WZ 1300 Moisture Meter manual
Please read the manual carefully and familiarize yourself with the functions of the unit before
using it. Retain these instructions for future reference and pass them on together with the
devic e when you pass on the device to other users.
Scope of delivery
Immediately after unpacking please check the package cont ents for completeness and if all
parts and the product are in good condition.
1 Moisture Meter
1 Instructions for use
Technical Data
Operating voltage: 9V
, 15 mA
Battery type: 6F22/6LR61 (9 V block battery)
Operating temperature: 0 °C to 40 °C
Protection class: IP 20
Resolution: 0.1%
Air humidity: up to a maximum of 80% (relative)
Prodcut Overview
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Technoline WZ 1300
Summary of Contents for Technoline WZ 1300
-
Page 1: Scope Of Delivery
WZ 1300 Moisture Meter manual Please read the manual carefully and familiarize yourself with the functions of the unit before using it. Retain these instructions for future reference and pass them on together with the devic e when you pass on the device to other users. -
Page 2: General Safety Information
(1) Protective cap (6) Battery compartment (2) Measuring pins (7) Display (3) MODE button (Material selection) (8) Moisture indicator in % (9) Material number button (displays measurement on (10) Battery indicator screen,°C or °F pre-selected) (11) Lock symbol (Measured value frozen) (12) Temperature display (°C or °F) button (ON/OFF) General safety information... -
Page 3: Taking A Measurement
Inserting / changing the battery If the battery symbol appears in the display (7), the inserted battery is almost drained and must be replaced. Empty batteries can falsify the measured result. To insert the battery proceed as follows: ● Open the battery compartment cover on the back of the device. You can remove the used battery more easily with the aid of the material strip, whic h is inside the battery compartment (6). - Page 4 Note: When measuring under the measurement range, the display shows “0.0%” or “Lo”. For measurements above the measurement range, the display shows “Hi”. ● Remove the protective cap (1) . ● Press both measuring pins (2) against the surface at the same time. After 1 -2 seconds you can read the percentage value.
-
Page 5: Troubleshooting
● If you are taking a meas urement in an area in which you can not read the display, press the button to freeze the result on the display. The displ ay will then also show the lock symbol. ● Press the button again to take another measurement. - Page 6 ● Clean the meas uring pins with a slightly dampened cloth and dry it afterwards. ● Check the device for visible external damage before every use. ● Check the measuring pins for damage before every use. Storage ● Always attach the protective cap (1) to the device when not in use. ●...
