Before operating your Air
Purifier, please read this
user manual carefully and
retain the manual for
future reference.
USER'S GUIDE
AIR PURIFIER
HexaDuo Smart
Contents
0
Page
1
2
3
3
4
6
8
10
11
11
15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HexaDuo Smart and is the answer not in the manual?

Questions and answers

Related Manuals for Nectar HexaDuo Smart

Summary of Contents for Nectar HexaDuo Smart

  • Page 1: Table Of Contents

    USER’S GUIDE AIR PURIFIER HexaDuo Smart Contents Page Features Safety Information Packing List Components Operations Instructions Clean and Maintenance Before operating your Air Purifier, please read this Trouble Shooting user manual carefully and retain the manual for Specification future reference.

  • Page 2: Features

    Thank you for purchasing HexaDuo Smart. The HexaDuo Smart is easy to use, and helps produce a clean and safe environment. It is an energy-efficient high performance air purifier with patent HIRD technology to help build a green life style.

  • Page 3: Safety Information

    Safety Information   Do not use outdoors. Do not use as a toy.   Do not use damaged Do not repair the unit by adaptor or plug. yourself.   Do not handle the adaptor Do not use in wet places. or device with wet hands.

  • Page 4: Packing List

    Packing List Components...

  • Page 5: Operations

    Operations Buttons / Indicators Descriptions Operation Modes Sleep mode: All the indicators will be off when the sleep mode operated. And that will resume to normal stage after 6 hours or you’re press any of the device and using the APP button...
  • Page 6 Warning Description Indication When the accumulated operation time reach two weeks, the Cleaning Indicator will be lights up to remind the user to clean the collection array. After cleaning the collection array, the user Cleaning mode should press the Intelligent Mode Button for 3 seconds to confirm the cleaning is completed, the Cleaning Indicator will be turn off and the device...

  • Page 7: Instructions

    Instructions 1. Connect the adaptor and manage the power cord. Note: Leave about 1ft (0.3m) behind and a free path way in the front to allow unobstructed air flow for best performance. 2. Turn on the unit.
  • Page 8 NOTE: You may hear static noise when the unit is first started. This is normal due to setting up of the hyper ionic field for capturing the airborne particles. 3. Adjust the required speed. 4. Stretch the bipod of the unit and put the unit on a flat table or floor.

  • Page 9: Clean And Maintenance

    Clean and Maintenance 1. Power off the unit and pull down the lock button to unlock and then remove the collection array from the unit. 2. For strong or sticky oil type pollutant, using spray soft cleaner and use cleaning tool to clean the individual dust plate and mesh cover.
  • Page 10 3. Immerse the whole collection array into water or rinse it thoroughly under running water. 4. Dry the collection array before re-install that to the unit. Re-install the collection array in vertical direction down and it will locked by lock button, HexaDuo Smart will be resume to normal operation.

  • Page 11: Trouble Shooting

    Note:  Continue using the unit for two weeks, the lights up to alert you having to clean the collection array. After cleaning, re-install collection array back to the unit, press button for 3 seconds to confirm cleaning is finished ...

  • Page 12: Specification

    The above specifications are only for reference. With more advanced development and innovation, the specifications will be changed. Nectar Smart APP The HexaDuo Smart mobile APP will let you control your HexaDuo Smart anywhere. You can connect your Nectar Smart through the WiFi router network with mobile devices.
  • Page 13 2. Launch Nectar Smart App and start Registered. 3. Fill in the information’s for Registration and Connect the your mobile to the Wi-Fi Network...
  • Page 14 4. Adding HexaDuo Smart(AP) to you mobile 5. Pairing between the Air Purifier and Nectar Smart APP.
  • Page 15 6. Pairing process completed and then Main Page Display. 7. Speed adjustment & Intelligent Mode.

  • Page 16: Customer Support

    Customer Support Email: Support@nectarsmartiving.com Website: www.nectarsmartiving.com/support Cautions：  WARNING - RISK OF ELECTRIC SHOCK – These servicing instructions are for use by qualified personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.
  • Page 17 use of the appliance in safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.  Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 18 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.  This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator &...
  • Page 19 (2) Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de l'appareil.  Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 etla conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne surl'exposition et la conformité...
