-7300, APCIe-7420, APCIe-7500/4C and breakout cables: Pin assignment RS232 RS422...
  • Page 17: Fig. 3-8: Apcie-7800: 78-Pin D-Sub Female Connector

    (Rx+) (Rx+) Tx/Rx+ (Rx+) Anode (CTS-) Termination Termination UART 0 100 Ω 120 Ω (CTS+) (RTS-) Source (RTS+) Source (Rx-) (Rx-) Tx/Rx- (Rx-) Cathode (Tx+) (Tx+) (Tx+) Collector UART 1 (Rx+) (Rx+) Tx/Rx+ (Rx+) Anode (Tx-) (Tx-) (Tx-) Emitter www.addi-data.com...
  • Page 18 100 Ω 120 Ω (CTS+) (RTS-) Source (RTS+) Source (Rx-) (Rx-) Tx/Rx- (Rx-) Cathode (Tx+) (Tx+) (Tx+) Collector (Tx-) (Tx-) (Tx-) Emitter (Rx+) (Rx+) Tx/Rx+ (Rx+) Anode UART 4 (CTS-) Termination Termination 100 Ω 120 Ω (CTS+) (RTS-) Source www.addi-data.com...
  • Page 19 Emitter (Rx+) (Rx+) Tx/Rx+ (Rx+) Anode (CTS-) Termination Termination UART 7 100 Ω 120 Ω (CTS+) (RTS-) Source (RTS+) Source (Rx-) (Rx-) Tx/Rx- (Rx-) Cathode A cable connection between the resistor (RS422/RS485) and R activates the termination resistor. Termination www.addi-data.com...
  • Page 20: Connection Cable St075 (Apcie-7500)

    (Tx-) (Tx-) Emitter (Rx+) (Rx+) Tx/Rx+ (Rx+) Anode (CTS-) Termination Termination 100 Ω 120 Ω (CTS+) (RTS-) Source (RTS+) Source (Rx-) (Rx-) Tx/Rx- (Rx-) Cathode A cable connection between the resistor (RS422/RS485) and R activates the termination resistor. Termination www.addi-data.com...
  • Page 21: Connection Cable St7809 (Apcie-7800)

    The pin assignment is to be found in Chapter 3.2.1. 3.3 Connection examples 3.3.1 RS232 Fig. 3-10: RS232 wiring 1: Where the modem control signals are not used, they must be connected externally across a wire bridge. 3.3.2 RS422 Fig. 3-11: RS422 wiring www.addi-data.com...
  • Page 22: Rs485

    Insertion and installation of the board APCIe-7xx0 Fig. 3-12: RS422 with RTS/CTS signals as RS422 signals 3.3.3 RS485 Fig. 3-13: RS485 wiring www.addi-data.com...
  • Page 23: Tty (20 Ma Current Loop)

    If the transmitter provides the current, it is active. In this case, the receiver is passive. If the receiver supplies the current, it is active and the transmitter is passive. Fig. 3-14: Active transmission / active reception Fig. 3-15: Active transmission / passive reception www.addi-data.com...
  • Page 24: Driver Installation

    Information on how to select and download the appropriate driver can be found in the document “Quick installation PC boards” (see PDF link). The installation of drivers of the type “ADDI-DATA Multiarchitecture Device Drivers 32-/64-Bit for x86/AMD64” as well as the installation of the corresponding samples is described in the installation instructions (see PDF link).
  • Page 25: Board Configuration

    Fig. 3-18: Device Manager On the “FIFOs” tab, the following settings can be made (example under Windows 7): Fig. 3-19: FIFOs PCIe bus and device numbers Management of the transmit and receive buffers Data flow control Resets to the default settings www.addi-data.com...
  • Page 26: Fig. 3-20: Settings Example: Rs485

    RS 485 echo enable: Receiver control for the RS485 half-duplex communication Ticked: When data is sent from the board to the peripherals, the receiver is enabled on the board. Not ticked: When data is sent from the board to the peripherals, the receiver is disabled on the board. www.addi-data.com...
  • Page 27: Fig. 3-21: Settings Example: Tty (20 Ma Current Loop)

    APCIe-7xx0 board (receiver) and the peripheral peripheral device (receiver) in standby state device (transmitter) in standby state (no serial (no serial data stream) data stream) Ticked: Current flowing Ticked: Current flowing Not ticked: No current flowing Not ticked: No current flowing www.addi-data.com...
  • Page 28: Board Test

    The short-circuit plug is used to set up a connection between the output signals (data transmission) and the input signals (data reception) in order to test the serial communication. Fig. 3-22: Connection of the short-circuit plug (RS232) Fig. 3-23: Connection of the short-circuit plug (RS422) www.addi-data.com...
  • Page 29: Test Program "Mttty

    Fig. 3-25: Connection of the short-circuit plug (TTY) – passive transmission / active reception 3.6.2 Test program “MTTTY” The test program MTTTY is to be found on the supplied CD 1 “ADDI-DATA Standard Drivers”. Start the MTTTY test program by double-clicking on the file “Mttty_255.exe” in the CD 1 folder “Mttty”.
  • Page 30: Fig. 3-26: Mttty Main Window

    The handshake of the modem control signals according to your application can be configured as follows: In the MTTTY main window, click on the “Flow Control…” button. In the “Flow Control Settings” window, you can make the desired settings: www.addi-data.com...
  • Page 31: Fig. 3-27: "Flow Control Settings" Window

    4. In the MTTTY main window, under “Port”, select the right COM interface. 5. Connect the interface via the menu item "File/Connect". If after pressing any key (= send data or character), a character is displayed on the screen (= receive data or character), the board works correctly. www.addi-data.com...
  • Page 32: Function Description

    Function description APCIe-7xx0 4 Function description 4.1 Block diagrams Fig. 4-1: APCIe-7300: Block diagram Fig. 4-2: APCIe-7420: Block diagram www.addi-data.com...
  • Page 33: Fig. 4-3: Apcie-7500: Block Diagram

    Function description APCIe-7xx0 Fig. 4-3: APCIe-7500: Block diagram Fig. 4-4: APCIe-7500/4C : Block diagram www.addi-data.com...
  • Page 34: Fig. 4-5: Apcie-7800: Block Diagram

    Function description APCIe-7xx0 Fig. 4-5: APCIe-7800: Block diagram www.addi-data.com...
  • Page 35: Return Or Disposal

    Place the board in an ESD protective cover. Then pack it in a cardboard box so that it is well- protected for shipping. Send the packed board together with your details to: ADDI-DATA GmbH Airpark Business Center Airport Boulevard B210 77836 Rheinmünster...
  • Page 36: Disposal Of Addi-Data Waste Equipment

    Return or disposal APCIe-7xx0 5.2 Disposal of ADDI-DATA waste equipment ADDI-DATA organises the disposal of ADDI-DATA products that were put on the German market after 13 August 2005. If you want to return waste equipment, please e-mail your request to: info@addi-data.com.
  • Page 37: Technical Data And Limit Values

    Fig. 6-1: APCIe-7xx0: Dimensions Dimensions (L x W): APCIe-7300, APCIe-7420, APCIe-7500: 110 x 98 mm APCIe-7800: 168 x 98 mm Weight: APCIe-7300, APCIe-7420, APCIe-7500: ca. 120 g APCIe-7800: approx. 150 g Insertion into: PCI Express slot Connection to peripherals: Front connector:...
  • Page 38: Versions

    6.3 Versions The board APCIe-7xx0 is available in the following versions: Table 6-1: Versions Version Features APCIe-7300 1-port serial interface (1 x 9-pin D-Sub) APCIe-7420 2-port serial interface (2 x 9-pin D-Sub) APCIe-7500 4-port serial interface (1 x 37-pin D-Sub) APCIe-7500/4C 4-port serial interface (4 x 9-pin.
  • Page 39: Rs232

    15 kV Short-circuit protection: available With optical isolation (SI422-G, SI485-G): Maximum Baud rate: 1 MBaud Baud rate on request: up to 2.5 MBaud ESD protection: 15 kV Creeping distance: 3.2 mm Test voltage: 1000 V DC Short-circuit protection: available www.addi-data.com...
  • Page 40: Tty 20 Ma Constant Current Loop (Current Loop, Sitty)

    Technical data and limit values APCIe-7xx0 6.4.3 TTY 20 mA constant current loop (current Loop, SITTY) Maximum Baud rate: 19.2 kBaud TVS-Dioden: 400 W Creeping distance: 3.2 mm Test voltage: 1000 V DC Load: 500 Ω Reverse voltage protection: www.addi-data.com...
  • Page 41: Appendix

    = Electrostatic discharge into account. ESD is the sudden and momentary electric current that flows between two objects at different electrical potentials caused by direct contact or induced by an electrostatic field. www.addi-data.com...
  • Page 42 One RS485 bus can have up to 32 users (transmitters/receivers) connected to it. RS485 has the following features: Two-wire connection (half duplex operation) or four-wire connection (full duplex operation); permitted cable length up to 1200 m; transfer rates up to 10 Mbit/s. www.addi-data.com...
  • Page 43: Index

    Intended use 7 Board Limit values 38 Description 9 Limits of use 7 Features 9 MTTTY 29 Handling 8 Pin assignment Insertion 11 APCIe-7300 16 Test 29 APCIe-7420 16 Cable APCIe-7500 14 ST074 20 APCIe-7500/4C 16 ST075 20 APCIe-7800 17 ST7809 21...
  • Page 44: Contact And Support

    Contact and support APCIe-7xx0 8 Contact and support Do you have any questions? Write or call us: Address: ADDI-DATA GmbH Airpark Business Center Airport Boulevard B210 77836 Rheinmünster Germany Phone: +49 7229 1847-0 Fax: +49 7229 1847-222 E-mail: info@addi-data.com Manual and software download from the Internet: www.addi-data.com...

This manual is also suitable for:

Apcie-7420Apcie-7500Apcie-7800
