Four-Faith F-IPC100 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
F-IPC100 User Manual
F-IPC100 User Manual
the user manual is suitable fort and the following model:
Document Version
Product Name
Model
Product Type
F-IPC100
Industrial Computer
Xiamen Four-Faith Communication Technology Co., Ltd.
Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen
Tel：+86 592-5907276 Fax:+86 592-5912735
Web:en.four-faith.com
V2.0.0
： F-IPC100
Page
Total:28

Advertisement

Table of Contents
loading

Related Manuals for Four-Faith F-IPC100

Summary of Contents for Four-Faith F-IPC100

  • Page 1 F-IPC100 User Manual the user manual is suitable fort and the following model: Model Product Type F-IPC100 Industrial Computer Xiamen Four-Faith Communication Technology Co., Ltd. Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen Tel：+86 592-5907276 Fax:+86 592-5912735 Web:en.four-faith.com...
  • Page 2 F-IPC100 Industrial Computer USER MANUAL Files Revised Record Date Version Remark Author 2016-1-21 V1.0 CYB/WZQ 2017-5-22 V1.1 Add Accessibility and System update 2017-10-10 V2.0.0 Change of company address Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 28 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com...
  • Page 3 Xiamen Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
  • Page 4 F-IPC100 Industrial Computer USER MANUAL Product appearance Note: There may be different components and interfaces in different model,please in kind prevail. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 28 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com...

  • Page 5: Table Of Contents

    F-IPC100 Industrial Computer USER MANUAL Contents Contents Chapter 1 Brief Introduction of Product..................7 1.1 General..........................7 1.2 Features and Benefits......................8 1.3 Product Specification......................10 1.3.1Cellular Specification....................10 1.3.2 Hardware System..................... 11 1.3.3Hardware Specification.....................11 Chapter 2 Installation Introduction....................13 2.1 Overview..........................
  • Page 6 F-IPC100 Industrial Computer USER MANUAL 4.1.12 RS485........................26 4.1.13 Hide navigation......................26 4.1.14 Display Interface Setting..................26 4.1.15 Accessibility......................26 4.1.16 System update......................27 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 6 of 28 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com...

  • Page 7: Chapter 1 Brief Introduction Of Product

    F-IPC100 is a function of the transmission belt 3G./4G ARM IPC, support 3G / 4G dial-up Internet access, support for firewall, VPN, QOS, port mapping, DDNS, system log...

  • Page 8: Features And Benefits

    F-IPC100 Industrial Computer USER MANUAL supports OTG interface. F-IPC100 support DC 9-25V wide input voltage and wide temperature properties are industrial applications, offers a variety of API, easy to read hardware information equipment manufacturers to achieve more development. 1.2 Features and Benefits Design for Industrial Application ...
  • Page 9 F-IPC100 Industrial Computer USER MANUAL  Enter into work state automatically when powered  Support 10/100 / 1000Mbps Ethernet  Support for multiple standard USB2.0 interface  Support for multiple interfaces RS232 DB9  Support for audio input and output interfaces ...

  • Page 10: Product Specification

    F-IPC100 Industrial Computer USER MANUAL 1.3 Product Specification 1.3.1Cellular Specification Item Content Cellular Module Industrial cellular module（Single module, dual module or no module） TDD-LTE/FDD-LTE/EVDO/WCDMA/TD-SCDMA/CDMA1X/GPRS/EDGE Standard and Band Optional singlemode, multimode or full Netcom FDD LTE(Download speed:100Mbps，upload speed:50Mbps) TDD LTE((Download speed:68Mbps，upload speed:17Mbps) Bandwidth EVDO ((Download speed:3.1Mbps，upload speed:1.8Mbps)

  • Page 11: Hardware System

    F-IPC100 Industrial Computer USER MANUAL 1.3.2 Hardware System Item Content Freescale i.MX6 Cortex-A9 1G DRAM On-board DDR3 2GB Flash 4 GB-32GB（ ） eMMC Optiona operating Android 4.4.2 system Software Support Compatible Android system rich applications Application BS architecture supports media distribution system 2D/3D OpenVG 1.1 for 2D;...
  • Page 12 F-IPC100 Industrial Computer USER MANUAL SATA WiFi 802.11b/g/n MINIPCIe Reserved，extend the network port or WIFI Interface HDMI 1920x1080, 1366x768, 1280x720, 1024x768 1920x1080, 1366x768, 1280x720, 1024x768 Dimensions 270.8x182x55 （mm） Physical Housing Iron Characteristi Protection class IP40 cooling method Fanless cooling Weight 1.6kg...

  • Page 13: Chapter 2 Installation Introduction

    F-IPC100 Industrial Computer USER MANUAL Chapter 2 Installation Introduction 2.1 Overview F-IPC100 must be installed correctly before they achieve the design features, the device must be installed in a generally recognized by the Company under the guidance of a qualified engineer.
  • Page 14 F-IPC100 Industrial Computer USER MANUAL Xiamen Four-Faith Communication Technology Co.,Ltd. Page 14 of 28 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735...

  • Page 15: Chapter 3 Hardware Functions

    3.1.1 Front view. 3.2 The front panel I/O connector 3.2.1 Audio Port(Speak-out & Mic-in) MB-F-IPC100 uses SGTL5000XNAA3 audio controller chip and TPA3113D2 amplifier chip. Green is the audio output interface (Speak-out), the pink microphone input interface (MIC-in). 3.2.2 LED Lights From the bottom left of the first column indicates the system power indicator PWR, SYS system running lights, WIFI working indicator, HDD hard disk light.

  • Page 16: Serial（Com1-Com6

    F-IPC100 Industrial Computer USER MANUAL 3.2.3 Serial（COM1-COM6） Provide 6 DB9 serial ports COM1-COM2 Pin definitions： Signal Signal Name Description transfer data Receive data Request to Send Allowed to send COM3-COM6Pin definitions： Signal Name Signal Description Carrier Detect Transfer data Receive data...

  • Page 17: Usb Interface

    4.8.12 3.2.5 Ethernet Interface(LAN/WAN) MB-F-IPC100 offers 1 * 10/100 / 1000Mbps Fast Ethernet ports, LAN / WAN, given below its pin definitions, LILED and ACTLED Ethernet interfaces on both sides of the green and yellow LED display them with the active LAN .

  • Page 18: Display Interface(Hdmi & Vga)

    F-IPC100 Industrial Computer USER MANUAL is stopped on or off 3.2.6 Display Interface(HDMI & VGA) Provide 1 high-definition HDMI display interface,1 VGA interface, dual-channel LVDS interface. 3.2.7 Power Interface DC-input, 9-25 VDC, power connector aviation head interface, the machine automatically when a call starts, you can set whether the power-on self start.

  • Page 19: Can&Rs485 Interface

    F-IPC100 Industrial Computer USER MANUAL 3.3.1 CAN&RS485 Interface Pin definitions： 6.7.8.9.10 Signal CANH CANL GPIO 3.3V/5V/12V Name 3.3.2 SATA Interface(mSATA, J23) 7+15pin SATA provides a signal interface and mSATA (mini PCI-e) interface. But not both, you can only choose one of these interfaces use.

  • Page 20: Audio Interface(Aduio, J22)

    2.24.39.41.52 VCC3V3 1.3.5.6.7.8.10.11.12.13.14.16.17. 19.20.28.30.32.36.38.42.45.46.47.48.49.50.51 3.3.3 Audio Interface(ADUIO, J22) MB-F-IPC100 uses SGTL5000-XNAA3 audio controller chip and TPA3113D2 amplifier chip. J22 audio jack. J22 audio pin definition： Xiamen Four-Faith Communication Technology Co.,Ltd. Page 20 of 28 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com...

  • Page 21: Display Interface(Lvds, Cn3)

    F-IPC100 Industrial Computer USER MANUAL Signal Name OUTPL OUTNL OUTNR OUTPR Audio amplifier Audio amplifier Audio amplifier Audio amplifier Function output output output output 3.3.4 Display Interface(LVDS, CN3) LCDS-socket interface pin definitions： Signal Name Signal Name LVDS0_TX3_3P VCC3V3/5V/12V LVDS0_TX3_3M VCC3V3/5V/12V...

  • Page 22: Mricro Sd Cards Lot

    CONTRAST LVDS1_TX0_0P LVDS1_TX0_0M 3.3.5 Mricro SD cards lot MB-F-IPC100 supports external expansion Microsd slot, maximum support 32G expansion. 3.3.6 SIM card slot 1 SIM card slot (supports optional dual SIM slot), support for 3G / 4G. Xiamen Four-Faith Communication Technology Co.,Ltd.

  • Page 23: Chapter 4 Software Functions

    F-IPC100 Industrial Computer USER MANUAL Chapter 4 Software Functions 4.1Android System 4.1.1Display Interface Support VGA and HDMI display differnce Support VGA and HDMI display same LVDS Interface(optional)。 4.1.2 USB 8*USB interface，Support USB disk, USB mouse/keyboard, USB camera, USB touch screen etc..

  • Page 24: Com

    F-IPC100 Industrial Computer USER MANUAL 4.1.3 COM COM device node：/dev/ttymxc1~/dev/ttymxc6(COM1~COM6) 4.1.4 TF Card TF Card mount on directory：/mnt/media_rw/extsd/，can read/write on PC by OTG cable。 4.1.5 Hard Disk Hard Disk mount on directory：/mnt/media_rw/sata，can read/write on PC by OTG cable。 4.1.6 WIFI Support SDIO interface module and usb interface module;Customer can select(used...

  • Page 25: Network Auto Switch

    F-IPC100 Industrial Computer USER MANUAL 4.1.8 Network Auto Switch Support Network auto switch. Priority:Ethernet->WIFI->3G/4G 4.1.9 USB Camera USB Camera support YUV、MJPG data format. 4.1.10 Voice Double channel Local audio and HDMI audio out,one channel MIC input. Local audio support poweramplifier an headphone out switch.

  • Page 26: Rs485

    F-IPC100 Industrial Computer USER MANUAL 4.1.12 RS485 1 channel RS485，decice node:/dev/ttymxc8 4.1.13 Hide navigation At “setting”->”display” set Hide navigation or on.Like the following figure: 4.1.14 Display Interface Setting At “setting”->”display” set Display Interface.Like the following figure: 4.1.15 Accessibility At “Setting” ->”Accessibility”->”Root adb Enable”.Like the following figure: Xiamen Four-Faith Communication Technology Co.,Ltd.

  • Page 27: System Update

    F-IPC100 Industrial Computer USER MANUAL Cancel root adb enable take effective after reboot. At “Setting” ->”Accessibility”->”VNC Enable”.Like the following figure: At “Setting” ->”Accessibility”->” adb network Enable”.Like the following figure: adb network enable need connect again if reboot. 4.1.16 System update At “Setting”->”About tablet”->”System update”->Local updates.

  • Page 28: Xiamen Four-Faith Communication Technology Co.,Ltd

    F-IPC100 Industrial Computer USER MANUAL Click update.zip to finish system update. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 28 of 28 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735...
