Deze garantie geldt gedurende 12 maanden voor elke fabricagefout aan uw JOY SPORT product die door een gemachtigd JOY SPORT dealer werd verkocht. Wanneer u garantie claimt bied JOY SPORT de mogelijkheid om naar eigen goeddunken het defecte apparaat of het betreffende onderdeel te herstellen of te vervangen.
Page 3
Veligheids instructies Lees de volgende veiligheids punten aandachtig door: 1. Houd kinderen altijd uit de buurt van dit apparaat, de enthousiastheid van kinderen kan leiden tot verkeerd gebruik van dit apparaat, zorg altijd dat wanneer kinderen dit apparaat gebruiken dit gebeurd onder toezicht van een volwassen persoon.
Page 5
Onderdelen & Gereedschap. Naam en Specificatie Photo Naam en Specificatie Photo tal. tal. M4*20 Schroef Stuurknop busje M5*16 Bout Stuurknop M8 Veerring M8*20 Bout M8 Gebogen ring M8 Borgmoer OD20*ID8.5*1.5T Ring 5MM inbussleutel M8*72 inbusbout Multifunctionele sleutel OD12*ID8*1.5T Ring Dopsleutel met Kruiskop...
Page 6
Voor stabilisator Houd de voor stabilisator (21) Dicht 16 17 bij het hoofdframe. Plaats een M8 veerring (16), M8 Gebogen ring (17) over de M8*72 inbusbout (19) en monteer de voor stabilisator vast op het hoofdframe.. Achter Stabilisator Houd de achter stabilisator (55) dicht bij het hoofdframe.
Page 7
5 Zadel Draai eerst de bout los zoals aangegeven op foto 5-A. Plaats nu het zadel (34) op de zadelpen (34). Draai nu de bout uit foto 5-A weer aan . Draai de zadelknop een stukje los en trek deze uit (44) Plaats nu de zadelpen (34) in het hoofdframe.
Page 8
7 Computer Demonteer de vier M5*12 schroefjes (2) welke al zitten gemonteerd in de computer (1). Sluit nu de kabel (30) aan op de achterzijde van de computer. Monteer nu de computer (1) op de stuurkolom (14) en gebruik hiervoor de vier M5*12 schroefjes voor.
Page 9
9 Bidonhouder Monteer de bidonhouder (35) op de stuurkolom. Gebruik hiervoor twee M5*16 schroefjes (12) om de bidonhouder op de stuurkolomte monteren. Plaats de bidon (36) in de bidonhouder. 10 Uw apparaat aansluiten op het lichtnet Zorg ervoor dat U de adaptor (81) altijd aansluit op het lichtnet met (230V-50HZ).
Page 11
Onderdelenlijst. Naam en Specificatie Aantal. NR. Naam en Specificatie Aantal. Computer Computer kabel Schroefjes M5*12 Plastic bus Afdichtdopje Zadelknop Stuur motor Foam Kabel Handgreepsensoren Hoofdframe Foam Kabel M3*10 schroefjes Lager R12 Kabel handgreepsensoren Borgveer Beschermkapje M10*6.35T Borgmoer M4*20 schroefjes M8*20 Bout M5*16 bout M8 Borgmoer Beschermkapje...
Page 12
Computer Handleiding handgrip sensoren vast gedurende 15 seconden. Uw lichaamsvet waarde zal worden weergegeven in het BODY FAT scherm. Tegelijkertijd zal ook links op het computerpaneel worden aangegeven in welke categorie u zich bevindt wat betreft uw gewicht (ondergewicht – normaal gewicht – overgewicht –...
Page 13
daartoe de procedure zoals hierboven beschreven tot 1 minuut wordt de hartslag weergegeven op het in de functie manual. Let wel, in de functie program scherm. kan “WATT” niet voorgeprogrammeerd worden. • Wenst u geen waarden in te stellen, druk dan direct op “ST/STOP”...
Page 14
De computer zal een alarm geven als U boven uw maximale hartslag komt en het alarm zal pas weer stoppen als uw hartslag weer op het gewenste niveau zit. (Optioneel) Ook verkrijgbaar is de draadloze hartslagband van JOY SPORT. Wanneer U deze band draagt tijdens Uw training hoeft U de handgrepen niet vast te houden.
Dear customer, We want to thank you for having chosen a JOY SPORT product, and wish you a lot of fun and success during training with your JOY SPORT exercisers. Please note and follow the enclosed safety and assembly instructions carefully.
General safety instructions In the design and the production of this fitness equipment, much attention has been paid to safety. Nevertheless, you need at all times to remain conscious of certain safety measures. Make certain that you have carefully read through the whole user manual prior to your use of the equipment.
Warning Consult with your physician prior to starting your exercises. A frequent and intensive training programme should first be approved by your family physician. This is especially important for individuals above 35 years of age or for those with physical problems. Carefully read through the entire user manual before you start exercising.
Page 19
手握心跳 Hand pulse 手把管 Handle bar 仪表 Meter Handle bar knob 手把旋扭 仪表杆组 Meter post 水壶 Water bottle 座垫 Seat Seat post adjust 拉销 knob 座垫调节旋扭 仪表杆护套 Meter post housing Seat support 右脚踏板 Right foot pedal 前贴地管 Front stabilizer Right body cover 右外盖...
Page 20
Parts & Tools Please review the following photos to identify the tool you will use for assembly. Name & Specs Photo Name & Specs Photo M4*20 cross screw handle bar knob tube bushing M5*16 round cross screw handle bar knob M8 spring washer M8*20 carriage screw M8 arc washer...
Page 21
FRONT STABILIZER Take the front stabilizer (21) close to 16 17 the front bottom of main frame. Inert through a M8 spring washer (16), M8 arc washer (17) with an M8*72 innerhexagon screw (19) and lock the up on the stabilizer. REAR STABILIZR GROUPP Attach the rear stabilizer group (55) on the rear bottom of the main frame.
Page 22
5 SEAT First loosen the nuts which are fixed with the seat (34) please refer to photo illustration 5-A. Then slide the seat (34) on the seat group (34). Tighten the loosen nuts. Pull out the seat post knob (44) and hold on. Insert the seat group (34) into the main frame.
Page 23
7 METER Remove the meter screws M5*12 (2) from the back of the meter (1). Combine the meter connecting upper wire (53) with meter wire at back of the meter. Attach the meter (1) on the top site of the meter post (14) and use the removed meter screws M5*12 to lock them up.
9 WATER BOTTLE Attach the water bottle holder (35) on the meter post. Use M5*16 round cross screw (12) to fix them. Insert the water bottle (36) into the holder. 10 POWER SUPPLY Please make sure the transformer is connected with your country’s power standard (200-240V~50/60Hz).
PARTS LIST. NAME & SPECS QTY. NAME & SPECS QTY. NR。 meter meter connecting lower wire meter screws M5*12 seat post bushing handle bar end caps seat post adjust knob handle bar motor handle bar foam 1 sensor wire with sensor and fixer handle pulse main frame handle bar foam 2...
Page 27
Computer Instructions the evaluation should also be different. Check the reference list shown below. RESET To clear the display and reset all data. Press for 3 seconds to clear all data, the display will show ‘U1’. Press for 1 second to clear last single entry or one single display.
Page 28
• Function value range If you donot intend setting any target value, start exercising by pressing the “ST/STOP” button. Functions Display Range Preset Range Training in USER mode Speed 0.0 - 99.9 km/h None 20 - 999 rpm None • Select “USER”, use “UP”and“DOWN”...
Page 29
To achieve a considerable improvement of your Some stretching and pedalling with low pedalling physical resistance and your health, some aspects of resistance will get you started. how to achieve the most efficient training should be followed: warming-up program Intensity Stretch or flexibility training is vital for a fit and healthy physique.
