This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
Z20013
p/n 2m-
Rev. -
WELLS MANUFACTURING
10 Sunnen Dr., St. Louis, MO 63143
telephone: 314-678-6314
www.wellsbloomfield.com
IMPORTANT: DO NOT DISCARD THIS MANUAL
fax: 314-781-2714
OWNERS MANUAL
SELF-CONTAINED
REFRIGERATED COUNTER
TOP SERVER
RCTS-4
INSTALLATION
USE & CARE
EXPLODED VIEW
PARTS LIST
WIRING DIAGRAM
RCTS-4
MODEL
Includes
14
M421
1028
421
Advertisement
Table of Contents
Related Manuals for Wells RCTS-4
Summary of Contents for Wells RCTS-4
- Page 1 Additional manuals are available from your WELLS DEALER. THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any questions concerning installation, operation or maintenance of this equipment.
-
Page 2: Warranty
Seller’s obligation under this warranty is warranted against defects in materials and workmanship limited to the repair of defects without charge by a Wells for a period of one year from the date of original installation Manufacturing factory authorized service agency or one of or 18 months from the date of shipment from our factory, its sub-service agencies. -
Page 3: Table Of Contents
PARTS & SERVICE CUSTOMER SERVICE DATA INTRODUCTION Thank You for purchasing this Wells Manufacturing appliance. Proper installation, professional operation and consistent maintenance of this appliance will ensure that it gives you the very best performance and a long, economical service life. -
Page 4: Features & Operating Controls
FEATURES & OPERATING CONTROLS NAMEPLATE ON/OFF POWER SWITCH CORD REAR VIEW 15.125” (4) 1/6 PANS (INCLUDED) 25.5” S/S PAN DIVIDER (INCLUDED) CLEARANCE 1” SIDE & REAR 12” OPN'G TOP VIEW OPTIONAL S/S NIGHT COVER 10.5 FRONT VIEW SIDE VIEW 1/9 1/9 1/9 1/9 1/9 1/9 1/9 1/9 1/9 VARIOUS OTHER PAN ARRANGEMENTS... -
Page 5: Precautions & General Information
PRECAUTIONS AND GENERAL INFORMATION This appliance is intended for use in commercial establishments only. WARNING: ELECTRIC This appliance is intended to assist in cleaning cooking utensils. No SHOCK HAZARD other use is recommended or authorized by the manufacturer or its agents. -
Page 6: Installation
INSTALLATION NOTE: DO NOT discard UNPACKING & INSPECTION the carton or other packing Carefully remove the appliance from the carton. Remove all protective materials until you have plastic film, packing materials and accessories from the Appliance inspected the appliance for before connecting electrical power or otherwise performing any hidden damage and tested it installation procedure. -
Page 7: Operation
OPERATION SUGGESTIONS: Inspect each pan insert for thorough cleaning. IMPORTANT: Additional hand cleaning may be necessary to insure complete food DO NOT put water or ice in removal. the well of the server. If detergent is used, items must be rinsed with clean water prior to use. PRE-CHILLING THE SERVER 1. -
Page 8: Cleaning Instructions
CLEANING INSTRUCTIONS WARNING: PREPARATION Turn power switch OFF SHOCK Unplug from electrical power Remove Removable Pans HAZARD FREQUENCY Turn power switch OFF and Daily, or as needed disconnect unit from electric TOOLS Bottle Brush, Soft Bristle Brush power before cleaning. Soft Cloth or Sponge IMPORTANT: CLEANING... -
Page 9: Temperature Adjustment
TEMPERATURE ADJUSTMENT TEMPERATURE ADJUSTMENT IMPORTANT: DO NOT adjust the RCTS differential settings of the refrigeration system. 1. The temperature has been preset at the factory to meet most Field adjustments of the applications. differential settings must 2. If temperature adjustments are required, the pressure switch, be made by qualified located on the condensing unit, is adjustable. - Page 10 TEMPERATURE ADJUSTMENT 3. Press the SET key again to access the differential. The LCD will IMPORTANT: display the current differential, and the DIF1 annunciator will blink DO NOT adjust the off and on to indicate that control is in the differential mode. differential settings of the refrigeration system.
-
Page 11: Troubleshooting Suggestions
TROUBLESHOOTING SUGGESTIONS SYMPTOM PROBABLE CAUSE SUGGESTED REMEDY Plug unit into appropriate receptacle No power to unit Unit unplugged or circuit breaker tripped Reset circuit breaker Power switch off Turn switch ON Damaged power cord Replace power cord Unit will not run Damaged power switch Replace switch Damaged motor... -
Page 12: Exploded View & Parts List
EXPLODED VIEW: RCTS-4 Model: RCTS-4 Refrigeration Countertop Server SK2813, Rev. -, 9/09/14... - Page 13 PARTS LIST: RCTS-4 Model: RCTS-4, REFRIGERATED COUNTER TOP SERVER Fig. No. Part No. Description SIDE PANEL, LEFT SIDE PANEL, RIGHT BOTTOM PANEL BOTTOM PANEL ANGLE ENCLOSURE PANEL LOUVERED PANEL LOUVERED PANEL NIGHT COVER 2V-Z19295 DIVIDER BAR 2L-Z19296 PAN, 6”D X 6.9375” L X 6.375” W...
- Page 14 NOTES:...
-
Page 15: Parts & Service
IMPORTANT: Use only factory authorized service parts and replacement filters. For factory authorized service, or to order factory authorized replacement parts, contact your Wells authorized service agency, or call: Wells Manufacturing 10 Sunnen Dr., St. Louis MO 63143 USA Service Dept. - Page 16 WELLS MANUFACTURING 10 Sunnen Dr., St. Louis, MO 63143 telephone: 314-678-6314 fax: 314-781-2714 www.wellsbloomfield.com...
