Summary of Contents for SunDash Radius 252
- Page 3 S pecifications Depth: 50" Door Closed, 63” Door Open Width : 39.5" Height: 90" Shipping Weight: 1325 Lbs. No. of Lamps : Electrical : 39 AMPS @ 225 Volts, Three Phase or 63 Amps @ 225 Volts, Single Phase Circuit Requirements: 120/225V 3 Phase 50 Amp or 120/225V Single Phase 80 Amp DANGER - ULTRAVIOLET RADIATION.
- Page 4 Warnings and Cautions It is recommended that only one person Certain drugs - particularly those that at a time should use the tanning system while p r o d u c e p h o t o s e n s i t i v i t y - m a y c a u s e in use, and advises using protective eyewear individuals under the influence of this type drug while taking a tanning session.
- Page 5 Care and Cleaning of Your Tanning Unit After each session is completed, spray the cloth because this will generate a slight static acrylic surface with specially formulated UVT charge which will attract dust. A mild liquid (ultraviolet transmitting) acrylic cleaner. Wipe detergent and water solution can be used the surface of the acrylic with a clean cloth.
- Page 6 Exposure Time and Frequencies Melanin - The brownish pigment produced The amount of melanin in your body by special cells in the base layer of your skin determines how quickly and dark you t an. The determines the individual’ s tan. As the skin is more melanin produced and exposure time an exposed to the ultraviolet light, the melanin is individual has, the faster and deeper the...
- Page 7 Assembly Instructions Step 1 Remove floor assembly from carton marked “Top” The floor of your tanning unit consists of - two (2) parts A- Base -lower floor B. Floor -upper floor Step 2 Illustration 1 Position base in desired location. Align floor allowing a minimum of 63"...
- Page 8 Assembly Instructions Step 5 Remove panel C from marked “PLC” and locate on base. Align slots in bottom plate of panel C with the alignment pins in floor . Align right side of panel C with left side of panel B, the side rails of both panels should nest together.
- Page 9 Assembly Instructions Step 9 Locate lamp harness and place on top. To connect lamp harness to panel A terminate harness to panel A cord 2 align plug and twist clock wise until locked. Repeat procedure for panel B cord 2, panel C cord 2 and door panel cord.
- Page 10 Assembly Instructions Step 15 Attach ballast access covers with #6 x 3/8 philips screws and snap caps. (See Illustration 11) Step 16 There are two terminal blocks located on the ballast tray installed in each panel. Each panel has a relay with four Illustration 11 power wires (2 Black &...
- Page 11 Intellitan Plus Operating Instructions To Set Time STEP 1:Press on the button labeled time to reach desired setting in minutes. STEP 2:Press “Start/Stop” to begin operation. The session is counted down in minutes and seconds. NOTE: If a session delay is preprogrammed (P04), the display will begin to flash the session time.
- Page 12 Timer Edit Procedure To Change Parameters To enter the System’s data bank, monitor operations and verify the vit a l functions concerning your unit, use the following step-by-step instructions. Note: Each timer manufactured after 1995 displays the current software version on power up. These instructions are for level 2 and above of the Intellitan Plus timer.
- Page 13 Parameter Detail Parameter 2 is the chime mechanism that provides an audible ‘beep’ sound when the keys are depressed and to indicate the various operations occurring. The audible beep can be turned on or turned off. The unit comes with the chime mechanism turned on to provide an audible beep. When parameter 02 is shown, the display will read 0001.
- Page 14 Parameter Detail Parameter 4 is the session delay. The session delay allows a programmable amount of time at the beginning of a session to get ready for the tanning session. The tanning session time shown on the timer flashes during the session delay. The unit comes with no session delay preprogrammed. To Change Parameter 4, Session Delay When parameter 04 is shown, the display will read 0.0 for no session delay.
- Page 15 Parameter Detail Parameter 7 is the measurement of the A/C voltage on phase A. The A/C voltage will be immediately displayed from 0000 to 0200 volts, with 0120 as the nominal reading. Now press "up" once and release it to reach Parameter 8 (P08), to measure A/C Voltage Phase B. Parameter 8 is the measurement of the A/C voltage on phase B.
- Page 16 Parameter Detail Parameter 14 is the measurement of the average ambient or room temperature during a previous session or current session if the unit is energized. The reading is immediately displayed. Measurement is in Fahrenheit. Now press "up" once and release it to reach Parameter 15 (P15), the Clean Room feature. Parameter 15 is the clean room feature.
- Page 17 Parameter Detail Parameter 18 is the Session Counter . The session counter displays the total number of times a session has been started since first day of operation. The session counter counts from 0000 to 9999 then rolls over. The session counter cannot be adjusted or reset. Now press once and release it to reach Parameter 19 (P19), Total Hour Accumulation.
- Page 18 Parameter Detail Parameter 26 is the Third Party Interface (TPI) Mode toggle. The default is 0 for disabled. The Intellitan Plus timer has a TPI jack built in to the timer itself. This jack replaces the need for a second or additional interface when using other timer systems.
- Page 19 Wiring Diagram...
- Page 20 Relay Diagram...
- Page 21 Relay Panel A...
- Page 22 Relay Panel B...
- Page 23 Relay Panel C...
- Page 24 Relay Terminal Block...
- Page 25 Ballast Tray Connection...
- Page 26 Ballast Tray A1, B1 and C1...
- Page 27 Ballast Tray A2 and C2...
- Page 28 Ballast Tray B2...
- Page 29 Bed Cords...
- Page 30 Door Harness...
- Page 31 3 Phase Connection...
- Page 32 Single Phase Connection NOTE: This unit is factory pre-wired for three phase operation. During conversion to single phase operation you must replace the incoming power wires to 4 gage THHN 90 degrees or equivalent.
- Page 33 General Troubleshooting Guide The following troubleshooting information is divided into two sections. Section A contains items in which the owner may check without the aid of a service person. Section B contains items which must be performed by QUALIFIED SERVICE PERSONNEL ONLY. If you have any questions other than the ones listed in your troubleshooting guide, contact your dealer or distributor NOTE: All tanning units are not the same, therefore some of the causes may not apply to your unit.) General Troubleshooting (Section A)
- Page 34 † The schedule for acrylic replacement listed refers only to the condition of the acrylic relating to safety and does not address the efficacy of UV transmission. ‡ Inspection may not be sufficient for some units of model Sundash Radius 252 and must have cord replaced. Contact JK Global Service for information regarding this component.
- Page 35 L i m i t e d Wa r r a n t y JK Products warrants its products to be free from defects in materials and workmanship under intended normal use as described in the unit’s Operation and Instruction Manual, for a period of one (1) year from date of sale.
- Page 36 L i m i t e d A c r y l i c Wa r r a n t y JK Products warrants its acrylic sheets to be free from defects in material and workmanship, under intended normal use, for a period of one (1) year from date of sale of the tanning bed. Due to the tanning lotions, cosmetics, disinfectant and improper cleaners used on tanning surfaces that cannot be controlled by JK Products af t er the first thirty (30) days of warranty period.
- Page 37 Wa r r a n t y C l a i m s P o l i c y & P r o c e d u r e s When to file a Warranty Claim: In the event that your tanning system is not functioning properly under intended normal use as described in the unit’...
- Page 38 Parts Warranty Claim/Credit Review Customer calls JK Products and notifies the Global Service Division of problem. JK Global Service determines course of action. JK Global Service ships part and R.A.I. to customer freight collect and bills customer on net 30 basis for part only.
- Page 40 1 Walter Kratz Drive 0071205301 Jonesboro, AR 72401 02/2012 V3 www.ergoline.us 800.643.0086 ergoline@sunergoline.com Notice: Any misuse, abuse, modification, alteration, improper maintenance, improper installation, etc. of this product or its intended use will subject said p arty to direct responsibility and liabilities for any and all consequences resulting from such action. Furthermore, such actions will void all warranties and may relieve of any liabilities relating to said product.
