SCHEMATIC DIAGRAMS
KD-SC601, KD-SC607
ATT
SOUND
U
R
F
SOURCE
D
VOL
VOL
ATT
SOUND
U
R
SOURCE
F
D
VOL
VOL
Contents
Printed circuit boards
CD RECEIVER
CD-ROM No.SML200401
KD-SC601
KD-SC607
KD-SC601E/EX
SUB-CABLE
STEERING CABLE
COPYRIGHT
2004 VICTOR COMPANY OF JAPAN, LTD.
E ----------- Continental Europe
EX --------------- Central Europe
EE --------- Russian Federation
KD-SC607EE
2-1
2-2 to 7
2-8, 9
KD-SC601
Area suffix
KD-SC607
Area suffix
No.MA035SCH
2004/1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for JVC KD-SC601
Summary of Contents for JVC KD-SC601
-
Page 1: Schematic Diagrams
SCHEMATIC DIAGRAMS CD RECEIVER KD-SC601, KD-SC607 CD-ROM No.SML200401 KD-SC601 KD-SC601 Area suffix SOUND E ----------- Continental Europe SOURCE EX --------------- Central Europe KD-SC607 Area suffix KD-SC607 EE --------- Russian Federation SOUND SOURCE KD-SC601E/EX KD-SC607EE SUB-CABLE STEERING CABLE Contents Block diagram... -
Page 2: Safety Precaution
Safety precaution Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an adjustment or operation check. -
Page 3: Block Diagram
IC581 CH.R CD CHANGER FOCUS+ CD L.P.F. FOCUS- CONTROL PICK UP IC481 LRCK SO,I/O INT,SCK CH.SCK IC801 S601 to S612 JVC BUS MP3STBY KEY0 S614 to S618 MP3CLK KEY1 MP3DOUT IC602 KEY MATRIX KEY2 MP3RESET REMOCON LCDCL OUTRF KEY0 MP3REQ... -
Page 4: Standard Schematic Diagrams
Standard schematic diagrams RB160M-30-X D243 Main amplifier section (KD-SC601) R248 R244 C243 R243 0.047 180k R245 C241 1/50 R242 R241 IC301 C242 22/16 LA47515 Q241 QAU0313-001 2SD601A/QR/-X LEVEL R793 R161 D240 MA111-X C312 220k 4.7u 0.47 R312 1/50 8.2K R311... - Page 5 CD servo section (KD-SC601) R504 R502 8.2k R586 6.8k FEED- FEED- R503 4.7k R581 8.2k R585 CD.R C582 47/10 R584 270P FEED+ FEED+ C513 R518 C501 C581 Q501 C508 3300P 0.01 C580 4.7/25 AOUTR- R582 8.2k C589 4.7/25 AOUTR+ R583 8.2k...
- Page 6 LCD & Key control section (KD-SC601) EN601 IC602 QSW0863-003 RPM7338-V4 CN601 NNZ0087-001 LCD1 REMOCON QLD0293-001 ACC5V ENC1 ENC2 R671 LCDCE R672 DATA LCDDA To CN701 R673 LCDCL KEY2 (SHEET 1) KEY1 KEY0 LEDBLUE LEDRED 2.2K R651 R615 R605 R604 R603...
- Page 7 Main amplifier section (KD-SC607) RB160M-30-X D243 R248 R244 C243 R243 0.047 180k R245 C241 1/50 R242 R241 IC301 C242 22/16 LA47515 Q241 QAU0314-001 2SD601A/QR/-X LEVEL R793 R161 D240 MA111-X C312 220k 4.7u 0.47 R312 QNB0100-002 1/50 8.2K R311 C311 R171 MA111-X 0.47 1/50...
- Page 8 CD servo section (KD-SC607) R504 R502 8.2k R586 6.8k FEED- FEED- R503 4.7k R581 8.2k R585 CD.R 47/10 C582 8.2k R584 270P FEED+ FEED+ C513 R518 C501 C581 Q501 C508 3300P 0.01 C580 4.7/25 AOUTR- R582 8.2k C589 4.7/25 AOUTR+ R583 8.2k IC581...
- Page 9 LCD & Key control section (KD-SC607) EN601 IC602 QSW0863-003 RPM7338-V4 CN601 NNZ0087-001 REMOCON LCD1 ACC5V QLD0293-001 ENC1 ENC2 R671 LCDCE R672 DATA LCDDA To CN701 R673 LCDCL KEY2 (SHEET 4) KEY1 KEY0 LEDBLUE LEDRED R651 2.2K R615 R605 R604 R603 R602 R601 KEY2...
- Page 10 Printed circuit boards Main board Main board Forward side Reverse side C331 C971 C910 C910 D971 J801 C361 D972 J321 C371 IC901 IC901 R971 J321 C321 Q341 Q331 C914 C712 C911 R331 L901 CN901 C914 D901 L901 C913 J801 C904 R903 R972 R892...
- Page 11 Front board Reverse side Forward side D603 D604 D605 D692 D694 D607 R606 R612 R613 R689 R607 R639 R638 C694 R673 R672 R671 D643 D642 C681 D624 R646 R647 D623 C611...
- Page 12 VICTOR COMPANY OF JAPAN, LIMITED AV & MULTIMEDIA COMPANY MOBILE ENTERTAINMENT CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan Printed in Japan (No.MA035SCH)
