Summary of Contents for Dometic SeaXChange XTC Series

  • Page 3 ................1 ....................8 ..............3 ......................................................................125...
  • Page 6 ACRONYM/SYMBOLS DEFINITION SEA WATER FRESH WATER...
  • Page 9 CAUTION: THE RATED PRODUCTION WILL HAVE TO BE CORRECTED FOR TEM- PERATURE OF SEA WATER WHEN DETERMINING RATED FLOW FOR YOUR UNIT. SEE THE BOOSTER PUMP MUST NEVER BE RUN DRY. OPERATING THE PUMP WITH- OUT SUFFICIENT FEED WATER WILL DAMAGE THE PUMP.
  • Page 10    ...
  • Page 12 NOTE: ALL TDS FIGURES MUST BE EXPRESSED IN THE SAME UNITS, TYPICALLY PARTS PER MILLION (PPM) OR MILLIGRAMS PER LITER (MG/L).
  • Page 14 3/4 hp Sylent Pump 252404461 General touch screen...
  • Page 15 NOTE: IT’S RECOMMENDED THAT A QUALIFIED ELECTRICIAN WIRE YOUR SYSTEM IN ACCORDANCE WITH ALL APPLICABLE CODES, RULES, AND REGULATIONS. WARNING: TO REDUCE THE RISK OF ELECTRICAL SHOCK, THE INCOMING POWER SUPPLY MUST INCLUDE A PROTECTIVE GROUND.
  • Page 16 Please see Complete Install Guide and the connection drawings on the following pages. CAUTION: ANY RESTRICTIONS OR BLOCKAGE IN THE CONCENTRATE LINE CAN CAUSE BACKPRESSURE, WHICH WILL INCREASE THE SYSTEM’S OPERATING PRESSURE. THIS CAN RESULT IN DAMAGE TO THE SYSTEM’S MEMBRANES AND COMPONENTS.
  • Page 17 When a system will not be used for a significant period of time (i.e. 3 months – 1 year), the best practice for storage of the system is to allow the automatic fresh water flush to operate by leaving the power to the system on and ensuring that the vessels fresh water system is ON and pressurized.
  • Page 22 NOTE: THE SYSTEM MUST BE OPERATED IN AC- CORDANCE TO FEED WATER SPECIFICATIONS. ¾” Flexible hose from Booster Pump 1/2” Tube to dedicated overboard.
  • Page 23 3/8” tubing to ship’s fresh water tank. Ship’s Fresh Water Tank...
  • Page 24 Fresh Water Flush Connecti n 1. Locate filter assembly labeled Fresh Water Flush and connect the inlet of fresh water flush solenoid to the ships pressurized fresh water system. Note - a shut off valve is recommended to be installed on supply Ship’s Fresh Water Tank 2.
  • Page 25   NOTE: IT’S RECOM- MENDED THAT QUALIFIED ELECTRI- CIAN WIRE YOUR SYS- TEM IN ACCORDANCE WITH ABYC REQUIRE- MENTS. WARNING: TO REDUCE THE RISK OF ELECTRI- CAL SHOCK, THE IN- COMING POWER SUP- PLY MUST INCLUDE A PROTECTIVE GROUND.
  • Page 28 4. Press the down arrow on Mode and select the OFF option in order to activate MANUAL FWF 5. MANUAL FWF icon should appear. Press the button to initiate a FWF and let it run. 6. Press the Booster Pump image.
  • Page 29 7. Press the “ON” button, then press the “X” button to exit the menu. When the Booster Pump is running wavy line should appear to the right of the Booster Pump image indicating that the motor is on. 8. Let the Booster pump run for 30 minutes to flush out all membrane preservative. 9.
  • Page 30 STANDARD OPERATION 1. Simply press the Start button and the system will automatically adjust to produce water. 2. You can set the system to automatically shut down as instructed on pages 35-38 or simply press the STOP button to stop the system. OPTION 1 OPTION 2...
  • Page 34 OPERATING DO’s & DON’Ts 1. Change the cartridge filters regularly 2. Monitor the system and keep a daily log 3. Adjust the system product to the recommended value 4. Always feed the pump with filtered water DON’T: 1. Permit chlorine to be present in the feed water 2.
  • Page 35 General...
  • Page 36       ...
  • Page 37         ...
  • Page 38 WARNING: ALL PRESSURE GAUGES MUST READ ZERO BEFORE PROCEEDING. BEFORE ATTEMPTING, DISCONNECT THE POWER FROM THE SYSTEM AND BLEED ALL WATER PRESSURE FROM THE SYSTEM. Remove 2. Remove the replacement membrane element(s) from the shipping box; the membrane(s) should be contained within a plastic oxygen barrier bag.
  • Page 39 INSERT DIRECTION INSERT DIRECTION SEAL FEED DIRECTION...
  • Page 40 CAUTION: WET MEMBRANES ARE SHIPPED IN A PRESERVATIVE SOLUTION. THE MEMBRANES MUST BE FLUSHED FOR AT LEAST 30 MINUTES TO RE- MOVE THE PRESERVATIVE FROM THE MEMBRANE. DISCARD ALL OF THE PERMEATE AND CONCENTRATE, WHICH IS PRODUCED DUR ING THE FLUSH PERIOD.
  • Page 43 as needed. During the shutdown period, the plant must be kept frost-free, or the temperature must not exceed 113°F (45°C).
  • Page 45 NOTE: OIL LEVEL CAN ONLY BE CHECKED WITH THE UNIT NOT RUNNING...
  • Page 47 NOTE: TO DETERMINE THE TEMPERATURE CORRECTION FACTOR, LOCATE THE TEMPERATURE CORRECTION TABLE IN THIS USER’S MANUAL AND FOLLOW THE DIRECTIONS. PG. 46...
  • Page 48 TEMPERATURE CORRECTION FACTORS FOR MEMBRANE Find the temperature correction factor (TCF) from the table below. Divide the rated permeate flow at 77°F by the temperature correction factor. The result is the permeate flow at the desired temperature. (See example on the next page) °F = (°C x 9/5)+ 32 Corrected Flow Rate = (Measured Flow Rate)*(TCF @ Feed Water Temp.)
  • Page 49 If a system is rated to produce 5 gpm of permeate water @ 77° F. The same system will produce more water at a higher temperature. It will also produce less water at a lower temperature. Use the temperature correction table to obtain the correct flow. Example: 1.25 gpm @ 59°...
  • Page 50 PROBLEM CAUSE SOLUTION...
  • Page 52     HOME SCREEN MENU...
  • Page 59 Time Remaining Gallons Produced...
  • Page 63 6. Press the plus or minus icons to move close or open the valve digitally. You can also press the number box to enter set number for the valve to go to. When the “Manual-Hand option is pressed you are able to mechanically turn the valve with you hand. The following icon message will Manually or electronically start appear on the Home Screen:...
  • Page 75 Warning! Never fully close valve. It will cause permanent damage to the system.
  • Page 81 EXAMPLE...
  • Page 107 EWM Series GENERAL PUMP A member of the Interpump Group 5/8" Hollow Shaft Pump Model EWM0515C EWM0815C EWM1015C EWM1615C EWM2315C EWM3015C EWM3715C EWM4215C Maximum Volume 0.5 GPM 0.8 GPM 1.1 GPM 1.6 GPM 2.3 GPM 3.0 GPM 3.7 GPM 4.2 GPM Maximum Discharge Pressure 1,500 PSI Maximum Pump Speed...
  • Page 108 EWM Series GENERAL PUMP A member of the Interpump Group 5/8" Hollow Shaft...
  • Page 109 EWM Series GENERAL PUMP A member of the Interpump Group 5/8" Hollow Shaft...
  • Page 110 EWM Series GENERAL PUMP A member of the Interpump Group 5/8" Hollow Shaft GENERAL PUMP...
  • Page 117 DOW FILMTEC™ Membranes DOW FILMTEC Seawater RO Elements for Marine Systems Features Improved DOW FILMTEC™ seawater reverse osmosis elements offer the highest productivity while maintaining excellent salt rejection. DOW FILMTEC SW30 membrane elements have the highest flow rates available to •...
  • Page 118 • Membrane Type Polyamide Thin-Film Composite Operating Limits • Maximum Operating Temperature 113°F (45°C) • Maximum Operating Pressure 1,000 psi (69 bar) • Maximum Pressure Drop 15 psig (1.0 bar) • pH Range, Continuous Operation 2 - 11 • pH Range, Short-Term Cleaning 1 - 13 •...

  • Page 120: The Operating Instructions

    Type 0121, 0330, 0331 (0124, 0125, 0332, 0333) 2/2- and 3/2-Way Solenoid Valve 2/2- und 3/2-Wege-Magnetventil Électrovanne à 2/2 et 3/2 voies Operating Instructions Bedienungsanleitung Manuel d‘utilisation Bürkert Fluid Control Systems Sales Center Christian-Bürkert-Str. 13-17 D-74653 Ingelfingen Tel. + 49 (0) 7940 - 10 91 111 Fax + 49 (0) 7940 - 10 91 448 E-mail: info@de.buerkert.com International address...

  • Page 121: Table Of Contents

    Type 0121 / 0330 / 0331 The operaTing insTrucTions Table of Contents The operating instructions contain important information. The operating instructions ....................2 ▶ Read the instructions carefully and follow the safety instructions. Authorized use ..........................3 ▶ Keep the instructions in a location where they are available to every user.

  • Page 122: System Description

    Type 0121 / 0330 / 0331 sysTem descripTion General hazardous situations. To prevent injuries: 4.1 general description ▶ In a potentially explosive area, the device may be used only in accor- The pivoted armature valves are direct acting 2/2 or 3/2-way solenoid dance with the specification on the type label.

  • Page 123: Assembly

    Type 0121 / 0330 / 0331 5.6 electrical data assemBly Connections DIN EN 175301-803 (DIN 43 650), shape A for Danger! cable plug Type 2508 or 2509 Risk of injury from high pressure in the system/device. 5.7 Type label ▶ Before working on the system or device, switch off the pressure and vent/drain lines.

  • Page 124: Disassembly

    Type 0121 / 0330 / 0331 → 7.1 standard model Check electrical continuity between coil and body (protective con- ductor function). → Connect L1/+ and N/– to terminals 1 and 2, independent of the polarity. Terminal 1 → Connect protective conductor. ∼...
  • Page 126 WHAT’S COVERED...
  • Page 127 WHAT’S NOT COVERED...
  • Page 128 COVERAGE PERIOD...
  • Page 129 GETTING COVERED WARRANTY SERVICE The customer may contact the Dometic Service Department at 1(800) 542-2477, Monday through Friday, 8:00am - 5:00pm. TABLE OF LIMITED WARRANTY PERIODS WATER PURIFICATION PRODUCTS: PRODUCT SALE TYPE WARRANTY COVERAGE OEM 1-year warranty, parts and labor, from date of delivery of vessel.
  • Page 130 OWNER’S LIMITED WARRANTY SECTION IV (CONTINUED) Dealer Installed and 1 year warranty, parts only. Wearable parts such as pump seals, brushes and plastic valves are not covered under warranty. Accessories OEM, Dealer Installed, 1 year warranty, parts only. Replacement Parts Aftermarket sales. 90-Day warranty, parts only.
