HW Group 1W-UNI Quick Start Manual

Flood detector 1W-UNI 3m
Water flood sensor – spot detector, 1-Wire UNI interface.
Water leak detection using four protruding pins on the sensor body. The
attached 3m cable can be directly connected to a RJ11 port of Ares or
Poseidon2 monitoring units.
The water sensor can be left lying on the floor (on an
electrically insulating surface), or attached to the floor
or to a wall. Designed for flood detection, senses
water and other electrically conductive liquids.
Specifications
Bus
Type
Supported
Output states
Connector
Power
Power limits
Max. distance
Sampling interval
Physical characteristics
Operating conditions
Mounting hole
Water resistance
Dimensions / mass
HW group
1-Wire UNI
HWg-Ares, Poseidon2, Poseidon 2250, 4002
0 = OK, 1 = flood
1x RJ11 on a 3m cable
Powered from the 1W-UNI (RJ11) bus
One active port (RJ11 connector of a Poseidon or Ares unit) can power
max. 2 "Flood detector 1W-UNI 3m" sensors.
To boost the power, use our "1-Wire hub Power" powered hub.
60 m (from the Poseidon / Ares unit active port)
Sensor status is sampled on the 1W-UNI bus every 1–3 seconds.
–25°C to +85°C (–13°F to +185°F) / 5 to 90 % relative humidity
1x Ø4 [mm]
IP67 – Sensor can be submerged in water
36 x 50 x 22 [mm] / 80 g
www.HW-group.com
