F-IPC110 Industrial
Computer User Manual
F-IPC110 Industrial Computer
the user manual is suitable fort and the following model:
Document Version
Product Name: F-IPC110
User Manual
Model
Product Type
F-IPC110
Industrial Computer
Xiamen Four-Faith Communication Technology Co., Ltd.
Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen
Tel：+86 592-5907276 Fax:+86 592-5912735
Web:en.four-faith.com
V2.0.0
Page
Total: 26
Advertisement
Table of Contents
Related Manuals for Four-Faith F-IPC110
Summary of Contents for Four-Faith F-IPC110
- Page 1 F-IPC110 Industrial Computer User Manual the user manual is suitable fort and the following model: Model Product Type F-IPC110 Industrial Computer Xiamen Four-Faith Communication Technology Co., Ltd. Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen Tel：+86 592-5907276 Fax:+86 592-5912735 Web:en.four-faith.com...
- Page 2 F-IPC110 Industrial Computer USER MANUAL Files Revised Record Date Version Remark Author 2016-1-21 V1.0.0 CYB/WZQ 2017-5-22 V1.1.0 Add accessibility and system update 2017-07-12 V1.1.1 Update hardware functions Harven 2017-10-10 V2.0.0 Change of company address Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 26 Add：...
- Page 3 Xiamen Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
- Page 4 F-IPC110 Industrial Computer USER MANUAL Product appearance Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 26 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735...
-
Page 5: Table Of Contents
F-IPC110 Industrial Computer USER MANUAL Contents Contents Contents.............................5 Contents Chapter 1 Brief Introduction of Product..................7 1.1 General..........................7 1.2 Features and Benefits......................8 1.3 Product Specification......................10 1.3.1Cellular Specification....................10 1.3.2 Hardware System..................... 10 1.3.3Hardware Specification.....................11 Chapter 2 Installation Introduction....................13 2.1 Overview.......................... - Page 6 F-IPC110 Industrial Computer USER MANUAL 4.1.12 Display Interface Setting..................24 4.1.13 Accessibility......................24 4.1.14 System update......................25 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 6 of 26 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com Tel： +86 592-5907276...
-
Page 7: Chapter 1 Brief Introduction Of Product
F-IPC110 is a function of the transmission belt 3G/4G ARM IPC, support 3G / 4G dial-up Internet access, support for firewall, VPN, QOS, port mapping, DDNS, system log... -
Page 8: Features And Benefits
F-IPC110 Industrial Computer USER MANUAL interface. F-IPC110 support DC 5-36V DC wide input voltage and wide temperature properties are industrial applications, offers a variety of API, easy to read hardware information equipment manufacturers to achieve more development. 1.2 Features and Benefits Design for Industrial Application ... - Page 9 F-IPC110 Industrial Computer USER MANUAL Enter into work state automatically when powered Support 10/100/1000Mbps Ethernet Support for multiple standard USB2.0 interface Support for multiple interfaces RS232 DB9 Support for audio input and output interfaces High-performance ...
-
Page 10: Product Specification
F-IPC110 Industrial Computer USER MANUAL 1.3 Product Specification 1.3.1Cellular Specification Item Content Cellular Module Industrial cellular module（Single module, dual module or no module） TDD-LTE/FDD-LTE/EVDO/WCDMA/TD-SCDMA/CDMA1X/GPRS/EDGE Standard and Band Optional single mode, multimode or full Netcom FDD LTE(Download speed:100Mbps，upload speed:50Mbps) Bandwidth EVDO Rev A ((Download speed:3.1Mbps，upload speed:1.8Mbps) WCDMA((Download speed:42Mbps，upload speed:5.76Mbps) -
Page 11: 3Hardware Specification
F-IPC110 Industrial Computer USER MANUAL Processing HDMI 1920x1080， 1366x768， 1280x720， 1024x768 etc. 1920x1080， 1366x768， 1280x720， 1024x768 etc. 3G/4G network support LTE, FDD-LTE, WCDMA (HSPA+) etc. Security function support VPN PPTP, IPSEC VPN Wi-Fi support 802.11b/g/n, Client/AP mode Hardware support monitor... - Page 12 F-IPC110 Industrial Computer USER MANUAL Operating -35~+75ºC（-31~+167℉） Temperature Environmenta Storage -40~+85ºC (-40~+185℉) l Limits Temperature Operating 95% ( unfreezing) Humidity Power Lights System Lights Lights ONLINE Module on-line indicator WIFI WIFI working lights Static electricity EN61000-4-2,level 3 (Contact 6 kv, 8 kv air discharge) indicators Xiamen Four-Faith Communication Technology Co.,Ltd.
-
Page 13: Chapter 2 Installation Introduction
F-IPC110 Industrial Computer USER MANUAL Chapter 2 Installation Introduction 2.1 Overview F-IPC110 must be installed correctly before they achieve the design features, the device must be installed in a generally recognized by the Company under the guidance of a qualified engineer. - Page 14 F-IPC110 Industrial Computer USER MANUAL Fixed Size IPC Size Xiamen Four-Faith Communication Technology Co.,Ltd. Page 14 of 26 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735...
-
Page 15: Chapter 3 Hardware Functions
3.1.2 Back view 3.2 The front panel I/O connector 3.2.1 Audio Port(Speak-out, Mic-in) MB-F-IPC110 uses SGTL5000XNAA3 audio controller chip. Green is the audio output interface (Speak-out), the pink microphone input interface (MIC-in). Xiamen Four-Faith Communication Technology Co.,Ltd. Page 15 of 26 Add：... -
Page 16: Led Lights
F-IPC110 Industrial Computer USER MANUAL 3.2.2 LED Lights From the bottom indicates: PWR system power indicator lights, SYS system running lights, the online module line indicator lights, WIFI working indicator light. 3.2.3 Serial（COM1-COM6） Provide 6 DB9 serial ports COM1-COM4 Pin definitions：... -
Page 17: Usb Interface
Request to Send Allowed to send RS485-B RS485 data- 3.2.4 USB Interface MB-F-IPC110 offers 4 standard USB2.0 interface, 1 OTG interface, support plug and play. USB Pin definitions： Signal Name Xiamen Four-Faith Communication Technology Co.,Ltd. Page 17 of 26 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com... -
Page 18: Ethernet Interface（Lan/Wan
F-IPC110 Industrial Computer USER MANUAL 3.2.5 Ethernet Interface（LAN/WAN） MB-F-IPC110 offers 1 * 10/100/1000Mbps Fast Ethernet ports, LAN or WAN, given below its pin definitions, LILED and ACTLED Ethernet interfaces on both sides of the green and yellow LED display them with the active LAN. -
Page 19: Power Interface
F-IPC110 Industrial Computer USER MANUAL 3.2.7 Power Interface DC-input, 5-36 VDC, power connector aviation head interface, the machine automatically when a call starts, you can set whether the power-on self start. 3.3 Internal interface specifications Please carefully read when connecting external connector of the present manual, in order to avoid damage to the motherboard. -
Page 20: Display Interface (Lvds&Cn3)
LVDS1_TX1_1M CONTRAST LVDS1_TX0_0P LVDS1_TX0_0M 3.3.4 Mricro SD cards lot MB-F-IPC110 supports external expansion Microsd slot, maximum support 32G expansion. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 20 of 26 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com Tel：... -
Page 21: Sim Card Slot
F-IPC110 Industrial Computer USER MANUAL 3.3.5 SIM card slot 1 SIM card slot, support for 3G/4G. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 21 of 26 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com Tel： +86 592-5907276... -
Page 22: Chapter 4 Software Functions
F-IPC110 Industrial Computer USER MANUAL Chapter 4 Software Functions 4.1 Android System 4.1.1Display Interface Support VGA and HDMI display differnce Support VGA and HDMI display same LVDS Interface(optional)。 4.1.2 USB 4*USB interface, Support USB Disk, USB mouse/keyboard, USB camera, USB touch screen etc.. -
Page 23: Wifi
F-IPC110 Industrial Computer USER MANUAL 4.1.6 WIFI Support SDIO interface module and usb interface module. Customer can select (used SDIO default). 4.1.7 Ethernet 10/100/1000Mbps Ethernet Mac. At android system“Setting”->”Ethernet”config. The following figure provides the Ethernet config： 4.1.8 Network Auto Switch Support Network auto switch. -
Page 24: Usb Camera
F-IPC110 Industrial Computer USER MANUAL 4.1.9 USB Camera USB Camera support YUV, MJPG data format. 4.1.10 Voice Double channel Local audio and HDMI audio out, one channel MIC input. Local audio support power amplifier an head phone out switch. 4.1.11 Hide navigation At “setting”->”display”... - Page 25 F-IPC110 Industrial Computer USER MANUAL Cancel root adb enable take effective after reboot. At “Setting” ->”Accessibility”->”VNC Enable”.Like the following figure: At “Setting” ->”Accessibility”->” adb network Enable”.Like the following figure: adb network enable need connect again if reboot. 4.1.14 System update At “Setting”->”About tablet”->”System update”->Local updates.
-
Page 26: Xiamen Four-Faith Communication Technology Co.,Ltd
F-IPC110 Industrial Computer USER MANUAL Click update.zip to finish system update. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 26 of 26 Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735...
