Smartlock Digital SMARTPOINT SMARTLINC II 9160 User Operating Instructions

AVAILABLE FEATURES
USER CODE
+
Open Lock
+ Change Code
+ Set Immediate Time Lock, if enabled
+
Time Lock Extension, if enabled
MULTIPLE LOCKS
+ Up to Five
TIME DELAY
+ Programmable on each lock
- Delay Period: 1 - 99 minutes
- Open Period: 1 - 19 minutes
+ Two Time Delays Can Run At Once
DUAL CODE
+
Requires the presence of two users to open
CHANGING YOUR CODE - USER
ALWAYS PERFORM THIS OPERATION WITH THE DOOR OPEN
1. Press any key to power up SMARTPOINT.
+ Display will show either "ENTER CODE" or SELECT LOCK" when two or more locks are installed.
2. Select lock if two or more locks are installed.
3. Enter "zero" six times
4. Enter existing six (6) digit code one time.
5. Enter NEW six (6) digit code two times (and scan finger, if set-up, after 2nd entry).
+ If a valid code is entered, display will show "CODE CHANGED"
6. Test lock operation several times before closing the door.
7. If code update verification does not appear the old code is still valid. Wait 30 seconds and repeat
steps 1 - 6
USING DURESS
The duress feature is available if the unit has been connected to an alarm system via a battery/
alarm box. To use simply enter your code with the last number either + or - 1 or use the duress
finger print, if enrolled.
Example: Existing code (2-9-2-9-2-9)Duress code (2-9-2-9-2-8 or 2-9-2-9-2-0)
SMARTPOINT SMARTLINC II
This system is available with or without biometric identification ability. If using the SMARTLINC II, without biometric ability, please disregard
any reference, in these instructions, to fingerprints. The functionality of the two systems are identical except for the use of fingerprints
for identification.
V1.0_9102 | Division of Davcor Group Pty Ltd
USER OPERATING INSTRUCTIONS
SMARTPOINT SMARTLINC II
Biometric Recognition Safe Locking System
9160
WRONG TRY PENALTY
+
Four (4) consecutive invalid codes initiates five-minute delay
period. Two additional invalid codes will begin another five-
minute delay.
LOW BATTERY WARNING
+ Repeated audio and visual signal (LCD readout and repeated
beeping) during opening indicates back-up battery is low and
should be replaced.
AUDIO AND VISUAL SIGNAL
+ Double signal (LCD readout and unit beeps) indicates entry is
valid or accepted
+ Triple signal indicates invalid or not accepted
TIME LOCK
+ Immediate Time Lock (From now until next available open
period)
+ Time Lock Open Period Extension (Max. two (2) hours), if
enabled
| www.smartlock.com.au |
9150
SELECT LOCK
ENTER LOCK
CONFIRM NEW
CODE CHANGED
CONFIRM CODE
www.smartlock.co.nz | Page 1
XX
X-X-X-X-X-X
OLD CODE
X-X-X-X-X-X
NEW CODE
X-X-X-X-X-X
X-X-X-X-X-X
NOT MATCH
