  • Page 1 Operating instructions RefreshButler V6000 Textile care system...
  • Page 2 These operating instructions apply to: Model designation Model number Type RefreshButler V6000 14003 RB6TWCL RB6TWBL Variations depending on the model are noted in the text. Colour operating instructions can be downloaded from the internet from www.vzug.com. © V-ZUG Ltd, CH-6302 Zug, 2019...

  • Page 3: Table Of Contents

    Cleaning the air duct..........  29 Instructions for use.......... 6 6.11 Operating mode............   29 Using for the first time  7 6.12 V-ZUG Service............  29 Your appliance  7 6.13 Updating the software..........   29 Appliance description ...........  7 Care and maintenance  30...

  • Page 4: Safety Precautions

    Safety precautions Symbols used or have been instructed on the safe use of the appliance Denotes important safety precau- tions. and have understood the haz- Failure to observe said precautions ards involved. Children shall can result in injury or in damage to not play with the appliance.
  • Page 5 1 Safety precautions ▪ The appliance has a max- or pillows with foam rubber imum dry load capacity of pads are not suitable for the 5 kg. appliance. ▪ The appliance is only to be ▪ Remove all foreign objects used with the recommended (cigarette lighter, match, etc.) vaporizing medium.

  • Page 6: Instructions For Use

    1 Safety precautions ▪ Do not operate the appliance without a Instructions for use fluff filter or with a damaged fluff filter. Fluff can destroy the appliance! Before using for the first time Caution: Risk of burns! ▪ The appliance must be installed and connected to the electricity supply in ▪...

  • Page 7: Using For The First Time

    Using for the first time The appliance can only be operated after standing in the normal operating position for around 2 hours. Your appliance Appliance description The RefreshButler uses steam and heat to refresh your clothes and reduce odours and creases.

  • Page 8: Appliance Construction

    3 Your appliance Appliance construction Clothes rail TouchDisplay, On/Off button Fold-down clothes rails Basket Main filter with filter mat below floor grille Water tank cover Fresh air grille with filter mat Fresh water tank Condensate tank Appliance door Accessories Clothes hangers For heavier clothes, such as jackets and coats, use the clothes hanger supplied for optimal results.

  • Page 9: Operating And Display Elements

    3 Your appliance Operating and display elements TouchDisplay On/Off button TouchDisplay All available functions are displayed in the TouchDisplay and the desired function can be selected by pressing the corresponding symbol or text. Programme Refreshing Programme selection Extra programmes Refresh Extra programmes Drying Hygiene...
  • Page 10 Timed drying Delayed start Easy care Hygiene Finishes in 1 h 30 Delayed start User settings Language Settings Brightness Button tone Water hardness Childproof lock Delayed start Descale Settings Cleaning the air duct Information Operating mode V-ZUG Service Update software...

  • Page 11: Programme Overview

    4 Programme overview Button state The buttons arranged on the TouchDisplay have three different states. Symbol Background Bright Dark Selectable function Programme or function can be selected. Bright Blue Function selected/changed Programme or function is active. Dark Dark Non-selectable function Programme or function is switched off.
  • Page 12 4 Programme overview The following diagram gives an overview of the programme settings in the main refresh programme. Strong Odour Medium Faint * Full Load Half-full Small * Easy care No * Timed refreshing Off * Crease guard No * Delayed start * Factory setting Odour...

  • Page 13: Extra Programme «Drying

    4 Programme overview Load For optimal refreshing results, we recommend reducing the load to small or half- full. ▪ Full For a maximum 5 kg dry load spread out on the upper and lower clothes rails. ▪ Half-full For a normal load spread out on the upper and/or lower clothes rail. ▪...
  • Page 14 4 Programme overview The following diagram gives an overview of the programme settings in the extra pro- gramme drying. Normal dry * Level of dryness Extra dry Full Load Half-full * Small Easy care No * Timed drying Off * * Factory setting Delayed start Level of dryness...

  • Page 15: Extra Programme «Hygiene

    4 Programme overview Timed drying ▪ The programme duration can be set to between 30 and 120 minutes. ▪ No other programme settings can be made if the Timed drying programme is selec- ted. Delayed start ▪ Take advantage of cheap-rate electricity. ▪...

  • Page 16: Operating The Appliance

    5 Operating the appliance Delayed start ▪ Take advantage of cheap-rate electricity. ▪ Programme the start or end – so that, for instance, the textiles are ready to put on in the morning without the appliance having to run all night. ▪...

  • Page 17: Loading Examples

    5 Operating the appliance Loading examples Refreshing and drying tips Loading tips ▪ Place woollens and other knitted items in the basket or on the rails at mid-height. ▪ Larger items of clothing can be hung diagonally in the appliance. ▪...

  • Page 18: Filling The Fresh Water Tank

    5 Operating the appliance General notes ▪ Crease guard is particularly suitable for heavy items of clothing, such as blazers and suit trousers, due to their own weight. ▪ Cotton, linen and some fine silks crease very easily. Here creases can only be re- moved to a limited degree.

  • Page 19: Emptying The Condensate Tank

    5 Operating the appliance Emptying the condensate tank ▸ Open the appliance door. ▸ Open the water tank cover 1 (press in the middle at the top). ▸ Take out the condensate tank 3 with the symbol by the handle. ▸...

  • Page 20: Programme Selection

    5 Operating the appliance Easy care Hygiene Finishes in 1 h 30 Delayed start Programme selection ▸ To switch the appliance on: press the button below the TouchDisplay. – The programme selection appears in Programme selection the display: Refresh Extra programmes ▸...

  • Page 21: Changing Selection

    5 Operating the appliance ▸ Press the desired setting value, e.g. half-full. – The selected button has a blue back- Refreshing ground. Finishes in 1 h 30 – The overview of the programme set- tings appears in the display again. ▪...

  • Page 22: Programme Selection With Childproof Lock Activated

    5 Operating the appliance 5.10 Programme selection with childproof lock activated The childproof lock can be switched on Unlock or off in the user settings. 0 0 0 Code ▸ Enter the code given into the display. ▸ Press the button to confirm the code.

  • Page 23: Aborting A Programme Before Time

    5 Operating the appliance 5.12 Aborting a programme before time Hot steam may escape when the appliance door is opened: scalding hazard! When the appliance door is opened, condensed drops of water can land on the floor. The inside of the appliance may be hot. Unload the washing carefully. ▸...

  • Page 24: User Settings

    6 User settings If the appliance door is not opened when the programme finishes, airing starts up again every 3 hours and lasts for 15 minutes. This ensures that the washing re- mains fresh for up to 24 hours after the end of the programme. The washing should be removed within 24 hours.
  • Page 25 6 User settings ▸ Press the desired user setting, e.g. language. – The selectable setting values ap- Languages pear in the display. Deutsch Français Italiano English Українська Русский Nederlands Svenska Norsk Türkçe ▸ Press the desired setting value to change the setting. –...

  • Page 26: Language

    Start in Delayed start Finish in * Information Descale Clean air duct Silent * Operating mode Standard V-ZUG Service Update software * Factory setting Language The language in the display can be changed. Different languages are available for selec- tion.

  • Page 27: Brightness

    6 User settings Brightness With this function the readability of the display can be adjusted to the prevailing lighting conditions. Levels of brightness Dark Medium Bright Very bright Button tone The button tone can be switched on/off. Water hardness The relevant range of water hardness can be set. There are 3 setting ranges for water hardness: Type Water hardness...
  • Page 28 6 User settings The descaling programme takes about 1 hour and 20 minutes. «durgol swiss steamer» descaler is mixed in the ratio of 1:2 (e.g. 0.5 l durgol to 1 l water). If the «Refresh» or «Hygiene» programme is used every second day, the following descaling intervals can be expected: Water hardness (see page 27) type Descaling interval...

  • Page 29: Cleaning The Air Duct

    Operating mode There are two different operating modes. The appliance can be operated in the «Stand- ard» mode or in the noise-optimized «Silent» mode. 6.12 V-ZUG Service This function is for use by the service technician. 6.13 Updating the software With this function the software can be updated.

  • Page 30: Care And Maintenance

    7 Care and maintenance Care and maintenance Cleaning intervals Pos. Appliance part Cleaning interval Cleaning As required * ▸ Remove any fluff. Main filter Whenever there is a heav- ▸ Clean with an abrasive liquid ier build-up of deposits cleaning agent and a sponge. ▸...

  • Page 31: Build-Up Of Fluff

    7 Care and maintenance Build-up of fluff Fluff is made up of fine textile fibres that largely come from the manufacturing process, from wear and tear during use and from items being washed. Fluff is not caused by ex- cessive strain on the washing in the appliance. Even when washing is hung out to dry on a washing line, fluff is shed when the washing is shaken out or ironed.

  • Page 32: Cleaning The Fresh Air Filter Mat

    7 Care and maintenance Cleaning the fresh air filter mat Do not operate the appliance without the filter mat. ▸ Open the appliance door. ▸ Pull out the fresh air grille 1. ▸ Take out the filter mat 2. ▸ Clean the filter mat under running wa- ter and allow to drip dry.
  • Page 33 7 Care and maintenance ▸ Push the lid back. ▸ Lift the lid at the front and back (through the opening). ▸ Press the lid down at the front and back. ▸ Slot the water tank into position in the water tank compartment and push the flap to close.

  • Page 34: Trouble-Shooting

    This section lists faults that can be solved simply by following the instructions given. If another fault is displayed, the fault cannot be resolved or «Contact V-ZUG» appears in the message, please call Customer Services. Before calling Customer Services, please note down the error message in full.
  • Page 35 8 Trouble-shooting ... «FXX/EXX FN XX» appears Possible cause Solution ▪ Various situations can lead to ▸ Cancel the error message by pressing the but- an «F» message. ton. ▸ Switch off the power supply for about 1 minute. ▸ Switch the power supply back on again and select a new programme.

  • Page 36: Accessories And Spare Parts

    9 Accessories and spare parts Accessories and spare parts Please give product family and exact designation when ordering parts. Clothes hangers Basket Fresh water tank Condensate tank Main filter Main filter mat Fresh air grille Fresh air filter mat durgol swiss steamer descaler The descaler is also available from specialist retailers.

  • Page 37: Technical Data

    10 Technical data Technical data External dimensions Height: 1960 mm Width: 775 mm Depth: 570 mm Weight: 170 kg Dry load capacity: 5 kg dry washing Ambient conditions Permissible room temperature: 5 °C to 30 °C Electrical connection ▸ See identification plate (see page 43) 10.1 Consumption data for factory setting Duration Energy Temperature...

  • Page 38: Disposal

    11 Disposal The interior illumination and the TouchDisplay go out 5 and 20 minutes respectively after the programme finishes. Energy consumption is reduced to an absolute minimum. The safety functions, however, remain active. Disposal 11.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation.

  • Page 39: Index

    Index Accessories ............8 Heat pump ............38 Basket ............... 8 Hygiene.............. 15 Clothes hangers.......... 8 Additional functions ......... 11 Airing ............11, 15 Information ............27 Ambient conditions.......... 37 Initial set-up ............. 4, 7 Appliance ............. 7 Instructions for use ..........6 Construction ............ 8 Description............ 7 Appliance disposal ..........
  • Page 40 Symbols ..............4 Technical data ..........37 Timed drying ............. 15 Timed refreshing ..........13 TouchDisplay ............9 Type............... 2 Software update ..........29 User settings..........10, 24 Validity..............2 V-ZUG Service ..........29 Washing Arranging............ 16 Water hardness ..........27...

  • Page 41: Notes

    Notes...

  • Page 43: Service & Support

    Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
  • Page 44 ▸ Empty the water tank. ▸ Close the appliance door. ▸ Press the button. 1073323-R02 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
