SMART CART. An exclusive feature of the Model 2001 is the Smart Cart
which can transport the complete machine or can be removed to handle
loaded cable drums separately. A double shaft arrangement on the cart
can be swung to carry the complete machine, or the cable drum, or
power unit separately. The cart is equipped with integral continuous belt
stair skids for easier transporting up and down stairways. A kick-stand at
the bottom of the cart supports it to stand alone.
KICKSTAND
Description (cont.)
WARNING: Insure the locking pin with chain located on the back
of the Smart Cart is always locked in position before transporting
the drum, and insure the double shaft spring loaded latch is
engaged in the lower lock position when transporting the machine.
If the locking pin with chain is not in position or the double shaft
spring latch is not engaged, the drum or machine can separate
from the Smart Cart and injury or property damage may result.
BELT
STAIR
SKIDS
10" PNEUMATIC TIRE
HANDLE
CART LOCK PIN
DOUBLE SHAFT ASSEMBLY
PIVOT BLOCK
