Chassis : sct55a
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
COLOR TELEVISION RECEIVER
COLOR TELEVISION RECEIVER
Chassis :
SCT55A
Model:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
C O N T E N T S
Precautions
Alignment and Adjustment s
Tr oubleshooting
Exploded View and Parts List
Electric Parts List
Schematic Diagrams

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS29A6MTRX/BWT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung CS29A6MTRX/BWT

Summary of Contents for Samsung CS29A6MTRX/BWT

  • Page 1 COLOR TELEVISION RECEIVER Chassis : SCT55A Model: CS29A6MTRX/BWT COLOR TELEVISION RECEIVER C O N T E N T S Precautions Reference Information Specifications Disassembly and Reassembly Alignment and Adjustment s Tr oubleshooting Exploded View and Parts List Electric Parts List...
  • Page 2 The current measured should the XÐray Protection Specifications Label, and not exceed 0.5 milliamp. Reverse the power- the Product Safety and X-ray Warning Note on plug prongs in the AC outlet and repeat the the service data schematic. test. Samsung Electronics...
  • Page 3 14. Components, parts and wiring that appear to have overheated or that are otherwise damaged should be replaced with parts that meet the original specifications. Always determine the cause of damage or overheat- ing, and correct any potential hazards. Samsung Electronics...
  • Page 4 Make sure that the portion around the serviced part has not been damaged. 8. Always connect a test instrumentÕs ground lead to the instrument chassis ground before connecting the positive lead; always remove the instrumentÕs ground lead last. Samsung Electronics...
  • Page 5 4. Do not use freon-propelled chemicals. These unpackaged replacement ESDs. Motions such can generate electrical charges that damage as brushing clothes together, or lifting a foot ESDs. from a carpeted floor can generate enough static electricity to damage an ESD. Samsung Electronics...

  • Page 6: Reference Information

    Millimeter Hour Millisecond Inches Per Second Millivolt Kilowatt-hour Nanofarad Ω Kilogram Kilohertz Picofarad kΩ Kilohm Pound Kilometer Revolutions Per Minute km/h Kilometer Per Hour Revolutions Per Second Kilovolt Second (Time) Kilovolt-ampere Volt Kilowatt Volt-ampere Liter Watt Megahertz Watt-hour Samsung Electronics...
  • Page 7 Fail Safe Voltage Controlled Oscillator Ground VCXO Voltage Controlled Crystal Oscillator Green-Y Very High Frequency High Video Intermediate Frequency High-Frequency Variable Resistor HI-FI High Fidelity Video Tape Recorder Inductance-Capacitance VTVM Vacuum Tube Voltmeter Integrated Circuit Transistor Intermediate Frequency Samsung Electronics...
  • Page 8 900 Series ............................... MICOM Section RT, CT, ICT ............................TELETEXT Section RC, CC, HC, SWY ......................SNAP-IN Section (Control) RV,CV,LV,QV ............................... V/M Section RJ,CJ,LJ,DJ,ICJ ............................NICAM Section RP,CP,LP,XP,ICP ............................PIP Section RC,CC,DZC,QC ........................... COMB Filter Section RP,PD ............................POWER-S/W Section Samsung Electronics...
  • Page 9 AUDIO MODULE IC601 TDA7297 SOUND AMP IC701 CXA1855S AUDIO/VIDEO SWITCHING IC IC801 STR-S6709 SMPS CONTROL IC POWER IC802 LTV817B PHOTO COUPLER POWER IC901 Z89313(Z90341) MICRO PROCESSOR IC902 KIA7042P RESET IC IC903 PQ09RF1 9V SWITCHABLE REGULATOR IC904 KA7808 8V REGULATOR Samsung Electronics...
  • Page 10 TDA3504 RGB-MATRIX PIP MODULE ICP07 KIA7042P RESET IC PIP MODULE ICP08 TDA4665T BASE BAND DELAY LINE PIP MODULE Option : OSD Language Table 2-2 Loc No. Specification Description Remarks ENG/ARAB/FRENCH/CHINESE/ 2-TUNER MALAYSIA/INDONESIA/VIETNAM/ MULTI-PIP IC901 SZM-162M THAI/RUSSIAN/CROATIA/BULGARIA/ MULTI-LANGUAGE POLAND/ROMANIA/CZECH/TURKEY/HUNGARY Samsung Electronics...

  • Page 11: Specifications

    SOUND B/G, D/K, I,M NICAM B/G,I ANTENNA IMPEDANCE 75 ohm unbalanced coaxial SCREEN SIZE 70.8 cm POWER REQUIREMENTS Main voltage : 220V/230V/240V~ Range : 100 - 260V~ FREQUENCY 50/60Hz PROGRAMME CHANNEL 100 channels Specifications are subject to change. Samsung Electronics...

  • Page 12: Disassembly And Reassembly

    3. To reassemble, place the receiver on a flat surface and repeat the sequence in reverse order. 4. To check that that the Chassis Assembly is installed correctly, attempt to pull if from the front cabinet. Fig. 4-1 Samsung Electronics...
  • Page 13 Disassembly and Reassembly 4-2 Speaker 1. Separate Connectors (a), (b). 2. Separate wires from twist-lock. 3. Remove 2 screws, (c). 4. To reassemble, repeat the sequence in reverse order. Fig. 4-2 Samsung Electronics...
  • Page 14 Disassembly and Reassembly 4-3 Chassis Assembly 4-3-1 Removal from Front Cabinet 1. Lift and pull back the chassis mounting. Fig. 4-3 Fig. 4-4 Samsung Electronics...
  • Page 15 4. To reassemble, refer to Fig. 4-6. TERMINAL-BOARD HOLDER-CHASSIS WIRELESS H/P-JACK S-VHS JACK BRACKET Fig. 4-5 Insert " " Insert on the left and right bottom of the terminal board, into " " hole on the holder chassis. Fig. 4-6 Samsung Electronics...
  • Page 16 3. The PCB guide is part of the chassis mounting ; if a new PCB guide is needed, the complete chassis mounting must be replaced. 4-3-4 SNAPIN Removal SNAPIN-CONTROL Fig. 4-7 Press the SNAPIN (b) with thumb ; pull the left holder-bracket (a) with index finger Samsung Electronics...
  • Page 17 2. Place the chassis bracket (b) onto (a) on the bottom of the cabinet. 3. Push the bracket into the hole (a) until a ÒclickÓ is heard. 4. Check that the SNAPIN door opens and closes. F/CABINET HOLDER-CHASSIS Fig. 4-8 Samsung Electronics...

  • Page 18: Alignment And Adjustments

    3. Adjust the Brightness and contrast controls to 1. Connect a digital voltmeter to the second both extremes. Ensure that the high voltage anode of the picture tube. does not exceed 32 KV under any conditions. Samsung Electronics...
  • Page 19 12. Tighten the deflection yoke. 6. Turn the CONTRAST and BRIGHTNESS controls to maximum. 7. Loosen the clamp screw holding the yoke. Slide the yoke backward or forward to produce a vertical green belt. (Fig. 5-2). Samsung Electronics...
  • Page 20 4. Turn both tabs at the same time, keeping the angle constant: Superimpose the red and blue horizontal lines in the center of the screen. RED/BLUE GREEN BLUE BLUE RED/BLUE GREEN 6-Pole Magnet Movement 4-Pole Magnet Movement Fig 5-3 Center Convergence Adjustment Samsung Electronics...

  • Page 21: Service Mode

    RIGHT SIDE DIGIT IS CHANGE "L"¢¡"H"(RED COLOR):STOP VOLTAGE CONTROL OSC. 00~127 SUB BRIGHTNESS 00~13 SUB CONTRAST 00~13 SUB COLOR 00~23 VERTICAL S-CORRECTION S-CORRECTION 00~63 HIGH LIGHT ADJUSTMENT RED GAIN 00~63 HIGH LIGHT ADJUSTMENT GREEN GAIN 00~63 HIGH LIGHT ADJUSTMENT BLUE GAIN 00~63 Samsung Electronics...
  • Page 22 SUB TINT (HUE) 0~15 NTSC NTSC VERTICAL SLOPE 0~63 NTSC NTSC VERTICAL AMPLITUDE 0~63 NTSC NTSC HORIZONTAL SHIFT 0~63 NTSC NTSC E-W WIDTH 0~63 NTSC NTSC E-W PARABOLA 0~63 NTSC NTSC E-W CORNER 0~63 NTSC NTSC E-W TRAPEZIUM 0~63 NTSC Samsung Electronics...
  • Page 23 Note PROGRAM NUMBER 0 ~ 99 DIRECT NUMERIC KEY IN BLACK OFFSET COMPENSATION ENABLE WINDOW SELECT USER VARIABLE GAMMA 0 ~ 63 ADAPTIVE GAMMA 0 ~ 63 NON LINEARITY AMPLITUDE 0 ~ 63 SUB SHARPNESS 0 ~ 15 Samsung Electronics...
  • Page 24 34 INCH ; 4 : 3 CRT USED REAR BACK JACK WAS USED 21-PIN JACK SCART REAR BACK JACK WAS USED RCA 9-PIN JACK USING ONECHIP : TDA8375 8375 CHIP USING ONECHIP : TDA8844 8844 BUILT IN LNA FUNCTION NO LNA FUNCTION Samsung Electronics...
  • Page 25 ENG/MALAYSIAN Malaysia ENG/INDONESIAN Indonesia ENG/VIETNAMESE Vietnam ENG/THAI Thai ENG/RUSSIAN/CROATIAN/BULGARIAN/POLISH/ LANGUAGE E.Europe RUMANIAN/CZECH/ TURKISH/HUNGARAN M. Russia ENG/RUSSIAN/CROATIAN/BULGARAN M. Poland ENG/POLISH/RUMANIAN/CZECH M. Hungary ENG/RUSSIAN/TURKISH/HUNGARAN Russia ENG/RUSSIAN Croatia ENG/CROATIAN Bulgaria ENG/BULGARIA Poland ENG/POLISH Rumania ENG/RUMANIAN Czech ENG/CZECH Turkey ENG/TURKISH Hungary ENG/HUNGARAN Samsung Electronics...

  • Page 26: Troubleshooting

    Power Board Check Check/Replace pin 1 of IC801 D817,R418, Q402, T401, Q401 Check/Replace Check Check/Replace D812, D813 PIN 3 of IC801 F802M,D806 R810, Q801 Q802, IC802 D811, D816 Check/Replace Check the Pin 9 IC802, D807 of IC801 Check/Replace IC801 Samsung Electronics...
  • Page 27 12 13 17 TDA8375, TDA8375 pin 28 (Y-output) 40 46 47 Replace Check TDA8375 IF CVBS Check TDA8375 pin 27 Y-input Check TDA8375 19 20 21 Check/Replace R/G/B Out IC203, IC204, IC208 Check Pin 8 of IC501, IC502 IC503 Samsung Electronics...
  • Page 28 High of Audio Module Low - High Check A/V Side connection CNH01 Check pin 9 Audio Module (9V) Check Check Pin 16, Pin 8,10 of the Audio Module Q905 Check/Replace Check/Replace Check/Replace Check/Replace IC901, Q905 IC6001 IC903 IC601 Samsung Electronics...
  • Page 29 MEMO Samsung Electronics...
  • Page 30 Exploded Views and Parts List 7. Exploded View & Parts List 7-1 CS29A6HP2X/HAC Samsung Electronics...

  • Page 31: Parts List

    BRACKET-CRATER;-,6277,STS304,T0.5,-,-,- AA03-00075A CRT-COLOR;-,A68QCP891X003(C),+380MG,-,11 AA65-30113A CLAMP-D,COIL;NYLON 66,V2,BLK,TVI 25~29,- AA60-10050V SCREW-ASSY;WC,HH,+,M6,L30,SWRCH18A,ZPC(S CRT+CF AA65-30017A CLAMP-D,COIL;NYLON-66,V0,NTR,DADH300,25 AA95-00281A ASSY-PCB,CRT;-,SCT55A,29,RUSSIA,PAL AA91-00149A ASSY-HOLDER,SPK;-,PP,8OHM/15W,BLK,IMPACT 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR SPKR+CF AA64-00027C CABINET-BACK;-,72A6,-,HIPS,V2,BLK,-,- 6003-001025 SCREW-TAPTITE;RH,+,B,M4,L20,ZPC(BLK),SWR CB+CF AA63-00005C COVER-TOP,SPEAKER;-,72A6,-,HIPS,V2,BLK,- 6003-001025 SCREW-TAPTITE;RH,+,B,M4,L20,ZPC(BLK),SWR CTS+CB AA39-10006X POWER-CORD;-,KKP419C,KLCE-2F,2.286MT,3P, AA63-40275A TERMINAL-BOARD,ANT;-,HIPS,BLK,CT3456V,V0 AA64-60416F INLAY-BACK;72A6,SCT55A SCRAT M-PIP,PS SH Samsung Electronics...

  • Page 32: Electric Parts List

    Remarks Part-No Description & Specification Remarks ASSY-PCB,MAIN(OPT) C241 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V C242 2201-000292 C-CERAMIC,DISC;1nF,10%,50V,Y5P,TP,5x3,5 * AA94-01190A ASSY-PCB,MAIN(OPT);CS29A6MTRX/BWT,SCT55A C243* 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m C244* 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m AV701 3722-000195 JACK-SCART;42P,-,SN,BLK,NO C245* 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m AV702 3722-000120 JACK-VHS;4P,3.5mm,AG,BLK,NO C246* 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m C102 2201-000119 C-CERAMIC,DISC;100nF,+80-20%,50V,Y5V,TP, C247* 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m C103 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5...
  • Page 33 DZ101 1203-000451 IC-VOLTAGE REGULATOR;33,TO-92,3P,-,PLAST C920 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 DZ201 0403-000563 DIODE-ZENER;MTZ9.1B,9.1V,8.57-9.01V,500m C921 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m DZ202 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500m C922 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 DZ601 0403-000289 DIODE-ZENER;MTZ10C,10V,9.7-10.2V,500mW,D C923 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5 DZ602 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500m C924 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m DZ651 0403-000664 DIODE-ZENER;MTZ3.6A,3.6V,3.455-3.695V,50 C925 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5 DZ701 0403-000654 DIODE-ZENER;MTZ12B,12V,11.44-12.03V,500m Samsung Electronics...
  • Page 34 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM L117 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm R206 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM L118 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm R207 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2M L201 2701-000215 INDUCTOR-AXIAL;8.2uH,10%,2.5x3.4mm R208 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M L202 2701-000299 INDUCTOR-AXIAL;13uH,10%,2.5x3.4mm R212 2004-001914 R-METAL;39Kohm,2%,1/8W,AA,TP,1.8x3.5mm L203 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm R215 2004-001403 R-METAL(S);7.5Kohm,1%,1/2W,AA,TP,2.4x6.4 L204 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm R217 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M Samsung Electronics...
  • Page 35 2001-001026 R-CARBON;910OHM,5%,1/8W,AA,TP,1.8X3.2MM R286* 2001-000534 R-CARBON;240OHM,5%,1/8W,AA,TP,1.8X3.2MM R758 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R293 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM R759 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R294 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M R760 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM R295 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R761 2001-000534 R-CARBON;240OHM,5%,1/8W,AA,TP,1.8X3.2MM R296 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R762 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3.2MM R297 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4 R763 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 36 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM * AA95-00203A ASSY-PCB,A/V SIDE;-,CS72A6,SCT55A,-,-,PA R957 2001-000723 R-CARBON;4.3KOHM,5%,1/8W,AA,TP,1.8X3.2M R958 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM CA01 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP R959 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM CA02 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5 R962 2001-000837 R-CARBON;51KOHM,5%,1/8W,AA,TP,1.8X3.2MM CA03 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP R966 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM CA04 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5 R968 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M CA05 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5 Samsung Electronics...
  • Page 37 RH04 2701-000158 INDUCTOR-AXIAL;22uH,10%,2.5x3.4mm C833 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5 C834 2401-002262 C-AL;10uF,20%,160V,WT,TP,10x20,5 ASSY-PCB,POWER C835 2201-000991 C-CERAMIC,DISC;560pF,10%,2KV,Y5P,TP,13x7 CH01 2306-000193 C-FILM,MPPF;360nF,5%,200V,TP,21x18.5x13, * AA95-00280A ASSY-PCB,POWER;CS29A6MTRX/BWT,SCT55A,29, CN01 3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI CNB03 3710-001141 CONNECTOR-SOCKET;12P,1R,2.5mm,STRAIGHT,S C301 2301-000254 C-FILM,PEF;39nF,5%,50V,TP,7.5x3.5x6.5mm, CNB04 3710-001141 CONNECTOR-SOCKET;12P,1R,2.5mm,STRAIGHT,S C304 2401-000326 C-AL;100uF,20%,35V,GP,TP,8x11.5,5 CNB13 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5MM,STRAIGH C305 2401-000326 C-AL;100uF,20%,35V,GP,TP,8x11.5,5 D301 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T...
  • Page 38 AA26-00011A TRANS-DUMMY;-,3.5MH,EE2834,-,BK R404 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M ASSY-PCB,CRT R405 2001-001163 R-CARBON(S);560OHM,5%,1/2W,AA,TP,2.4X6.4 R406 2004-001986 R-METAL(S);35.7Kohm,1%,1/2W,AA,TP,2.4x6. R407 2004-001376 R-METAL(S);11Kohm,1%,1/2W,AA,TP,2.4x6.4m * AA95-00281A ASSY-PCB,CRT;-,SCT55A,29,RUSSIA,PAL R408 2004-001379 R-METAL(S);12Kohm,1%,1/2W,AA,TP,2.4x6.4m R409 2004-001390 R-METAL(S);1Kohm,2%,1/2W,AA,TP,2.4x6.4mm C501 2201-000193 C-CERAMIC,DISC;10pF,0.3pF,50V,CH,TP,5x3, R410 2004-001396 R-METAL(S);390Kohm,2%,1/2W,AA,TP,2.4x6.4 C502 2201-000193 C-CERAMIC,DISC;10pF,0.3pF,50V,CH,TP,5x3, R411 2001-000052 R-CARBON(S);3.3KOHM,5%,1/2W,AA,TP,2.4X6. C503 2201-000193 C-CERAMIC,DISC;10pF,0.3pF,50V,CH,TP,5x3, Samsung Electronics...
  • Page 39 2004-001893 R-METAL(S);22Kohm,1%,1/2W,AA,TP,2.5x6.5m D512 0401-000005 DIODE-SWITCHING;1N4148,75V,200MA,DO-35,T RG05 2001-001159 R-CARBON(S);510OHM,5%,1/2W,AA,TP,2.4X6.4 D513 0401-000005 DIODE-SWITCHING;1N4148,75V,200MA,DO-35,T RG06 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4 D514 0401-000005 DIODE-SWITCHING;1N4148,75V,200MA,DO-35,T RG07 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4 DG01 0401-000005 DIODE-SWITCHING;1N4148,75V,200MA,DO-35,T RG08 2001-001163 R-CARBON(S);560OHM,5%,1/2W,AA,TP,2.4X6.4 DL01 4711-001009 DELAY LINE;110nS/200KHz,3.5MHz,16.5x8x12 RV01 2008-001090 R-FUSIBLE(S);10OHM,5%,1/2W,AC,BK,2.5X6.5 DV01 0401-000005 DIODE-SWITCHING;1N4148,75V,200MA,DO-35,T RV02 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 40 R6012 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012 C6012 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012, R6013 2007-000881 R-CHIP;4.7ohm,5%,1/10W,DA,TP,2012 C6015 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,- R6014 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 C6016 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 R6015 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 C6018 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5 R6016 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012 C6019 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP, R6017 2007-000642 R-CHIP;270OHM,5%,1/10W,DA,TP,2012 C6020 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 R6018 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012 Samsung Electronics...
  • Page 41 DZ202 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500m CP37 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, IC202 1209-000214 IC-DELAY LINE;TDA4665,DIP,16P,300MIL,PLA CP38 2203-000374 C-CERAMIC,CHIP;15nF,10%,50V,X7R,TP,2012, IC203 1204-000524 IC-DECODER;TDA8395P/N1,DIP,16P,-,PLASTIC CP39 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 L201 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm CP40 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, R233 2001-001077 R-CARBON(S);150OHM,5%,1/2W,AA,TP,2.4X6.4 CP41 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP, CP43 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, ASSY-PCB,PIP CP44 2404-000235 C-TA,CHIP;4.7uF,20%,16V,-,TP,3528,1.4 8-10 Samsung Electronics...
  • Page 42 ICP07 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL RP123 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012 ICP08 1209-001125 IC-DELAY LINE;TDA4665T,SOP,16P,300MIL,PL RP124 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 LP01 2701-000219 INDUCTOR-AXIAL;820nH,10%,2.5x3.4mm RP125 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012 LP02 2701-000177 INDUCTOR-AXIAL;33UH,10%,2.5X3.4MM RP126 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 LP05 2701-000158 INDUCTOR-AXIAL;22uH,10%,2.5x3.4mm RP127 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012 LP06 2701-000158 INDUCTOR-AXIAL;22uH,10%,2.5x3.4mm RP128 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 Samsung Electronics 8-11...
  • Page 43 SPK01 AA47-20001A SPARK-GAP;-,ICE60,6.1MM,KS,EU,BK RP49 2007-000931 R-CHIP;470OHM,5%,1/10W,DA,TP,2012 SWC01 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP RP50 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012 SWC02 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP RP51 2007-000931 R-CHIP;470OHM,5%,1/10W,DA,TP,2012 SWC03 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP RP52 2007-000221 R-CHIP;1.2KOHM,5%,1/10W,DA,TP,2012 SWC04 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP RP53 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012 SWC05 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP RP55 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012 SWC06 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 8-12 Samsung Electronics...
  • Page 44 INDLEDAA64-40517B INDICATOR-LED;-,-,-,ACRYL,-,CLEAR,- IN-AV AA64-60445E INLAY-AV;72A6,SCT55A EL MULTI-PIP,PS SH IN-PC AA64-60446A INLAY-PC;-,-,PS SHEET,T0.5,-,-,- BADGE AA64-70117B BADGE-BRAND;AL,SS,SILVER,L65,R2000,-,- C-CORD AA65-30008A CLAMP-CORD;PE,HB,BLK,-,-,- C-D,CO AA65-30017A CLAMP-D,COIL;NYLON-66,V0,NTR,DADH300,25 AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE C-WIREAA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE C-D,CO AA65-30113A CLAMP-D,COIL;NYLON 66,V2,BLK,TVI 25~29,- AA91-00098A ASSY-HOLDER,SPK;-,-,4OHM/20W,-,29A6 T/W, Samsung Electronics 8-13...
  • Page 45 Block Diagrams 9. Block Diagrams 9-1 Main PIP-FB PIP-Y/U/V TDA3504 RGB-MATRIX PIP-R/G/B SAB9077H SUV-Y/U/V CONTROLLER 548262 MEMORY- VIF/SIF-DETECTOR K9462 PIP-SOUND MAIN-Y/U/V Samsung Electronics...
  • Page 46 Block Diagrams 9-2 POWER TDA4665T TDA3504 TDA9160A 1H-DELAY RGB-MATRIX CHROMA-DEC. SAB9077H PIP-CONTROLLER 548262 DRAM Samsung Electronics...
  • Page 47 Q210 DZ708 Q601 DZ709 Q651 DZ710 Q701 DZ711 Q703 DZ712 Q704 DZ713 Q705 DZ714 Q706 DZ715 Q902 DZ716 Q903 DZ717 Q904 DZ901 Q905 DZ902 Q906 Q907 IC101 Q908 IC201 Q909 IC203 Q910 IC204 Q911 IC205* QT01 IC206 Samsung Electronics 10-1...
  • Page 48 D411 IC301 D412 IC401 D413 IC801 D415 IC802 TRANSISTOR D804* D805 Q401 D806 Q402 D807 Q404 D808 Q405 D809 Q406* D810 Q407* D811 Q408* D812 Q801 D813 Q802 D814 Q803 D815 Q804 D816 Q805 D817 Q806 D818 10-2 Samsung Electronics...
  • Page 49 PCB Layout 10-3 PWB-CRT 10-4 PWB-PIP Samsung Electronics 10-3...
  • Page 50 PCB Layout 10-5 SNAP-IN 10-6 PWB A/V SIDE 10-7 AUDIO-MODULE 10-8 POWER-S/W 10-4 Samsung Electronics...

  • Page 51: Wiring Diagram

    FRONT STD-S/W D-COIL S-IN 6.5V-A CNB13 TIMER CNB12 14.5V(A) GND (S) GND (S) 8.5V (A) S/T-LED CUT/OFF CNB04 V-SYNC TILT H-DRIVE V-DRIVE-P V-DRIVE-N CN203 16.5V (B) 33 V HEATER 135V CNB03 14.5V CN701 -14.5V 215V CNH01 CN01 Samsung Electronics 11-1...
  • Page 52 Schematic Diagrams 12. Schematic Diagrams 12-1 PWB-MAIN (1/4) Samsung Electronics 12-1...
  • Page 53 Schematic Diagrams 11-2 PWB-MAIN (2/4) 12-2 Samsung Electronics...
  • Page 54 Schematic Diagrams 11-3 PWB-MAIN (3/4) Samsung Electronics 12-3...
  • Page 55 Schematic Diagrams 12-4 PWB-MAIN (4/4) 12-4 Samsung Electronics...
  • Page 56 Schematic Diagrams 12-5 POWER Samsung Electronics 12-5...
  • Page 57 Schematic Diagrams 12-6 CRT 12-6 Samsung Electronics...
  • Page 58 Schematic Diagrams 12-7 AUDIO Samsung Electronics 12-7...
  • Page 59 Schematic Diagrams 12-8 PIP 12-8 Samsung Electronics...
  • Page 60 Schematic Diagrams 12-9 AV3-INPUT, S-VHS(2), SNAPIN, HEADPHONE HEADPHONE AV3-INPUT S-VHS (2) SNAP-IN Samsung Electronics 12-9...
  • Page 61 Schematic Diagrams 12-10 SECAM-MODULE, MASTER S/W, LED, REMOCON MASTER S/W SECAM-MODULE REMOCON 12-10 Samsung Electronics...
